- Page 1 EN User Manual | Hob ZIBN646K...
-
Page 2: Table Of Contents
VISIT OUR WEBSITE TO: Get usage advice, brochures, trouble shooter, service and repair information: www.zanussi.com/support Subject to change without notice. CONTENTS 1. SAFETY INFORMATION................2 2. SAFETY INSTRUCTIONS................4 3. INSTALLATION....................6 4. PRODUCT DESCRIPTION................8 5. DAILY USE......................9 6. HINTS AND TIPS..................11 7. - Page 3 • Keep all packaging away from children and dispose of it appropriately. • WARNING: The appliance and its accessible parts become hot during use. Keep children and pets away from the appliance when in use and when cooling down. • If the appliance has a child safety device, it should be activated.
-
Page 4: Safety Instructions
• Do not use the appliance before installing it in the built-in structure. • Do not use a steam cleaner to clean the appliance. • After use, switch off the hob element by its control and do not rely on the pan detector. •... - Page 5 2.2 Electrical Connection • The electrical installation must have an isolation device which lets you disconnect the appliance from the mains at all poles. WARNING! The isolation device must have a contact Risk of fire and electric shock. opening width of minimum 3 mm. •...
-
Page 6: Installation
• Do not put flammable products or items use abrasive products, abrasive cleaning that are wet with flammable products in, pads, solvents or metal objects. near or on the appliance. 2.5 Service WARNING! • To repair the appliance contact the Risk of damage to the appliance. - Page 7 3.4 Connection diagram Insert the shunt between the screws as shown. The shunt is located in the pocket of the mains terminal cover. Wiring colours Blue Brown 3.5 Assembly If you install the hob under a hood, please see the installation instructions of the hood for the minimum distance between the appliances.
-
Page 8: Product Description
Combination with standard oven Combination with double oven A = min. 6 mm, for double ovens from AEG, Electrolux and Zanussi. A = min. 12 mm, for double ovens from other brands. 4. PRODUCT DESCRIPTION 4.1 Cooking surface layout Induction cooking zone Control panel 4.2 Control panel layout... -
Page 9: Daily Use
Sensor Function Comment field On / Off To activate and deactivate the hob. Lock / Child Safety Device To lock / unlock the control panel. To select the cooking zone. Heat setting display To show the heat setting. To set a heat setting. 4.3 Heat setting displays Display Description... - Page 10 5.6 Booster The relation between the heat setting and the time after which the hob deactivates: This function makes more power available to the induction cooking zones. The function can Heat setting The hob deactivates be activated for the induction cooking zone after only for a limited period of time.
-
Page 11: Hints And Tips
power supply, this function divides the comes on. Touch for 4 seconds. Set the available power between all cooking zones. heat setting in 10 seconds. You can The hob controls heat settings to protect the operate the hob. When you deactivate the fuses of the house installation. - Page 12 • For both safety reasons and optimal • humming: you use a high power level. cooking results, do not use cookware • clicking: electric switching occurs. larger than indicated in "Cooking zones • hissing, buzzing: the fan operates. specification". Avoid keeping cookware The noises are normal and do not indicate close to the control panel during the any malfunction.
-
Page 13: Care And Cleaning
7. CARE AND CLEANING otherwise, the dirt can cause damage to WARNING! the hob. Take care to avoid burns. Use a special hob scraper on the glass surface Refer to Safety chapters. at an acute angle and move the blade on the surface. - Page 14 Problem Possible cause Remedy An acoustic signal sounds and You put something on one or more Remove the object from the sensor the hob deactivates. sensor fields. fields. An acoustic signal sounds when the hob is deactivated. The hob deactivates. You put something on the sensor Remove the object from the sensor field.
-
Page 15: Technical Data
9. TECHNICAL DATA 9.1 Rating plate Model ZIBN646K PNC 949 492 560 00 Typ 64 B4A 00 AA 220 - 240 V, 50 / 60 Hz Induction 3.0 kW Made in: Romania Ser.Nr....3.0 kW ZANUSSI 9.2 Cooking zones specification... -
Page 16: Environmental Concerns
IEC / EN 60350-2, BS EN 60350-2 - • When you heat up water, use only the Household electric cooking appliances - Part amount you need. 2: Hobs - Methods for measuring • If it is possible, always put the lids on the performance. - Page 20 867373801-C-072023...
