Summary of Contents for ViewSonic Cine5000
- Page 1 ViewSonic ® Cine5000 DLP Projector - User Guide - Guide de l’utilisateur - Bedienungsanleitung - Guía del usuario - Guida dell’utente - Guia do usuário - Användarhandbok - Käyttöopas - Pyководство пользователя - 使用手冊 - 使用手冊 Model No. : VS11481...
-
Page 2: Compliance Information
The mark shown to the right is in compliance with the Waste Electrical and Electronic Equipment Directive 2002/96/EC (WEEE). The mark indicates the requirement NOT to dispose the equipment as unsorted municipal waste, but use the return and collection systems according to local law. ViewSonic Cine5000... -
Page 3: Important Safety Instructions
ViewSonic Cine5000... -
Page 4: Copyright Information
Microsoft, Windows, Windows NT, and the Windows logo are registered trademarks of Microsoft Corporation in the United States and other countries. ViewSonic, the three birds’ logo, OnView, ViewMatch, and ViewMeter are registered trademarks of ViewSonic Corporation. VESA is a registered trademark of the Video Electronics Standards Association. DPMS and DDC are trademarks of VESA. -
Page 5: Table Of Contents
TABLE OF CONTENTS 1. Product Overview Features Package Contents Main Unit Control Panel Rear Terminals 2. Installation Turning on/off the projector 2-1-1 Starting up the projector 2-1-2 Shutting down the projector 2-1-3 LED Indication Status Adjusting the Projector Image 2-2-1 Adjusting the Projected Height 2-2-2 Adjusting the Zoom and Focus... -
Page 6: Product Overview
PRODUCT OVERVIEW 1-1.FEATURES ◆ 250 W P-VIP lamp. Life 2000hrs at Boost mode, 3000hrs in Eco mode (200W). ◆ High efficiency cooling system with low system acoustic noise level. ◆ Lamp is easily replaceable by user. ◆ Manual zoom and focus lens with a 1:1.2 zoom ratio and 100% lens offset. -
Page 7: Main Unit
1-3.MAIN UNIT DRAWING 1 DRAWING 2 DRAWING 3 DRAWING 4 DRAWING 5 IR Receiver (Front) Projection Lens Hot Air Exhaust I/O Connection Panel IR Receiver (Back) AC Power Inlet Power Switch Elevator Button Focus Ring Zoom Ring Control Panel Elevator Feet Ceiling Mount Screw Holes Adjustable Foot PRODUCT OVERVIEW... -
Page 8: Control Panel
PRODUCT OVERVIEW 1-4.CONTROL PANEL Menu Source Aspect Keystone Power Boost Thermal DRAWING 6 Menu Source Vol+ Vol- Boost Mode Indicator Boost Thermal Indicator Power Power Indicator Keystone Aspect Cursor 1-5.REAR TERMINALS Vol+ Vol- DRAWING 7 Kensington Lock Composite Video Input Audio Input (R / L) Component Video Input Trigger for Screen Relay (12V) -
Page 9: Installation
INSTALLATION 2-1.TURNING ON/OFF THE PROJECTOR 2-1-1.STARTING UP THE PROJECTOR Ensure that the supplied power cord is securely connected at the AC inlet of the projector (Drawing 8) and power outlet. Remove the lens cap. Turn on the power switch. Ensure the "Power" indicator on the Control Panel is flashing blue, indicating the projector is in Standby mode. -
Page 10: Adjusting The Projector Image
INSTALLATION 2-2.ADJUSTING THE PROJECTED IMAGE 2-2-1.ADJUSTING THE PROJECTED HEIGHT Press the Elevator buttons. (Drawing 3) Raise the projector to the desired display angle, allowing the legs to extend, release the buttons to lock them in position. Use the Adjustable foot (Drawing 5) at the rear of the unit to fine-tune the display angle. -
Page 11: Control Panel And Remote Control
CONTROL PANEL AND REMOTE CONTROL 3-1.CONTROL PANEL AND REMOTE CONTROL Control functions through the Control Panel and Remote Control. 3-1-1.USING CONTROL PANEL MENU: Displays the OSD. Press again to exit the OSD. ASPECT: Selects your desired aspect ratio. KEYSTONE: Adjusts image distortion caused by tilting the projector. -
Page 12: On-Screen Display Menu
CONTROL PANEL AND REMOTE CONTROL 3-2.ON-SCREEN DISPLAY MENU 3-2-1.HOW TO OPERATE Press the "Menu" button on the Remote Control or Control Panel to enter the ON- Screen Display (OSD) menu. When the OSD is displayed, use "Cursor" buttons on the Control Panel or on the Remote Control to choose the item you need. - Page 13 button to select Red, Green, or Blue adjustment. Red, Green, Blue: Increases or decreases the value to find the desired color temperature. Image Display System Language Audio Aspect Ratio 16:9 Zoom Keystone Color Temperature Cool Middle Warm User Green Blue DRAWING 23 3-2-2-4.AUDIO Volume: Adjusts the volume.
-
Page 14: Appendices
APPENDICES 4-1.TROUBLE SHOOTING No images appears ◆ Check the power cable connection at the power inlet of the projector and at the wall outlet. ◆ Confirm that the main power switch at the rear of the projector is in the "on" position. -
Page 15: Cleaning The Projector
◆ To reset the lamp timer Press the Menu button on control panel or Remote Control. Go into the system menu and move the cursor to the lamp reset item. Select "Yes" to execute the lamp reset and the lamp hours will reset to 0 hour. Image Display Audio... -
Page 16: Specifications
APPENDICES 4-3.SPECIFICATION Color system Computer Compatibility Screen Size (Diagonal) Throw Distance DMD Panel Number of Pixels Projection Lens Projection Lamp Digital Keystone Front Elevation Scanning Frequency Operating Temperature Input Output Audio Power Supply Power Consumption Dimensions (W x D x H) Net Weight Regulations Accessories... -
Page 17: Customer Support
Thailand South Africa/Other www.viewsonic.com countries Hong Kong www.hk.viewsonic.com/support/ Macau www.hk.viewsonic.com/support/ Korea www.viewsonic.com ViewSonic Cine5000 T=Telephone E-mail F=Fax T= 800 688 6688 service.us@viewsonic.com F= 909 468 1202 T= 866 463 4775 service.ca@viewsonic.com T= 0207 949 0307 service.eu@viewsoniceurope.com Contact your reseller service.eu@viewsoniceurope.com AUS= 1800 880 818 service@au.viewsonic.com... -
Page 18: Limited Warranty
ViewSonic warrants its products to be free from defects in material and workmanship during the warranty period. If a product proves to be defective in material or workmanship during the warranty period, ViewSonic will at its sole option repair or replace the product with a like product.
