ViewSonic PJL3211 User Manual

Xga lcd projector
Hide thumbs Also See for PJL3211:
Table of Contents

Advertisement

Quick Links

Download this manual
ViewSonic
®
PJL3211
XGA LCD Projector
- User Guide
- Guide de l'utilisateur
- Bedienungsanleitung
- Guía del usuario
- Guida dell'utente
- Guia do usuário
- Användarhandbok
- Käyttöopas
- Руководство пользователя
- 使用手冊 (繁體)
- 使用手冊 (簡體)
- 사용자 안내서
Model No. : VS12417

Advertisement

Table of Contents
loading

Related Manuals for ViewSonic PJL3211

Summary of Contents for ViewSonic PJL3211

  • Page 1 ViewSonic ® PJL3211 XGA LCD Projector - User Guide - Guide de l’utilisateur - Bedienungsanleitung - Guía del usuario - Guida dell’utente - Guia do usuário - Användarhandbok - Käyttöopas - Руководство пользователя - 使用手冊 (繁體) - 使用手冊 (簡體) - 사용자 안내서...

  • Page 2: Content

    If the batteries or accumulators included with this equipment, display the chemical symbol Hg, Cd, or Pb, then it means that the battery has a heavy metal content of more than 0.0005% Mercury or more than, 0.002% Cadmium, or more than 0.004% Lead. ViewSonic PJL3211...

  • Page 3: Important Safety Instructions

    ViewSonic PJL3211...

  • Page 4: Declaration Of Rohs Compliance

    0.4% lead by weight and as a cooper alloy containing up to 4% lead by weight. ViewSonic Proposed Maximum Actual Concentration Concentration 0.1% 0.1% 0.01% 0.1% 0.1% 0.1% < 0.1% < 0.1% < 0.01% < 0.1% < 0.1% < 0.1% PJL3211...

  • Page 5: Copyright Information

    VESA. PS/2, VGA and XGA are registered trademarks of International Business Machines Corporation. Disclaimer: ViewSonic Corporation shall not be liable for technical or editorial errors or omissions contained herein; nor for incidental or consequential damages resulting from furnishing this material, or the performance or use of this product.

  • Page 6: About This Manual

    Projector PJL3211 User's Manual (detailed) - Operating Guide Contents of package (1) Projector (2) Remote control wth two AA batteres (3) Power cord (4) RGB cable (5) Soft case (6) Quck Start Gude and VewSonc Wzard CD (7) Lens cover, Rvet and Strap...

  • Page 7: Table Of Contents

    RS-232C . . . . . . . . . . . . . . . . . 58  execute rightness harpness ilter time amma olor temp y memory position position olor space omputer in eystone udio lank amp time ervice PJL3211...

  • Page 8: Projector Features

    Please refer to the “Air filter” (50) for how to detach and attach a filter cover. WARNING ►Consult with your dealer before a specal nstallaton such as suspendng from a celng. ViewSonic Projector features / Preparations Strap hole Strap hole Flter cover PJL3211...

  • Page 9: Part Names

    HOT! (1) (2) (3) (10) (9) (8) (11) (Bottom) (12) (14) (15) (16) (17) (18) (19) (20) COMPUTER IN1 COMPUTER IN2 S-VIDEO VIDEO MONITOR OUT CONTROL (25) (24) (13) HOT! (21) (22) AUDIO IN1 AUDIO IN2 AUDIO OUT (23) PJL3211...

  • Page 10: Control Panel

    MY BUTTON (16) (17) (20) POSITION (22) ENTER (24) Back of the remote control Part names (4) (5) (6) LAMP MENU TEMP POWER BLANK (12) (14) VOLUME (15) MUTE (13) KEYSTONE (19) (18) (21) MENU RESET (23) (25) (26) PJL3211...

  • Page 11: Setting Up

    261 103 5.6 222 327 129 7.1 278 392 154 8.5 334 10.2 400 (c) up (c) down 16 : 9 screen (c) Screen height (c) up mn. max. down inch inch inch (c) down inch 304 120 365 144 PJL3211...
  • Page 12 Placing the projector in such places could cause fire, electric shock and/or malfuncton of the projector. • Do not place the projector near humidifiers, smoking spaces or a kitchen. ►Position the projector to prevent light from directly hitting the projector's remote sensor. ViewSonic Setting up PJL3211...

  • Page 13: Connecting Your Devices

    For cables wth a core only at one end, connect the end wth the core to the projector. ►Make sure that devices are connected to the correct ports. An incorrect connecton may result n malfuncton or damage to the devce and the projector. ViewSonic Monitor Speakers PJL3211...
  • Page 14 • Take advantage of ths feature by connectng an RGB cable to the COMPUTER IN1 port (DDC 2B compatble). Plug-and-Play may not work properly f any other type of connecton s attempted. • Please use the standard drvers n your pc as ths projector s a Plug-and-Play montor. ViewSonic Setting up PJL3211...

  • Page 15: Connecting Power Supply

    NOTE • The securty slot s not comprehensve theft preventon measures. It s ntended to be used as supplemental theft preventon measure. ViewSonic AC nlet Connector of the power cord Securty slot COMPUTER IN1 S-VIDEO VIDEO POWER ndcator POWER to the outlet COMPUTER IN2 MONITOR OUT CONT PJL3211...

  • Page 16: Remote Control

    • The remote control may not work correctly if strong light (such as direct sun light) or light from an extremely close range (such as from an inverter fluorescent lamp) shines on the remote sensor of the projector. Adjust the position of projector avoiding those lights. ViewSonic Remote control 30º 30º Approx. PJL3211...

  • Page 17: Changing The Frequency Of Remote Control Signal

    MY BUTTON KEYSTONE POSITION MENU ENTER RESET USB port AUDIO IN1 AUDIO IN2 COMPUTER/ STORAGE SEARCH VIDEO AUDIO OUT BLANK ASPECT AUTO CONTROL MAGNIFY HOME PAGE UP VOLUME PAGE DOWN MUTE FREEZE MY BUTTON KEYSTONE POSITION MENU ENTER RESET PJL3211...

  • Page 18: Power On/Off

    POWER BLANK AUTO COMPUTER/ STORAGE VIDEO SEARCH ASPECT AUTO BLANK MAGNIFY PAGE UP HOME VOLUME PAGE UP VOLUME HOME PAGE DOWN MUTE FREEZE MY BUTTON KEYSTONE PAGE DOWN MUTE POSITION MENU ENTER RESET MY BUTTON KEYSTONE MENU ENTER RESET PJL3211...

  • Page 19: Operating

    KEYSTONE POSITION MENU ENTER RESET INPUT/ENTER LAMP INPUT/ STANDBY/ON ENTER MENU TEMP POWER COMPUTER /STORAGE COMPUTER/ STORAGE VIDEO SEARCH ASPECT AUTO BLANK MAGNIFY HOME PAGE UP VOLUME PAGE DOWN MUTE FREEZE MY BUTTON KEYSTONE (37) POSITION MENU ENTER RESET PJL3211...

  • Page 20: Searching An Input Signal

    HOME PAGE UP VOLUME PAGE DOWN MUTE FREEZE MY BUTTON KEYSTONE POSITION MENU ENTER RESET ASPECT COMPUTER/ STORAGE VIDEO SEARCH BLANK ASPECT AUTO MAGNIFY HOME PAGE UP VOLUME PAGE DOWN MUTE FREEZE MY BUTTON KEYSTONE POSITION MENU ENTER RESET PJL3211...

  • Page 21: Adjusting The Projector's Elevator

    tself. Adjusting the zoom and focus Use the zoom rng to adjust the screen sze. Use the focus rng to focus the pcture. ViewSonic To finely adjust, twist the foot. Focus rng Zoom rng PJL3211...

  • Page 22: Using The Automatic Adjustment Feature

    HOME PAGE UP VOLUME PAGE DOWN MUTE FREEZE MY BUTTON KEYSTONE POSITION MENU ENTER RESET COMPUTER/ STORAGE VIDEO SEARCH ASPECT AUTO BLANK MAGNIFY HOME PAGE UP VOLUME PAGE DOWN MUTE FREEZE MY BUTTON KEYSTONE POSITION MENU ENTER RESET POSITION PJL3211...

  • Page 23: Correcting The Keystone Distortions

    PAGE UP VOLUME HOME PAGE DOWN MUTE FREEZE MY BUTTON KEYSTONE POSITION MENU ENTER RESET MAGNIFY ON/OFF COMPUTER/ STORAGE SEARCH VIDEO ASPECT AUTO BLANK MAGNIFY HOME PAGE UP VOLUME PAGE DOWN MUTE FREEZE MY BUTTON KEYSTONE POSITION MENU ENTER RESET PJL3211...

  • Page 24: Freezing The Screen

    VOLUME HOME PAGE DOWN MUTE FREEZE MY BUTTON KEYSTONE POSITION MENU ENTER RESET s pressed. BLANK COMPUTER/ STORAGE SEARCH VIDEO ASPECT AUTO BLANK MAGNIFY HOME PAGE UP VOLUME PAGE DOWN MUTE FREEZE MY BUTTON KEYSTONE POSITION MENU ENTER RESET PJL3211...

  • Page 25: UsNg The Menu FunctOn

    ENTER MENU TEMP POWER ESC button EASY MENU COMPUTER/ STORAGE SEARCH VIDEO BLANK ASPECT AUTO MAGNIFY HOME PAGE UP VOLUME PAGE DOWN MUTE MENU button FREEZE MY BUTTON KEYSTONE Cursor buttons POSITION MENU ENTER RESET RESET button Advanced MENU PJL3211...

  • Page 26: Easy Menu

    tem n SETUP menu (31). NORMAL ó CINEMA ó DYNAMIC COLOR TEMP MID DEFAULT LOW DEFAULT HIGH DEFAULT H-BRIGHT-1 DEFAULT H-BRIGHT-2 DEFAULT MID DEFAULT EASY MENU GAMMA #1 DEFAULT #2 DEFAULT #3 DEFAULT #4 DEFAULT #3 DEFAULT #5 DEFAULT PJL3211...

  • Page 27: Language

    See the LANGUAGE tem n SCREEN menu (33). Select “Go to Advanced Menu…” on the menu, and press the ► Go to or ENTER button to use the menu of PICTURE, IMAGE, INPUT, Advanced Menu... SETUP, SCREEN or OPTION. ViewSonic PJL3211...

  • Page 28: Picture Menu

    • When ths functon s performed, lnes or other dstorton may appear. (contnued on next page) ViewSonic Description Ramp  Gray scale of 15 steps PICTURE Menu ENTER, GAMMA [ CUSTOM-1 ] PJL3211...
  • Page 29 LOW DEFAULT � LOW CUSTOM � Hi-BRIGHT-1 DEFAULT � Hi-BRIGHT-1 CUSTOM Hi-BRIGHT-2 DEFAULT � Hi-BRIGHT-2 CUSTOM Ramp  Gray scale of 15 steps ENTER, OFFSET GAIN R G B R G B +0 +0 +0 +0 COLOR TEMP [CUSTOM-1] PJL3211...
  • Page 30 • Remember that the current data beng stored of a memory wll be lost by savng a new data nto the memory. ViewSonic Description LOAD1 ó LOAD2 ó LOAD3 ó LOAD4 SAVE4 óSAVE3 ó SAVE2 ó SAVE1 PICTURE Menu PJL3211...

  • Page 31: Image Menu

    • When ths functon s performed on a vdeo sgnal, s-vdeo sgnal, or component vdeo sgnal, the range of ths adjustment depends on the OVER SCAN (above) settng. It s not possble to adjust when the OVER SCAN s set to 10. (contnued on next page) ViewSonic Description PJL3211...
  • Page 32 For a component vdeo sgnal, also the horzontal phase wll be automatcally set to the default. • The automatc adjustment operaton requres about 10 seconds. Also please note that t may not functon correctly wth some nput. ViewSonic Description IMAGE Menu PJL3211...

  • Page 33: Input Menu

    • The AUTO mode automatcally selects the optmum mode. • The AUTO operaton may not work well at some sgnals. In such a case, t mght be good to select a sutable mode except AUTO. (contnued on next page) ViewSonic Description PJL3211...

  • Page 34: Ideo Format

    SYNC ON G OFF on the menu, and then reconnect the sgnal. • Component sgnal can be supported through COMPUTER IN1 port, f AUTO s selected for the COMPUTER IN1 port. (contnued on next page) ViewSonic Description N-PAL ó M-PAL ó NTSC4.43 INPUT Menu PJL3211...
  • Page 35 ◄ button. The screen wll then return to the RESOLUTION menu dsplayng the prevous resoluton. • For some pctures, ths functon may not work well. ViewSonic PJL3211...

  • Page 36: Setup Menu

    • The adjustable range of ths functon wll vary wth the type of nput KEYSTONE sgnal. For some nput, ths functon may not work well. • Ths functon wll be unavalable when the Transton Detector s on (46). (contnued on next page) ViewSonic Description SETUP Menu PJL3211...
  • Page 37 ◄/► buttons. AUDIO 1 ó 2 ó • When nterlockng wth the nput port, and any tems n AUDIO menu are nvald. ViewSonic Description s selected to an nput port, any audo ports do not work PJL3211...

  • Page 38: Screen Menu

    NORSK ó NEDERLANDS ó PORTUGUÊS ó 日本語 ó ó SUOMI ó POLSKI ó TÜRKÇE Feature Screen can be regstered by the MyScreen tem (35) Screen preset as the standard screen. Plan screens n each color. SCREEN Menu ó SVENSKA ó PJL3211...

  • Page 39: Tart Up

    • When the TURN ON s selected to the MyScreen PASSWORD of SECURITY tem n OPTION menu (43), the START UP s fxed to MyScreen. (contnued on next page) ViewSonic Description Feature Screen can be regstered by the MyScreen tem (35) Screen preset as the standard screen. Plan black screen. PJL3211...
  • Page 40 MyScreen Lock ths functon for protectng the current MyScreen. • Ths functon cannot be selected when the TURN ON s selected to the MyScreen PASSWORD of SECURITY tem n OPTION menu (43). (contnued on next page) ViewSonic SCREEN Menu Description PJL3211...

  • Page 41: FreezNg The Screen

    (5) Select INPUT buttons when finished entering text. To revert to the prevous name wthout saving changes press the ESC or ◄ button and the INPUT button smultaneously. ViewSonic Description and press the ENTER or PJL3211...

  • Page 42: Option Menu

    s detected for about 30 mnutes, the projector s turned off, even though the AUTO OFF functon (38) s dsabled. (contnued on next page) ViewSonic Description COMPUTER IN1 ð COMPUTER IN2 VIDEO  S-VIDEO EXECUTE n the SETUP Menu for automatc OPTION Menu PJL3211...
  • Page 43 • Please reset the filter time only when you have cleaned or replaced the air filter, for a suitable indication about the air filter. • For the air filter cleaning, see the section "Air filter" (50). (contnued on next page) ViewSonic Description AUTO OFF AUTO OFF ENABLE DISABLE PJL3211...
  • Page 44 Note that the projector s noser when the HIGH s selected. HIGH ó NORMAL (contnued on next page) ViewSonic Description EXECUTE: FACTORY RESET ó I NFORMATION ó REMOTE FREQ. OPTION Menu When no data s saved n memory, a dalog s dsplayed. PJL3211...
  • Page 45 • It s recommended to choose “100h” n general. Please be careful wth the operatng envronment of the projector and the condton of the air filter, especially when the “200h”, “300h” or “TURN OFF” is chosen. (contnued on next page) ViewSonic Description nput sgnal PJL3211...
  • Page 46 ntal settng. Note that the tems LAMP TIME, FILTER TIME, LANGUAGE and SECURITY are not reset. RESET  CANCEL (contnued on next page) ViewSonic Description INPUT-INFORMATION INPUT-INFORMATION COMPUTER1 S-VIDEO 1024x768 @60 FRAME LOCK ON AUTO OPTION Menu INPUT-INFORMATION COMPUTER 1 576 @50 PJL3211...
  • Page 47 PASSWORD AGAIN BOX and press the ► button and the NOTE NEW PASSWORD BOX wll be dsplayed for about 20 seconds, please make note of the PASSWORD durng ths tme. Pressng the ENTER button wll close the NOTE NEW PASSWORD BOX. PJL3211...

  • Page 48: Using The Myscreen Password Function

    PASSWORD on/off menu to select TURN ON. PASSWORD. Move the cursor to the rght sde of the ENTER PASSWORD BOX (small) and press the ► button to dsplay the CHECK PASSWORD BOX, enter the same PASSWORD agan. OPTION Menu PJL3211...

  • Page 49: Using The Pin Lock Function

    Inqurng Code wll be dsplayed nsde the BOX. Code. Your PASSWORD wll be sent after your user registration information is confirmed. to select PIN LOCK and press the ► button or the ENTER button to dsplay the PIN LOCK on/off menu. PJL3211...
  • Page 50 RESET button for three seconds or press and hold the INPUT and ► buttons for three seconds. The 10 dgt Inqurng Code wll be dsplayed. will be sent after your user registration information is confirmed. OPTION Menu PJL3211...
  • Page 51 ► button to dsplay the CHECK PASSWORD BOX, enter the same PASSWORD agan. CHECK PASSWORD BOX and press the ► button to display the PASSWORD for about 20 seconds, please make note of the PASSWORD durng ths tme. Function PASSWORD PJL3211...
  • Page 52 If necessary repeat the process from 4.3-1. menu. PASSWORD BOX (large). The 10 dgt Inqurng Code wll be dsplayed nsde the BOX. Code. Your PASSWORD wll be sent after your user registration information is confirmed. OPTION Menu PJL3211...

  • Page 53: Maintenance

    CAUTION ►Do not touch any inner space of the projector, while the lamp s taken out. NOTE • Please reset the lamp tme only when you have replaced the lamp, for a sutable ndcaton about the lamp. ViewSonic The lamp cover The handle PJL3211...

  • Page 54: Lamp Warning

    When the pctures appear dark, or when the color tone s poor, please replace the lamp as soon as possble. Do not use old (used) lamps; ths s a cause of breakage. ViewSonic HIGH TEMPERATURE Maintenance HIGH PRESSURE PJL3211...

  • Page 55: Air Filter

    • The projector may dsplay the message such as “CHECK THE AIR FLOW” or turn off the projector, to prevent the nternal heat level rsng. ViewSonic The air filter is set in the reverse sde Swelled part Air filter Flter cover The filter cover PJL3211...

  • Page 56: Other Care

    Incorrect care could cause not only an injury but adverse influence such as dscoloraton, peelng pant, etc. ►Do not use cleaners or chemicals other than those specified in this manual. ►Do not polish or wipe with hard objects. ViewSonic Maintenance PJL3211...

  • Page 57: Troubleshooting

    Please mmedately turn the power off, and clean or change the air filter referring to the “Air Filter” section of this manual. After you have cleaned or changed the air filter, please be sure to reset the filter timer (50). PJL3211...

  • Page 58: RegardNg The NdCator Lamps

    n the fan, etc., and then turn the power on agan. If the same ndcaton s dsplayed after the remedy, please contact your dealer or servce company. Troubleshooting Description PJL3211...

  • Page 59: Shutting The Projector Down

    After the remedy, reset the power to ON. There is a possibility that the interior portion has become overcooled. Please use the unt wthn the usage temperature parameters (5°C to 35°C). After the treatment, reset the power to ON. Description COMPUTER IN1 COMPUTER IN2 Shutdown swtch PJL3211...

  • Page 60: Phenomena That May Be Easy To Be Mistaken For Machine Defects

    Remove the lens cover. No pctures are dsplayed. The signal cables are not correctly connected. Correctly connect the connecton cables. (contnued on next page) ViewSonic Cases not involving a machine defect Troubleshooting Reference page 10, 13 – 14, 15 PJL3211...
  • Page 61 NOTE • Although brght spots or dark spots may appear on the screen, ths s a unque characterstc of lqud crystal dsplays, and t does not consttute or mply a machne defect. ViewSonic Cases not involving a machine defect Reference page 21, 23 21, 24, 21, 23 22, 32 16, 27 PJL3211...

  • Page 62: Specifications

    S-VIDEO ...mn DIN 4 pn x1 VIDEO ... RCA x1 AUDIO IN1 ... Stereo mn x1 AUDIO IN2 ... Stereo mn x1 AUDIO OUT ... Stereo mn x1 CONTROL ... D-sub 9pn x1 USB ...USB-B x1 Specifications [unt: mm] PJL3211...

  • Page 63: Rs-232C

    (9) RI byte_3 byte_4 Type Settng code hgh Content Change settng to desred value. Read projector nternal setup value. Increment setup value by 1. Decrement setup value by 1. Run a command. RS-232C port of the PC byte_5 hgh PJL3211...
  • Page 64 • Provde an nterval of at least 40ms between the response code and any other code. • The projector outputs test data when the power supply s swtched ON, and when the lamp s lt. Ignore ths data. • Commands are not accepted durng warm-up. ViewSonic RS-232C Communication (continued) PJL3211...
  • Page 65 A1 30 22 00 01 00 A1 30 12 00 01 00 A1 30 23 00 01 00 A1 30 13 00 01 00 A1 30 24 00 01 00 A1 30 14 00 02 00 A1 30 00 00 PJL3211...
  • Page 66 52 F4 04 00 B1 30 00 00 83 F5 05 00 B1 30 00 00 70 F4 02 00 B2 30 00 00 16 F4 04 00 B2 30 00 00 C7 F5 05 00 B2 30 00 00 PJL3211...
  • Page 67 79 72 02 00 07 22 00 00 26 72 01 00 06 22 01 00 D6 72 01 00 06 22 02 00 46 73 01 00 06 22 03 00 85 73 02 00 06 22 00 00 PJL3211...
  • Page 68 16 70 01 00 12 22 09 00 26 77 01 00 12 22 02 00 86 71 01 00 12 22 08 00 76 74 01 00 12 22 07 00 75 76 02 00 12 22 00 00 PJL3211...
  • Page 69 64 20 00 00 02 00 61 20 00 00 04 00 61 20 00 00 05 00 61 20 00 00 02 00 62 20 00 00 04 00 62 20 00 00 05 00 62 20 00 00 PJL3211...
  • Page 70 C4 D3 02 00 05 30 00 00 04 D7 02 00 15 30 00 00 62 D7 04 00 15 30 00 00 B3 D6 05 00 15 30 00 00 DC C6 06 00 43 70 00 00 PJL3211...
  • Page 71 30 70 00 00 02 00 A0 10 00 00 06 00 40 70 00 00 06 00 0D 20 00 00 01 00 0F 20 00 00 01 00 0F 20 01 00 02 00 0F 20 00 00 PJL3211...
  • Page 72 Type Settng Code 02 00 07 30 00 00 04 00 07 30 00 00 05 00 07 30 00 00 01 00 02 30 00 00 01 00 02 30 01 00 02 00 02 30 00 00 PJL3211...

  • Page 73: Customer Support

    Renta y Datos, 29 SUR 721, COL. LA PAZ, 72160 PUEBLA, PUE. Tel: 01.222.891.55.77 CON 10 LINEAS Electroser, Av Reforma No. 403Gx39 y 41, 97000 Merida, Yucatan. Tel: 01.999.925.19.16 Other places please refer to http://www.viewsonic.com/la/soporte/index.htm#Mexico Latin America (Peru) www.viewsonic.com/la/ Macau www.hk.viewsonic.com...

  • Page 74: Limited Warranty

    Europe: 3 years for all parts excluding the lamp, 3 years for labor, 1 year for the original lamp from the date of the first consumer purchase. Other regions or countries: Please check with your local dealer or local ViewSonic office for the warranty information.
  • Page 75 Exclusion of damages: ViewSonic’s liability is limited to the cost of repair or replacement of the product. ViewSonic shall not be liable for: 1. Damage to other property caused by any defects in the product, damages based upon...

  • Page 76: Mexico Limited Warranty

    Exclusion of damages: ViewSonic’s liability is limited to the cost of repair or replacement of the product. ViewSonic shall not be liable for: 1. Damage to other property caused by any defects in the product, damages based upon inconvenience,...
  • Page 77 Tel: (52) 999-925-1916 E-Mail: rrrb@sureste.com Tijuana: Av Ferrocarril Sonora #3780 L-C Col 20 de Noviembre Tijuana, Mexico 4.3: ViewSonic Mexico Limited Warranty ViewSonic Villahermosa: Compumantenimietnos Garantizados, S.A. de C.V. AV. GREGORIO MENDEZ #1504 COL, FLORIDA C.P. 86040 Tel: 01 (993) 3 52 00 47 / 3522074 / 3 52 20 09 E-Mail: compumantenimientos@prodigy.net.mx...
