Table of Contents

Advertisement

Quick Links

Download this manual
Pictorial index
For safety
1
and security
Instrument
2
cluster
Operation of
3
each component
Driving
4
Interior features
5
Maintenance
6
and care
When trouble
7
arises
Vehicle
8
specifications
Index
YARIS_GRMN_OM_Europe_OM52J40E
Search by illustration
Make sure to read through them
How to read the gauges and meters, the variety of
warning lights and indicators, etc.
Opening and closing the doors and windows,
adjustment before driving, etc.
Operations and advices which are necessary for driving
Usage of the interior features, etc.
Caring for your vehicle and maintenance procedures
What to do in case of malfunction or emergency
Vehicle specifications, customizable features, etc.
Search by symptom
Search alphabetically

Advertisement

Table of Contents
loading

Related Manuals for Toyota Yaris GRMN

Summary of Contents for Toyota Yaris GRMN

  • Page 1 Pictorial index Search by illustration For safety Make sure to read through them and security Instrument How to read the gauges and meters, the variety of cluster warning lights and indicators, etc. Operation of Opening and closing the doors and windows, each component adjustment before driving, etc.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS For your information .......6 Operation of Reading this manual.......8 each component How to search ........9 Pictorial index .......10 3-1. Key information Keys ........112 For safety and security 3-2. Opening, closing and locking the doors Side doors ......116 1-1.
  • Page 3 Driving Interior features 4-1. Before driving 5-1. Using the air conditioning system and defogger Driving the vehicle .....176 Air conditioning Cargo and luggage ....184 system......220 Trailer towing .....186 5-2. Using the interior lights 4-2. Driving procedures Interior lights list ....227 Engine (ignition) switch..187 •...
  • Page 4 TABLE OF CONTENTS Maintenance and care When trouble arises 6-1. Maintenance and care 7-1. Essential information Cleaning and protecting Emergency flashers ..316 the vehicle exterior ..242 If your vehicle has to Cleaning and protecting be stopped in the vehicle interior ...247 an emergency ....
  • Page 5 Refer to “Navigation and multimedia system Owner’s manual” for information regarding the equipment listed below. • Navigation system • Rear view monitor system • Hands-free system • Audio system (for cellular phone) Toyota Motor Europe NV/SA, Avenue du Bourget 60 - 1140 Brussels, Belgium www.toyota-europe.com YARIS_GRMN_OM_Europe_OM52J40E...

  • Page 6: For Your Information

    Accessories, spare parts and modification of your Toyota Both genuine Toyota and a wide variety of other spare parts and accessories for Toyota vehicles are currently available in the market. Should it be deter-...
  • Page 7 Scrapping of your Toyota The SRS airbag and seat belt pretensioner devices in your Toyota contain explosive chemicals. If the vehicle is scrapped with the airbags and seat belt pretensioners left as they are, this may cause an accident such as fire. Be...

  • Page 8: Reading This Manual

    Reading this manual WARNING: Explains something that, if not obeyed, could cause death or serious injury to people. NOTICE: Explains something that, if not obeyed, could cause damage to or a malfunction in the vehicle or its equipment. Indicates operating or working procedures. Follow the steps in numerical order.

  • Page 9: How To Search

    How to search Searching by name ■ • Alphabetical index ..P. 389 Searching installation ■ position • Pictorial index....P. 10 Searching by symptom or ■ sound • What to do if... (Troubleshooting) ..P. 386 Searching by title ■...

  • Page 10: Pictorial Index

    Pictorial index Pictorial index ■ Exterior Side doors ........P. 116 Locking/unlocking .
  • Page 11 Pictorial index Windshield wiper ........P. 202 Precautions against winter season .
  • Page 12 Pictorial index ■ Instrument panel (left-hand drive vehicles) Engine switch ........P. 187 Starting the engine .
  • Page 13 Pictorial index Multi-information display ......P. 100 If a warning message or indicator is displayed ..P. 327, 332 Parking brake.
  • Page 14 Pictorial index ■ Switches (left-hand drive vehicles) Outside rear view mirror switches....P. 166 Manual headlight leveling dial ..... . . P. 198 Window lock switch .
  • Page 15 Pictorial index Audio remote control switches Meter control switches ......P. 101 “TRIP”...
  • Page 16 Pictorial index ■ Interior (left-hand drive vehicles) SRS airbags ........P. 37 Floor mats .
  • Page 17 Pictorial index Inside rear view mirror ......P. 164 Sun visors ........P. 236 Vanity mirrors .
  • Page 18 Pictorial index ■ Instrument panel (right-hand drive vehicles) Engine switch ........P. 187 Starting the engine .
  • Page 19 Pictorial index Multi-information display ......P. 100 If a warning message or indicator is displayed ..P. 327, 332 Parking brake.
  • Page 20 Pictorial index ■ Switches (right-hand drive vehicles) Outside rear view mirror switches....P. 166 Manual headlight leveling dial ..... . . P. 198 Window lock switch .
  • Page 21 Pictorial index Audio remote control switches Meter control switches ......P. 101 “TRIP”...
  • Page 22 Pictorial index ■ Interior (right-hand drive vehicles) SRS airbags ........P. 37 Floor mats .
  • Page 23 Pictorial index Inside rear view mirror ......P. 164 Sun visors ........P. 236 Vanity mirrors .
  • Page 24 Pictorial index YARIS_GRMN_OM_Europe_OM52J40E...

  • Page 25: For Safety And Security

    For safety and security 1-1. For safe use Before driving.......26 For safe driving ....28 Seat belts......30 SRS airbags......37 Exhaust gas precautions ..49 1-2. Child safety Airbag manual on-off system .......50 Riding with children....52 Child restraint systems ..53 1-3. Theft deterrent system Engine immobilizer system .......78 YARIS_GRMN_OM_Europe_OM52J40E...

  • Page 26: 1-1. For Safe Use

    1-1. For safe use Before driving Floor mat Use only floor mats designed specifically for vehicles of the same model and model year as your vehicle. Fix them securely in place onto the carpet. Insert the retaining hooks (clips) into the floor mat eyelets. Turn the upper knob of each retaining hook (clip) to secure the floor mats in place.
  • Page 27 When installing the driver’s floor mat ● Do not use floor mats designed for other models or different model year vehicles, even if they are Toyota Genuine floor mats. ● Only use floor mats designed for the driver’s seat. ●...

  • Page 28: For Safe Driving

    1-1. For safe use For safe driving For safe driving, adjust the seat and mirror to an appropriate position before driving. Correct driving posture Adjust the angle of the seat- back so that you are sitting straight up and so that you do not have to lean forward to steer.
  • Page 29 1-1. For safe use WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ● Do not adjust the position of the driver’s seat while driving. Doing so could cause the driver to lose control of the vehicle. ●...

  • Page 30: Seat Belts

    1-1. For safe use Seat belts Make sure that all occupants are wearing their seat belts before driving the vehicle. Correct use of the seat belts ● Extend the shoulder belt so that it comes fully over the shoulder, but does not come into contact with the neck or slide off the shoulder.
  • Page 31 1-1. For safe use Fastening the rear center seat belt Take out the plates, and then pull the seat belt. Push the plate into the buckle in Plate “A” Plate “B” the order of plate “A” and plate “B” until a clicking sound is heard.
  • Page 32 1-1. For safe use Releasing and stowing the rear center seat belt To release the hooked plate “B”, push the buckle release button. To release the hooked plate “A”, insert the plate “B” or the mechanical key (P. 113) into the hole on the buckle.
  • Page 33 ■ Seat belt regulations If seat belt regulations exist in the country where you reside, please contact any authorized Toyota retailer or Toyota authorized repairer, or any reliable repairer for seat belt replacement or installation. YARIS_GRMN_OM_Europe_OM52J40E...
  • Page 34 Each seat belt should be used by one person only. Do not use a seat belt for more than one person at once, including children. ● Toyota recommends that children be seated in the rear seat and always use a seat belt and/or an appropriate child restraint system. ●...
  • Page 35 Ensure that the belt and plate are locked and the belt is not twisted. If the seat belt does not function correctly, immediately contact any autho- rized Toyota retailer or Toyota authorized repairer, or any reliable repairer. ● Replace the seat assembly, including the belts, if your vehicle has been involved in a serious accident, even if there is no obvious damage.
  • Page 36 1-1. For safe use WARNING ■ When using the rear center seat belt ● Do not use the rear center seat belt with either buckle released. Fastening only one of the buckles may result in death or serious injury in case of sudden braking or a collision.

  • Page 37: Srs Airbags

    1-1. For safe use SRS airbags The SRS airbags inflate when the vehicle is subjected to certain types of severe impacts that may cause significant injury to the occupants. They work together with the seat belts to help reduce the risk of death or serious injury. ◆...
  • Page 38 1-1. For safe use SRS airbag system components Seat belt pretensioners and Driver airbag force limiters (front seats) SRS warning light Side impact sensors (front) Driver knee airbag Side airbags Airbag sensor assembly Curtain shield airbags Front impact sensor Seat belt pretensioners and Airbag manual on-off switch force limiters (rear outboard Front passenger airbag...
  • Page 39 1-1. For safe use The main SRS airbag system components are shown above. The SRS airbag system is controlled by the airbag sensor assembly. As the airbags deploy, a chemical reaction in the inflators quickly fills the airbags with non-toxic gas to help restrain the motion of the occu- pants.
  • Page 40 An infant or child who is too small to use a seat belt should be properly secured using a child restraint sys- tem. Toyota strongly recommends that all infants and children be placed in the rear seats of the vehicle and properly restrained. The rear seats are safer for infants and children than the front passenger seat.
  • Page 41 1-1. For safe use WARNING ■ SRS airbag precautions ● Do not lean against the door, the roof side rail or the front, side and rear pil- lars. ● Do not allow anyone to kneel on the passenger seat toward the door or put their head or hands outside the vehicle.
  • Page 42 1-1. For safe use WARNING ■ SRS airbag precautions ● Do not attach anything to areas such as a door, windshield, side window, front or rear pillar, roof side rail and assist grip. (Except for the speed limit label P. 342) ●...
  • Page 43 If the areas where the SRS airbags are stored, such as the steering wheel pad and front and rear pillar garnishes, are damaged or cracked, have them replaced by any authorized Toyota retailer or Toyota authorized repairer, or any reliable repairer.
  • Page 44 1-1. For safe use ■ If the SRS airbags deploy (inflate) ● Slight abrasions, burns, bruising, etc., may be sustained from SRS airbags, due to the extremely high speed deployment (inflation) by hot gases. ● A loud noise and white powder will be emitted. ●...
  • Page 45 1-1. For safe use ■ Conditions under which the SRS airbags may deploy (inflate), other than a collision The SRS front airbags and SRS curtain shield airbags may also deploy if a serious impact occurs to the underside of your vehicle. Some examples are shown in the illustration.
  • Page 46 1-1. For safe use ■ Types of collisions that may not deploy the SRS airbags (SRS side airbags and SRS curtain shield airbags) The SRS side airbags and SRS curtain shield airbags may not activate if the vehicle is subjected to a collision from the side at certain angles, or a collision to the side of the vehicle body other than the passenger compartment.
  • Page 47 When to contact any authorized Toyota retailer or Toyota authorized repairer, or any reliable repairer In the following cases, the vehicle will require inspection and/or repair. Con- tact any authorized Toyota retailer or Toyota authorized repairer, or any reli- able repairer as soon as possible. ●...
  • Page 48 1-1. For safe use ● The surface of the seats with the side airbag is scratched, cracked, or other- wise damaged. ● The portion of the front pillars, rear pil- lars or roof side rail garnishes (padding) containing the curtain shield airbags inside is scratched, cracked, or other- wise damaged.

  • Page 49: Exhaust Gas Precautions

    The exhaust system needs to be checked periodically. If there is a hole or crack caused by corrosion, damage to a joint or abnormal exhaust noise, be sure to have the vehicle inspected and repaired by any authorized Toyota retailer or Toyota authorized repairer, or any reliable repairer.

  • Page 50: 1-2. Child Safety

    1-2. Child safety Airbag manual on-off system This system deactivates the front passenger airbag. Only deactivate the airbags when using a child restraint system on the front passenger seat. “PASSENGER AIR BAG” indi- cator The “ON” indicator light turns on when the airbag system is on (only when the engine switch is in IGNITION ON mode).
  • Page 51 “PASSENGER AIR BAG” indicator information If any of the following problems occur, it is possible that there is a malfunction in the system. Have the vehicle inspected by any authorized Toyota retailer or Toyota authorized repairer, or any reliable repairer.

  • Page 52: Riding With Children

    1-2. Child safety Riding with children Observe the following precautions when children are in the vehi- cle. Use a child restraint system appropriate for the child, until the child becomes large enough to properly wear the vehicle’s seat belt. ● It is recommended that children sit in the rear seats to avoid acci- dental contact with the shift lever, wiper switch etc.

  • Page 53: Child Restraint Systems

    ● The use of a Toyota genuine child restraint system is recom- mended, as it is safer to use in this vehicle. Toyota genuine child restraint systems are made specifically for Toyota vehicles. They can be purchased at a Toyota dealer.

  • Page 54: Points To Remember

    ● Toyota strongly urges the use of a proper child restraint system that con- forms to the weight and size of the child, installed on the rear seat. Accord- ing to accident statistics, the child is safer when properly restrained in the rear seat than in the front seat.
  • Page 55 1-2. Child safety WARNING ■ Handling the child restraint system If the child restraint system is not properly fixed in place, the child or other passengers may be seriously injured or even killed in the event of sudden braking, sudden swerving, or an accident. ●...

  • Page 56: Child Restraint System

    1-2. Child safety Child restraint system Install the available child restraint system in vehicle upon confirming the following items. Standards for child restraint systems ■ Use a child restraint system that conforms to ECE R44 or ECE 1, 2 R129 The following approval mark is displayed on child restraint systems which are conformed.
  • Page 57 1-2. Child safety Mass group (ECE R44 only) ■ This Mass group table is required when confirming the child restraint system compatibility. Confirm in accordance with the child restraint system compatibility table. (P. 62,70). The child restraint system which conforms to the standard of ECE R44 is categorized into 5 groups according to the weight of the child.
  • Page 58 1-2. Child safety Types of child restraint system installation methods ■ Confirm with the operation manual enclosed with the child restraint system about the installation of the child restraint system. Installation method Page Seat belt P. 62 attachment ISOFIX rigid anchor P.

  • Page 59: When Using A Child Restraint System

    1-2. Child safety When using a child restraint system When installing a child restraint system to a front passenger ■ seat For the safety of a child, install a child restraint system to a rear seat. When installing a child restraint system to a front passenger seat is unavoidable, adjust the seat as follows and install the child restraint system.
  • Page 60 1-2. Child safety WARNING ■ When using a child restraint system Observe the following precautions. Failure to do so may result in death or serious injury. ● Never use a rear-facing child restraint system on the front passenger seat when the airbag manual on-off switch is on.
  • Page 61 1-2. Child safety WARNING ■ When using a child restraint system ● Only put a forward-facing child restraint system on the front seat when unavoid- able. When installing a forward-facing child restraint on the front passenger seat, move the seat as far back as pos- sible.

  • Page 62: Fixed With A Seat Belt

    1-2. Child safety Child restraint system fixed with a seat belt ◆ Confirming the possible installation seating positions and the Mass Group for the seat belt installation type child restraint systems. Confirm the corresponding [Mass group] from the weight of the child (P.
  • Page 63 Recommended seat Mass Child Restraint groups Airbag manual Systems on-off switch Outboard Center “TOYOTA G 0+, Up to BABY SAFE PLUS” 10 kg “TOYOTA MINI” (22 lb.) “TOYOTA G 0+, BABY SAFE PLUS with SEAT BELT Up to FIXATION, BASE 13 kg PLATFORM”...
  • Page 64 1-2. Child safety Key of letters inserted in the above table: X: Not suitable seat position for children in this mass group. U: Suitable for “universal” category child restraint systems approved for use in this mass group. UF: Suitable for forward-facing “universal” category child restraint sys- tems approved for use in this mass group.
  • Page 65 1-2. Child safety ● When installing a forward- facing child seat, if there is a gap between the child seat and the seatback, adjust the seatback angle until good contact is achieved. ● If the seat belt shoulder anchor is ahead of the child seat belt guide, move the seat cushion forward.
  • Page 66 1-2. Child safety ◆ Installing child restraint system using a seat belt Install the child restraint system in accordance to the operation manual enclosed with the child restraint system. If installing the child restraint system to the front passenger seat is unavoidable, refer to P.
  • Page 67 If your child restraint system does not provide a locking clip, you can purchase the following item from any authorized Toyota retailer or Toyota authorized repairer, or any reli- able repairer: Locking clip for child restraint system (Part No.
  • Page 68 1-2. Child safety WARNING ■ When installing a child restraint system Observe the following precautions. Failure to do so may result in death or serious injury. ● Do not allow children to play with the seat belt. If the seat belt becomes twisted around a child’s neck, it may lead to choking or other serious inju- ries that could result in death.

  • Page 69: Fixed With An Isofix Rigid Anchor

    1-2. Child safety Child restraint system fixed with an ISOFIX rigid anchor ISOFIX rigid anchors (ISOFIX child restraint system) ■ Lower anchors are provided for the rear outboard seats. (Tags displaying the location of the anchors are attached to the seats.) Confirming the Mass group and Size class for ECE R44 ISOFIX ■...
  • Page 70 1-2. Child safety Child restraint systems fastened with ISOFIX (ECE R44) - Com- ■ patibility and Recommended child restraint systems table ISOFIX child restraint systems are divided in different “size class”. According to this “size class”, you will be allowed to use it in the vehicle seating position mentioned in the table below.
  • Page 71 Child Restraint class Systems Passen- Outboard Center ger seat Carrycot — Up to 10 kg “TOYOTA MINI” (22 lb.) “TOYOTA MIDI” Up to 13 kg “TOYOTA MINI” (28 lb.) “TOYOTA MIDI” — “TOYOTA MIDI” 9 to 18 kg (20 to 39 lb.) “TOYOTA DUO+”...
  • Page 72 1-2. Child safety Key of letters inserted in the above table: Not suitable seat position for ISOFIX child restraint systems in this mass group and/or size class. IUF: Suitable for ISOFIX forward-facing child restraint systems of “uni- versal” category approved for use in this mass group. Suitable for ISOFIX child restraint systems of the categories for “specific vehicles”, “restricted”, or “semi-universal”...
  • Page 73 1-2. Child safety i-Size child restraint systems fastened with ISOFIX (ECE ■ R129) - Compatibility table If your child restraint system is of “i-Size” category, you can install it on the positions mentioned by i-U in the table below. Child restraint system category can be found in the child restraint system manual.
  • Page 74 1-2. Child safety Installation with ISOFIX rigid anchor (ISOFIX child restraint ■ system) Install the child restraint system in accordance to the operation manual enclosed with the child restraint system. If the head restraint interferes with the child restraint system installation and the head restraint can be removed, remove the head restraint.

  • Page 75: Using An Anchor Bracket (For Top Strap)

    1-2. Child safety WARNING ■ When installing a child restraint system Observe the following precautions. Failure to do so may result in death or serious injury. ● After securing a child restraint system, never adjust the seat. ● When using the lower anchors, be sure that there are no foreign objects around the anchors and that the seat belt is not caught behind the child restraint system.
  • Page 76 1-2. Child safety Fixing the top strap to the anchor bracket ■ Install the child restraint system in accordance to the operation manual enclosed with the child restraint system.  Remove the luggage cover. ( P. 233) Adjust the head restraint to the upmost position.
  • Page 77 1-2. Child safety WARNING ■ When installing a child restraint system Observe the following precautions. Failure to do so may result in death or serious injury. ● Firmly attach the top strap and make sure that the belt is not twisted. ●...

  • Page 78: 1-3. Theft Deterrent System

    1-3. Theft deterrent system Engine immobilizer system The vehicle’s keys have built-in transponder chips that prevent the engine from starting if a key has not been previously regis- tered in the vehicle’s on-board computer. Never leave the keys inside the vehicle when you leave the vehi- cle.
  • Page 79 1-3. Theft deterrent system ■ Certifications for the engine immobilizer system YARIS_GRMN_OM_Europe_OM52J40E...
  • Page 80 1-3. Theft deterrent system YARIS_GRMN_OM_Europe_OM52J40E...
  • Page 81 1-3. Theft deterrent system YARIS_GRMN_OM_Europe_OM52J40E...
  • Page 82 1-3. Theft deterrent system YARIS_GRMN_OM_Europe_OM52J40E...
  • Page 83 1-3. Theft deterrent system YARIS_GRMN_OM_Europe_OM52J40E...
  • Page 84 1-3. Theft deterrent system YARIS_GRMN_OM_Europe_OM52J40E...
  • Page 85 1-3. Theft deterrent system YARIS_GRMN_OM_Europe_OM52J40E...
  • Page 86 1-3. Theft deterrent system YARIS_GRMN_OM_Europe_OM52J40E...
  • Page 87 1-3. Theft deterrent system YARIS_GRMN_OM_Europe_OM52J40E...
  • Page 88 1-3. Theft deterrent system YARIS_GRMN_OM_Europe_OM52J40E...
  • Page 89 1-3. Theft deterrent system YARIS_GRMN_OM_Europe_OM52J40E...
  • Page 90 1-3. Theft deterrent system NOTICE ■ To ensure the system operates correctly Do not modify or remove the system. If modified or removed, the proper operation of the system cannot be guaranteed. YARIS_GRMN_OM_Europe_OM52J40E...

  • Page 91: Instrument Cluster

    Instrument cluster Instrument cluster Warning lights and indicators ......92 Gauges and meters .....96 Multi-information display ..100 Fuel consumption information.......107 YARIS_GRMN_OM_Europe_OM52J40E...

  • Page 92: Warning Lights And Indicators

    2. Instrument cluster Warning lights and indicators The warning lights and indicators on the instrument cluster and center panel inform the driver of the status of the vehicle’s vari- ous systems. For the purpose of explanation, the following illustration dis- plays all warning lights and indicators illuminated.
  • Page 93 There may be a mal- function in a system if a light does not come on, or if the lights do not turn off. Have the vehicle inspected by any authorized Toyota retailer or Toyota authorized repairer, or any reliable repairer.
  • Page 94 There may be a mal- function in a system if a light does not come on, or if the lights do not turn off. Have the vehicle inspected by any authorized Toyota retailer or Toyota authorized repairer, or any reliable repairer.
  • Page 95 Have the vehicle inspected by any authorized Toyota retailer or Toyota authorized repairer, or any reliable repairer immediately if this occurs.

  • Page 96: Gauges And Meters

    2. Instrument cluster Gauges and meters Tachometer Displays the engine speed in revolutions per minute. Outside temperature display Displays the outside temperature within the range of -40°C (-40°F) to 50°C (122°F). Low outside temperature indicator comes on when the ambient temperature is 3°C (37°F) or lower.
  • Page 97 2. Instrument cluster Odometer and trip meter display: Displays the following items. Odometer: Displays the total distance the vehicle has been driven. Trip meter: Displays the distance the vehicle has been driven since the meter was last reset. Trip meters “A” and “B” can be used to record and display different distances independently.
  • Page 98 2. Instrument cluster Instrument cluster light control The brightness of the instrument cluster lights can be adjusted. Display the instrument cluster light control by pressing the “TRIP” switch. Then, press and hold the switch. Adjust the brightness to the desired level by pressing the switch.
  • Page 99 ● When “--” or “E” is displayed, the system may be malfunctioning. Take your vehicle to any authorized Toyota retailer or Toyota authorized repairer, or any reliable repairer. ● The temperature range that can be displayed is from -40°C (-40°F) to 50°C (122°F).

  • Page 100: Multi-Information Display

    2. Instrument cluster Multi-information display Display contents The multi-information display presents the driver with a variety of vehi- cle data. ● Menu icons Displays the following informa- tion when an icon is selected. (P. 101) Some of the information may be displayed automatically depending on the situation.
  • Page 101 2. Instrument cluster Warning message display Select to display warning messages and measures to be taken if a malfunction is detected. (P. 332) Settings display Select to change the meter display settings and the operation set- tings of some vehicle functions. (P. 103) Operating the meter control switches The multi-information display is operated using the meter control...
  • Page 102 2. Instrument cluster Drive information Items displayed can be switched by pressing “<” or “>” of the meter control switches to select and pressing “” or “”. ● Average fuel consumption (after reset /after start/after refuel) Displays the average fuel consumption since the function was reset, the engine was started, and the vehicle was refueled, respectively Use the displayed average fuel consumption as a reference.
  • Page 103 2. Instrument cluster Settings display The settings of the following items can be changed, refer to P. 380. For functions that can be enabled or disabled, the function switches between on and off each time is pressed. ● Clock Adjusts the hour and minute, and switches between 12-hour and 24-hour display of the clock.
  • Page 104 2. Instrument cluster Clock The time can be adjusted through the for the multi-information dis- play. Adjust the clock mode (12 or 24 hour) Adjust the hours Adjust the minutes Time adjustment ■ Press “” or “” of the meter control switches (P. 101), select “Clock”...
  • Page 105 2. Instrument cluster ■ Pop-up display In some situations, such as when a switch operation is performed, a pop-up display will be temporarily displayed on the multi-information display. The pop-up display function can be set on/off. ■ Setting display automatic cancelation “Settings”...
  • Page 106 2. Instrument cluster WARNING ■ Caution for use while driving ● When operating the multi-information display while driving, pay extra attention to the safety of the area around the vehicle. ● Do not look continuously at the multi-information display while driving as you may fail to see pedestrians, objects on the road, etc., ahead of the vehicle.

  • Page 107: Fuel Consumption Information

    2. Instrument cluster Fuel consumption information Fuel consumption information can be displayed on the naviga- tion/multimedia system. Navigation/multimedia system Trip information Press the button on the navigation/multimedia system. YARIS_GRMN_OM_Europe_OM52J40E...
  • Page 108 2. Instrument cluster Select “Trip information”. Average vehicle speed since the engine was started. Cruising range (P. 110) Fuel consumption in the past 15 minutes Elapsed time since engine was started. Resetting the consumption data Average fuel consumption for the past 15 minutes is divided by color into past averages and averages attained since the engine switch was last turned to IGNITION ON mode.
  • Page 109 2. Instrument cluster Past record Press the button on the navigation/multimedia system. Select “Past record”. Best recorded fuel consump- tion Previous fuel consumption record Average fuel consumption Updating the average fuel consumption data Resetting the past record data The average fuel consumption history is divided by color into past averages and the average fuel consumption since the last updated.
  • Page 110 2. Instrument cluster ■ Updating the past record data Update the average fuel consumption by selecting “Update” to measure the current fuel consumption again. ■ Resetting the data The fuel consumption data can be deleted by selecting “Clear”. ■ Cruising range Displays the estimated maximum distance that can be driven with the quan- tity of fuel remaining.

  • Page 111: Operation Of Each Component

    Operation of each component 3-1. Key information Keys........112 3-2. Opening, closing and locking the doors Side doors......116 Back door......120 Smart entry & start system .....125 3-3. Adjusting the seats Front seats......154 Rear seats ......156 Head restraints ....159 3-4. Adjusting the steering wheel and mirrors Steering wheel ....162 Inside rear view mirror ..164...

  • Page 112: Keys

    3-1. Key information Keys The keys The following keys are provided with the vehicle. Electronic keys • Operating the smart entry & start system (P. 125) • Operating the wireless remote control function Mechanical keys Key number plate Wireless remote control Locks all the doors ( ...
  • Page 113 ■ If you lose your keys New genuine keys can be made by any authorized Toyota retailer or Toyota authorized repairer, or any reliable repairer using the other key and the key number stamped on your key number plate. Keep the plate in a safe place such as your wallet, not in the vehicle.
  • Page 114 ■ Confirmation of the registered key number The number of keys already registered to the vehicle can be confirmed. Ask any authorized Toyota retailer or Toyota authorized repairer, or any reliable repairer for details. ■ If a wrong key is used The key cylinder rotates freely to isolate inside mechanism.
  • Page 115 In case of a smart entry & start system malfunction or other key-related problems Take your vehicle with all the electronic keys provided with your vehicle to any authorized Toyota retailer or Toyota authorized repairer, or any reliable repairer. ■...

  • Page 116: Side Doors

    3-2. Opening, closing and locking the doors Side doors The vehicle can be locked and unlocked using the entry func- tion, wireless remote control, key or door lock switch. Unlocking and locking the doors from the outside ◆ Entry function Carry the electronic key to enable this function.
  • Page 117 3-2. Opening, closing and locking the doors ■ Operation signals The emergency flashers flash to indicate that the doors have been locked/ unlocked. (Locked: once; Unlocked: twice) ■ Security feature If a door is not opened within approximately 30 seconds after the vehicle is unlocked, the security feature automatically locks the vehicle again.
  • Page 118 3-2. Opening, closing and locking the doors Unlocking and locking the doors from the inside ◆ Door lock switch Unlocks all the doors Locks all the doors ◆ Inside door lock buttons Locks the doors Unlocks the doors The side doors can be opened by pulling the inside handle even if the inside door lock but- ton is in the lock position.
  • Page 119 3-2. Opening, closing and locking the doors ■ Using the mechanical key The doors can also be locked and unlocked with the mechanical key. P. 356) ■ Open door warning buzzer If a door or the back door is not fully closed, a buzzer will sound when the vehicle speed reaches 5 km/h (3 mph).

  • Page 120: Back Door

    3-2. Opening, closing and locking the doors Back door The back door can be locked/unlocked and opened by the fol- lowing procedures. Unlocking and locking the back door ◆ Entry function Carry the electronic key to enable this function. Press the button to unlock the back door.
  • Page 121 3-2. Opening, closing and locking the doors Opening the back door from the outside the vehicle Raise the back door while pushing up the back door opener switch. The back door cannot be closed immediately after the back door opener switch is pushed. When closing the back door Lower the back door using the back door handle, and make sure...
  • Page 122 3-2. Opening, closing and locking the doors WARNING ■ Caution while driving ● Keep the back door closed while driving. If the back door is left open, it may hit near-by objects while driving or lug- gage may be unexpectedly thrown out, causing an accident. In addition, exhaust gases may enter the vehicle, causing death or a seri- ous health hazard.
  • Page 123 If a bicycle carrier or similar heavy object is attached to the back door, it may suddenly shut again after being opened, causing someone’s hands, head or neck to be caught and injured. When installing an accessory part to the back door, using a genuine Toyota part is recommended. YARIS_GRMN_OM_Europe_OM52J40E...
  • Page 124 Do not touch the damper stay rod with gloves or other fabric items. ● Do not attach any accessories other than genuine Toyota parts to the back door. ● Do not place your hand on the damper stay or apply lateral forces to it.

  • Page 125: Smart Entry & Start System

    3-2. Opening, closing and locking the doors Smart entry & start system The following operations can be performed simply by carrying the electronic key on your person, for example in your pocket. (The driver should always carry the electronic key.) ●...
  • Page 126 3-2. Opening, closing and locking the doors ■ Effective range (areas within which the electronic key is detected) When locking or unlocking the doors The system can be operated when the electronic key is within about 0.7 m (2.3 ft.) either of the outside door handles and back door.
  • Page 127 When “Check entry & start system.” is displayed on the multi-informa- tion display The system may be malfunctioning. Have the vehicle inspected by any autho- rized Toyota retailer or Toyota authorized repairer, or any reliable repairer immediately. ■ Battery-saving function...
  • Page 128 3-2. Opening, closing and locking the doors ■ Conditions affecting operation The smart entry & start system uses weak radio waves. In the following situa- tions, the communication between the electronic key and the vehicle may be affected, preventing the smart entry & start system, wireless remote control and engine immobilizer system from operating properly.
  • Page 129 3-2. Opening, closing and locking the doors ■ Notes for the entry function ● Even when the electronic key is within the effective range (detection areas), the system may not operate properly in the following cases: • The electronic key is too close to the window or outside door handle, near the ground, or in a high place when the doors are locked or unlocked.
  • Page 130 3-2. Opening, closing and locking the doors ● Touching the door lock or unlock sensor while wearing gloves may prevent lock or unlock operation. ● When the lock operation is performed using the lock sensor, recognition sig- nals will be shown up to two consecutive times. After this, no recognition signals will be given.
  • Page 131 3-2. Opening, closing and locking the doors ■ When the vehicle is not driven for extended periods ● To prevent theft of the vehicle, do not leave the electronic key within 2 m (6 ft.) of the vehicle. ● The smart entry & start system can be deactivated in advance. (P. 380) ■...
  • Page 132 3-2. Opening, closing and locking the doors ■ Certification for the smart entry & start system YARIS_GRMN_OM_Europe_OM52J40E...
  • Page 133 3-2. Opening, closing and locking the doors YARIS_GRMN_OM_Europe_OM52J40E...
  • Page 134 3-2. Opening, closing and locking the doors YARIS_GRMN_OM_Europe_OM52J40E...
  • Page 135 3-2. Opening, closing and locking the doors YARIS_GRMN_OM_Europe_OM52J40E...
  • Page 136 3-2. Opening, closing and locking the doors YARIS_GRMN_OM_Europe_OM52J40E...
  • Page 137 3-2. Opening, closing and locking the doors YARIS_GRMN_OM_Europe_OM52J40E...
  • Page 138 3-2. Opening, closing and locking the doors YARIS_GRMN_OM_Europe_OM52J40E...
  • Page 139 3-2. Opening, closing and locking the doors YARIS_GRMN_OM_Europe_OM52J40E...
  • Page 140 3-2. Opening, closing and locking the doors YARIS_GRMN_OM_Europe_OM52J40E...
  • Page 141 3-2. Opening, closing and locking the doors YARIS_GRMN_OM_Europe_OM52J40E...
  • Page 142 3-2. Opening, closing and locking the doors YARIS_GRMN_OM_Europe_OM52J40E...
  • Page 143 3-2. Opening, closing and locking the doors YARIS_GRMN_OM_Europe_OM52J40E...
  • Page 144 3-2. Opening, closing and locking the doors YARIS_GRMN_OM_Europe_OM52J40E...
  • Page 145 3-2. Opening, closing and locking the doors YARIS_GRMN_OM_Europe_OM52J40E...
  • Page 146 3-2. Opening, closing and locking the doors YARIS_GRMN_OM_Europe_OM52J40E...
  • Page 147 3-2. Opening, closing and locking the doors YARIS_GRMN_OM_Europe_OM52J40E...
  • Page 148 3-2. Opening, closing and locking the doors YARIS_GRMN_OM_Europe_OM52J40E...
  • Page 149 3-2. Opening, closing and locking the doors YARIS_GRMN_OM_Europe_OM52J40E...
  • Page 150 3-2. Opening, closing and locking the doors YARIS_GRMN_OM_Europe_OM52J40E...
  • Page 151 3-2. Opening, closing and locking the doors YARIS_GRMN_OM_Europe_OM52J40E...
  • Page 152 3-2. Opening, closing and locking the doors YARIS_GRMN_OM_Europe_OM52J40E...
  • Page 153 (P. 125) The radio waves may affect the operation of such devices. If necessary, the entry function can be disabled. Ask any authorized Toyota retailer or Toyota authorized repairer, or any reliable repairer for details, such as the frequency of radio waves and timing of the emitted radio waves.

  • Page 154: 3-3. Adjusting The Seats

    3-3. Adjusting the seats Front seats Adjustment procedure Seat position adjustment lever Seatback angle adjustment lever Vertical height adjustment lever (driver’s seat only) Slide lock release strap (front passenger’s seat only) Getting on and off the rear seat Pull the reclining adjustment lever.
  • Page 155 3-3. Adjusting the seats WARNING ■ When adjusting the seat position ● Take care when adjusting the seat position to ensure that other passen- gers are not injured by the moving seat. ● Do not put your hands under the seat or near the moving parts to avoid injury.

  • Page 156: Rear Seats

    3-3. Adjusting the seats Rear seats The seatbacks of the rear seats can be folded down. Folding down the rear seatbacks Stow the rear seat belt buckles as shown. Stow the seat belts. Center: P. 32 Outside: Use the seat belt hangers to prevent the belts from being tangled.
  • Page 157 3-3. Adjusting the seats Pull the seatback lock release knob and fold the seatback down. Each seatback may be folded sep- arately. Returning the rear seatbacks Lift up the seatback until it locks. Return the seat belt to the origi- nal position.
  • Page 158 3-3. Adjusting the seats WARNING ■ When folding the rear seatbacks down Observe the following precautions. Failure to do so may result in death or serious injury. ● Do not fold the seatbacks down while driving. ● Stop the vehicle on level ground, set the parking brake and shift the shift lever to N.

  • Page 159: Head Restraints

    3-3. Adjusting the seats Head restraints Head restraints are provided for all seats. Adjusting the head restraints Front seats  The front head restraints do not have adjusted function. Rear seats  Pull the head restraints up. Down Push the head restraint down while pressing the lock release button.
  • Page 160 3-3. Adjusting the seats Pull the head restraint up while pushing the lock release button. Lock release button ■ Installing the head restraints Rear center seat  Align the head restraint with the installa- tion holes and push it down to the lock position.
  • Page 161 3-3. Adjusting the seats WARNING ■ Head restraint precautions Observe the following precautions regarding the head restraints. Failure to do so may result in death or serious injury. ● Use the head restraints designed for each respective seat. ● Adjust the head restraints to the correct position at all times. ●...

  • Page 162: Steering Wheel

    3-4. Adjusting the steering wheel and mirrors Steering wheel Adjustment procedure Hold the steering wheel and push the lever down. Adjust to the ideal position by moving the steering wheel hori- zontally and vertically. After adjustment, pull the lever up to secure the steering wheel.
  • Page 163 3-4. Adjusting the steering wheel and mirrors ■ After adjusting the steering wheel Make sure that the steering wheel is securely locked. The horn may not sound if the steering wheel is not securely locked. WARNING ■ Caution while driving Do not adjust the steering wheel while driving.

  • Page 164: Inside Rear View Mirror

    3-4. Adjusting the steering wheel and mirrors Inside rear view mirror The rear view mirror’s position can be adjusted to enable suffi- cient confirmation of the rear view. Adjusting the height of rear view mirror The height of the rear view mirror can be adjusted to suit your driving posture.
  • Page 165 3-4. Adjusting the steering wheel and mirrors ■ To prevent sensor error To ensure that the sensors operate prop- erly, do not touch or cover them. WARNING Do not adjust the position of the mirror while driving. Doing so may lead to mishandling of the vehicle and cause an accident, resulting in death or serious injury.

  • Page 166: Outside Rear View Mirrors

    3-4. Adjusting the steering wheel and mirrors Outside rear view mirrors Adjustment procedure To select a mirror to adjust, press the switch. Left Right To adjust the mirror, press the switch. Right Down Left YARIS_GRMN_OM_Europe_OM52J40E...
  • Page 167 3-4. Adjusting the steering wheel and mirrors Folding the mirrors From outside  Push the mirror back in the direc- tion of the vehicle’s rear. From inside  Press the button to fold back the mirrors Push once more to return to the original position.
  • Page 168 3-4. Adjusting the steering wheel and mirrors Automatic electric stowing function The outside rear view mirror will automatically stow away and return when operating the door lock and unlocking via the smart entry & start system and wireless remote control. The automatic electric stowing function is turned on and off using the following procedures.
  • Page 169 3-4. Adjusting the steering wheel and mirrors ■ Mirror angle can be adjusted when The engine switch is in ACCESSORY or IGNITION ON mode. ■ When the mirrors are fogged up The outside rear view mirrors can be cleared using the mirror defoggers. Turn on the rear window defogger to turn on the outside rear view mirror defog- gers.
  • Page 170 3-4. Adjusting the steering wheel and mirrors WARNING ■ Important points while driving Observe the following precautions while driving. Failure to do so may result in loss of control of the vehicle and cause an accident, resulting in death or serious injury. ●...

  • Page 171: Opening And Closing

    3-5. Opening and closing the windows Power windows Opening and closing procedures The power windows can be opened and closed using the switches. Operating the switch moves the windows as follows: Closing One-touch closing (driver’s win- dow only) Opening One-touch opening (driver’s window only) : To stop the window partway, oper-...
  • Page 172 If you release the switch while the window is moving, start again from the beginning. If the window continues to close but then re-open slightly even after perform- ing the above procedure correctly, have the vehicle inspected by any autho- rized Toyota retailer or Toyota authorized repairer, or any reliable repairer. YARIS_GRMN_OM_Europe_OM52J40E...
  • Page 173 3-5. Opening and closing the windows WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ Closing the windows ● The driver is responsible for all the power window operations, including the operation for the passengers. In order to prevent accidental operation, especially by a child, do not let a child operate the power windows.
  • Page 174 3-5. Opening and closing the windows YARIS_GRMN_OM_Europe_OM52J40E...

  • Page 175: Driving

    Driving 4-1. Before driving 4-4. Refueling Driving the vehicle .....176 Opening the fuel tank cap........207 Cargo and luggage ....184 4-5. Using the driving support Trailer towing .....186 systems 4-2. Driving procedures Driving assist systems ..210 Engine (ignition) switch..187 4-6. Driving tips Manual transmission..192 Winter driving tips ....216 Turn signal lever ....194...

  • Page 176: 4-1. Before Driving

    4-1. Before driving Driving the vehicle The following procedures should be observed to ensure safe driving: Starting the engine P. 187 Driving While depressing the clutch pedal, shift the shift lever to 1. (P. 192) Release the parking brake. (P. 195) Gradually release the clutch pedal.
  • Page 177 ■ Breaking in your new Toyota To extend the life of the vehicle, observing the following precautions is recom- mended: ●...
  • Page 178 4-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When driving the vehicle ● Do not drive if you are unfamiliar with the location of the brake and accel- erator pedals to avoid depressing the wrong pedal.
  • Page 179 4-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When driving on slippery road surfaces ● Sudden braking, acceleration and steering may cause tire slippage and reduce your ability to control the vehicle. ●...
  • Page 180 If you hear a squealing or scraping noise (brake pad wear indicators) Have the brake pads checked and replaced by any authorized Toyota retailer or Toyota authorized repairer, or any reliable repairer as soon as possible. Rotor damage may result if the pads are not replaced when needed.
  • Page 181 4-1. Before driving WARNING ● Do not attach adhesive discs to the windshield or windows. Do not place containers such as air fresheners on the instrument panel or dashboard. Adhesive discs or containers may act as lenses, causing a fire in the vehi- cle.
  • Page 182 4-1. Before driving NOTICE ■ When driving the vehicle ● Do not depress the accelerator and brake pedals at the same time during driving, as this may restrain the engine output. ● Do not shift gears unless the clutch pedal is fully depressed. After shifting, do not release the clutch pedal abruptly.
  • Page 183 Engine damage caused by water immersion In the event that you drive on a flooded road and the vehicle is flooded, be sure to have any authorized Toyota retailer or Toyota authorized repairer, or any reliable repairer check the following: ●...

  • Page 184: Cargo And Luggage

    4-1. Before driving Cargo and luggage Take notice of the following information about storage precau- tions, cargo capacity and load: WARNING ■ Things that must not be carried in the luggage compartment The following things may cause a fire if loaded in the luggage compartment: ●...
  • Page 185 4-1. Before driving WARNING ■ Load and distribution ● Do not overload your vehicle. ● Do not apply loads unevenly. Improper loading may cause deterioration of steering or braking control which may cause death or serious injury. YARIS_GRMN_OM_Europe_OM52J40E...

  • Page 186: Trailer Towing

    4-1. Before driving Trailer towing Toyota does not recommend towing a trailer with your vehicle. Your vehicle is not designed for trailer towing. YARIS_GRMN_OM_Europe_OM52J40E...

  • Page 187: Driving Procedures

    4-2. Driving procedures Engine (ignition) switch Performing the following operations when carrying the elec- tronic key on your person starts the engine or changes engine switch mode. Starting the engine Check that the parking brake is set. Check that the shift lever is set in N. Firmly depress the clutch pedal.
  • Page 188 4-2. Driving procedures Stopping the engine Stop the vehicle. Shift the shift lever to N. Set the parking brake (P. 195). Press the engine switch. Release the clutch pedal and check that “Power on” on the multi- information display is off. Changing engine switch modes Modes can be changed by pressing the engine switch with clutch pedal released.
  • Page 189 P. 129 ■ If the engine does not start The engine immobilizer system may not have been deactivated. (P. 78) Contact any authorized Toyota retailer or Toyota authorized repairer, or any reliable repairer. ■ Steering lock After turning the engine switch off and opening and closing the doors, the steering wheel will be locked due to the steering lock function.
  • Page 190 4-2. Driving procedures ■ Operation of the engine switch ● If the switch is not pressed shortly and firmly, the engine switch mode may not change or the engine may not start. ● If attempting to restart the engine immediately after turning the engine switch off, the engine may not start in some cases.
  • Page 191 Symptoms indicating a malfunction with the engine switch If the engine switch seems to be operating somewhat differently than usual, such as the switch sticking slightly, there may be a malfunction. Contact any authorized Toyota retailer or Toyota authorized repairer, or any reliable repairer immediately. YARIS_GRMN_OM_Europe_OM52J40E...

  • Page 192: Manual Transmission

    4-2. Driving procedures Manual transmission Shifting the shift lever Fully depress the clutch pedal before operating the shift lever, and then release it slowly. Shifting the shift lever to R Shift the shift lever to R while lift- ing up the ring section. YARIS_GRMN_OM_Europe_OM52J40E...
  • Page 193 4-2. Driving procedures ■ Maximum downshifting speeds Observe the downshifting speeds in the following table to prevent over-rev- ving the engine. km/h (mph) Shift position Maximum speed 53 (32) 98 (60) 135 (83) 182 (113) 194 (120) NOTICE ■ To prevent damage to the 6-speed transmission ●...

  • Page 194: Turn Signal Lever

    4-2. Driving procedures Turn signal lever Operation instructions Right turn Lane change to the right (push and hold the lever partway) The right hand signals will flash until you release the lever. Lane change to the left (push and hold the lever partway) The left hand signals will flash until you release the lever.

  • Page 195: Parking Brake

    4-2. Driving procedures Parking brake Operation instructions To set the parking brake, fully pull the parking brake lever while depressing the brake pedal. To release the parking brake, slightly raise the lever and lower it completely while press- ing the button. ■...

  • Page 196: Headlight Switch

    4-3. Operating the lights and wipers Headlight switch The headlights can be operated manually or automatically. Operation instructions Turning the end of the lever turns on the lights as follows: The daytime running lights turn on. (P. 199) The front position, tail, license plate and instru- ment cluster lights turn on.
  • Page 197 4-3. Operating the lights and wipers Turning on the high beam headlights With the headlights on, push the lever away from you to turn on the high beams. Pull the lever toward you to the center position to turn the high beams off.
  • Page 198 4-3. Operating the lights and wipers Manual headlight leveling dial The level of the headlights can be adjusted according to the number of passengers and the loading condition of the vehicle. Left-hand drive vehicles Right-hand drive vehicles   Raises the level of the headlights Lowers the level of the headlights ■...
  • Page 199 4-3. Operating the lights and wipers ■ Daytime running light system To make your vehicle more visible to other drivers during daytime driving, the daytime running lights turn on automatically whenever the engine is started and the parking brake is released with the headlight switch off or in the “AUTO”...
  • Page 200 4-3. Operating the lights and wipers ■ Light reminder buzzer A buzzer sounds when the engine switch is turned off and the driver’s door is opened while the lights are turned on. ■ Battery-saving function In all conditions following below, the headlights and the other remaining lights will go off automatically after 20 minutes in order to prevent the vehicle bat- tery from being discharged: ●...

  • Page 201: Fog Light Switch

    4-3. Operating the lights and wipers Fog light switch The fog lights secure excellent visibility in difficult driving con- ditions, such as in rain and fog. Operation instructions Turns the front and rear fog light off Turns the front fog lights Turns both front and rear fog light on Releasing the switch ring...

  • Page 202: Windshield Wiper And Washer

    4-3. Operating the lights and wipers Windshield wiper and washer Operating the wiper lever Operate the lever as follows to operate the wiper. When is selected, the wiper will operate automatically when the sensor detects falling rain. The system automatically adjusts wiper timing in accordance with rain volume and vehicle speed.
  • Page 203 4-3. Operating the lights and wipers Washer/wiper dual operation The wiper will automatically oper- ate a couple of times after the washer squirts. (After operating several times, the wiper operate one more time after a short delay to prevent dripping.) ■...
  • Page 204 ■ When a nozzle becomes blocked In this case, contact any authorized Toyota retailer or Toyota authorized repairer, or any reliable repairer. Do not try to clear it with a pin or other object. The nozzle will be damaged.

  • Page 205: Rear Window Wiper And Washer

    4-3. Operating the lights and wipers Rear window wiper and washer Operation instructions Turning the end of the lever turns on the rear window wiper and washer. Intermittent window wiper operation Normal window wiper operation Washer/wiper dual opera- tion Washer/wiper dual opera- tion The wiper will automatically operate a couple of times...
  • Page 206 ■ When a nozzle becomes blocked In this case, contact any authorized Toyota retailer or Toyota authorized repairer, or any reliable repairer. Do not try to clear it with a pin or other object. The nozzle will be damaged.

  • Page 207: Refueling

    4-4. Refueling Opening the fuel tank cap Perform the following steps to open the fuel tank cap: Before refueling the vehicle ● Turn the engine switch off and ensure that all the doors and win- dows are closed. ● Confirm the type of fuel. ■...
  • Page 208 4-4. Refueling WARNING ■ When refueling Observe the following precautions to prevent fuel overflowing from the fuel tank: ● Securely insert the fuel nozzle into the fuel filler neck. ● Stop filling the tank after the fuel nozzle automatically clicks off. ●...
  • Page 209 WARNING ■ When replacing the fuel tank cap Do not use anything but a genuine Toyota fuel tank cap designed for your vehicle. Doing so may cause a fire or other incident which may result in death or serious injury.

  • Page 210: 4-5. Using The Driving Support Systems

    4-5. Using the driving support systems Driving assist systems To help enhance driving safety and performance, the following systems operate automatically in response to various driving situations. Be aware, however, that these systems are supple- mentary and should not be relied upon too heavily when operat- ing the vehicle.
  • Page 211 4-5. Using the driving support systems When the TRC/VSC systems are operating The slip indicator light will flash while the TRC/VSC systems are operating. Disabling the TRC system If the vehicle gets stuck in mud, dirt or snow, the TRC system may reduce power from the engine to the wheels.
  • Page 212 TRC has been disabled even if has not been pressed TRC is temporary deactivated. If the information continues to show, contact any authorized Toyota retailer or Toyota authorized repairer, or any reliable repairer. ■ Operating conditions of hill-start assist control...
  • Page 213 4-5. Using the driving support systems ■ Sounds and vibrations caused by the ABS, brake assist, VSC, TRC, and hill-start assist control systems ● A sound may be heard from the engine compartment when the brake pedal is depressed repeatedly, when the engine is started or just after the vehicle begins to move.
  • Page 214 4-5. Using the driving support systems WARNING ■ The ABS does not operate effectively when ● The limits of tire gripping performance have been exceeded (such as excessively worn tires on a snow covered road). ● The vehicle hydroplanes while driving at high speed on wet or slick roads. ■...
  • Page 215 The ABS, TRC and VSC systems will not function correctly if different tires are installed on the vehicle. Contact any authorized Toyota retailer or Toyota authorized repairer, or any reliable repairer for further information when replacing tires or wheels. ■...

  • Page 216: 4-6. Driving Tips

    4-6. Driving tips Winter driving tips Carry out the necessary preparations and inspections before driving the vehicle in winter. Always drive the vehicle in a man- ner appropriate to the prevailing weather conditions. Preparation for winter ● Use fluids that are appropriate to the prevailing outside tempera- tures.
  • Page 217 4-6. Driving tips When driving the vehicle Accelerate the vehicle slowly, keep a safe distance between you and the vehicle ahead, and drive at a reduced speed suitable to road con- ditions. When parking the vehicle Park the vehicle and move the shift lever to 1 or R without setting the parking brake.
  • Page 218 4-6. Driving tips WARNING ■ Driving with snow tires Observe the following precautions to reduce the risk of accidents. Failure to do so may result in a loss of vehicle control and cause death or serious injury. ● Use tires of the specified size. ●...

  • Page 219: Interior Features

    Interior features 5-1. Using the air conditioning 5-3. Using the storage features system and defogger List of storage features ..229 Air conditioning system..220 • Glove box ......230 • Cup holders ....231 5-2. Using the interior lights • Bottle holders ....232 Interior lights list....227 •...

  • Page 220: Air Conditioning System

    5-1. Using the air conditioning system and defogger Air conditioning system Air outlets and fan speed are automatically adjusted according to the temperature setting. Air conditioning controls Adjusting the temperature setting ■ To adjust the temperature set- ting, turn the temperature con- trol dial clockwise...
  • Page 221 5-1. Using the air conditioning system and defogger Change the airflow mode ■ To change the air outlets, press outlets used switched each time the button is pressed. Air flows to the upper body Air flows to the upper body and feet Air flows to the feet Air flows to the feet and the windshield defogger operates...
  • Page 222 5-1. Using the air conditioning system and defogger Other functions Switching between outside air and recirculated air modes ■ Press The mode switches each time the button is pressed. The indicator comes on when the recirculated air mode is on. Defogging the windshield ■...
  • Page 223 5-1. Using the air conditioning system and defogger Adjusting the position, opening and closing the air outlets ■ Front center outlets  Direct air flow to the left or right, up or down. Turn the knob to open or close the vent. Front side outlets ...
  • Page 224 5-1. Using the air conditioning system and defogger ■ Using automatic mode Fan speed is adjusted automatically according to the temperature setting and the ambient conditions. Therefore, the fan may stop for a while until warm or cool air is ready to flow immediately after is pressed.
  • Page 225 There may be a problem in the air conditioning system if the indicator light goes off again. Turn the air conditioning system off and have it inspected by any authorized Toyota retailer or Toyota authorized repairer, or any reliable repairer.
  • Page 226 5-1. Using the air conditioning system and defogger WARNING ■ To prevent the windshield from fogging up ● Do not use during cool air operation in extremely humid weather. The difference between the temperature of the outside air and that of the windshield can cause the outer surface of the windshield to fog up, block- ing your vision.

  • Page 227: Interior Lights List

    5-2. Using the interior lights Interior lights list Interior light (P. 228) Engine switch light Personal lights (P. 228) YARIS_GRMN_OM_Europe_OM52J40E...

  • Page 228: Interior Light

    5-2. Using the interior lights Interior light Door position Personal lights ■ Illuminated entry system The lights automatically turn on/off according to engine switch mode, the presence of the electronic key, whether the doors are locked/unlocked, and whether the doors are opened/closed. ■...

  • Page 229: Using The Storage Features

    5-3. Using the storage features List of storage features Glove box (P. 230) Bottle holders (P. 232) Cup holders (P. 231) Auxiliary box (P. 232) WARNING ● Do not leave glasses, lighters or spray cans in the storage spaces, as this may result in the following when cabin temperature becomes high: •...

  • Page 230: Glove Box

    5-3. Using the storage features Glove box Pull up the lever to open the glove box. ■ Using the glove box vent Air from the air conditioning system can be distributed into the glove box by open- ing and closing the vent. Open Close The air is conditioned the same as the air...

  • Page 231: Cup Holders

    5-3. Using the storage features Cup holders Front ■ Rear ■ WARNING Do not place anything other than cups or aluminum cans in the cup holders. Other items may be thrown out of the holders in the event of an accident or sudden braking, causing injury.

  • Page 232: Bottle Holders

    5-3. Using the storage features Bottle holders ■ When using the bottle holders ● When storing a bottle, close the cap. ● The bottle may not be stored depending on its size or shape. WARNING Do not place anything other than a bottle in the bottle holders. Other items may be thrown out of the holders in the event of an accident or sudden braking and cause injury.

  • Page 233: Luggage Compartment Features

    5-3. Using the storage features Luggage compartment features Luggage cover The luggage cover can be removed by the following procedure: Unhook the cords and return the luggage cover to horizontal position. Lift the luggage cover and pull it toward you to remove it. YARIS_GRMN_OM_Europe_OM52J40E...
  • Page 234 5-3. Using the storage features Deck board Deck board height adjustment ■ Upper position Lower position The lower position can be used when the deck board is placed on the luggage floor cover. Removing the deck board ■ Lift the deck board and pull it toward you to remove it.
  • Page 235 5-3. Using the storage features Auxiliary box Lift the deck board and the lug- gage floor cover. YARIS_GRMN_OM_Europe_OM52J40E...

  • Page 236: 5-4. Using The Other Interior Features

    5-4. Using the other interior features Other interior features Sun visors To set the visor in the forward position, flip it down. To set the visor in the side posi- tion, flip down, unhook, and swing it to the side. Vanity mirrors Open the cover.
  • Page 237 5-4. Using the other interior features ■ Vanity lights Turns the lights on Turns the lights off ■ Vanity lights can be used when The engine switch is ACCESSORY or IGNITION ON mode. NOTICE ■ To prevent battery discharge Do not leave the vanity lights on for extended periods while the engine is not running.

  • Page 238: Power Outlet

    5-4. Using the other interior features Power outlet Please use as a power supply for electronic goods that use less than 12 VDC/10 A (power consumption of 120 W). Open the lid. The power outlets can be used when the engine switch is in ACCESSORY or IGNITION ON mode.

  • Page 239: Assist Grips

    5-4. Using the other interior features Assist grips An assist grip installed on the ceil- ing can be used to support your body while sitting on the seat. WARNING Do not use the assist grip when getting in or out of the vehicle or rising from your seat.
  • Page 240 5-4. Using the other interior features YARIS_GRMN_OM_Europe_OM52J40E...

  • Page 241: Maintenance And Care

    Maintenance and care 6-1. Maintenance and care 6-3. Do-it-yourself maintenance Cleaning and protecting Do-it-yourself service the vehicle exterior ..242 precautions ......253 Cleaning and protecting Hood ........256 the vehicle interior ...247 Positioning a floor jack..258 6-2. Maintenance Engine compartment..260 Maintenance Tires........271 requirements....250 Replacing the tire....274 Tire inflation pressure ..282...

  • Page 242: Maintenance And Care Cleaning And Protecting

    6-1. Maintenance and care Cleaning and protecting the vehicle exterior Perform the following to protect the vehicle and maintain it in prime condition: ● Working from top to bottom, liberally apply water to the vehicle body, wheel wells and underside of the vehicle to remove any dirt and dust.
  • Page 243 6-1. Maintenance and care ■ Aluminum wheels ● Remove any dirt immediately by using a neutral detergent. Do not use hard brushes or abrasive cleaners. Do not use strong or harsh chemical clean- ers. Use the same mild detergent and wax as used on the paint. ●...
  • Page 244 6-1. Maintenance and care WARNING ■ When cleaning the windshield Set the wiper switch to off. If the wiper switch is in “AUTO”, the wiper may operate unexpectedly in the follow- ing situations, and may result in hands being caught or other serious injuries and cause damage to the wiper blades.
  • Page 245 6-1. Maintenance and care NOTICE ■ To prevent paint deterioration and corrosion on the body and compo- nents (aluminum wheels, etc.) ● Wash the vehicle immediately in the following cases: • After driving near the sea coast • After driving on salted roads •...
  • Page 246 6-1. Maintenance and care NOTICE ■ Antenna installation and removal precautions (pole type) ● Before driving, ensure that the antenna is installed. ● When the antenna is removed, such as before entering an automatic car wash, make sure to store it in a suitable place so as not to lose it. Also, before driving, make sure to reinstall the antenna in its original position.

  • Page 247: Cleaning And Protecting The Vehicle Interior

    6-1. Maintenance and care Cleaning and protecting the vehicle interior The following procedures will help protect your vehicle’s interior and keep it in top condition: Protecting the vehicle interior ● Remove dirt and dust using a vacuum cleaner. Wipe dirty surfaces with a cloth dampened with lukewarm water.
  • Page 248 6-1. Maintenance and care ■ Caring for leather areas Toyota recommends cleaning the interior of the vehicle at least twice a year to maintain the quality of the vehicle’s interior. ■ Shampooing the carpets There are several commercial foaming-type cleaners available. Use a sponge or brush to apply the foam.
  • Page 249 6-1. Maintenance and care NOTICE ■ Cleaning detergents ● Do not use the following types of detergent, as they may discolor the vehi- cle interior or cause streaks or damage to painted surfaces: • Non-seat portions: Organic substances such as benzene or gasoline, alkaline or acidic solutions, dye, and bleach •...

  • Page 250: Maintenance Maintenance Requirements

    Scheduled maintenance Scheduled maintenance should be performed at specified intervals according to the maintenance schedule. For full details of your maintenance schedule, refer to the “Toyota Service Booklet” or “Toyota Warranty Booklet”. Do-it-yourself maintenance What about do-it-yourself maintenance? Many of the maintenance items are easy to do yourself if you have a little mechanical ability and a few basic automotive tools.
  • Page 251 There can also be advantages in utilizing authorized Toyota retailers or repairers for non-warranty repairs and services, as members of the Toyota network will be able to expertly assist you with any difficulties you may encounter.
  • Page 252 6-2. Maintenance WARNING ■ If your vehicle is not properly maintained Improper maintenance could result in serious damage to the vehicle and possible death or serious injury. ■ Handling of the battery Battery posts, terminals and related accessories contain lead and lead com- pounds which are known to cause brain damage.

  • Page 253: Precautions

    • Grease Battery condition • Conventional wrench (for terminal clamp bolts) (P. 267) • Distilled water • “Toyota Super Long Life Coolant” or a similar high quality ethylene glycol-based non-silicate, non- Engine/inter- amine, non-nitrite and non-borate coolant with long- cooler coolant life hybrid organic acid technology level (P.
  • Page 254 6-3. Do-it-yourself maintenance WARNING The engine compartment contains many mechanisms and fluids that may move suddenly, become hot, or become electrically energized. To avoid death or serious injury, observe the following precautions. ■ When working on the engine compartment ● Keep hands, clothing and tools away from the moving fan and engine drive belt.
  • Page 255 6-3. Do-it-yourself maintenance NOTICE ■ If you remove the air cleaner filter Driving with the air cleaner filter removed may cause excessive engine wear due to dirt in the air. ■ If the fluid level is low or high It is normal for the brake fluid level to go down slightly as the brake pads wear or when the fluid level in the accumulator is high.

  • Page 256: Hood

    6-3. Do-it-yourself maintenance Hood Release the lock from the inside of the vehicle to open the hood. Pull the hood lock release lever. The hood will pop up slightly. Pull up the auxiliary catch lever and lift the hood. Hold the hood open by inserting the supporting rod into the slot.
  • Page 257 6-3. Do-it-yourself maintenance WARNING ■ Pre-driving check Check that the hood is fully closed and locked. If the hood is not locked properly, it may open while the vehicle is in motion and cause an accident, which may result in death or serious injury. ■...

  • Page 258: Positioning A Floor Jack

    6-3. Do-it-yourself maintenance Positioning a floor jack When using a floor jack, follow the instructions in the manual provided with the jack and perform the operation safely. When raising your vehicle with a floor jack, position the jack cor- rectly. Improper placement may damage your vehicle or cause injury.
  • Page 259 6-3. Do-it-yourself maintenance NOTICE ■ When raising your vehicle Do not jack the vehicle at the suspen- sion. The suspension may be damaged. Suspension Front YARIS_GRMN_OM_Europe_OM52J40E...

  • Page 260: Engine Compartment

    6-3. Do-it-yourself maintenance Engine compartment Fuse boxes (P. 292) Battery (P. 267) Engine oil filler cap Engine coolant reservoir (P. 262) (P. 264) Engine oil level dipstick Electric cooling fan (P. 261) Condenser (P. 266) Intercooler coolant reservoir Radiator (P. 266) (P.
  • Page 261 6-3. Do-it-yourself maintenance Engine oil With the engine at operating temperature and turned off, check the oil level on the dipstick. Checking the engine oil ■ Park the vehicle on level ground. After warming up the engine and turning it off, wait more than 5 minutes for the oil to drain back into the bottom of the engine.
  • Page 262 6-3. Do-it-yourself maintenance Adding engine oil ■ If the oil level is below or near the low level mark, add engine oil of the same type as that already in the engine. Make sure to check the oil type and prepare the items needed before adding oil.
  • Page 263 Call any authorized Toyota retailer or Toyota authorized repairer, or any reliable repairer service station or auto parts store for information concern- ing recycling or disposal.
  • Page 264 6-3. Do-it-yourself maintenance Coolant Engine coolant reservoir ■ The coolant level is satisfactory if it is between the “FULL” and “LOW” lines on the reservoir when the engine is cold. Reservoir cap “FULL” line “LOW” line If the level is on or below the “LOW”...
  • Page 265 “Toyota Super Long Life Coolant” is a mixture of 50% coolant and 50% deion- ized water. (Minimum temperature: -35C [-31F]) For more details about coolant, contact any authorized Toyota retailer or Toyota authorized repairer, or any reliable repairer.
  • Page 266 Check the radiator, condenser and intercooler and clear away any for- eign objects. If any of the above parts is extremely dirty or you are not sure of their condition, have your vehicle inspected by any authorized Toyota retailer or Toyota authorized repairer, or any reliable repairer. WARNING ■...
  • Page 267 6-3. Do-it-yourself maintenance Battery Check the battery as follows. Caution symbols ■ The meanings of each caution symbol on the top of the battery are as follows: No smoking, no naked Battery acid flames, no sparks Note operating instruc- Shield eyes tions Keep away from children Explosive gas...
  • Page 268 Take extra care when connecting the battery if the engine switch mode prior to discharge is unknown. If the engine will not start even after multiple attempts, contact any authorized Toyota retailer or Toyota authorized repairer, or any reliable repairer. WARNING ■...
  • Page 269 6-3. Do-it-yourself maintenance WARNING ■ Where to safely charge the battery Always charge the battery in an open area. Do not charge the battery in a garage or closed room where there is insufficient ventilation. ■ How to recharge the battery Only perform a slow charge (5 A or less).
  • Page 270 6-3. Do-it-yourself maintenance Washer fluid If none of the washers do not work, add washer fluid to “FULL” line. WARNING ■ When adding washer fluid Do not add washer fluid when the engine is hot or running as washer fluid contains alcohol and may catch fire if spilled on the engine, etc.

  • Page 271: Tires

    6-3. Do-it-yourself maintenance Tires Replace or rotate tires in accordance with maintenance sched- ules and treadwear. Checking tires Check if the treadwear indicators are showing on the tires. Also check the tires for uneven wear, such as excessive wear on one side of the tread.
  • Page 272 A tire goes flat repeatedly or cannot be properly repaired due to the size or location of a cut or other damage If you are not sure, consult with any authorized Toyota retailer or Toyota authorized repairer, or any reliable repairer.
  • Page 273 Do not mix tires of different makes, models or tread patterns. Also, do not mix tires of remarkably different treadwear. ● Do not use tire sizes other than those recommended by Toyota. ● Do not mix differently constructed tires (radial, bias-belted or bias-ply tires).

  • Page 274: Replacing The Tire

    Improper placement may damage your vehicle or cause injury. If necessary tire replacement seems difficult to perform, contact any authorized Toyota retailer or Toyota authorized repairer, or any reliable repairer. Before jacking up the vehicle ● Stop the vehicle in a safe place on a hard, flat surface ●...
  • Page 275 Towing eyelet Wheel nut wrench : A jack, jack handle and wheel nut wrench are not included with the vehicle. A jack and tools can be purchased at any authorized Toyota retailer or Toyota authorized repairer, or any reliable repairer. YARIS_GRMN_OM_Europe_OM52J40E...
  • Page 276 6-3. Do-it-yourself maintenance WARNING ■ Using the tire jack Observe the following precautions. Improper use of the tire jack may cause the vehicle to suddenly fall off the jack, leading to death or serious injury. ● Only use the tire jack that comes with this vehicle for replacing a tire. Do not use it on other vehicles, and do not use other tire jacks for replac- ing tires on this vehicle.
  • Page 277 6-3. Do-it-yourself maintenance Taking out the jack Move the front left seat to the front most position. Remove the cover. Take out the jack. For tightening For loosening YARIS_GRMN_OM_Europe_OM52J40E...
  • Page 278 6-3. Do-it-yourself maintenance Replacing a flat tire Chock the tires. Tire position Wheel chock positions Left-hand side Behind the rear right-hand side tire Front Right-hand side Behind the rear left-hand side tire Left-hand side In front of the front right-hand side tire Rear Right-hand side In front of the front left-hand side tire...
  • Page 279 • If there are any cracks or deformations in the bolt screws, nut threads or bolt holes of the wheel, have the vehicle inspected by any authorized Toyota retailer or Toyota authorized repairer, or any reliable repairer. • When installing the wheel nuts, be sure to install them with the tapered ends facing inward.
  • Page 280 6-3. Do-it-yourself maintenance Installing the spare tire Remove any dirt or foreign mat- ter from the wheel contact sur- face. If foreign matter is on the wheel contact surface, the wheel nuts may loosen while the vehicle is in motion, causing the tire to come off.
  • Page 281 6-3. Do-it-yourself maintenance Firmly tighten each wheel nut two or three times in the order shown in the illustration. Tightening torque: 103 N·m (10.5 kgf·m, 76 ft·lbf) Stow the tire, jack and all tools. WARNING ■ After using the tools and jack Before driving, make sure all the tools and jack are securely in place in their storage location to reduce the possibility of personal injury during a collision or sudden braking.

  • Page 282: Tire Inflation Pressure

    ● Reduced safety ● Damage to the drive train If a tire needs frequent inflating, have it checked by any authorized Toyota retailer or Toyota authorized repairer, or any reliable repairer. ■ Instructions for checking tire inflation pressure When checking tire inflation pressure, observe the following: ●...
  • Page 283 6-3. Do-it-yourself maintenance WARNING ■ Proper inflation is critical to save tire performance Keep your tires properly inflated. If the tires are not properly inflated, the following conditions may occur which could lead to an accident resulting in death or serious injury: ●...

  • Page 284: Wheels

    ● Used wheels ● Bent wheels that have been straightened Aluminum wheel precautions ● Use only Toyota wheel nuts and wrenches designed for use with your aluminum wheels. ● When rotating, repairing or changing your tires, check that the wheel nuts are still tight after driving 1600 km (1000 miles).
  • Page 285 6-3. Do-it-yourself maintenance WARNING ■ When replacing wheels ● Do not use wheels that are a different size from those recommended in the Owner’s Manual, as this may result in a loss of handling control. ● Never use an inner tube in a leaking wheel which is designed for a tube- less tire.

  • Page 286: Air Conditioning Filter

    6-3. Do-it-yourself maintenance Air conditioning filter The air conditioning filter must be changed regularly to maintain air conditioning efficiency. Removal method Turn the engine switch off. Open the glove box and slide off the damper. Push in each side of the glove box to disconnect the upper claws.
  • Page 287 Inspect and replace the air conditioning filter according to the maintenance schedule. In dusty areas or areas with heavy traffic flow, early replacement may be required. (For scheduled maintenance information, please refer to the “Toyota Service Booklet” or “Toyota Warranty Booklet”.) ■ If air flow from the vents decreases dramatically The filter may be clogged.
  • Page 288 6-3. Do-it-yourself maintenance NOTICE ■ When using the air conditioning system Make sure that a filter is always installed. Using the air conditioning system without a filter may cause damage to the system. ■ When removing the glove box Always follow the specified procedure to remove the glove box (P. 286). If the glove box is removed without following the specified procedure, the hinge of the glove box may become damaged.

  • Page 289: Electronic Key Battery

    6-3. Do-it-yourself maintenance Electronic key battery Replace the battery with a new one if it is depleted. You will need the following items: ● Flathead screwdriver ● Lithium battery CR2032 Replacing the battery Take out the mechanical key. Remove the cover. To prevent damage to the key, cover the tip of the screwdriver with a tape.
  • Page 290 ■ Use a CR2032 lithium battery ● Batteries can be purchased at any authorized Toyota retailer or Toyota authorized repairer, or any reliable repairer local electrical appliance shops or camera stores. ● Replace only with the same or equivalent type recommended by the manu- facturer.
  • Page 291 6-3. Do-it-yourself maintenance NOTICE ■ For normal operation after replacing the battery Observe the following precautions to prevent accidents: ● Always work with dry hands. Moisture may cause the battery to rust. ● Do not touch or move any other component inside the remote control. ●...

  • Page 292: Checking And Replacing Fuses

    6-3. Do-it-yourself maintenance Checking and replacing fuses If any of the electrical components do not operate, a fuse may have blown. If this happens, check and replace the fuses as nec- essary. Turn the engine switch off. Open the fuse box cover. Engine compartment: type A and B fuse boxes ...
  • Page 293 6-3. Do-it-yourself maintenance Engine compartment: type C fuse box (left-hand drive vehicles)  Pull the rubber strip on the edge to unhook it from the cover, and then push the tabs in and lift the cover off. Remove the battery terminal cover and then the fuse box cover.
  • Page 294 6-3. Do-it-yourself maintenance Instrument panel (left-hand drive vehicles)  Remove the lid. Instrument panel (right-hand drive vehicles)  Remove the cover. Do not pull off the cover using excessive force as it is attached to the footwell light. Remove the lid. Remove the fuse with the pull- out tool.
  • Page 295 Replace the blown fuse with a new fuse of an appropriate amperage rat- ing. The amperage rating can be found on the fuse box lid. Type C: Contact any authorized Toyota retailer or Toyota authorized repairer, or any reliable repairer. Type A Type B ...
  • Page 296 (P. 298) ● If the replaced fuse blows again, have the vehicle inspected by any autho- rized Toyota retailer or Toyota authorized repairer, or any reliable repairer. ■ If there is an overload in a circuit The fuses are designed to blow, protecting the wiring harness from damage.
  • Page 297 Do not modify the fuses or fuse boxes. NOTICE ■ Before replacing fuses Have the cause of electrical overload determined and repaired by any authorized Toyota retailer or Toyota authorized repairer, or any reliable repairer as soon as possible. YARIS_GRMN_OM_Europe_OM52J40E...

  • Page 298: Light Bulbs

    As there is a danger that components may be damaged, we recommend that replacement is carried out by any authorized Toyota retailer or Toyota authorized repairer, or any reliable repairer. For more information about replacing other light bulbs, contact any authorized Toyota retailer or Toyota authorized repairer, or any reliable repairer.
  • Page 299 6-3. Do-it-yourself maintenance Rear ■ License plate lights Rear turn signal lights Back-up light YARIS_GRMN_OM_Europe_OM52J40E...
  • Page 300 6-3. Do-it-yourself maintenance Replacing light bulbs Halogen headlights ■ Turn the bulb base counter- clockwise. Pull the bulb out while press- ing the lock release of the connector. Replace the light bulb, plug connector, then install the bulb base. Align the 3 tabs on the light bulb with the mounting and insert.
  • Page 301 6-3. Do-it-yourself maintenance Front fog lights ■ Turn the steering wheel in the opposite direction of the light to be replaced. Turn the steering wheel to a point that allows your hand to easily fit between the tire and fender liner. Remove the screw.
  • Page 302 6-3. Do-it-yourself maintenance Unplug the connector while pressing the lock release. Turn the bulb base counter- clockwise. Set the new light bulb. Align the 3 tabs on the light bulb with the mounting, and insert. Turn and secure the bulb. YARIS_GRMN_OM_Europe_OM52J40E...
  • Page 303 6-3. Do-it-yourself maintenance Install the connector. Shake the bulb base gently to check that it is not loose, turn the front fog light, on once and visually confirm that no light is leaking through the mounting. Reinstall the fender liner. Attach the end of the fender liner to the inside of the front bumper.
  • Page 304 6-3. Do-it-yourself maintenance Front turn signal lights ■ Turn the bulb base counter- clockwise. Remove the light bulb When installing, reverse the steps listed. YARIS_GRMN_OM_Europe_OM52J40E...
  • Page 305 6-3. Do-it-yourself maintenance Side turn signal lights ■ Depress the mirror. Remove the mirror. To prevent damaging the vehi- cle, wrap the screwdriver with a tape. Remove the bulb base. Remove the light bulb. YARIS_GRMN_OM_Europe_OM52J40E...
  • Page 306 6-3. Do-it-yourself maintenance After installing the new bulb, secure the bulb base to the mirror body. Align the tabs, and secure the mirror by pushing in each diagonally-opposite pair of tabs in order. Make sure to insert the tabs in order as shown in the illustra- tion, and push them in until a click is heard.
  • Page 307 6-3. Do-it-yourself maintenance Rear turn signal lights ■ Open the back door and remove the cover. To prevent damaging the vehi- cle, wrap the screwdriver with a tape. Turn the bulb base counter- clockwise. Remove the light bulb. YARIS_GRMN_OM_Europe_OM52J40E...
  • Page 308 6-3. Do-it-yourself maintenance Install the new bulb. Turn and secure the bulb base. Install the cover. Align the cover claws with the notches. Press the cover until it is fixed. YARIS_GRMN_OM_Europe_OM52J40E...
  • Page 309 6-3. Do-it-yourself maintenance License plate light ■ Remove the lens. lnsert a small flathead- screwdriver, etc. into either the right or left hole of the lens Lens Push the screwdriver side- ways in the direction of the arrow shown in the illustra- tion, disengage the hook, and then remove the lens.
  • Page 310 6-3. Do-it-yourself maintenance Install the lens. Fit the lens into either the right or left fitting portion. Push the lens into place. After installation, confirm that the lens is properly installed by gently pulling it. Fitting portion YARIS_GRMN_OM_Europe_OM52J40E...
  • Page 311 6-3. Do-it-yourself maintenance Back-up light ■ Open the back door and remove the cover. Press down on the notch on the cover and remove the cover. It is recommended for safe- guarding to wrap the tip of the screwdriver with a cloth, etc., in order to prevent scratches to the vehicle.
  • Page 312 6-3. Do-it-yourself maintenance Install the bulb base. Install the back door cover. Align the cover 2 tabs on the cover and install. YARIS_GRMN_OM_Europe_OM52J40E...
  • Page 313 LEDs. If any of the LEDs burn out, take your vehicle to any authorized Toyota retailer or Toyota authorized repairer, or any reliable repairer to have the light replaced.
  • Page 314 6-3. Do-it-yourself maintenance WARNING ■ Replacing light bulbs ● Turn off the lights. Do not attempt to replace the bulb immediately after turning off the lights. The bulbs become very hot and may cause burns. ● Do not touch the glass portion of the light bulb with bare hands. When it is unavoidable to hold the glass portion, use and hold with a clean dry cloth to avoid getting moisture and oils on the bulb.

  • Page 315: When Trouble Arises

    When trouble arises 7-1. Essential information If the engine will not start ...354 Emergency flashers...316 If the electronic key does not operate properly ..356 If your vehicle has to be stopped in If the vehicle battery is an emergency....317 discharged .......359 If your vehicle overheats..363 7-2.

  • Page 316: Emergency Flashers

    7-1. Essential information Emergency flashers The emergency flashers are used to warn other drivers when the vehicle has to be stopped in the road due to a breakdown, etc. Press the switch. All the turn signal lights will flash. To turn them off, press the switch once again.

  • Page 317: If Your Vehicle Has To Be Stopped In An Emergency

    7-1. Essential information If your vehicle has to be stopped in an emergency Only in an emergency, such as if it becomes impossible to stop the vehicle in the normal way, stop the vehicle using the follow- ing procedure: Steadily step on the brake pedal with both feet and firmly depress it. Do not pump the brake pedal repeatedly as this will increase the effort required to slow the vehicle.
  • Page 318 7-1. Essential information WARNING ■ If the engine has to be turned off while driving Power assist for the brakes and steering wheel will be lost, making the brake pedal harder to depress and the steering wheel heavier to turn. Decelerate as much as possible before turning off the engine.

  • Page 319: Steps To Take In An Emergency If Your Vehicle Needs To Be Towed

    Situations when it is necessary to contact dealers before towing The following may indicate a problem with your transmission. Contact any authorized Toyota retailer or Toyota authorized repairer, or any reliable repairer or commercial towing service before towing. ● The engine is running but the vehicle does not move.
  • Page 320 7-2. Steps to take in an emergency Towing with a wheel-lift type truck From the front From the rear   Release the parking brake. Use a towing dolly under the front wheels. Using a flatbed truck If your vehicle is transported by a flatbed truck, it should be tied down at the locations shown in the illustration.
  • Page 321 7-2. Steps to take in an emergency Emergency towing If a tow truck is not available in an emergency, your vehicle may be temporarily towed using cables or chains secured to the emergency towing eyelets. This should only be attempted on hard surfaced roads for at most 80 km (50 miles) at under 30 km/h (18 mph).
  • Page 322 If the engine is not running, the power assist for the brakes and steering will not function, making steering and braking more difficult. ■ Wheel nut wrench Wheel nut wrench can be purchased at any authorized Toyota retailer or Toyota authorized repairer, or any reliable repairer. YARIS_GRMN_OM_Europe_OM52J40E...
  • Page 323 7-2. Steps to take in an emergency WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When towing the vehicle Be sure to transport the vehicle with the front wheels raised or with all four wheels raised off the ground.
  • Page 324 7-2. Steps to take in an emergency NOTICE ■ To prevent damage to the vehicle when towing using a wheel-lift type truck ● Do not tow the vehicle from the rear when the engine switch is off. The steering lock mechanism is not strong enough to hold the front wheels straight.

  • Page 325: If You Think Something Is Wrong

    If you think something is wrong If you notice any of the following symptoms, your vehicle proba- bly needs adjustment or repair. Contact any authorized Toyota retailer or Toyota authorized repairer, or any reliable repairer as soon as possible. Visible symptoms ●...

  • Page 326: Fuel Pump Shut Off System

    7-2. Steps to take in an emergency Fuel pump shut off system To minimize the risk of fuel leakage when the engine stalls or when an airbag inflates upon collision, the fuel pump shut off system stops the supply of fuel to the engine. Follow the procedure below to restart the engine after the system is activated.

  • Page 327: If A Warning Light Turns On Or A Warning Buzzer Sounds

    However, if this continues to occur, have the vehicle inspected by any authorized Toyota retailer or Toyota authorized repairer, or any reliable repairer. Warning light and warning buzzer list...
  • Page 328 Malfunction indicator lamp Indicates a malfunction in: • The electronic engine control system; • The electronic throttle control system;  Have the vehicle inspected by any authorized Toyota retailer or Toyota authorized repairer, or any reliable repairer immediately. SRS warning light Indicates a malfunction in: •...
  • Page 329 7-2. Steps to take in an emergency Warning light Warning light/Details/Actions Driver’s and front passenger’s seat belt reminder light (warning buzzer) Warns the driver and front passenger to fasten their seat belts.  Fasten the seat belt. If the passenger’s seat is occupied, the front passen- ger’s seat belt also needs to be fastened to make the warning light (warning buzzer) turn off.
  • Page 330 If the fuel tank is empty, refuel the vehicle imme- diately. The malfunction indicator lamp will go off after several trips. If the malfunction indicator lamp does not go off, contact any authorized Toyota retailer or Toyota authorized repairer, or any reliable repairer as soon as possible. ■...
  • Page 331 If both the ABS and the brake system warning lights remain on Stop your vehicle in a safe place immediately and contact any authorized Toyota retailer or Toyota authorized repairer, or any reliable repairer. The vehicle will become extremely unstable during braking, and the ABS system may fail, which could cause an accident resulting in death or serious injury.

  • Page 332: If A Warning Message Is Displayed

    Multi-information display If any of the warning messages are shown again after the following actions have been performed, contact any authorized Toyota retailer or Toyota authorized repairer, or any reliable repairer. : The master warning light may not come on or flash when a warning mes- sage is displayed.
  • Page 333 The warning lights and warning buzzers operate as follows depending on the content of the message. If a message indicates the need for inspection by a dealer, have the vehicle inspected by any authorized Toyota retailer or Toyota authorized repairer, or any reliable repairer immediately. System...
  • Page 334 If “Visit your dealer” is shown ■ The system or part shown on the multi-information display is mal- functioning. Have the vehicle inspected by any authorized Toyota retailer or Toyota authorized repairer, or any reliable repairer. ■ If a message about an operation is shown ●...
  • Page 335 If “Engine oil pressure low.” is shown ■ Indicates that the engine oil pressure is too low. Immediately stop the vehicle in a safe place and contact any authorized Toyota retailer or Toyota authorized repairer, or any reliable repairer. Warning buzzer ■...

  • Page 336: If You Have A Flat Tire

    (P. 338) After temporarily repairing the tire with the kit, have the tire repaired or replaced by any authorized Toyota retailer or Toyota authorized repairer, or any reliable repairer. Repairs conducted using the emergency tire puncture repair kit are only a tempo- rary measure.
  • Page 337 7-2. Steps to take in an emergency Before repairing the tire ● Stop the vehicle in a safe place on a hard, flat surface. ● Set the parking brake. ● Shift the shift lever to N. ● Stop the engine. ●...
  • Page 338 A flat tire that cannot be repaired with the emergency tire puncture repair In the following cases, the tire cannot be repaired with the emergency tire puncture repair kit. Contact any authorized Toyota retailer or Toyota autho- rized repairer, or any reliable repairer.
  • Page 339 : Use of the jack, jack handle and wheel nut wrench. (P. 274) A jack, jack handle and wheel nut wrench can be purchased at any authorized Toyota retailer or Toyota authorized repairer, or any reliable repairer. YARIS_GRMN_OM_Europe_OM52J40E...
  • Page 340 7-2. Steps to take in an emergency Emergency tire puncture repair kit components Nozzle Pressure release button Hose Power plug Compressor switch Stickers Air pressure gauge YARIS_GRMN_OM_Europe_OM52J40E...
  • Page 341 7-2. Steps to take in an emergency Taking out the emergency tire puncture repair kit Lift the deck board and pull it toward you to remove it. (P. 234) Remove luggage floor cover. Take out the emergency tire puncture repair kit. YARIS_GRMN_OM_Europe_OM52J40E...
  • Page 342 If it is impossible to attach the label, make sure to tell any authorized Toyota retailer or Toyota authorized repairer, or any reliable repairer when you have them repair and replace the tire that sealant is injected.
  • Page 343 7-2. Steps to take in an emergency Connect the nozzle to the valve. Screw the end of the nozzle clock- wise as far as possible. The bottle should hang vertically without contacting the ground. If the bottle does not hang vertically, move the vehicle so that the tire valve is located properly.
  • Page 344 7-2. Steps to take in an emergency Make sure that the compressor switch is off. Remove the power plug from the compressor. Connect the power plug to the power outlet socket or cigarette lighter socket. (P. 238) Check the specified tire inflation pressure.
  • Page 345 Turn the compressor switch off and contact any authorized Toyota retailer or Toyota authorized repairer, or any reliable repairer. • If the tire inflation pressure exceeds the specified air pressure, let out some air to adjust the tire inflation pressure.
  • Page 346 7-2. Steps to take in an emergency Turn the compressor off Disconnect the nozzle from the valve on the tire and then pull out the power plug from the power outlet socket. Some sealant may leak when the nozzle is removed. Press the button to release pressure from the bottle.
  • Page 347 If the tire inflation pressure is under 130 kPa (1.3 kgf/cm or bar, 19 psi): The puncture cannot be repaired. Contact authorized Toyota retailer or Toyota authorized repairer, reliable repairer. If the tire inflation pressure is 130 kPa (1.3 kgf/cm or bar, 19 psi) or higher, but less than the specified air pressure: Proceed to If the tire inflation pressure is the specified air pressure (P.
  • Page 348 Store the compressor in the luggage compartment. Taking precautions to avoid sudden braking, sudden acceleration and sharp turns, drive carefully at under 80 km/h (50 mph) to the nearest authorized Toyota retailer or Toyota authorized repairer, or any reliable repairer for tire repair or replacement. ■...
  • Page 349 The sealant stored in the emergency tire puncture repair kit can be used only once to temporarily repair a single tire. If the sealant has been used and needs to be replaced, purchase a new bottle at any authorized Toyota retailer or Toyota authorized repairer, or any reliable repairer. The compres- sor is reusable.
  • Page 350 7-2. Steps to take in an emergency WARNING ■ Do not drive the vehicle with a flat tire Do not continue driving with a flat tire. Driving even a short distance with a flat tire can damage the tire and the wheel beyond repair.
  • Page 351 7-2. Steps to take in an emergency WARNING ■ When fixing the flat tire ● Stop your vehicle in a safe and flat area. ● Do not touch the wheels or the area around the brakes immediately after the vehicle has been driven. After the vehicle has been driven, the wheels and the area around the brakes may be extremely hot.
  • Page 352 7-2. Steps to take in an emergency WARNING ■ Driving to spread the liquid sealant evenly Observe the following precautions to reduce the risk of accidents. Failing to do so may result in a loss of vehicle control and cause death or serious injury.
  • Page 353 7-2. Steps to take in an emergency NOTICE ■ When performing an emergency repair ● A tire should only be repaired with the emergency tire puncture repair kit if the damage is caused by a sharp object such as nail or screw passing through the tire tread.

  • Page 354: If The Engine Will Not Start

    7-2. Steps to take in an emergency If the engine will not start If the engine will not start even though correct starting proce- dures are being followed (P. 187), consider each of the follow- ing points: The engine will not start even though the starter motor operates normally.
  • Page 355 ● The battery may be discharged. (P. 359) ● There may be a malfunction in the steering lock system. Contact any authorized Toyota retailer or Toyota authorized repairer, or any reliable repairer if the problem cannot be repaired, or if repair procedures are unknown.

  • Page 356: If The Electronic Key Does Not Operate Properly

    7-2. Steps to take in an emergency If the electronic key does not operate properly If communication between the electronic key and vehicle is interrupted (P. 128) or the electronic key cannot be used because the battery is depleted, the smart entry & start system and wireless remote control cannot be used.
  • Page 357 Firmly depress the clutch pedal and check that and mes- sages are shown on the multi-information display. Press the engine switch. In the event that the engine still cannot be started, contact any autho- rized Toyota retailer or Toyota authorized repairer, or any reliable repairer. YARIS_GRMN_OM_Europe_OM52J40E...
  • Page 358 7-2. Steps to take in an emergency ■ Stopping the engine Shift the shift lever to N and press the engine switch as you normally do when stopping the engine. ■ Replacing the key battery As the above procedure is a temporary measure, it is recommended that the electronic key battery be replaced immediately when the battery is depleted.

  • Page 359: If The Vehicle Battery Is Discharged

    The following procedures may be used to start the engine if the vehicle’s battery is discharged. You can also call any authorized Toyota retailer or Toyota autho- rized repairer, or any reliable repairer. If you have a set of jumper (or booster) cables and a second vehicle with a 12-volt battery, you can jump start your vehicle by following the steps below.
  • Page 360 Once the vehicle’s engine has started, remove the jumper cables in the exact reverse order from which they were connected. Once the engine starts, have the vehicle inspected at any authorized Toyota retailer or Toyota authorized repairer, or any reliable repairer as soon as possible. ■...
  • Page 361 • If the 20 hour rate capacity is low, even if the time period where the vehicle is not used is a short time, the battery may discharge and the engine may not be able to start. ● For details, consult any authorized Toyota retailer or Toyota authorized repairer, or any reliable repairer WARNING ■...
  • Page 362 7-2. Steps to take in an emergency WARNING ■ Battery precautions The battery contains poisonous and corrosive acidic electrolyte, while related parts contain lead and lead compounds. Observe the following pre- cautions when handling the battery: ● When working with the battery, always wear safety glasses and take care not to allow any battery fluids (acid) to come into contact with skin, clothing or the vehicle body.

  • Page 363: If Your Vehicle Overheats

    7-2. Steps to take in an emergency If your vehicle overheats The following may indicate that your vehicle is overheating: ● The needle of the engine coolant temperature gauge (P. 96) enters the red zone or a loss of engine power is experienced. (For example, the vehicles speed does not increase.) ●...
  • Page 364 Radiator Cooling fan If a large amount of coolant leaks, immediately contact any authorized Toyota retailer or Toyota authorized repairer, or any reliable repairer. The coolant level is satisfactory if it is between the “FULL” and “LOW” lines on the reservoir.
  • Page 365 Stop the engine immediately and contact any authorized Toyota retailer or Toyota authorized repairer, or any reliable repairer. If the fan is operating: Have the vehicle inspected at the nearest authorized Toyota retailer or Toyota authorized repairer, or any reliable repairer. YARIS_GRMN_OM_Europe_OM52J40E...
  • Page 366 7-2. Steps to take in an emergency WARNING ■ To prevent an accident or injury when inspecting under the hood of your vehicle Observe the following precautions. Failure to do so may result in serious injury such as burns. ● If steam is seen coming from under the hood, do not open the hood until the steam has subsided.

  • Page 367: If The Vehicle Becomes Stuck

    7-2. Steps to take in an emergency If the vehicle becomes stuck Carry out the following procedures if the tires spin or the vehicle becomes stuck in mud, dirt or snow: Stop the engine. Set the parking brake and shift the shift lever to N. Remove the mud, snow or sand from around the front wheels.
  • Page 368 7-2. Steps to take in an emergency WARNING ■ When attempting to free a stuck vehicle If you choose to push the vehicle back and forth to free it, make sure the surrounding area is clear to avoid striking other vehicles, objects or people. The vehicle may also lunge forward or lunge back suddenly as it becomes free.

  • Page 369: Vehicle Specifications

    Vehicle specifications 8-1. Specifications Maintenance data (fuel, oil level, etc.)...370 Fuel information ....378 8-2. Customization Customizable features ..380 YARIS_GRMN_OM_Europe_OM52J40E...

  • Page 370: Specifications Maintenance Data

    8-1. Specifications Maintenance data (fuel, oil level, etc.) Dimensions and weights Overall length 3945 mm (155.3 in.) Overall width 1695 mm (66.7 in.) Overall height 1490 mm (58.7 in.) Wheelbase 2510 mm (98.8 in.) Front 1470 mm (57.9 in.) Tread Rear 1455 mm (57.3 in.) Gross vehicle...
  • Page 371 The vehicle identification number (VIN) is the legal identifier for your vehicle. This is the primary identification number for your Toyota. It is used in registering the ownership of your vehicle. This number is stamped under the front right seat.
  • Page 372 8-1. Specifications Engine Model 2ZR-FE Type 4-cylinder in line, 4-cycle, gasoline 80.5  88.3 mm (3.17  3.48 in.) Bore and stroke Displacement 1798 cm (109.7 cu.in.) Valve clearance Automatic adjustment (engine cold) 12.0 — 13.0 mm (0.47 — 0.51 in.) Generator Supercharger Water pump...
  • Page 373 8-1. Specifications Fuel Fuel type Unleaded gasoline only Research Octane 97 or higher Number Fuel tank capacity 42 L (11.1 gal., 9.2 Imp.gal.) (Reference) Lubrication system Oil capacity (Drain and refill — reference ■ With filter 4.9 L (5.2 qt., 4.3 Imp.qt.) Without filter 4.6 L (4.9 qt., 4.0 Imp.qt.) : The engine oil capacity is a reference quantity to be used when changing...
  • Page 374 5.4 L (5.7 qt., 4.8 Imp.qt.) Intercooler 1.7 L (1.8 qt., 1.5 Imp.qt.) Use either of the following: • “Toyota Super Long Life Coolant” • A similar high-quality ethylene glycol-based Coolant type non-silicate, non-amine, non-nitrite, and non- borate coolant with long-life hybrid organic acid technology Do not use plain water alone.
  • Page 375 Toyota recommends to use “TOYOTA Genuine Manual Transmission Gear Oil LV GL-4 75W” to achieve optimal performance. • Your Toyota vehicle is filled with “TOYOTA Genuine Manual Transmission Gear Oil LV GL-4 75W” at the factory. Use Toyota approved “TOYOTA Genuine Manual Transmission Gear Oil LV GL-4 75W”...
  • Page 376 8-1. Specifications Brakes Left-hand drive vehicles  80 mm (3.15 in.) MIN. Pedal clearance Right-hand drive vehicles  75 mm (2.95 in.) MIN. Pedal free play 1 — 6 mm (0.04 — 0.24 in.) Parking brake lever 4 — 7 clicks travel Fluid type SAE J1704 or FMVSS No.
  • Page 377 8-1. Specifications Light bulbs Light Bulbs Type Halogen headlights Front fog lights Front turn signal lights Exterior Side turn signal lights Rear turn signal lights Back-up light License plate lights Vanity lights Interior Personal lights/interior light Luggage compartment light A: HIR2 halogen bulbs B: H16 halogen bulbs C: Wedge base bulbs (clear) D: Wedge base bulbs (amber)

  • Page 378: Fuel Information

    ■ If your engine knocks ● Consult any authorized Toyota retailer or Toyota authorized repairer, or any reliable repairer. ● You may occasionally notice light knocking for a short time while accelerat- ing or driving uphill. This is normal and there is no need for concern.
  • Page 379 Bioethanol fuel sold under names such as “E5”, “E10”, or any fuel contain- ing ethanol should not be used. The use of these fuels will damage the vehicle’s fuel system. In case of any doubt, ask any authorized Toyota retailer or Toyota authorized repairer, or any reliable repairer. ●...

  • Page 380: Customizable Features

    Some function settings are changed simultaneously with other func- tions being customized. Contact any authorized Toyota retailer or Toyota authorized repairer, or any reliable repairer for further details. Customizing vehicle features When customizing vehicle features, ensure that the vehicle is parked in a safe place with the shift lever in N and the parking brake set.
  • Page 381 (For further information on customizing settings using the Naviga- tion/Multimedia system, refer to the “Navigation and multimedia system Owner’s manual”.) Settings that can be changed by any authorized Toyota retailer or Toyota authorized repairer, or any reliable repairer Definition of symbols: O = Available, — = Not available Multi-information display (P.
  • Page 382 8-2. Customization Instrument cluster (P. 96) ■ Default Customized Function setting setting Sensor sensitivity for darken- ing the brightness of the instru- Standard -2 to 2 – – ment cluster depending on the outside brightness Sensor sensitivity for returning the brightness of the instrument cluster to the original level Standard -2 to 2...
  • Page 383 8-2. Customization Wireless remote control (P. 112, 116) ■ Default Customized Function setting setting Wireless remote control — — Operation signal — (Emergency flashers) Time elapsed before auto- 60 seconds matic door lock function is 30 seconds — — activated if door is not opened 120 seconds after being unlocked Open door warning buzzer...
  • Page 384 8-2. Customization Illumination (P. 227) ■ Default Customized Function setting setting 7.5 seconds Time elapsed before the inte- 15 seconds — rior lights turn off 30 seconds Operation when the doors are — — unlocked Operation after the engine — —...

  • Page 385: Index

    Index What to do if... (Troubleshooting) .....386 Alphabetical index ......389 Refer to “Navigation and multimedia system Owner’s manual” for information regarding the equipment listed below. • Navigation system • Hands-free system (for cellular phone) • Rear view monitor system • Audio system YARIS_GRMN_OM_Europe_OM52J40E...
  • Page 386 You lose your keys ● If you lose your keys, new genuine keys can be made by any authorized Toyota retailer or Toyota authorized repairer, or any reliable repairer. (P. 113) ● If you lose your electronic keys, the risk of vehicle theft increases signifi- cantly.
  • Page 387 What to do if... (Troubleshooting) If you think something is wrong The engine does not start ● Did you press the engine switch while firmly depressing the clutch pedal? (P. 187) ● Is the electronic key anywhere detectable inside the vehicle? (P. 126) ●...
  • Page 388 What to do if... (Troubleshooting) A warning buzzer sounds during driving ● The seat belt reminder light is flashing Is the driver wearing the seat belts? (P. 329) ● The brake system warning light is on Is the parking brake released? (P. 327) Depending on the situation, other types of warning buzzer may also sound.

  • Page 389: Alphabetical Index

    Alphabetical index Alphabetical index Side airbag operating conditions ......44 A/C..........220 Side airbag precautions ..39 Air conditioning filter....286 Side and curtain shield Automatic air conditioning airbags operating system ........ 220 conditions ......44 ABS (Anti-lock Brake Side and curtain shield System) ........
  • Page 390 Alphabetical index Back door ......... 120 Care........242, 247 Luggage compartment Aluminum wheels....243 light ........121 Exterior ......... 242 Back-up lights Interior........247 Replacing light bulb....311 Seat belts......248 Wattage......... 377 Chains........217 Battery ........267 Child restraint system....53 If the vehicle battery is Fixed with a seat belt ....
  • Page 391 Alphabetical index Cleaning......242, 247 Aluminum wheels....243 Daytime running light Exterior........242 system........199 Interior........247 Replacing light bulbs..... 313 Seat belts ......248 Defogger Clock ........96, 104 Outside rear view mirrors..222 Clutch........375 Rear window ......222 Condenser ........
  • Page 392 Alphabetical index Doors Back door......120 Electric Power Steering Door glasses ......171 (EPS)........210 Door lock....... 116, 120 Function ........ 210 Open door warning Warning light......328 buzzer......119, 121 Electronic key ......112 Outside rear view mirrors..166 Battery-saving function ..
  • Page 393 Alphabetical index If your vehicle has to be Engine oil ......... 261 stopped in an emergency ... 317 Capacity........ 373 If your vehicle needs to be Checking....... 261 towed ........319 Preparing and checking If your vehicle overheats ..363 before winter.......
  • Page 394 Alphabetical index Fuel Capacity........ 373 Flat tire........336 Fuel gauge......96 Floor mats ........26 Fuel pump shut off system..326 Fluid Information......378 Brake........376 Refueling....... 207 Clutch........375 Type........373 Washer........270 Warning light......328 Fog lights........201 Fuel consumption Replacing light bulbs..
  • Page 395 Alphabetical index Hands-free system Identification ......371 (for cellular phone) Engine........371 Hazard lights Vehicle ........371 Switch ........316 Ignition switch Head restraints......159 (engine switch) ...... 187 Headlights ........ 196 Ignition switch light Follow me home system ..197 (engine switch light) .....
  • Page 396 Alphabetical index Jack Lever Positioning a floor jack ..258 Auxiliary catch lever....256 Jam protection function Hood lock release lever ..256 Power window....... 172 Parking brake lever....195 Shift lever......192 Turn signal lever ....194 Wiper lever....202, 205 Keyless entry License plate lights ....
  • Page 397 Alphabetical index Maintenance Navigation system Do-it-yourself maintenance ... 253 Maintenance data ....370 Maintenance requirements ... 250 Odometer........96 Malfunction indicator lamp ..328 Manual headlight leveling Engine oil ......373 dial .......... 198 Manual transmission oil ..375 Manual transmission ....192 Opener Oil..........
  • Page 398 Alphabetical index Parking brake ......195 Radiator ........266 Operation ......195 Rear fog light ......201 Parking brake engaged Replacing light bulbs..... 313 warning buzzer ....327 Switch ........201 Personal lights ......228 Rear passengers’ seat belt Switch ........228 reminder light ......
  • Page 399 Alphabetical index Sensor Automatic headlight Seat belt reminder light... 329 system ........ 199 Seat belts........30 Inside rear view mirror ..165 Child restraint system Rain-sensing wind shield installation......53 wipers ......... 203 Cleaning and maintaining Shift lever ......... 192 the seat belt ......
  • Page 400 Alphabetical index Steering wheel ......162 Power door lock switch ..118 Adjustment ......162 Power window switches..171 Audio switches Rear window defogger Meter control switches ..101 switch ......... 222 “TRIP” switch ....97, 98 Rear window wiper and Stop lights washer switch.....
  • Page 401 Alphabetical index Tires .......... 271 Chains........217 Warning buzzers Checking ....... 271 Brake system ......327 If you have a flat tire....336 Electric power steering ..328 Inflation pressure ....376 Open door..... 119, 121 Replacing ...... 274, 336 Parking brake......
  • Page 402 Alphabetical index Warning messages ....332 Washer......202, 205 Checking ....... 270 Preparing and checking before winter....... 216 Switch ......202, 205 Washing and waxing ....242 Weight........370 Wheels ........284 Replacing ......284 Size ........376 Window glasses....... 171 Window lock switch....
  • Page 403 Alphabetical index YARIS_GRMN_OM_Europe_OM52J40E...
  • Page 404 GAS STATION INFORMATION Auxiliary catch lever Fuel filler door P. 256 P. 208 Hood lock release Fuel filler door opener Tire inflation pressure lever P. 256 P. 208 P. 376 Fuel tank capacity 42 L (11.1 gal., 9.2 Imp.gal.) (Reference) Fuel type P.

Table of Contents
