- Page 1 YARIS LIFTBACK 2 0 1 6 QUICK REFERENCE GUIDE...
- Page 3 Pairing a Bluetooth Device ® Parking brake Power outlet Seat adjustments-Front Seat-Folding rear seat Seats-Head restraints Steering wheel switches Tilt steering wheel USB/AUX port Windows-Power Windshield wipers & washers * Visit your Toyota dealer for information on customizing this feature.
-
Page 4: Instrument Panel
OVERVIEW Instrument panel Steering wheel controls Steering wheel audio controls Cruise control Headlight, turn signal and front fog light controls Wiper and washer controls Emergency flasher switch “AIR BAG ON” and “AIR BAG OFF” indicator Rear window defogger switch Air Conditioning controls... - Page 5 USB port/AUX port 12V DC power outlet Ignition switch Tilt steering lock release lever Hood release Instrument panel light control Power outside rearview mirror control switches If equipped...
-
Page 6: Instrument Cluster
Brake system warning Driver seat belt reminder (alarm will sound if speed is over 12 mph) If indicator does not turn off within a few seconds of starting engine, there may be a malfunction. Have vehicle inspected by your Toyota dealer. - Page 7 Eco Driving indicator light Charging system warning Malfunction/Check Engine indicator Low engine oil pressure warning Open door warning Airbag SRS warning Low windshield washer fluid warning Electric power steering system warning Low fuel level warning Engine oil replacement reminder AIR BAG ON indicator AIR BAG OFF indicator VSC OFF indicator TRAC OFF indicator...
-
Page 8: Keyless Entry (If Equipped)
OVERVIEW Keyless entry (if equipped) Locking operation Type A Type B Push Unlocking operation Type A Type B Push ONCE: Driver door TWICE: All doors NOTE: I f a door is not opened within 60 seconds of unlocking, all doors will relock for safety. -
Page 9: Hood Release
Hood release Pull Pull up latch and raise hood Engage support rod Engine maintenance Engine oil filler cap Engine coolant reservoir Engine oil level dipstick Windshield washer and rear window washer fluid tank NOTE: Regularly scheduled maintenance, including oil changes, will help extend the life of your vehicle and maintain performance. -
Page 10: Features/Operations
FEATURES/OPERATIONS Automatic transmission (if equipped) Park* Reverse Neutral Drive Third gear Second gear First gear * The ignition switch must be “ON” and the brake pedal depressed to shift from Park. Downshifting increases power going uphill, or provides engine braking downhill. For best fuel economy during normal driving conditions, always drive with the shift lever in the “D”... - Page 11 Lights & turn signals Headlights Type A Type B Headlights Headlights Parking lights Parking lights Type C High beam flasher Low beam Headlights Parking lights DRL ON High beam Turn signals Right turn Lane change Lane change Left turn Front fog lights (if equipped) Type A Type B Turn...
-
Page 12: Cruise Control (If Equipped)
FEATURES/OPERATIONS Cruise control (if equipped) Turning system ON/OFF Functions Resume Increase speed Cancel Set/Decrease speed System ON/OFF The set speed may also be cancelled by depressing the brake pedal or the clutch pedal (Manual Transmission). Unless vehicle speed drops below 10 mph, the set speed may be resumed once vehicle exceeds 25 mph. -
Page 13: Seat-Folding Rear Seat
Seat-Folding rear seat Before folding (2) Push (2) Push (1) Store (3) Store (4) Store (5) Pull up (8) Pull up (7) Push (6) Fold down Fold (split seat) (3) Pull up (2) Lower (1) Push (4) Fold down... - Page 14 FEATURES/OPERATIONS Windshield wipers & washers Front Type A Type B Mist Single wipe Interval wipe Interval wipe Slow Slow Pull to wash and wipe Pull to wash and wipe Fast Fast Rear Type B Type A Wash and wipe Wash and wipe Wipe Wipe Wash...
-
Page 15: Air Conditioning/Heating
Air conditioning/heating With air conditioning ON/OFF button Without air conditioning ON/OFF button Airflow vent “ ” mode uses outside air to reduce window fogging Fan speed Temperature selector Air conditioning ON/OFF Rear window defogger ON/OFF Recirculate cabin air (outside air when OFF) -
Page 16: Multi-Information Display (Mid)
FEATURES/OPERATIONS Multi-Information Display (MID) Type A Type B Type C Push button to change information in the following succession (shown in box indicated above): (1) Odometer (2) Trip meters (3) Miles left on remaining fuel (RANGE/MI) (4) Average gas mileage (AVG/MPG) (5) Current gas mileage (MPG) (6) Average vehicle speed from engine start (AVG/MPH) Clock... -
Page 17: Light Control-Instrument Cluster
Light control-Instrument cluster Brightness control USB/AUX port (if equipped) USB port By connecting a USB-compatible portable audio device or USB memory to the USB port, you can listen to music from the portable audio device or USB memory through the vehicle’s speaker system. AUX port By inserting a mini plug into the AUX port, you can listen to music from a portable audio device through the vehicle’s speaker system while in AUX mode. -
Page 18: Pairing A Bluetooth
FEATURES/OPERATIONS Audio Yaris Entune™ Audio Eject CD Turn to tune radio stations manually Push to turn or select ON/OFF tracks SETUP Push to display Button audio screen Push to display Bluetooth ® Seek station/ hands-free CD track select system APPS button Pairing a Bluetooth Device ®... -
Page 19: Safety And Emergency Features
SAFETY AND EMERGENCY FEATURES Door locks-Power Unlock Lock Doors-Child safety locks Rear door (5-door models only) Moving the lever downward will allow the door to be opened only from the outside. Seat belts Take up slack Too high Keep as low on hips as possible NOTE: If a passenger’s seat belt is fully extended, then retracted even slightly, the Automatic locking retractor (ALR) will prevent it from being re-extended... -
Page 20: Tire Pressure Monitoring (Warning) System
” indicator will illuminate. Correctly adjusting tire inflation will turn off the light after a few minutes. If the light does not turn off, have the system checked by your Toyota dealer. Refer to the Owner’s Manual for more details. -
Page 21: Star Safety System
Traction Control helps maintain traction on loose gravel and wet, icy, or uneven surfaces by applying brake force to the spinning wheel(s). Toyota’s TRAC sensors are activated when one of the drive wheels starts to slip. TRAC limits engine output and applies the brakes to the spinning wheel. This transfers power to the wheels that still have traction to help keep you on track. -
Page 22: Floor Mat Installation
Floor mat installation There are two types of Toyota floor mats: carpeted and all-weather. Each vehicle has model-specific floor mats. Installation is easy. To keep your floor mat properly positioned, follow these steps: •... - Page 24 CUSTOMER EXPERIENCE CENTER 1-800-331-4331 Printed in U.S.A. 12/15 15-TCS-08593 00505QRG16YARLB...
