- Page 1 GAE SERIES Gasoline engine USER'S MANUAL www.daewoopowerproducts.com Manufactured under license of Daewoo International Corporation, Korea...
-
Page 2: Table Of Contents
INDEX 1. SAFETY INFORMATION .......................... 2 2. COMPONENT & CONTROL LOCATION ....................2 3. BEFORE OPERATING CHECK ......................2 4. OPERATION ............................. 3 5. MAINTENANCE............................6 6. TROUBLESHOOTING ........................... 13 7. SPECIFICATIONS........................... 15 8. WIRING DIAGRAM ..........................18 WARRANTY ............................... 19... -
Page 3: Safety Information
1. SAFETY INFORMATION 1. Understand the operation of all controls and learn how to stop the engine quickly in case of emergency. Make sure the operator receives adequate instruction before operating the equipment. 2. Do not allow children to operate the engine. Keep children and pets away from the area of operation. -
Page 4: Operation
you find, or have your servicing dealer correct it, before you operate the engine. Before beginning your preoperation checks, be sure the engine is level and the engine switch is in the OFF position. Always check the following items before you start the engine: Check the General Condition of the engine 1. - Page 5 To restart a warm engine, leave the choke lever in the OPEN position. Some engine applications use a remote-mounted choke control rather than the engine-mounted choke lever shown here. Refer to the instructions provided by the equipment manufacturer. OPERATION 3.Move the throttle lever away from the MIN. position, about 1/3 of the way toward the MAX. position. Some engine applications use a remote-mounted throttle control rather than the engine-mounted throttle lever shown here.
- Page 6 Turn the key to the START position, and hold it there until the engine starts. If the engine fails to start within 5 seconds, release the key, and wait at least 10 seconds before operating the starter again. NOTICE Using the electric starter for more than 5 seconds at a time will overheat the starter motor and can damage it.
-
Page 7: Maintenance
5. MAINTENANCE Remember that an authorized servicing dealer knows your engine best and is fully equipped to maintain and repair it. To ensure the best quality and reliability, use only new genuine parts or their equipments for repair and replacement. MAINTENANCE SCHEDULE REGULAR SERVICE PERIOD (3) Every 6... - Page 8 NOTICE Fuel can damage paint and some types of plastic. Be careful not to spill fuel when filling your fuel tank. Damage caused by spilled fuel is not covered under the Distributor's Limited Warranty. Never use stale or contaminated gasoline or oil/gasoline mixture. Avoid getting dirt or water in the fuel tank.
- Page 9 SAE 10W-30 is recommended for general use. Other viscosities shown in the chart may be used when the average temperature in your area is within the indicated range. Oil Level Check Check the engine oil level with the engine stopped and in a level position. 1.
- Page 10 WASHER OIL LEVEL DRAIN PLUG OIL FILLER CAP/DIPSTICK Recommended Oil Use the same oil that is recommended for the engine. Oil Level Check Check the reduction case oil level with the engine stopped and in a level position. Reduction Case With Centrifugal Clutch 1.
- Page 11 FILLER CAP/DIPSTICK UPPER LIMIT LOWER LIMIT DRAIN PLUG AIR CLEANER A dirty air cleaner will restrict air flow to the carburetor, reducing engine performance. If you operate the engine in very dusty areas, clean the air filter more often than specified in the MAINTENANCE SCHEDULE.
- Page 12 5. Clean the air filter elements if they are to be reused. Paper air filter element: Tap the filter element several times on a hard surface to remove dirt, or blow compressed air [not exceeding 207 kPa (2.1 kgf/cm 2, 30 psi)] through the filter element from the inside.
- Page 13 SEDIMENT CUP Cleaning 1. Move the fuel valve to the OFF position, then remove the fuel sediment cup and 0-ring. 2. Wash the sediment cup and 0-ring in nonflammable solvent, and dry them thoroughly. 3. Place the 0-ring in the fuel valve, and install the sediment cup. Tighten the sediment cup securely. 4.
-
Page 14: Troubleshooting
the threads in the cylinder head. 9. Attach the spark plug cap to the spark plug. 6. THROUBLESHOOTING WARNING 1. To avoid severe burns or fire hazards, let the engine cool before transporting it or storing it indoors. 2. When transporting the engine, turn the fuel valve to the OFF position and keep the engine level to prevent fuel spillage. - Page 15 4.Remove the spark plug and pour about a tablespoon of clean engine oil into the cylinder. Crank the engine several revolutions to distribute the oil, then reinstall the spark plug. 5.Pull the starter rope slowly until resistance is felt. Continue pulling until the notch on the starter pulley aligns with the hole on the recoil starter (see illustration below).
-
Page 16: Specifications
e. If there is no spark, replace the plug. If OK, try to start the engine according to the instructions. 7. If the engine still does not start, take the engine to the dealer. Engine will not start, using electric starter: 1. - Page 17 Oil Capacity: 0.6 L Min fuel consumption: 395 g/kW. h Starting system: Recoil start/Electric start Ignition system: transistor magneto Engine model: OHV 25º tilt, single cylinder, 4-stroke,forced air cooled Packing dimension: 405 x 365 x 380 mm N.W. / G.W.: 14/15 kg Model: GAE168FB Max power output: 6.5 hp (3.6 kW) / 3600 rpm Bore stroke: 68 x 54 mm...
- Page 18 Engine model: OHV 25º tilt, single cylinder, 4-stroke, forced air cooled Packing dimension: 480 x 435 x 505 mm N.W. / G.W.: 25/27 kg Model: GAE177F Max power output: 9 hp (5.8 kW) / 3600 rpm Bore stroke: 77 x 58 mm Displacement: 270 cc Compression ratio: 8.2:1 Max torque: 16 N.m /2500 rpm...
-
Page 19: Wiring Diagram
Model: GAE190F Max power output: 15 hp (8.0 kW) / 3600 rpm Bore stroke: 90 x 66 mm Displacement: 418 cc Compression ratio: 8.5:1 Max torque: 23.5 N.m / 2500 rpm Fuel tank capacity: 6.5 L Oil Capacity: 1.1 L Min fuel consumption: 374 g/kW. -
Page 20: Warranty
WARRANTY CARD Product model Date of sale Company Serial number Client's signature Username The product is in good conditions and fully complete. Read and agree the terms of the warranty. GUARANTEE The warranty period starts from the date of sale of the products and covers 1 year for all power products. During the warranty period, free failures caused due to the use of poor-quality materials in the production and manufacturer workmanship admitted fault are removed. - Page 21 Manufactured under license of Daewoo International Corporation, Korea...
