Using your gas cooktop
Details how to use the cooktop of your Seven-Function cooker.
1. Auxiliary burner
2. Semi-rapid burner
3. Triple-ring wok burner
Gas burners
The knob controls the flow of gas through the safety valve.
0
•
= closed valve (OFF)
•
https://producthelp.fisherpaykel.com/au/Cook/Freestanding_Cookers/Dual_Fuel/OR60SDBGFX2/User_Guide_OR60SDBGFX...
Fig. 44 Cooktop layout
Updated: Wed, 12 Apr 2023 09:11:19 GMT
Powered by
1
Advertisement
Related Manuals for Fisher & Paykel OR60SDBGFX2
Summary of Contents for Fisher & Paykel OR60SDBGFX2
- Page 1 Fig. 44 Cooktop layout 1. Auxiliary burner 2. Semi-rapid burner 3. Triple-ring wok burner Gas burners The knob controls the flow of gas through the safety valve. • = closed valve (OFF) • https://producthelp.fisherpaykel.com/au/Cook/Freestanding_Cookers/Dual_Fuel/OR60SDBGFX2/User_Guide_OR60SDBGFX… Updated: Wed, 12 Apr 2023 09:11:19 GMT Powered by...
-
Page 2: Before Using Your Cooktop
(OFF). Fig. 45 Burner control knob Before using your cooktop Before using your new cooktop, please: • Read this user guide, taking special note of the ‘Safety and warnings’ section. https://producthelp.fisherpaykel.com/au/Cook/Freestanding_Cookers/Dual_Fuel/OR60SDBGFX2/User_Guide_OR60SDBGFX… Updated: Wed, 12 Apr 2023 09:11:19 GMT Powered by... -
Page 3: Flame Failure Safety Feature
• If the flames are accidentally extinguished, turn off the burner and do not try to light it again for at least one minute (to allow the gas to disperse). https://producthelp.fisherpaykel.com/au/Cook/Freestanding_Cookers/Dual_Fuel/OR60SDBGFX2/User_Guide_OR60SDBGFX… Updated: Wed, 12 Apr 2023 09:11:19 GMT Powered by... - Page 4 Diameters of pans which may be used on the cooktop Burners Minimum Maximum Auxiliary 12 cm (6 cm with small pan support) 14 cm https://producthelp.fisherpaykel.com/au/Cook/Freestanding_Cookers/Dual_Fuel/OR60SDBGFX2/User_Guide_OR60SDBGFX… Updated: Wed, 12 Apr 2023 09:11:19 GMT Powered by...
- Page 5 This pan support is to be placed on top of the auxiliary burner when using small diameter pans, in order to prevent them from tipping over. Fig. 48a Small pan support Wok stand The wok stand fits over the triple-ring wok burner trivet. https://producthelp.fisherpaykel.com/au/Cook/Freestanding_Cookers/Dual_Fuel/OR60SDBGFX2/User_Guide_OR60SDBGFX… Updated: Wed, 12 Apr 2023 09:11:19 GMT Powered by...
- Page 6 • The wok stand MUST BE PLACED ONLY over the trivet for the triple-ring wok burner. • The cooktop becomes very hot during operation. Keep children well out of reach. https://producthelp.fisherpaykel.com/au/Cook/Freestanding_Cookers/Dual_Fuel/OR60SDBGFX2/User_Guide_OR60SDBGFX… Updated: Wed, 12 Apr 2023 09:11:19 GMT Powered by...
