Table of Contents
Exterior Views
D6502, D6503, D6543 & L50W
Tools
Disassembly
SIM Tray
Back Panel
Adhesive Battery
Sheet FPC Battery & Battery
Antenna WLAN
Main Camera
Sheet CU 17 X 4
Front Assy & Main PBA
Replacement
SIM Tray
Back Panel & Adhesive Panel Back
Adhesive Battery
Sheet FPC Battery
Battery
Antenna WLAN
Main Camera
Sheet CU 17 X 4
Display Frame
Adhesive MIC con
Cable RF Coax
Camera Chat
Cap SD
Cap USB
Core Unit Label
Cushion Relay FPC
Earspeaker (Top Speaker) & Adhesive Earspeaker
FPC Audio Jack & Adhesive Audio Jack
Fpc Cg
FPC Relay & Adhesive CU 25 X 6 - 3 Pcs & Sheet CU 46 X 5 & Sheet CU 18 X 5
Holder 2Nd MIC
Holder Camera Chat
Holder Loudspeaker & Adhesive Loudspeaker Lid & Adh Speaker
Back & Adh VIB Conn & Adh with Mesh 14 X 5
PBA Antenna
Plate Speaker
Ring Audio Jack
Sheet Battery Adhesive Top
Sheet LCD 18 X 7
Sheet LCD 7 X 7
Sheet Thermal Conductive
Shield Camera
Spacer 10 X 4
Tray Core Unit Label
Water Indicator I
Water Indicator II
Vibrator & Adhesive VIB & Spacer 5 X 2.5
Cushion Cam
Sheet Guide Label
Sheet 5X10
Spacer 8X5
Sheet 1St MIC
Board Swap - Replacement
Board Swap - Change Label
Board Swap - Customize of Software
Reassembly
Front Assy & Main PBA
Sheet CU 17 X 4
Main Camera
Antenna WLAN
Battery & Sheet FPC Battery
Adhesive Battery
Back Panel with Adhesive Panel Back
SIM Tray
Revision History
Advertisement
Quick Links
Download this manual
Working Instructions
- mechanical -
TM
Xperia
Z2
D6502, D6503, D6543, L50w
1285-2552 Rev 8
© Sony Mobile Communications AB – Company Internal
Table of
Contents
Previous
Page
Next
Page
1
2
3
4
5
