Siemens Speedfax HMM3M800 Installation Instructions

s
Motor Circuit Protection, Frame MG
Protector Del Circuito Del Motor, Caja Base MG
Protecteur De Circuit De Moteur, de Base MG
Installation Instructions / Instructivo de Instalación
Hazardous Voltage. Hazardous Voltage.
Will cause death or serious injury. Will cause death or serious injury.
Turn off and lock out all power supplying this device before Turn off and lock out all power supplying this device before
working on this device. working on this device.
Replace all covers before power supplying this device is Replace all covers before power supplying this device is
turned on. turned on.
Use only with Siemens certified Components.
Utilizar únicamente con componentes certificados de Siemens.
A utiliser uniquement avec les composants certifiés Siemens.
NOTE - These instructions do not purport to cover all details or
variations in equipment, or to provide for every possible contingency
to be met in connection with installation, operation or maintenance.
Should further information be desired or should particular problems
arise, which are not covered sufficiently for the purchaser's purposes,
the matter should be referred to the local Siemens sales office. The
contents of this instruction manual shall not become part of or modify
any prior or existing agreement, commitment or relationship. The
sales contract contains the entire obligation of Siemens. The
warranty contained in the contract between the parties is the sole
warranty of Siemens. Any statements contained herein do not create
new warranties or modify the existing warranty.
Trademarks - Unless otherwise noted, all names identified by ® are
registered trademarks of Siemens AG or Siemens Industry, Inc. The
remaining trademarks in this publication may be trademarks whose
use by third parties for their own purposes could violate the rights of
the owner.
1
Trip
[ Interrumpir ]
8 0 6 9 5 5 A 0 2
Tensión peligrosa. Tensión peligrosa.
Puede causar la muerte o lesiones graves. Puede causar la muerte o lesiones graves.
Desenergice totalmente antes de instalar o darle servicio. Desenergice totalmente antes de instalar o darle servicio.
Reemplace todas las barreras y cubiertas antes de Reemplace todas las barreras y cubiertas antes de
energizar el interruptor. energizar el interruptor.
1 / 3
Euro Order No.
U.S. Cat. No.
Item: HMM3M800 3VL6180-2KK30-0AA0
Tension dangereuse. Tension dangereuse.
Danger de mort ou risque de blessures graves. Danger de mort ou risque de blessures graves.
Couper l'alimentation de l'appareil et barrer avant de Couper l'alimentation de l'appareil et barrer avant de
travailler. travailler.
Remplacez touts les couverts avant que Remplacez touts les couverts avant que
l'approvisionnement de pouvoir soit alimenté. l'approvisionnement de pouvoir soit alimenté.
7/16"
10mm
1/4 x 20 x 4.5
MSKM4
M6 x 1.0 x 110 mm
3VL96008SA40
HMM3M800
3VL6180-2KK30-0AA0
Ø = .28"
[ Ø = 7.1 ]
I.L. No. 806955A02
