Page 1: Table Of Contents
COLOR TELEVISION Contents AV-14FN14 Knowing your TV’s features ......2 AV-20NN14 Remote control buttons and basic functions . 3 TV buttons and functions ......5 AV-21CN14 Setting up your TV ........6 AV-21YN14 Basic setting for picture ......... 8 Advanced setting for picture ......9 Original features for picture ......
Page 2: Knowing Your Tv's Features
4 Do not allow objects or liquid into the cabinet openings. 5 In the event of a fault, unplug the unit and call a JVC service technician. Do not attempt to repair it yourself or remove the rear cover. 6 The surface of the TV screen is easily damaged. Be very careful with it when handling the TV.
Page 3: Remote Control Buttons And Basic Functions
Remote control buttons and basic functions RM-C1262 No. Press POWER Turn on or off the TV from standby mode. MENU/OK Display menu and confirm selected function. 5/∞/2/3 Select and adjust menu function. CHANNEL M Select the desired channel number. VOLUME M Adjust the volume level.
Page 4 Remote control buttons and basic functions How to operate menus and menu locations Operation Note Press the MENU/OK button 2. Display the MENU. To exit the MENU, press the DISPLAY/BACK button* 8 or choose EXIT menu. Display the top menu. Press 5/∞ buttons 3 to choose a menu title. Press ∞...
Page 5: Tv Buttons And Functions
TV buttons and functions The following illustrations are for AV-14FN14 and AV-21YN14 only, which are used for explanation purposes. Your TV may not look exactly like the illustration. Front of the TV 3 2 1 AV-14FN14 MENU VIDEO AUDIO IN (VIDEO-2)
Page 6: Setting Up Your Tv
The illustration shown is just a sample. It may not be same as your TV. 2 Connecting the compatible AC plug to the AC outlet. 4 Turn on the TV by pressing the main power button. JVC logo appears on the screen.
Page 7 MENU/OK button. To set undesired channels to be skipped, see page 12. • If the JVC logo does not appear, use AUTO PROGRAM function to make the initial settings. This function is located in the INSTALL menu. • If the JVC logo appears, although you had made the initial settings, press the TV/VIDEO...
Page 8: Basic Setting For Picture
Basic setting for picture To operate this function with a menu: COLOR SYSTEM ❇ MENU PICTURE PICTURE MODE You can select the appropriate color system when the picture is not clear or no color appears. To return the USER setting to the default, press the blue button when the PICTURE SETTING Press the COLOR SYSTEM button to select a menu appears.
Page 9: Advanced Setting For Picture
Advance setting for picture BLUE BACK You can set the TV to automatically change to a blue screen and mute the sound if the signal is weak or absent, or when there is no input from an antenna. Select the BLUE BACK in the INSTALL menu, then choose ON or OFF.
Page 10: Favorite Channel And Video Setting
Favorite channel and video setting To register the favorite channel To adjust the video setting (VIDEO SETTING) You can register and recall 4 favorite channels by using the color buttons (red, green, yellow, blue). You can adjust the picture settings for video inputs.
Page 11: Customized Setting
Customized setting AUTO SHUTOFF You can reduce the noise. You can set the TV to turn off automatically Select the VNR in the PICTURE FEATURES menu when no signal is received for about 15 minutes under PICTURE menu, then choose a setting of or longer after the end of a broadcast.
Page 12: Tv Channel Presetting
TV channel presetting To register the TV channels auto- matically You can register the TV channels into the TV’s channel list automatically. 1 Display the INSTALL menu. MENU INSTALL ❇ 2 Choose AUTO PROGRAM, then press the MENU/OK button. 3 Press the 5/∞ button to select AIR or CABLE, then press the MENU/OK button.
Page 13: Additional Preparation
Additional preparation The illustrations shown in this section are for AV-21YN14 only, which are used for explanation purposes. Your TV may not look exactly the same as the illustration. Before connecting Front of the TV • Read the manuals provided with the devices Camcorder or TV game for the proper connection.
Page 14: Specifications
Specifications TV RF systems Color systems TV mode: NTSC 3.58 MHz VIDEO mode: PAL, SECAM, NTSC 3.58 MHz, NTSC 4.43 MHz Receiving channels VHF low channel (VL), VHF high channel (VH), UHF channel (U) Receives cable channels in mid band, super band and hyper band. Power requirements AC 110 to 240 V, 50/60 Hz External input / output...
Page 15 MEMO...
