- Page 1 Air conditioner User manual AR**CSFC**** Thank you for purchasing this Samsung air conditioner. Before operating this unit, please read this user manual carefully and retain it for future reference.
-
Page 2: Table Of Contents
Contents Safety Information Safety Information At a Glance Indoor Unit Overview Display Remote Control Overview Replacing the remote control batteries Remote Control Operation Selecting an operation mode To set the temperature To adjust the fan speed To adjust the airflow direction Setting the Current time Smart Features Power Smart Features... - Page 3 Cleaning and Maintenance Schedule Cleaning Appendix Troubleshooting SmartThings app English...
-
Page 4: Safety Information
Safety Information Safety Information WARNING: Read This Manual Read and follow all safety information and instructions before installation, use, or maintenance of this appliance. Incorrect installation, use, or maintenance of this appliance can result in death, serious injury, or property damage. Keep these instructions with this appliance. This manual is subject to change. For the latest version, visit www.samsunghvac.com. - Page 5 FOR GENERAL California Proposition 65 Warning (US) WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
- Page 6 Safety Information Fix the outdoor unit firmly so that the electric part of the outdoor unit is not exposed. Failing to do so may result in electric shock, fire, explosion, or problems with the product. Do not install this appliance near a heater, or flammable material. Do not install this appliance in a humid, oily or dusty location, in a location exposed to direct sunlight and water (or rain).
- Page 7 FOR POWER SUPPLY WARNING When the circuit breaker is damaged, contact a qualified installer or HVAC service company. Do not pull or excessively bend the power line. Do not twist or tie the power line. Do not hook the power line over a metal object, place a heavy object on the power line, insert the power line between objects, or push the power line into the space behind the appliance.
- Page 8 Safety Information To reinstall the air conditioner, please contact a qualified installer or HVAC service company. Failing to do so may result in problems with the product, water leakage, electric shock, or fire. Delivery service for the product is not provided. If you reinstall the product in another location, additional construction expenses and an installation fee will be charged.
- Page 9 CAUTION Do not place objects or devices under the indoor unit. Water dripping from the indoor unit may result in fire or property damage. Check that the installation frame of the outdoor unit is not broken at least once a year. Failing to do so may result in injury, death or property damage.
- Page 10 Safety Information Do not touch the pipes connected with the product. This may result in burns or injury. Do not use this air conditioner to preserve precision equipment, food, animals, plants or cosmetics, or for any other unusual purposes. This may result in property damage. Avoid directly exposing humans, animals or plants to the airflow from the air conditioner for long periods of time.
-
Page 11: At A Glance
Indoor Unit Overview The appearance of the actual product may differ slightly from the image below. 01 Air intake 05 Airflow blade (left and right) 02 Air filter 06 Power button/Remote control receiver 03 WindFree panel 07 Room temperature sensor 04 Airflow blade (up and down) 08 Display English... -
Page 12: Display
Indoor Unit Overview Display 01 Temperature indicator (numeric) Filter reset indicator ( Electricity consumption indicator (numeric / For the multi system, usage time indicator) Auto clean indicator ( Defrost indicator ( 02 AI Energy indicator 03 AI Auto indicator 04 Timer indicator good'sleep indicator 05 Wi-Fi indicator NOTE... -
Page 13: Remote Control Overview
Remote Control Overview Most operating instructions in this manual require using the remote control. 01 Set temperature indicator 02 Timer option indicator 03 Operation mode indicator 04 Options indicator 05 Low battery indicator 06 Transmit indicator 07 Fan speed indicator 08 WindFree indicator 09 Vertical air swing indicator 10 Horizontal air swing indicator... -
Page 14: Remote Control Operation
Remote Control Operation Remote Control Operation You can use the air conditioner easily by selecting a mode and then by controlling the temperature, fan speed, and air direction. Selecting an operation mode To change the current mode between Auto, Cool, Dry, Fan, and Heat, press the (Mode) button. -
Page 15: To Set The Temperature To Adjust The Fan Speed To Adjust The Airflow Direction
To set the temperature To control the temperature in each mode, press the (Temperature) button: Mode Temperature control AI Auto/Auto/ Cool Heat No temperature control. To adjust the fan speed Select from the following fan speeds in each mode: Mode Available fan speeds AI Auto/Auto/ (Auto) -
Page 16: Setting The Current Time
Remote Control Operation Setting the Current time Before using the functions of the air-conditioner, set the current time. Select Clock. Set the time. NOTE You can set the time in hourly units from 1 hour to 12 hours according to AM, PM and in minute units from 0 to 59 minutes. Current time setting will be cancelled if you don't press the (SET) button within 10 seconds after setting the time. -
Page 17: Smart Features
Power Smart Features WindFree Cooling function Use the WindFree Cooling function to enjoy a mild breeze coming through fine holes in the WindFree panel instead of air coming directly through the airflow blades. In Cool/Dry/Fan mode NOTE To cancel this function, press the (WindFree) button again. -
Page 18: Ai Auto Mode Ai Energy Mode
Power Smart Features AI Auto mode Use AI Auto mode to automatically operate any of Cool, Dry, Heat, and WindFree Cooling modes depending on the learned user patterns gathered from an external server via Wi-Fi module. The favourite temperature and operation mode are also set based on the current temperatures (indoor/ outdoor) and the gathered user patterns. -
Page 19: Auto Mode Cool Mode
Auto mode Use Auto mode to perform the powerful cooling or heating function to automatically reach the desired temperature. When the difference between the room temperature and the set temperature decreases, the air conditioner controls the fan speed and airflow direction. Select Auto. -
Page 20: Dry Mode Fan Mode
Power Smart Features Dry mode Use Dry mode in rainy or humid weather to maximize moisture removal from the air. Select Dry. NOTE The proper set temperature range for dehumidifying operation is seems high, use a lower set temperature. You cannot use Dry mode for heating. Dry mode is designed to produce a cooling side-effect. -
Page 21: Heat Mode Automatic Defrost
Heat mode Use Heat mode to stay warm. Select Heat. NOTE While the air conditioner warms up, the fan may not operate for about 3 to 5 minutes at the beginning to prevent cold blasts. If the air conditioner heats insufficiently, use an additional heating appliance in combination with the air conditioner. -
Page 22: Variety Smart Features
Variety Smart Features Variety Smart Features Fast function Use the Fast function to quickly cool or heat your room. This function is the most powerful cooling and heating function provided by the air conditioner. You can select this function in Cool or Heat mode. In Cool or Heat mode NOTE You can change the airflow direction, but you cannot change the... -
Page 23: Eco Function
Eco function This function is not supported by Free Joint Multi systems. Use the Eco function to reduce electricity consumption while staying cool or warm. You can select this function in Cool or Heat mode. In Cool or Heat mode Select Eco. -
Page 24: Quiet Function Electricity Consumption Check
Variety Smart Features Quiet function Use the Quiet function to reduce the unit’s operating noise. You can select this function in Cool or Heat mode. In Cool or Heat mode Select Quiet. NOTE You can change the set temperature and the airflow direction, but you cannot change the fan speed. -
Page 25: Usage Time Check Beep Function
Usage time check This function is only supported by Free Joint Multi systems. Use the Usage time function to check the operation duration from the moment when the air conditioner is turned on to the moment when the Usage time function is selected. The usage time is displayed on the indoor unit display for a few seconds, and the set indoor temperature appears. -
Page 26: Auto Clean Function
Variety Smart Features Auto clean function Use the Auto clean function if the indoor unit produces odors. Activating Auto clean To activate Auto clean, press the (Options) button for at least 3 seconds. The indoor unit display shows: If the air conditioner is off, Auto clean starts immediately. If the air conditioner is running, Auto clean starts as soon as the air conditioner turns off. - Page 27 Canceling Auto clean To cancel Auto clean while it is running, follow the procedure below: Press and hold for 3 or more seconds. Select Clean. NOTE Canceling Auto clean does not deactivate it. Deactivating Auto clean To deactivate Auto clean, follow the procedure below while the air conditioner is in operation.
-
Page 28: Freeze Wash Function
Variety Smart Features Freeze Wash function This function is not supported by Free Joint Multi systems. Use the Freeze Wash function to wash away microorganisms or dust on the surface of the indoor heat exchanger by freezing and thawing operation. In operation stop condition, Select Wash. -
Page 29: Display Lighting Function Wi-Fi Function (Smartthings App)
Display lighting function Use the Display lighting function to turn on or off the lighting of the indoor unit display. Select Display. NOTE If you change the current mode or function when the Display lighting function is on, the display lighting turns on for 5 seconds and then turns off again. -
Page 30: Time Scheduling
Time scheduling Time scheduling Timed on/ Timed off function Use the Timed on/off function to turn the air conditioner on or off after a duration. Scheduling durations before the air conditioner turns on or off helps use the air conditioner economically. Check the current time on the remote controller before using this function. -
Page 31: Good'sleep Function
good'sleep function Use the good'sleep function to save energy while you are sleeping. You can select this function in Cool or Heat mode. In Cool or Heat mode (Select (Set the duration.) NOTE When you start the good'sleep function, the (Timer) indicator appears on the indoor unit display. -
Page 32: Cleaning And Maintenance
Schedule Schedule Task How often By whom Instruction Run the Auto clean "Auto clean function" on As needed Owner function. page 26. Run the Freeze Wash "Freeze Wash function" on Once every two weeks Owner function. page 28. "Cleaning the filter" on page Clean the filter. -
Page 33: Cleaning
Cleaning Cleaning the outside of the indoor unit 1 Turn off the air conditioner and wait until the fan stops. 2 Disconnect the power supply. 3 Use a soft brush or tepid damp cloth to clean the exterior. Soft brush Tepid damp cloth WARNING Do not clean the appliance by spraying water... - Page 34 Cleaning Cleaning the filter Clean the air filter every two weeks or when the (filter-cleaning reminder) appears on the indoor unit display. The time between cleanings may vary, depending on the usage and environmental conditions. Vacuum cleaner Soft brush 30 minutes Mild detergent 1 Slide the filter off of the unit.
- Page 35 Cleaning the WindFree panel Clean the WindFree panel at least once a month. 1 Pull the airflow blade open. 2 Hold and pull both sides of the WindFree panel until it comes free from the air conditioner. 3 Use a soft brush or vacuum cleaner to remove any dust. WindFree 5 Align the projections of the WindFree panel with the grooves at the top, middle, and bottom of the front panel.
-
Page 36: Appendix
Troubleshooting Troubleshooting If the air conditioner is not operating normally, refer to the troubleshooting guide below. Problem Solution Make sure the unit is receiving power. Check the circuit breaker. If it is flipped off, flip it on again and The air conditioner stops restart the unit. - Page 37 Problem Solution Replace the batteries in the remote control. Make sure the remote control can send an unobstructed signal to The remote control does not the unit. work. Keep bright lights away from the unit. Light from fluorescent bulbs or neon signs may interrupt the signal from the remote control.
-
Page 38: Smartthings App
3 Tap Log In. 2 Tap Settings Wi-Fi on your smartphone. 4 If you have no Samsung account, tap Add account to create your Samsung account. 3 Tap the Wi-Fi switch to activate it, and then select the 2.4 GHz Wi-Fi access point to connect 5 Log in to your Samsung account. - Page 39 4 seconds. To notify that registration of the selected air The software included in this product contains conditioner to your Samsung account is in progress, open source software. You may obtain the complete (Transmit) indicator blinks for several...
