Location Code - ASCOM T942C System Installation

System Installation
Ascom Paging System
For several reasons an address register should be kept for each installation, with the name,
address, and location of each unit.
Address Register
Address (hex)
Figure 10. Example of an address register.
When using sequential transmission, the sequence number is set by sections 5-8 of the
address switch. The central transmitter always transmits in sequence 0 (address 00) and
the transmitters that are meant to transmit simultaneously should also have hex 0 as the
first digit in the address. Next sequence uses hex 1 as the first address digit and so on.
Each sequence can have up to 16 transmitters. Sequential transmission is used to avoid
interference between the transmitters but cannot be used in speech systems.
Address Register
Address (hex)
Figure 11. Example of an address register in an installation with sequential
9.1

Location Code

Setting the location code in a locator is done with the same type of dip switches as for
setting the address in a fixed unit. Two switches with a total of 16 sections are divided into
four hexadecimal digits. To set the location code, refer to the Installation Guide for the
relevant locator (LF or IR type).
10 October 2013 / Ver. D
Unit
0 0 T942C
0 1 T940PX
0 2 T840IU
0 3 T966CI
0 4 U952T
Unit
0 0 T942C
0 1 T942PX
0 2 T840IU
0 3 T966CI
0 4 U952T
1 0 U952T
2 0 U952T
transmission.
Location
Attic, head office
Exchange room, head office
Exchange room, head office
Reception, head office
Beneath the roof, storeroom
Location
Attic, head office
Exchange room, head office
Exchange room, head office
Reception, head office
Beneath the roof, storeroom
Cellar, head office
Culvert, head office
TD 90227GB
17
