Page 1 DIGITAL VIDEO HYBRID RECORDER DNW-A100/A100P DNW-A50/A50P DNW-A45/A45P ANALOG COMPOSITE DECODER BOARD BKDW-505/506 SDTI INPUT KIT BKNW-103 ANALOG COMPONENT INPUT BOARD BKNW-104 AES/EBU I/F KIT BKNW-105 MAINTENANCE MANUAL Part 1 1st Edition (Revised 5)
Page 2 ! WARNING This manual is intended for qualified service personnel only. To reduce the risk of electric shock, fire or injury, do not perform any servicing other than that contained in the operating instructions unless you are qualified to do so. Refer all servicing to qualified service personnel.
Page 3 Attention-when the product is installed in Rack: 1. Prevention against overloading of branch circuit When this product is installed in a rack and is supplied power from an outlet on the rack, please make sure that the rack does not overload the supply circuit.
Page 5: Table Of Contents
http://getMANUAL.com Table of Contents Manual Structure Purpose of this manual ....................6 Contents ........................6 Related manuals ......................7 Caution for Handling the Unit with Built-in HDD (for Part 1) ......... 8 1. Installation 1-1. Installation Procedure.................. 1-1 1-2. Supplied Accessories .................. 1-1 1-3.
Page 6 1-18. Installation of BKNW-104 ................ 1-40 1-18-1. Procedure .................. 1-40 1-18-2. Adjustment after Installing ............1-41 1-19. Installation of BKNW-105 ................ 1-55 1-19-1. Procedure .................. 1-55 1-19-2. Check after Installing ............... 1-58 2. Service Overview 2-1. Notes on Power Supply Block ..............2-1 2-1-1.
Page 7 4. Maintenance Mode 4-1. Overview of Maintenance Mode ..............4-1 4-2. TAPE Maintenance Mode (M0)..............4-6 4-2-1. Overviews .................. 4-6 4-2-2. SERVO CHECK Mode (C0) ........... 4-14 4-2-3. RF CHECK Mode (C1) ............4-31 4-2-4. AUDIO/VIDEO CHECK Mode (C2) ........4-35 4-2-5.
Page 8 6. Replacement of Plug-in Boards 6-1. Service Overview for Plug-in Board Replacement ........6-1 6-1-1. Notes on Plug-in Board Replacement ........6-1 6-1-2. Service Action before/after Plug-in Board Replacement ... 6-2 6-1-3. Plug-in Board Pulling out/Insertion ........... 6-3 6-1-4. Equipment List ................6-4 6-1-5.
Page 9 Appendix A Outline of Format A-1. Outline ......................A-1 A-2. Recording Format..................A-1 A-3. Head Configuration ..................A-5 A-4. Signal Processing ..................A-6 A-4-1. Features of Signal Processing ........... A-6 A-4-2. Outline of Signal Processing ............. A-6 Appendix B Setting Check Sheet Appendix C Block Diagrams INDEX ........................
Page 10: Manual Structure
Manual Structure Purpose of this manual This manual is the maintenance manual part1 of digital video hybrid recorder DNW series. DNW series includes the following models. DNW-A100/A50/A45 DNW-A100P/A50P/A45P This manual is intended for use by trained system and service engineers, and provides the information that is required to install, maintenance information, and the information for service such as replacement of plug-in boards.
Page 11: Related Manuals
These manuals describe the information that premises the parts level service (adjustments, board layouts, schematic diagrams, detailed parts list, etc.) for this unit and optional boards. If these manuals are required, please contact your local Sony Sales Office/Service Center. • Protocol Manual of Remote (9-pin) Connector (available on request) This manual explains the protocol for controlling the VTR via the RS-422A (9-pin serial remote).
Page 12: Caution For Handling The Unit With Built-In Hdd (For Part 1)
Caution for Handling the Unit with Built-in HDD (for Part 1) This unit has two built-in hard disk drives (HDDs). Pay careful attention to the following and perform operations with care when installing, servicing, and maintaining this unit. Never give any mechanical shock and vibration. This may cause an HDD trouble or destroy the data in HDD.
Page 13: Installation
Section 1 Installation 1-1. Installation Procedure 1-2. Supplied Accessories AC power cord set ............. 1 This unit has build-in hard disk drives (HDDs). Pay careful Plug holder ................. 1 attention when installing the unit. SCSI terminal connector ............ 1 Screws for rack mounting (PSW 4 x 16) ......4 Be careful not to give a shock and mechanical vibration to it.
Page 14: Operating Conditions
If the unit destined for Europe is used in the area except AC 100 to 240 V ± 10% Power voltage: the United Kingdom, please contact your local Sony Sales Power frequency: 50 Hz or 60 Hz Office/Service Center.
Page 15: Installation Space
http://getMANUAL.com 1-5. Installation Space 1-5. Installation Space When the unit is mounted in the rack, leave a space on the top and bottom of this unit by 1U. When installing, the installation space must be secured in Moreover, an air flow that is effective in cooling the unit is consideration of the ventilation and service operation.
Page 16: Rack Mounting
1-6. Rack Mounting 1-6. Rack Mounting . Hexagon socket head cap screws ..8 . Flat washers ........8 . Screws (RK5 x 14) ......2 Explains how to mount this unit into a 19-inch standard . Ornamental washers ......2 rack.
Page 17 1-6. Rack Mounting . Attachment of inner rails . Attachment of rack angles (handles) 4. Pull out the inner rails from the two intermediate rails. 8. Remove the four screws from both sides (left and 5. While pressing the stopper of the inner rail in the right) of the unit.
Page 18 1-6. Rack Mounting . Temporary attachment of rail brackets . Attachment of outer rails 10. After sliding the outer rail and the intermediate rail as 12. As shown in the figure, loosely attach the outer rails shown in the figure, loosely attach the rail bracket to on both sides (left and right) to the 2U position from the outer rail with a plate nut (large) and two screws.
Page 19 1-6. Rack Mounting 15. Check that the two intermediate rails attached to the rack are parallel. Intermediate rails Width : A = A' = 416 mm 16. Using the L-shaped hexagon wrench, fully tighten the hexagon socket head cap screws (four positions, total eight) to fix the two outer rails to the rack.
Page 20 1-6. Rack Mounting . Mounting in rack 21. Slide the unit in and out from the rack about three times and check that the slide rails move smoothly. Be sure to carry the unit by the two persons or more. If they are not smoothly, demount the unit and go back to “Attaching outer rails”...
Page 21: Matching Connectors And Cables
1-7. Matching Connectors and Cables When external cables are connected to the connector of this unit, the hardware listed below (or equiva- lents) must be used. Panel indication Matching connector (cable) Sony part No. VIDEO INPUT BNC 75Z, MALE VIDEO OUTPUT BNC 75Z, MALE...
Page 22: Signal Inputs And Outputs
1-8. Signal Inputs and Outputs 1-8. Signal Inputs and Outputs < Reduced drawing of rear panel > AC IN BREAKER Remote connector 7 SCSI 68P connector Differential type bus (SCSI-2) 7 REMOTE (9P) D-SUB 9P connector (RS-422A interface) Remote control 7 RS-232C D-SUB 25P connector (RS-232C interface) for ISR (Interactive Status Reporting)
Page 23 1-8. Signal Inputs and Outputs < Rear panel > DIGITAL INPUT DIGITAL OUTPUT DIGITAL INPUT DIGITAL SDTI SDTI ( OPTION ) SDTI SDTI ( OPTION ) AUDIO INPUT TIME CODE TIME LEVEL LEVEL LEVEL LEVEL HIGH HIGH HIGH HIGH AUDIO INPUT(AES/EBU) 600Ω...
Page 24 1-8. Signal Inputs and Outputs SCSI: 68-pin (female) REMOTE (9P): 9-pin (female) External view External view Pin No. Signal Pin No. Signal Pin No. Signal +DB(12) _DB(12) +DB(13) _DB(13) RM TX(_) +DB(14) _DB(14) RM RX(+) +DB(15) _DB(15) +DB(P1) _DB(P1) PRIORITY +DB(0) _DB(0) RM TX(+)
Page 25: Switch Settings On Connector Panel
http://getMANUAL.com 1-8. Signal Inputs and Outputs 1-9. Switch Settings on Connector Panel 1-9. Switch Settings on Connector Panel VIDEO CONTROL: 15-pin (male) External view When the unit is installed, be sure to perform the following setup. Refer to the operation manual “Section 2 Location and Function of Parts”...
Page 26: Switch And Shorting Plug Setting On Pc Boards
1-10. Switch and Shorting Plug Setting on PC Boards 1-10. Switch and Shorting Plug Setting on PC Boards 1-10-1. APR-12 Board APR–12 LOTNO, S NO, A No. Refer to “2-13. Pulling Out/ RV500 RV600 Insertion of Plug-in Board” for S500 S600 pulling out and insertion of board.
Page 27 1-10. Switch and Shorting Plug Setting on PC Boards Audio input headroom (CH1, CH2) setting Input headrooms (CH3, CH4) are set on the APR-13 board. Channel Ref. No. Display Input headroom (dB) [ ]: Factory setting Fine adjustment [20] COR101 Short Open Open...
Page 28 1-10. Switch and Shorting Plug Setting on PC Boards 1-10-2. APR-13 Board APR–13 LOTNO, S NO, A No. Refer to “2-13. Pulling Out/ RV200 RV100 COR200 COR100 Insertion of Plug-in Board” for –3 –20 –3 –20 COR101 COR201 pulling out and insertion of board. 1618 20 1618 20 COR300...
Page 29 1-10. Switch and Shorting Plug Setting on PC Boards Audio output level setting Channel Ref. No. Display Output level (dBm/600 Z) [ ]: Factory setting Fine adjustment [+4] COR301 Short Open Open Open RV300 Open Short Open Open Open Open Short Open Open...
Page 30 1-10. Switch and Shorting Plug Setting on PC Boards 1-10-3. DM-89 Board Never change the settings of the factory use switches. DM-89 Refer to “2-13. Pulling Out/ S501 A No. LOTNO, S NO, S901 Insertion of Plug-in Board” for pulling out and insertion of board. S302 S301 TEST NOR...
Page 31 1-10. Switch and Shorting Plug Setting on PC Boards 1-10-4. TBC-23 Board Never change the settings of the factory use switches. TBC-23 [1] [2] [3] [4] [5] [6] [7] [8] [1] [2] [3] [4] Refer to “2-13. Pulling Out/ RV202 S500 COMB Y MUTE...
Page 32: Board
1-10. Switch and Shorting Plug Setting on PC Boards 1-10-5. SS-63 Board Never change the settings of the factory use switches/shorting plugs. SS-63 RV100 A No. LOT No. S No. S1100 S100 S1101 COR102 >EP–GW< S1900 S1102 S101 COR103 COR100 COR101 * 1 : Board number suffix -13 and higher COR104...
Page 33 1-10. Switch and Shorting Plug Setting on PC Boards SS-63 board switch Switch No. Name Description Factory setting S100 REEL POSITION Press this switch when changing the reel position. ————— This switch does not operate in the state of installing the cassette compertment. S101 FLASH MEMORY nDo not change the setting of this switch during installation.
Page 34: Ssx Board
1-10. Switch and Shorting Plug Setting on PC Boards 1-10-6. SSX Board Never change the settings of the factory use switches. A No. LOTNO, S NO, S301 >EP–GW< SSX Board (Side A) Refer to “2-13. Pulling Out/ Insertion of Plug-in Board” for pulling out and insertion of board.
Page 35: Mode Switching Of Search Dial
http://getMANUAL.com 1-11. Mode Switching of Search Dial 1-11. Mode Switching of Search Dial 5. After checking that the shaft of the search dial is not seen in the round hole of the mode selection plate and There are two kinds of operation to switch the search dial then tighten the screw.
Page 36: Setup Menu (Item F-Series)
1-12. Setup Menu (ITEM F-Series) 1-12. Setup Menu (ITEM F-Series) This section explains the F-series items on the setup menu, which are for use during adjustment or maintenance. For details on other series items, refer to the operation manual supplied with the unit. 1-12-1.
Page 37: F-Series Items
1-12. Setup Menu (ITEM F-Series) 1-12-2. F-Series Items ITEM DATA Description [ON] AUDIO NR IN SP Turns on and off the Dolby NR when using a metal tape. MODE ON: Dolby NR is turned on usually SW: Dolby NR switch is turned on and off depending on the setting of the sub control panel .
Page 38: Reference System
1-13. Reference System 1-13. Reference System For each reference signal in this unit, an external reference video signal (*1) or input video signal (*2) is automatically selected by the setting of the OUT REF switch on the sub control panel, the setting of setup menu ITEM-309, and the operation mode (PB/EDIT/REC) of this unit.
Page 39: Switching Between 525/625 Line Systems
1-14. Switching between 525/625 Line Systems 1-14. Switching between 525/625 Line Systems In the NTSC Model (DNW-A100/A50/A45) This unit can be switched from 525/60 system to 625/50 system. The tape recorded based on the Betacam SX format of 625/50 system can be played back, and the signal of 625/50 system (except the analog composite video input) can be also recorded by switching the system.
Page 40: Settings And Adjustment When Peripheral Equipment Is Connected
1-15. Settings and Adjustment when Peripheral Equipment is Connected 1-15. Settings and Adjustment when Peripheral Equipment is Connected Refer to Section 1-15-4 for setting when connecting the disk unit BKNW-116. 1-15-1. Time Code Setting When Editing with an Editor Capable of the 1st Edit (BVE-2000 etc.) Set the TC GENERATOR switches on the upper control panel as follows.
Page 41: System Phase Alignment
1-15. Settings and Adjustment when Peripheral Equipment is Connected 1-15-3. System Phase Alignment An external reference video signal and analog composite signal (when BKDW-505/506 is used) must be input to this unit after they are adjusted so that SC-H conforms to the specification. When Connecting to a Digital Switcher Fundamentally, the system phase adjustment is not necessary.
Page 42: Setting When Bknw-116 Is Connected
ROM version 3.01 or higher If the ROM version is lower than the value described above, the version-up must be required. For the version-up, contact your local Sony Sales Office/Service Center. BLACK file installation When BKNW-116 is first used after factory-shipping, maintenance menu D4 : BLACK INSTALLATION is automatically started when the power is first turned on after connection to this unit.
Page 43: Installation Of Bkdw-505/506
1-16. Installation of BKDW-505/506 1-16. Installation of BKDW-505/506 By installing the analog composite decoder board BKDW-505/506 in the unit, a composite video signal is converted to a digital signal, then decoded to a component digital signal. For DNW-A100/A50/A45 ---------- BKDW-505 For DNW-A100P/A50P/A45P ----- BKDW-506 If the BKNW-104 is already installed, the BKDW-505/506 can not be installed in the unit.
Page 44: Check After Installing
1-16. Installation of BKDW-505/506 1-16-2. Check after Installing Equipment BKDW-505 (For DNW-A100/A50/A45) Analog composite video signal generator (TEKTRONIX TSG-170A or equivalent) Analog composite waveform/vector monitor (TEKTRONIX 1750/1780R or equivalent) Video monitor 75 Z terminators (2 pcs) BKDW-506 (For DNW-A100P/A50P/A45P) Analog composite video signal generator (TEKTRONIX TSG-271A or equivalent) Analog composite waveform/vector monitor (TEKTRONIX 1751/1781R or equivalent) Video monitor 75 Z terminators (2 pcs)
Page 45 http://getMANUAL.com 1-16. Installation of BKDW-505/506 Setting of Unit Side Turn on the power, and set each control panel as shown below. PRESET(Push) PB.EE Lights COMPOSITE VIDEO INPUT SELECT AUDIO INPUT/MIXING/MONITOR SELECT TC GENERATOR REMOTE /LOCAL CH-1 CH-2 CH-3 CH-4 VITC SDTI (VIDEO &...
Page 46 1-16. Installation of BKDW-505/506 Operation Method of Maintenance Mode Normal State 1. Entering the Maintenance Mode [S1101] [MENU] Press S1101 on the SS-63 board. MAINTENANCE MODE TAPE MAINTENANCE MODE [SET] M0 : TAPE MAINTENANCE C0 : SERVO CHECK M1 : DISK MAINTENANCE C1 : CHECK 2.
Page 47 1-16. Installation of BKDW-505/506 Check and Adjustment Wait more than 30 minutes after turning on the power, then perform the check and adjustment. 1. Check and Adjustment of Analog Composite Input Level (1) Set the output signal of a signal generator to color-bar signal. For BKDW-505: 75% color-bar signal For BKDW-506: 100% color-bar signal (2) Check using a waveform monitor that the level between the pedestal and peak white satisfies the...
Page 48 1-16. Installation of BKDW-505/506 2. Frequency Response Check (1) Set the output signal of the signal generator to the multi-burst signal. (2) Check using the waveform monitor that the level of each frequency component is uniform. If the level is not uniform, perform steps (3) to (8). 3 3.58 4.2 MHz 0.5 1 4 4.8 5.8 MHz...
Page 49: Installation Of Bknw-103
For the version-up, (5) Pinch the claws of the hole plug using a long-nose contact your local Sony Sales Office/Service Center. pliers as shown in the figure, then remove the plug holder by pushing it from the inside of the connector panel .
Page 50 (6) Insert the BNC connector on the CP-300 board into the (13)Place the CP shield plate (B) and rear shield lid so that hole of the connector panel, then loosely attach the the claws of the shield plate (B) place the inside of the CP-300 board with the supplied screw (PSW 3 x 6).
Page 51: Check After Installing
1-17-2. Check after Installing Equipment BNC cable Pre-recorded tape or Alignment tape : SR5-1 (For 525/60 system) SR5-1P (For 625/50 system) Check (1) Connect the BNC cable between the SDTI INPUT on the connector panel and the SDTI OUTPUT (1 or 2) . (2) Set the OUT REF switch on the sub control panel to REF.
Page 52: Installation Of Bknw-104
1-18. Installation of BKNW-104 1-18. Installation of BKNW-104 By installing the analog component input board BKNW-104 in the unit, an analog component signal is converted to a digital signal then recorded. If the BKDW-505/506 is already installed, the BKNW-104 can not be installed in the unit. When installing the BKNW-104, remove the BKDW-505/506.
Page 53: Adjustment After Installing
1-18. Installation of BKNW-104 1-18-2. Adjustment after Installing Perform the adjustment as shown below after installing the AD-105 board. Items of Adjustment No. Item Adjustment point Notes Component video output level check –––– VIDEO OUTPUT COMPONENT Y –––– VIDEO OUTPUT COMPONENT R-Y ––––...
Page 54 1-18. Installation of BKNW-104 Equipment Analog component waveform monitor (TEKTRONIX WFM300 or equivalent) Serial component waveform monitor (TEKTRONIX WFM601 or equivalent) Video monitor 75 Z terminators (3 pcs) Connection Connect the equipment described above as shown below depending on the items of adjustment. Connection 1 Video monitor (75 Z...
Page 55 http://getMANUAL.com 1-18. Installation of BKNW-104 Setting of Unit Side 1. Turn on the power. 2. Set S1100-1 on the SS-63 board to ON (CLOSE) to treat the extended menu. S1100 SS-63 board Set S1100-1 to ON 3. Set each switch on the control panels as shown below. PB.EE Lights COMPONENT VIDEO INPUT SELECT...
Page 56 1-18. Installation of BKNW-104 Operation Method of Maintenance Mode 1. Entering the Maintenance Mode Press S1101 on the SS-63 board. 2. Shifting to the Next Menu (1) Press the JOG button once to enter the JOG mode (2) Turn the search dial and set the * mark to a desired menu (mode). (3) Press the SET button.
Page 57 1-18. Installation of BKNW-104 The sub mode and menu of the maintenance mode that is used when installing the AD-105 board (BKNW-104) is as shown below. M0: TAPE MAINTENANCE C2: AUDIO/VIDEO CHECK C21: VIDEO TEST SG A2: AUDIO/VIDEO ADJUST A20: VPR VR A22: AD VR (LOOP) A2F: NV-RAM CONTROL Check and Adjustment...
Page 58 1-18. Installation of BKNW-104 Component Video Output Level Check Refer to 1-44 page for the operation method of the maintenance mode when checking. (1) Connect as connection 1. (2) Press S1101 on the SS-63 board so as to enter the maintenance mode. (3) Select C21: VIDEO TEST SG of C2: AUDIO/VIDEO CHECK of the maintenance mode.
Page 59 1-18. Installation of BKNW-104 Component Video Betacam Output Level Check (In 525/60 system) This check can be performed only in 525/60 system. When the check is performed in 625/50 system, go to “3. Component Video Output Phase Check”. Refer to 1-44 page for the operation method of the maintenance mode when checking. (1) Connect as connection 1.
Page 60 1-18. Installation of BKNW-104 3. Component Video Output Phase Check Refer to 1-44 page for the operation method of the maintenance mode when checking. (1) Connect as connection 1. (2) Select C21: VIDEO TEST SG of C2: AUDIO/VIDEO CHECK of the maintenance mode. (3) Set TEST SG output to BOWTIE.
Page 61 1-18. Installation of BKNW-104 4. Component Video Input Leve Adjustment Refer to 1-44 page for the operation method of the maintenance mode when adjusting. (1) Connect as connection 2. (2) Select A22: AD VR (LOOP) of A2: AUDIO/VIDEO ADJUST of the maintenance mode. (3) Select “Y INPUT LEVEL”.
Page 62 1-18. Installation of BKNW-104 5. Component Video Input Phase Adjustment Refer to 1-44 page for the operation method of the maintenance mode when adjusting. (1) Connect as connection 3 or 2. (2) Select “Y INPUT PHASE” of A22: AD VR (LOOP) of the maintenance mode. (3) Magnify the horizonal axis on the screen of the waveform monitor, then display 2T pulse.
Page 63 1-18. Installation of BKNW-104 6. Component Video Betacam Input Level Adjustment (In 525/60 system) This adjustment can be performed only in 525/60 system, When the adjustments are performed in 625/50 system, go to “7. Component Video Input Frequency Response Adjustment”. Refer to 1-44 page for the operation method of the maintenance mode when adjusting.
Page 64 1-18. Installation of BKNW-104 7. Component Video Input Frequency Response Adjustment Refer to 1-44 page for the operation method of the maintenance mode when adjusting. (1) Connect as connection 3. (2) Select “Y FREQ COMP” of A22: AD VR (LOOP) of the maintenance mode. (3) Adjust “Y FREQ COMP”...
Page 65 http://getMANUAL.com 1-18. Installation of BKNW-104 (5) Select “R-Y FREQ COMP”. (6) Adjust “R-Y FREQ COMP” that the fluctuation level is minimum. (7) Regard 1st signal of each frequency as 100 % (REF), then check that the level of signal after looping satisfies the specifications.
Page 66 1-18. Installation of BKNW-104 8. Component Video Betacam Level Input Check and Adjustment (In 625/50 system) When this unit is adjusted in 625/50 system, perform this adjustment after switching this unit to 525/60 system. When this unit is adjusted in 525/60 system, this adjustment is not required. Refer to 1-44 page for the operation method of the maintenance mode when adjusting.
Page 67: Installation Of Bknw-105
If the ROM version is lower than the value described board. above, the version-up must be required. For the version - up, consult with Sony’s sales/service organization. Turn off the power before starting the installation. Never reuse the removed screws (BVTT 3 x 6).
Page 68 1-19. Installation of BKNW-105 (6) Remove the shield plate and CP insulator (A). (9) Attach the ornamental plate by supplied screws A and B (BVTT 3 x 6) . Keep the CP insulator (A) with the CP-278 board. It (Screw in order of A,B shown in the figure.) needs when installing the CP-278 board again.
Page 69 1-19. Installation of BKNW-105 Installation of DIF-44 board (13)Fit the shield plate. Gather the harness in a space of the CP shield plate as (17)Remove the upper lid. (Refer to Section 2-3-1.) not to catch the harness. (18)Loose one screw fully, then remove the board retainer (S).
Page 70: Check After Installing
1-19. Installation of BKNW-105 1-19-2. Check after Installing Equipment Video monitor Headphones BNC cables (For the loop connection) 2 pcs Procedure (1) Connect between the VIDEO OUTPUT COMPOSITE 3 (SUPER) connector of the unit and a video monitor. (2) Plug the headphones. (3) Set S1100-1 on the SS-63 board to ON (CLOSE) to treat the extended menu.
Page 71 1-19. Installation of BKNW-105 Preparation for dubbing [through step (26)] (1) Turn on the power. (2) Select EXT as a player device, and DISK MASTER as (17)Select DISK MASTER as a player device. a recorder device. (Push the DISK MASTER button while pressing the (Press the EXT button while pressing the PLAYER PLAYER button.) button.
Page 72 1-19. Installation of BKNW-105 Check [through step (37) ] (32)Wear the headphones. (33)Select the EXT as a player device. (Press the EXT button while pressing the PLAYER button.) (34)Press the PLAY button to playback the file that is recorded in step (29), and check that the all audio level meter (CH-1/2/3/4) read _20 dB FS.
Page 73: Service Overview
Section 2 Service Overview 2-1. Notes on Power Supply Block 2-2. Cleaning when the Heads are Clogged 2-1-1. Warning on Primary Circuit Block and Electric Shock Clean using a cleaning cassette tape (specified product: BCT-5CLN) when the video heads are clogged. For the cleaning, refer to “5-2-1.
Page 74: Removal/Installation Of Cabinet
2-3. Removal/Installation of Cabinet 2-3. Removal/Installation of Cabinet 2-3-1. Upper Lid, Side Panels, and Bottom Plate Removal/Installation Turn off the power and unplug the power cord before starting the removal/installation. Screws with stopper Upper lid Screw with stopper B4 x 6 B3 x 6 B3 x 6 B4 x 6...
Page 75: Control Panels Removal/Installation
http://getMANUAL.com 2-3. Removal/Installation of Cabinet (4) Unhook the two hooks at lower portion on the upper Upper Lid control panel. (1) Loosen the three fixing screws. (2) Remove the upper lid by moving in the direction Hooks BVTT3 x 6 indicated by the arrow.
Page 76 2-3. Removal/Installation of Cabinet 2-3-3. Connector Panel Assembly Removal/ Installation Turn off the power and unplug the power cord before starting the removal/installation. For your safety, turn off the power and unplug the power Lower Control Panel cord before starting the removal/installation. (1) Slightly pull the lower control panel forward, then pull (1) Remove the six screws indicated 8 on the connector it more strongly.
Page 77: Plate Md Assembly Removal/Installation
2-3. Removal/Installation of Cabinet 2-4. Plate MD Assembly Removal/Installation 2-4. Plate MD Assembly Removal/ 2-3-4. Power Supply Panel Assembly Installation Removal/Installation For your safety, turn off the power and unplug the power Turn off the power and unplug the power cord before cord before starting the removal/installation.
Page 78: Cassette Compartment Removal/Installation
2-5. Cassette Compartment Removal/Installation (5) Hold the cassette compartment at the portions A and 2-5. Cassette Compartment Removal/ Installation slightly lift up the cassette compartment (by 1 cm). When the four cassette compartment positioning legs come off from the four positioning holes on a mechan- .
Page 79: Lower Control Panel Assembly Removal/Installation
2-5. Cassette Compartment Removal/Installation 2-6. Lower Control Panel Assembly Removal/Installation 2-6. Lower Control Panel Assembly Installation Removal/Installation (7) Place the cassette compartment into the unit in the direction as shown in the figure (with the cassette lid Turn off the power and unplug the power cord before down).
Page 80: Circuit Function
2-7. Circuit Function 2-7. Circuit Function System configuration Board name Circuit function Digital process SSX-1/2 SDTI-SCSI transfer * DPR-71 Digital data processor (Audio/Video encoder, Outer error correction) DPR-73 Digital data processor (Audio/Video processor) DIF-42 4:2:2 component serial digital interface with Embedded audio Video process * VPR-17 Video signal processor (A-D, D-A, Reference clock generator, Composite encoder)
Page 81 2-7. Circuit Function System configuration Board name Circuit function Cassette CL-29 Cassette up/down motor, Cassette down sensors compartment LP-81 Lamp of cassette compartment PC-70 Cassette-in sensors, Cassette size sensor Front panel FP-91 Panel function (Switches, LEDs) control, CAV control level conversion VR-223 Audio REC and Phone level VRs, Phone connector VR-224...
Page 82: Location Of Main Part
2-8. Location of Main Part 2-8. Location of Main Part 2-8-1. Printed Circuit Boards, Power Supply 90674 Unit, and HDD Units Location AC-169 ....$. AD-105 ....7 (BKNW-104) APR-12 ....!- APR-13 ....!= CCM-15 ....@-@= CL-29 ...... #= CP-277 ....
Page 83 2-8. Location of Main Part < Front View > < Rear View > There figures are for DNW-A100. 2-11 DNW-A100/A50/A45 DNW-A100P/A50P/A45P...
Page 84 2-8. Location of Main Part < Top View of Mechanical Deck > < Top View of Cassette Compartment > 2-12 DNW-A100/A50/A45 DNW-A100P/A50P/A45P...
Page 85: Main Mechanical Parts Location
http://getMANUAL.com 2-8. Location of Main Part 2-8-2. Main Mechanical Parts Location < Top View of Mechanical Deck > INDEX !; T worm wheel 1 Audio/TC head !' Worm gear 2 Audio/TC erase head !, Drive gear 3 TG-3 tape guide !.
Page 86: Function And Location Of Sensors
2-9. Function and Location of Sensors 2-9. Function and Location of Sensors !/ != < Top View of Mechanical Deck > Upper Lower < Top View of Cassette Compartment > 2-14 DNW-A100/A50/A45 DNW-A100P/A50P/A45P...
Page 87 2-9. Function and Location of Sensors ![ L cassette (SP) REC inhibit sensor 1 Threading motor FG sensor This sensor (switch) detects the condition of a REC This sensor detects the rotation speed of the threading inhibit plug for the Betacam/Betacam SP large motor.
Page 88: System Of Cassette
2-9. Function and Location of Sensors 2-10. System of Cassette Heat up sensor This sensor determines the temperrature of the hard disk drive. Heats the hard disk drives by the heat up device when tee temperature becomes less 5dC. 2-10. System of Cassette As shown in the figure below, plugs and tabs are provided at the back side of the cassette tape.
Page 89 2-10. System of Cassette REC Inhibit Plugs Back side of the cassette Same surface Plug is down Recording impossible Recording possible Detection Tabs In cassette for Betacam or Betacam SP With tab (Close hole) Without tab (Open hole) Thick (Tape thickness is 20 µm) Thin (Tape thickness is 15 µm) Tape thickness detection Metal tape detection...
Page 90: Function Of Leds On Circuit Boards
2-11. Function of LEDs on Circuit Boards 2-11. Function of LEDs on Circuit Boards SSX board SS-63 board D1905 D1904 D700 D1903 D1902 D600 Lower Upper D1104 D1105 D301 D1103 D1102 D112 D301 D108 SSX board LED No. Name Color Description Normal state D301...
Page 91 2-11. Function of LEDs on Circuit Boards SS-63 board LED No. Name Color Description Normal state D108 Amber Represents the result of communication test of ROM and RAM Blinks in power-on by blinking pattern. (Refer to below.) D112 TRVR Amber Lights when the tracking VR is enable.
Page 92 2-11. Function of LEDs on Circuit Boards Upper Lower DIF-42 board D100, D104 D108 - D115, D703, D705 - D707, D709 - D712, D714 D713 TBC-23 board D200 DM-89 board D902 DM-89 board LED No. Name Color Description Normal state D902 ADJUST Amber...
Page 93 2-11. Information of LEDs on Circuit Boards DIF-42 board LED No. Name Color Description Normal state 525/60 system 625/50 system D100 RX AUDIO Green Lights when an AUDIO CH-1 signal is detected from the signal EXIST CH-1 received by the SDI INPUT connector. D104 RX AUDIO Lights when an error occurs in the AUDIO CH-1 signal detected...
Page 94: How To Take Out The Cassette When The Tape Is Slacking
2-12. How to Take out the Cassette when the Tape is Slacking 2-12. How to Take out the Cassette when (7) Slightly pull the lower control panel forward, then pull the Tape is Slacking it more strongly to tilt the lower control panel upward (to 90d position).
Page 95: Pulling Out/Insertion Of Plug-In Board
http://getMANUAL.com 2-13. Pulling out/Insertion of Plug-in Board 2-13. Pulling out/Insertion of Plug-in (4) Pull up the eject levers on the board to the direction of Board the arrows. (Disconnect the board from motherboard.) (5) Hold the eject levers and slowly pull the board out. .
Page 96: Fixtures And Adjustment Equipment List
Cleaning 7-432-114-11 Locking compound (200 g) — Inhibits loosening of screws 7-661-018-18 Diamond oil NT-68 (50 ml) — 7-651-000-10 Sony grease SGL-601 (50 g) — 7-700-736-01 L-shaped hexagonal wrench (d=1.27 mm) — 7-700-736-05 L-shaped hexagonal wrench (d=1.5 mm) — 7-700-736-06 L-shaped hexagonal wrench (d=0.89 mm)
Page 97 2-14. Fixtures and Adjustment Equipment List 2-25 DNW-A100/A50/A45 DNW-A100P/A50P/A45P...
Page 98: Equipment For Adjustment
Sony BVG-1600PS (For 625/50 system) Time code reader Sony BVG-1500 (For 525/60 system) Sony BVG-1500PS (For 625/50 system) Terminator — 75-ohm, BNC type BNC T adapter — 75-ohm Recording tape Sony BCT-SX series Cassette tape for Betacam SX 2-26 DNW-A100/A50/A45 DNW-A100P/A50P/A45P...
Page 99: Isr
This unit corresponds to ISR (Interactive Status Reporting) function. When this unit is connected to the personal computer which activates Sony’s ISR application software, the status of this unit or the contents of a generated error can be intensively monitored and managed on the monitor screen of a personal computer.
Page 100: Information Of Connecting Cable
2-15. ISR 2-15-2. Information of Connecting Cable Prepare the cables by refering the following information. 1. For connecting directly to a personal computer Use the RS-232C cross cable. RS-232C DB25 DB25 Signal ( 3 ) ( 2 ) ( 7 ) ( 8 ) ( 6 ) ( 5 )
Page 101 2-15. ISR 2. For connecting to a personal computer via LAN (Terminal server: 6-pin port) The connection varies depend on the terminal server. Be sure to check the pin assignment of terminal server side, and follow it. Terminal Server RS-232C RJ12 (Modular type) DB25 3.
Page 102: Procedure For Hard Disk Drive Check
2-16. Procedure for Hard Disk Drive Check 2-16. Procedure for Hard Disk Drive Check If abnormality such as is found (momentary freeze of picture or intermittent of sound) during disk operation, check the hard disk drive equipped with this unit according to the procedure below. For more details of D0 : ERROR COUNTER, D2 : DIAGNOSIS, D3 : INSTALLATION, and D9 : DISK CLEANING, refer to “4-3.
Page 103: Error Message
Section 3 Error Message 3-1. Overview of Error Message This unit has self-diagnostics function. When trouble is detected, an ALARM indicator is lighted immediately on the lower control panel, and an error message and error code are displayed in the time data ERROR-01 display area and event display area.
Page 104 3-1. Overview of Error Message Error messages are described on Section 3-2 in the order of list. Error List Code Message Page Description on time data display area NO COMMUNICATION Abnormality in the interface between the lower control panel (KY-364 board) and SYS1 CPU (SS-63 board) is detected in the lower control panel side.
Page 105: Details Of Error Messages
http://getMANUAL.com 3-1. Overview of Error Message 3-2. Details of Error Messages . Error codes 01 through 14 are detected in both/one of the SS-63 and/or MS-50 boards. Error codes 20 through 23 are detected in the MS-50 board. Error codes 92 through 99 are detected in the SS-63 board. Error codes D1 through D8 are detected in the SSX board.
Page 106 3-2. Details of Error Messages (NO COMMUNICATION) Description: Abnormality in the interface between the lower control panel’s MPU (on the KY-364 board) and SYS1 CPU (SS-63 board) was detected. This error message is only displayed on the time data display area in that the abnormality of the interface is detected in the lower control panel side.
Page 107 3-2. Details of Error Messages Hard disk drive warming up function If the hard disk drive is started up under cold conditions (below 5dC/41dF), its reliability may be severely reduced. This unit includes a function to inhibit starting of the hard disk drive when the temperature is below 5dC/ 41dF.
Page 108 3-2. Details of Error Messages ERROR-02 REEL TROUBLE - 2 (REEL TROUBLE) Description: Tape slacking or tape breaking was detected in SEARCH, FF, or REW mode. Detecting conditions: 1) When the take-up value is lower than the specified value with respect to the tape supply value.
Page 109 3-2. Details of Error Messages ERROR-03 REEL TROUBLE - 3 (REEL TROUBLE) Description: Tape slacking, tape breaking, or supply or take-up reel locking was detected in the REC or PLAY mode. Detecting conditions: 1) When the take-up value is lower than the specified value with respect to the tape supply value.
Page 110 3-2. Details of Error Messages ERROR-04 REEL TROUBLE - 4 (REEL TROUBLE) Description: Abnormal tape transport speed was detected in the FF or REW mode. Detecting condition: When the tape speed calculated from the supply reel FG and take-up reel FG is under a half of the specified tape speed continuously for more than four seconds.
Page 111 3-2. Details of Error Messages ERROR-06 TAPE TENSION ERROR (TAPE TENSION) Description: Excessive tension was detected in the REC or PLAY mode. Detecting condition: When the tension value calculated from supply tension sensor output is more than 55 g continuously for more than three seconds. Sub error message: None Possible causes:...
Page 112 3-2. Details of Error Messages ERROR-08 DRUM TROUBLE (DRUM TROUBLE) Description: Malfunction of drum motor was detected. When the drum FG cycle is shifted more than about ± 30 % continuously for Detecting condition: more than 10 seconds as compared with during normal rotation. Sub error message: None Possible causes:...
Page 113 3-2. Details of Error Messages ERROR-0A THREADING TROUBLE (THREADING) Description: It was detected that the tape top processing in the thread state is not completed. Detecting condition: When the tape top is detected again after it is processed. Tape top processing In this processing, the tape is slightly forwarded without taking out the tape after unthread because the tape top was detected during threading.
Page 114 3-2. Details of Error Messages ERROR-11 TAPE TOP/END SENSOR TROUBLE (TAPE T/E SENSOR) Description: The tape top and tape end were detected simultaneously. Detectiong condition: When the simultaneous detection of the tape end and tape top is continued for more than seven seconds. Sub error message: None Possible causes:...
Page 115 http://getMANUAL.com 3-2. Details of Error Messages ERROR-13 TAPE END SENSOR TROUBLE (TAPE END SENSOR) Description: Malfunction of tape end sensor was detected. Detecting condition: When the tape end is detected continuously for more than seven seconds. Sub error message: None .
Page 116 3-2. Details of Error Messages ERROR-14 FAN MOTOR TROUBLE (FAN MOTOR) Description: Malfunction of cooling fan motor was detected. If this error occurred, stop immediately operation of the unit, and turn off the power. If the unit uses continuously under the fan is stopped state, overhearting inside the unit can cause a fire or a failure.
Page 117 3-2. Details of Error Messages ERROR-20 CASSETTE COMPARTMENT MOTOR LOCK (CASS COMP MOTOR) Description: Malfunction of cassette compartment-up or down operation was detected. Detectiong condition: When no operation is completed within about six seconds after operation start. Sub error message: None Possible causes: .
Page 118 3-2. Details of Error Messages ERROR-22 REEL POSITION SENSOR TROUBLE (REEL POS SENSOR) Description: The L and S cassette positions of the reel table were detected simultaneously. Detecting condition: When the L and S position sensors detect the L and S cassette positions, respec- tively at the same time.
Page 119 3-2. Details of Error Messages ERROR-92 INTERNAL INTERFACE ERROR 1 (INTERNAL I/F 1) Description: Abnormality was detected in the communication between SYS1 CPU (IC704 on SS-63 board) and other CPU/MPU. Sub error messages and Detecting conditions: SY2: When the SYS2 CPU (IC1505 on SS-63 board) initialization at power-on is in abnormal state.
Page 120 3-2. Details of Error Messages ERROR-96 SY NV-RAM ERROR (SY NV-RAM ERROR) Description: The abnormal operation of an NV-RAM (IC710 on SS-63 board) for the system control system was detected. Sub error messages and Detecting conditions: CURRENT SETUP: When the data error occurs in the setup menu current memory area during the data write or read .
Page 121 3-2. Details of Error Messages ERROR-97 SV NV-RAM ERROR (SV NV-RAM) Description: The abnormal operation of an NV-RAM (MS-50 board) for the servo system was detected. Detecting condition: When the checksum of NV-RAM data does not coincide during activation. Sub error message: None Possible cause: NV-RAM (IC9 on MS-50 board) trouble...
Page 122 3-2. Details of Error Messages ERROR-99 INTERNAL INTERFACE ERROR 2 (INTERNAL I/F 2) Description: Abnormality was detected in the communication between SYS2 CPU (SS-63 board) and SERVO CPU (SS-63 board) or MPU (on EQ-56, DM-89, TBC-23, or DIF-42 board). Sub error messages and Detecting conditions: When the SERVO CPU (IC103 on SS-63 board) initialization at power- on is in abnormal state.
Page 123 3-2. Details of Error Messages ERROR-D1 SSX CPU PERIPHERAL ERROR (SSX CPU ERROR) Description: Abnormality in CPU peripheral devices on SSX board is detected. Sub error messages and Detecting conditions: FLASH Write Fail(11): During the data transmission from S-RAM to the flash memory, when the time- out is detected within the flash memory or when the data write is not completed within a regulation time (about 30 seconds).
Page 124 3-2. Details of Error Messages ERROR-D2 HDD INITIALIZATION ERROR (HDD INIT ERROR) Description: Abnormality is detected during the hard disk drives (HDDs) initialization. Sub error messages and Detecting conditions: HDD Not Connected(21): When no response is transmitted from the HDD with respect to the INQUIRY command to each HDD.
Page 125 http://getMANUAL.com 3-2. Details of Error Messages Protecting operations: HDD Illegal Format(24): After the following step automatically performs according to the occurring state of abnormal Cautomatically enters D3 : INSTALLATION (hard disk installation menu) of the maintenance mode. . Copies the file system’s data to the abnormal HDD from the normal HDD when the abnormality was found in one of a pair.
Page 126 3-2. Details of Error Messages ERROR-D3 SSX DIAGNOSTIC ERROR (SSX DIAGNOSTIC) Description: Abnormality is detected in the diagnostic process of the SSX board at power-on. Sub error messages and Detecting conditions: DIAG Data Not In(31): When the transfer completing flag is not set to the memory store register of SSX IC (IC800 on SSX board) during transfer the test data to SD-RAM from Diag FIFO on the SSX board.
Page 127 3-2. Details of Error Messages DIAG Data Not In(31): Possible causes: . SSX board’s 27M reference clock (IN CLK 2, 3) lines trouble . SSX board’s 27M reference clock (REF CLK 1) line trouble . SSX board’s 27M reference clock (CLK27) line trouble .
Page 128 3-2. Details of Error Messages ERROR-D4 SSX IC RELATED ERROR (SSX IC ERROR) Description: Abnormality is detected during the initialization or data transfer for SD-RAM on SSX board. Sub error messages and Detecting conditions: SDRAM Init Fail(41): When the initialized completing flag is not set to the system status register of SSX IC (IC800 on SSX board) until lapses about 10 ms after the power-on reset.
Page 129 3-2. Details of Error Messages Protecting operation: Disables the access to the hard disk drive. All operations can not be performed concerning the hard disk drives. Supp. remarks (for Error-D4) For the sub error message “HDD-SDRAM Incompl 1(44)”, the error message of error code D1 is not displayed in the time data display area on the lower control panel and it is not superimposed on the video monitor.
Page 130 3-2. Details of Error Messages ERROR-D6 SSX OPERATIONAL ERROR (SSX OP ERROR) Description: Abnormality is detected during a record or a playback of the hard disk(s). Sub error messages and Detecting conditions: State Time Over(61): When the HDD operation does not change to the mode that corresponds to the playback even though the play back time has elapsed for five seconds.
Page 131 3-2. Details of Error Messages Supp. remarks 1. For the sub error message “Normal Playback Fail(63)”, the error message of error code D8 is not displayed in the time data display area on the lower control panel and it is not superimposed on the video monitor.
Page 132 3-2. Details of Error Messages ERROR-D7 SCSI DRIVER RELATED ERROR (SCSI DRIVER) Description: Abnormality (parity error, bus stop) in the SCSI bus is detected. Sub error messages and Detecting conditions: SCSI Bus Parity(71): When SCSI protocol controller (IC400 on SSX board) detects the parity error. SCSI Bus Stop(72): When the SCSI bus keeps a condition except BUS FREE for more than fifteen seconds.
Page 133 3-2. Details of Error Messages ERROR-D8 SCSI TARGET ERROR (SCSI TARGET) Description: The occurrence of the medium error or hardware error in hard disk drive is detected by the transmitted sense code from the hard disk drive (HDD). Sub error messages and Detecting conditions: Medium Error in File(81): When the medium error occurs during the read/write of the file system data in HDD.
Page 134 3-2. Details of Error Messages Supp. remarks 1. For the sub error messages “Medium Error during AV Record/Playback(82)” and “Medium Error during NonAV Record/Playback(83)”, the error message of error code D8 is not displayed in the time data display area on the lower control panel and it is not superimposed on the video monitor.
Page 135: Maintenance Mode
http://getMANUAL.com Section 4 Maintenance Mode 4-1. Overview of Maintenance Mode This unit has the maintenance mode that is useful during maintenance and trouble diagnosis. This maintenance mode consists of the three modes below. The contents of the maintenance mode are superimposed on the video monitor connected to the VIDEO OUTPUT COMPOSITE 3 (SUPER) connector.
Page 136 4-1. Overview of Maintenance Mode Buttons and Switches for Operation The main buttons and switches related to the operation of maintenance mode are as follows: The ordinary functions of these buttons and switches and how to use them are described below. 1 Time data display area The time data display area displays the menu (mode) No., menu title, selection item, status, or data.
Page 137 4-1. Overview of Maintenance Mode 9 S1101/SS-63 board: Maintenance mode start switch (MAINTE MODE START) Press this switch to activate the maintenance mode. 0 S1100-2/SS-63 board: Maintenance mode access approval switch (MAINTE MODE Access) Set this switch to ON (upper) in advance when activating the maintenance mode by the button operation on the control panel.
Page 138 4-1. Overview of Maintenance Mode Activating the Maintenance Mode (1) Confirm that the video monitor is connected to the VIDEO OUTPUT COMPOSITE 3 (SUPER) connector. (2) Press the 9 S1101 switch (on the SS-63 board). (3) The mode screen in the maintenance mode is superimposed on the video monitor. In a 1 time data display area, “M0-TAPE MAINTEN”...
Page 139 4-1. Overview of Maintenance Mode Specifying the Menu (Mode) and Item How to specify the menu (mode) and item using the search dial (JOG mode) is described below with the mode selection given as an example. MAINTENANCE MODE MAINTENANCE MODE MAINTENANCE MODE Turn search dial Turn search dial...
Page 140: Tape Maintenance Mode (M0)
4-2. TAPE Maintenance Mode (M0) 4-2-1. Overviews 4-2. TAPE Maintenance Mode (M0) 4-2-1. Overviews The TAPE maintenance mode is used for the maintenance and check of a VTR. This unit has the nine submodes below. TAPE MAINTENANCE MODE C0 : SERVO CHECK C1 :...
Page 141 4-2. TAPE Maintenance Mode (M0) 4-2-1. Overviews C0 : SERVO CHECK This submode is used to check the servo system of a VTR. For more details, refer to Section 4-2-2 (on page 4-14). SERVO CHECK SERVO CHECK [SET] C00-03:SERVO CHECK C00:INPUT CHECK C01:MOTOR CHECK C02:PLUNGER SOL.
Page 142 4-2. TAPE Maintenance Mode (M0) 4-2-1. Overviews C1 : RF CHECK This submode is used to check the RF system. For more details, refer to Section 4-2-3 (on page 4-31). RF CHECK MODE RF CHECK MODE C10:CH CONDITION (1/2) C11:CH CONDITION C11:CH CONDITION (2/2) For DNW-A100/A100P For DNW-A50/A45/A50P/A45P...
Page 143 4-2. TAPE Maintenance Mode (M0) 4-2-1. Overviews C3 : BETACAM PB CHECK This submode is used to check the PB system based on a Betacam/Betacam SP format. For more details, refer to Section 4-2-5 (on page 4-38). BETACAM PB CHECK MODE C30:CHANNEL CONDITION Title Page...
Page 144 4-2. TAPE Maintenance Mode (M0) 4-2-1. Overviews A0 : SERVO ADJUST This submode is used to adjust the servo system of a VTR. For more details, refer to Section 4-2-7 (on page 4-44). SERVO ADJUST (CONTINUED) SERVO ADJUST SERVO ADJUST [SET] CONTINUE PREVIOUS...
Page 145 http://getMANUAL.com 4-2. TAPE Maintenance Mode (M0) 4-2-1. Overviews A1 : RF ADJUST This submode is used to adjust the RF system. For more details, refer to Section 4-2-8 (on page 4-51). RF ADJUST MODE RF ADJUST MODE A10:EQUALIZER (1/2) A11:EQUALIZER A11:EQUALIZER (2/2) A12:REC CURRENT A12:REC CURRENT...
Page 146 4-2. TAPE Maintenance Mode (M0) 4-2-1. Overviews A2 : AUDIO/VIDEO ADJUST This submode is used to adjust the audio and video systems. For more details, refer to Section 4-2-9 (on page 4-59). AUDIO/VIDEO ADJUST MODE AUDIO/VIDEO ADJUST MODE A20:VPR VR A20:VPR VR A21:AD VR A23:CP VR...
Page 147 4-2. TAPE Maintenance Mode (M0) 4-2-1. Overviews A3 : BETACAM PB ADJUST This submode is used to adjust the PB system based on a Betacam/Betacam SP format. For more details, refer to Section 4-2-10 (on page 4-68). BETACAM PB ADJUST MODE A30:EQ VR A32:DM VR 1 A33:DM VR 2...
Page 148: Servo Check Mode (C0)
4-2. TAPE Maintenance Mode (M0) 4-2-2. SERVO CHECK Mode (C0) 4-2-2. SERVO CHECK Mode (C0) The C0 : SERVO CHECK mode is used to check the servo system of a VTR. The underlined menus and submenus in the menu tree below are described next. In the servo check mode, only the menu number is displayed in a time data display area.
Page 149 4-2. TAPE Maintenance Mode (M0) 4-2-2. SERVO CHECK Mode (C0) C000 : CASSETTE SW This submenu checks the functions of cassette tab sensors and REC inhibit sensors SERVO CHECK INPUT CHECK (switches). C000:CASSETTE SW 1:REEL HUB 2:METAL/OX 3:THICKNESS 4:SPARE (1) Push each sensor (switch) with fingers. 5:SPARE 6:DGTL/ANLG 7:S REC INH 8:L REC INH...
Page 150 4-2. TAPE Maintenance Mode (M0) 4-2-2. SERVO CHECK Mode (C0) C001 : CASSETTE COMP. SW This submenu checks the sensor (switch) function of a compartment. SERVO CHECK INPUT CHECK C001:CASSETTE COMP. SW (1) Push up the cassette door to the inside with fingers. SW1:CASSETTE IN SW 1 SW2:CASSETTE IN SW 2 SW3:LARGE CASSETTE SW...
Page 151 4-2. TAPE Maintenance Mode (M0) 4-2-2. SERVO CHECK Mode (C0) C002 : TOP/END SENSOR This submenu checks the functions of a tape top sensor and tape end sensor. SERVO CHECK INPUT CHECK C002:TOP/END SENS0R (1) Bring a metallic screwdriver near each sensor. .
Page 152 4-2. TAPE Maintenance Mode (M0) 4-2-2. SERVO CHECK Mode (C0) C003 : DEW SENSOR This submenu checks the function of a dew condensation sensor. SERVO CHECK INPUT CHECK C003:DEW SENSOR (1) Slightly touch the sensor with the cotton swab moistened with water. .
Page 153 4-2. TAPE Maintenance Mode (M0) 4-2-2. SERVO CHECK Mode (C0) C010 : S REEL MOTOR C011 : T REEL MOTOR SERVO CHECK MOTOR CHECK These menus check the function of an S reel motor or T reel motor. C010:S REEL MOTOR (1) Turn the search dial (JOG mode) in FORWARD (2) or REVERSE (3) direc- TURN JOG DIAL tion.
Page 154 4-2. TAPE Maintenance Mode (M0) 4-2-2. SERVO CHECK Mode (C0) C012 : THREADING MOTOR This menu checks the functions of a threading motor and threading end sensor/ SERVO CHECK MOTOR CHECK unthreading end sensor. C012:THREADING MOTOR * * * * * * UNTHREAD END (1) Turn the search dial (JOG mode) slowly in FORWARD (2) direction.
Page 155 http://getMANUAL.com 4-2. TAPE Maintenance Mode (M0) 4-2-2. SERVO CHECK Mode (C0) Threading motor Threading ring Unthreading end sensor Threading end sensor (Unthreading end state) Locations of Threading End and Unthreading End Sensors 4-21 DNW-A100/A50/A45 DNW-A100P/A50P/A45P...
Page 156 4-2. TAPE Maintenance Mode (M0) 4-2-2. SERVO CHECK Mode (C0) C013 : CASSETTE COMP. This menu checks the functions of a cassette compartment motor and cassette-down SERVO CHECK MOTOR CHECK sensor. C013:CASSETTE COMP. Be careful not to execute this menu with the foreign matter put into the cassette compartment.
Page 157 4-2. TAPE Maintenance Mode (M0) 4-2-2. SERVO CHECK Mode (C0) Rear Upper Cassette down sensor (1) Lower Cassette down sensor (2) Cassette compartment motor Front Top View of Cassette Compartment 4-23 DNW-A100/A50/A45 DNW-A100P/A50P/A45P...
Page 158 4-2. TAPE Maintenance Mode (M0) 4-2-2. SERVO CHECK Mode (C0) C014 : CAPSTAN MOTOR This menu checks the function of a capstan motor. SERVO CHECK MOTOR CHECK C014:CAPSTAN MOTOR (1) Press the SET button. . Confirm that the capstan shaft rotates in the forward (3) direction. .
Page 159 4-2. TAPE Maintenance Mode (M0) 4-2-2. SERVO CHECK Mode (C0) C015 : DRUM MOTOR This menu checks the function of a drum motor. SERVO CHECK MOTOR CHECK C015:DRUM MOTOR (1) Press the SET button. SPEED : . Confirm that the drum rotates. PHASE : .
Page 160 4-2. TAPE Maintenance Mode (M0) 4-2-2. SERVO CHECK Mode (C0) C016 : REEL SHIFT MOTOR This menu checks the functions of a reel shift motor and reel position sensor. SERVO CHECK MOTOR CHECK C016:REEL SHIFT MOTOR The power supply to the motor stops to protect the motor and movable part when the S-POSITION driving time of a motor continuously exceeds about six seconds due to abnormality.
Page 161 4-2. TAPE Maintenance Mode (M0) 4-2-2. SERVO CHECK Mode (C0) C020 : PINCH ROLLER This menu checks the function of a pinch roller solenoid. SERVO CHECK PLUNGER SOLENOID C020:PINCH ROLLER (1) Press the SET button. . Confirm that the pinch lever comes near a capstan and makes sound when the pinch roller solenoid is turned on.
Page 162 4-2. TAPE Maintenance Mode (M0) 4-2-2. SERVO CHECK Mode (C0) C021 : S REEL BRAKE C022 : T REEL BRAKE SERVO CHECK PLUNGER SOLENOID These menus check the function of an S or T reel brake solenoid. C021:S REEL BRAKE (1) Press the SET button.
Page 163 4-2. TAPE Maintenance Mode (M0) 4-2-2. SERVO CHECK Mode (C0) C023 : CLEANING ROLLER This menu checks the function of a cleaning roller solenoid. SERVO CHECK PLUNGER SOLENOID C023:CLEANING ROLLER (1) Press the SET button. . Confirm that the cleaning roller solenoid operates and that the cleaning roller momentarily touches the drum and is immediately released from it.
Page 164 4-2. TAPE Maintenance Mode (M0) 4-2-2. SERVO CHECK Mode (C0) C03 : REEL/CAPSTAN MOTOR & FG CHECK This menu checks the following items automatically and continuously. SERVO CHECK . S reel FG duty ratio (C031 : S REEL FG/MOTOR CHECK) C00:INPUT CHECK C01:MOTOR CHECK .
Page 165: Rf Check Mode (C1)
http://getMANUAL.com 4-2. TAPE Maintenance Mode (M0) 4-2-3. RF CHECK Mode (C1) 4-2-3. RF CHECK Mode (C1) In these menus, the error condition for each channel is displayed in three steps (GRN, YEL, and RED) when the The C1 : RF CHECK mode is used to check the PB RF tape recorded based on a Betacam SX format is played system based on an Betacam SX format.
Page 166 4-2. TAPE Maintenance Mode (M0) 4-2-3. RF CHECK Mode (C1) To execute the check (4) Confirm the check result on the superimpose picture. (1) Insert the cassette tape recorded by a Betacam SX . If no abnormality is found, “GRN” is displayed on format.
Page 167 4-2. TAPE Maintenance Mode (M0) 4-2-3. RF CHECK Mode (C1) Example of display and operation ALL is selected in C11 : CH CONDITION (2/2) for DNW- A100/A100P. (continued) Superimpose picture Time data display area C11 -ALL C11-ALL RF CHECK MODE RF CHECK MODE C11:CH CONDITION (2/2) C11:CH CONDITION (2/2)
Page 168 4-2. TAPE Maintenance Mode (M0) 4-2-3. RF CHECK Mode (C1) If the error condition is not improved in the way mentioned For Condition NG above, the possible cause below are considered. Confirm, recheck, and clean the drum (video heads) . VTR’s servo system adjustment defect or circuit defect according to the procedures below.
Page 169: Audio/Video Check Mode (C2)
4-2. TAPE Maintenance Mode (M0) 4-2-4. AUDIO/VIDEO CHECK Mode (C2) 4-2-4. AUDIO/VIDEO CHECK Mode (C2) For Check Failure Change the playback portion on the tape, then recheck. The C2 : AUDIO/VIDEO CHECK mode has four menus If no check failure occurs again, a trouble is considered to that are useful for checking audio and video systems.
Page 170 4-2. TAPE Maintenance Mode (M0) 4-2-4. AUDIO/VIDEO CHECK Mode (C2) C20 : SYSTEM EE C21 : VIDEO TEST SG AUDIO/VIDEO CHECK MODE AUDIO/VIDEO CHECK MODE C20:SYSTEM EE C21:VIDEO TEST SG This menu selects the system E-E function to be enabled or This menu selects the operation in the maintenance mode disable in the maintenance mode, and additionally selects a of a video test signal generator incorporated into this unit.
Page 171 4-2. TAPE Maintenance Mode (M0) 4-2-4. AUDIO/VIDEO CHECK Mode (C2) C22 : MULTI LOOP (10TIMES) C23 : AUDIO TEST SG AUDIO/VIDEO CHECK MODE AUDIO/VIDEO CHECK MODE C22:MULTI LOOP(10TIMES) C23:AUDIO TEST SG This menu selects the multi-loop function enabled or This menu selects the operation in the maintenance mode disabled in the maintenance mode, and additionally selects of an audio test signal generator incorporated in this unit.
Page 172: Betacam Pb Check Mode (C3)
4-2. TAPE Maintenance Mode (M0) 4-2-5. BETACAM PB CHECK Mode (C3) 4-2-5. BETACAM PB CHECK Mode (C3) (4) Confirm that “>>>” is displayed in the “GRN” column of Y and C channels. . If “>>>” is displayed in columns other than “GRN”, The C3 : BETACAM PB CHECK mode is used to check the playback RF system based on a Betacam/Betacam SP refer to the “For Condition NG”...
Page 173: Others Check Mode (C4)
4-2. TAPE Maintenance Mode (M0) 4-2-5. BETACAM PB CHECK Mode (C3) 4-2-6. OTHERS CHECK Mode (C4) 4-2-6. OTHERS CHECK Mode (C4) For Condition NG Confirm, recheck, and perform the drum (video heads) The C4 : OTHERS CHECK mode has seven menus. cleaning according to the procedures below.
Page 174 4-2. TAPE Maintenance Mode (M0) 4-2-6. OTHERS CHECK Mode (C4) C40 : ROM VERSION C41 : SERIAL NUMBER OTHERS CHECK MODE OTHERS CHECK MODE C40:ROM VERSION C41:SERIAL NUMBER DNW-A100(UC) 10001 SY1 V1.00 SY2 V1.00 SV1 V1.00 SSX V1.00 --- Option Boards --- Component Input(AD-105) The display on the left is one of the displayed examples.
Page 175 http://getMANUAL.com 4-2. TAPE Maintenance Mode (M0) 4-2-6. OTHERS CHECK Mode (C4) 4 The number of errors below that occur during recep- C42 : RS-232C STATUS tion is displayed on the superimpose picture. OTHERS CHECK MODE (This menu fail Parity error C42:RS-232C STATUS to function in Framing error...
Page 176 4-2. TAPE Maintenance Mode (M0) 4-2-6. OTHERS CHECK Mode (C4) C45 : MEMORY CHECK C46 : HOUR METER RESET OTHERS CHECK MODE OTHERS CHECK MODE C45:MEMORY CHECK C46:HOUR METER RESET 0000 0000: E8 FF BD 27 DRUM HOURS 1234 0000 0004: 14 00 BF AF TAPE HOURS 0000 0008: 10 80 03 3C THREAD COUNTER...
Page 177 4-2. TAPE Maintenance Mode (M0) 4-2-6. OTHERS CHECK Mode (C4) C47 : METER HEAD ROOM C48 : PATH MODE SEL OTHERS CHECK MODE OTHERS CHECK MODE C47:METER HEAD ROOM C48:PATH MODE SEL 20dB Switcning PB This menu can change the head room setting of an audio This menu sets the PB mode for confirming and adjusting level meter.
Page 178: Servo Adjust Mode (A0)
4-2. TAPE Maintenance Mode (M0) 4-2-7. SERVO ADJUST Mode (A0) 4-2-7. SERVO ADJUST Mode (A0) A00-01 : SERVO ADJUST The A0 : SERVO ADJUST mode is used to adjust the In the A00-01 : SERVO ADJUST menu, the whole menu servo system of a VTR.
Page 179 4-2. TAPE Maintenance Mode (M0) 4-2-7. SERVO ADJUST Mode (A0) Example of display and operation A000 : A001-A008 ADJ. Example of A001 : S REEL FG DUTY Superimpose picture Time data display area This menu is used to execute the adjustment menus below A000 automatically and continuously.
Page 180 4-2. TAPE Maintenance Mode (M0) 4-2-7. SERVO ADJUST Mode (A0) Example of display and operation A001 : S REEL FG DUTY Example of A001 : S REEL FG DUTY A002 : T REEL FG DUTY A003 : CAPSTAN FG DUTY SERVO ADJUST A001:S REEL FG DUTY A004 : S REEL OFFSET/FRICTION...
Page 181 4-2. TAPE Maintenance Mode (M0) 4-2-7. SERVO ADJUST Mode (A0) (3) Press the MENU button to terminate the menu. A010 : CAPSTAN FREE SPEED (4) To save the adjustment data in the NV-RAM of a This menu is used to perform the automatic adjustment of servo system, execute the SAVE SERVO ADJUST a capstan free speed.
Page 182 4-2. TAPE Maintenance Mode (M0) 4-2-7. SERVO ADJUST Mode (A0) Example of display and operation A011 : RF SWITCHING POS. Superimpose picture Time data display area This menu is used to adjust the RF switching position A0110 SERVO ADJUST automatically or manually. Only the automatic adjustment A011:RF SWITCHING POS.
Page 183 4-2. TAPE Maintenance Mode (M0) 4-2-7. SERVO ADJUST Mode (A0) A005 : T REEL OFFSET/FRICTION For Automatic Adjustment Failure A007 : T REEL TORQUE The circuit in which failure occurred can be traced to some “# T REEL TROUBLE #” is displayed in these menus. degree by the trouble message displayed together when Execute the T reel FG duty adjustment (A002 : T message “# ADJUST INCOMPLETE #”...
Page 184 4-2. TAPE Maintenance Mode (M0) 4-2-7. SERVO ADJUST Mode (A0) Example of display and operation A012 : NV-RAM CONTROL Superimpose picture Time data display area The A012 : NV-RAM CONTROL menu is used to save A0120 SERVO ADJUST A012:NV-RAM CONTROL the servo adjustment data adjusted in the SERVO ADJUST NO OPERATION mode in the NV-RAM of a servo system.
Page 185: Rf Adjust Mode (A1)
http://getMANUAL.com 4-2. TAPE Maintenance Mode (M0) 4-2-8. RF ADJUST Mode (A1) 4-2-8. RF ADJUST Mode (A1) A10 : EQUALIZER(1/2) ..(For DNW-A100/A100P only) The A1 : RF ADJUST mode is used to adjust the RF A11 : EQUALIZER(2/2) system of a VTR....
Page 186 4-2. TAPE Maintenance Mode (M0) 4-2-8. RF ADJUST Mode (A1) Right side display is an example of the adjustment data during the STOP button is pressed. Actually, adjustment data is displayed at the “xx” portion. RF ADJUST MODE RF ADJUST MODE RF ADJUST MODE RF ADJUST MODE A10:EQUALIZER (1/2)
Page 187 4-2. TAPE Maintenance Mode (M0) 4-2-8. RF ADJUST Mode (A1) 3 To perform the automatic adjustment in all channels Description of superimpose picture (circuits) at a time, select ALL. RF ADJUST MODE After the automatic adjustment in all channels (cir- A10:EQUALIZER (1/2) cuits) is completed, “OK”...
Page 188 4-2. TAPE Maintenance Mode (M0) 4-2-8. RF ADJUST Mode (A1) Menu Ordinary adjustment time Tape amount required (Transport mode) A10 : EQUALIZER T About 2 min./ALL, about 15 sec./channel Adjustment time (PLAY) A11 : EQUALIZER T A12 : REC CURRENT T About 7 sec./ALL, about 3 sec./channel Adjustment time (REC) A13 : PLAY PLL...
Page 189 4-2. TAPE Maintenance Mode (M0) 4-2-8. RF ADJUST Mode (A1) Example of display and operation Ex.: ALL is selected in Ex.: ALL is selected in Ex.: ALL is elected in A11 : EQUALIZER (2/2) A13 : PLAY PLL A12 : REC CURRENT. for DNW-A100/A100P.
Page 190 4-2. TAPE Maintenance Mode (M0) 4-2-8. RF ADJUST Mode (A1) (5) Press the SET button. A17 : A10-A16 ALL ADJUST . The automatic adjustment (A12 : REC CURRENT) ....(For DNW-A100/A100P) in a REC system is initiated when the SET button is A17 : A11-A16 ALL ADJUST pressed.
Page 191 4-2. TAPE Maintenance Mode (M0) 4-2-8. RF ADJUST Mode (A1) Example of display and operation Example in DNW-A100/A100P (continued) Superimpose picture Time data display area A17-PUSH RF ADJUST MODE RF ADJUST MODE SET BTN A17:A10-A17 ALL ADJUST A17:A10-A17 ALL ADJUST Auto Adjust (Push SET) Set a blank tape and push SET button for...
Page 192 4-2. TAPE Maintenance Mode (M0) 4-2-8. RF ADJUST Mode (A1) For Condition NG/Automatic Adjustment Failure A1F : NV-RAM CONTROL Confirm in the procedure below when message “Condition The A1F : NV-RAM CONTROL menu is used to save the NG” or “Auto Adjust Failure” is displayed during execu- RF adjustment data adjusted in the RF ADJUST mode in tion of adjustment menus A10 to A17.
Page 193: Audio/Video Adjust Mode (A2)
4-2. TAPE Maintenance Mode (M0) 4-2-8. RF ADJUST Mode (A1) 4-2-9. AUDIO/VIDEO ADJUST Mode (A2) 4-2-9. AUDIO/VIDEO ADJUST Mode (A2) Example of display and operation (In data save) The A2 : AUDIO/VIDEO ADJUST mode is used to adjust Superimpose picture Time data display area the audio and video systems.
Page 194 4-2. TAPE Maintenance Mode (M0) 4-2-9. AUDIO/VIDEO ADJUST Mode (A2) The adjustment menus other than submenus of A23 and A20 : VPR VR menu A24 are used for manual adjustment. AUDIO/VIDEO ADJUST MODE AUDIO/VIDEO ADJUST MODE In the submenus of A23 and menu A24, automatic adjust- A20:VPR VR A20:VPR VR ment (AUTO) or manual adjustment (MANUAL) can be...
Page 195 http://getMANUAL.com 4-2. TAPE Maintenance Mode (M0) 4-2-9. AUDIO/VIDEO ADJUST Mode (A2) A21 : AD VR A22 : AD VR(LOOP) AUDIO/VIDEO ADJUST MODE AUDIO/VIDEO ADJUST MODE AUDIO/VIDEO ADJUST MODE AUDIO/VIDEO ADJUST MODE A21:AD VR A21:AD VR A22:AD VR (LOOP) A22:AD VR (LOOP) Y INPUT LEVEL Y INPUT LEVEL Y INPUT LEVEL...
Page 196 4-2. TAPE Maintenance Mode (M0) 4-2-9. AUDIO/VIDEO ADJUST Mode (A2) Description of superimpose picture A23 : CP VR AUDIO/VIDEO ADJUST MODE AUDIO/VIDEO ADJUST MODE AUDIO/VIDEO ADJUST MODE A231:SDI ENC VCO A23:CP VR A23:CP VR Manual A231:SDI ENC VCO A231:SDI ENC VCO SDI ENC VCO A232:SDI DEC VCO A232:SDI DEC VCO...
Page 197 4-2. TAPE Maintenance Mode (M0) 4-2-9. AUDIO/VIDEO ADJUST Mode (A2) To execute the automatic adjustment Example of display and operation Example of A231 : SDI ENC VCO (except A234) (1) Display “Auto (Push SET Button)” on the superim- Superimpose picture Time data display area pose picture and “PUSH SET”...
Page 198 4-2. TAPE Maintenance Mode (M0) 4-2-9. AUDIO/VIDEO ADJUST Mode (A2) Change of adjustment mode A24 : INPUT CF DETECT The relation between the adjustment mode and display is shown in the table below. AUDIO/VIDEO ADJUST MODE A24:INPUT CF DETECT Manual Adj.
Page 199 4-2. TAPE Maintenance Mode (M0) 4-2-9. AUDIO/VIDEO ADJUST Mode (A2) Example of display and operation Caution during manual adjustment Confirm the adjustment data range in which the SCH status Superimpose picture Time data display area is set to “1” and set the adjustment data to the intermediate MANUAL AUDIO/VIDEO ADJUST MODE value when performing the manual adjustment.
Page 200 4-2. TAPE Maintenance Mode (M0) 4-2-9. AUDIO/VIDEO ADJUST Mode (A2) A25 : DEC VR A26 : DEC VR (LOOP) AUDIO/VIDEO ADJUST MODE AUDIO/VIDEO ADJUST MODE A25:DEC VR A25:DEC VR (LOOP) VIDEO GAIN VIDEO GAIN AGC VIDEO GAIN VIDEO FREQ COMP VIDEO FREQ COMP This menu is used to adjust the composite video input This menu is used to adjust the composite video input...
Page 201 4-2. TAPE Maintenance Mode (M0) 4-2-9. AUDIO/VIDEO ADJUST Mode (A2) Example of display and operation A2F : NV-RAM CONTROL (In data save) The A2F : NV-RAM CONTROL menu is used to save the Superimpose picture Time data display area audio/video adjustment data adjusted in the AUDIO/ NO OPERA AUDIO/VIDEO ADJUST MODE TION...
Page 202: Betacam Pb Adjust Mode (A3)
4-2. TAPE Maintenance Mode (M0) 4-2-10. BETACAM PB ADJUST Mode (A3) 4-2-10. BETACAM PB ADJUST Mode (A3) To save the adjustment data Execute SAVE ALL ADJUST DATA in an A3F : NV- The A3 : BETACAM PB ADJUST mode is used to adjust RAM CONTROL menu.
Page 203 4-2. TAPE Maintenance Mode (M0) 4-2-10. BETACAM PB ADJUST Mode (A3) A33 : DM VR 2 A36 : DM VR 5 BETACAM PB ADJUST MODE BETACAM PB ADJUST MODE A33:DM VR 2 A36:DM VR 5 MAIN METAL-Y-A DO TH METAL-Y MAIN METAL-Y-B DO TH METAL-C MAIN METAL-C-A...
Page 204 4-2. TAPE Maintenance Mode (M0) 4-2-10. BETACAM PB ADJUST Mode (A3) Example of display and operation A3F : NV-RAM CONTROL (In data save) The A3F : NV-RAM CONTROL menu is used to save the Superimpose picture Time data display area Betacam PB adjustment data adjusted in the BETACAM NO OPERA BETACAM PB ADJUST MODE...
Page 205: Disk Maintenance Mode (M1)
http://getMANUAL.com 4-3. DISK Maintenance Mode (M1) 4-3-1. Outline 4-3. DISK Maintenance Mode (M1) The ID number indicated in this section corresponds to the 4-3-1. Outline SCSI ID number. The hard disk drives incorporated into this unit are assigned to ID-0[ID-00] and ID-1[ID-01]. ID- 2[ID-02] and later are assigned to the hard disk drive of a The DISK maintenance mode is used for the maintenance hard disk array unit (the products release is not fixed yet)
Page 206: Error Counter Display Menu (D0)
4-3. DISK Maintenance Mode (M1) 4-3-2. Error Counter Display Menu (D0) 4-3-2. Error Counter Display Menu (D0) Menu operation All error counters in one ID number are superimposed on The D0 : ERROR COUNTER menu is used to display the the video monitor.
Page 207: Device Information Display Menu (D1)
4-3. DISK Maintenance Mode (M1) 4-3-2. Error Counter Display Menu (D0) 4-3-3. Device Information Display Menu (D1) 4-3-3. Device Information Display Menu (D1) Example of display and operation (D0) Superimpose picture Time data display area The D1 : DEVICE INFO menu is used to display the _ID-00_ DISK MAINTENANCE MODE D0:ERROR COUNTER...
Page 208: Hdd Diagnosis Menu (D2)
4-3. DISK Maintenance Mode (M1) 4-3-3. Device Information Display Menu (D1) 4-3-4. HDD Diagnosis Menu (D2) 4-3-4. HDD Diagnosis Menu (D2) Example of display and operation (D1) Superimpose picture Time data display area The D2 : DIAGNOSIS menu is used to measure the _ID-00_ DISK MAINTENANCE MODE D1:DEVICE INFO...
Page 209 4-3. DISK Maintenance Mode (M1) 4-3-4. HDD Diagnosis Menu (D2) To execute the measurement Example of display and operation (1) Turn the search dial in FORWARD (2) direction Superimpose picture Time data display area while pressing the JOG button and change the display D2-DIAGN DISK MAINTENANCE MODE OSIS OFF...
Page 210: Hdd Installation Menu (D3)
4-3. DISK Maintenance Mode (M1) 4-3-5. HDD Installation Menu (D3) 4-3-5. HDD Installation Menu (D3) (2) Turn the search dial in FORWARD (2) direction while pressing the JOG button and display “MARK”. The D3 : INSTALLATION menu is used to install the hard disk drive when replacing an internal hard disk drive.
Page 211: Black File Installation Menu (D4)
4-3. DISK Maintenance Mode (M1) 4-3-5. HDD Installation Menu (D3) 4-3-6. BLACK File Installation Menu (D4) 4-3-6. BLACK File Installation Menu (D4) Example of display and operation (D3) Superimpose picture Time data display area The D4 : BLACK INSTALLATION menu is used when a _ID-00_ DISK MAINTENANCE MODE LA136291...
Page 212 4-3. DISK Maintenance Mode (M1) 4-3-6. BLACK File Installation Menu (D4) To execute the BLACK file installation Example of display and operation (1) Turn the search dial in FORWARD(2) direction while Superimpose picture Time data display area pressing the JOG button and change the display from D4-BLACK DISK MAINTENANCE MODE INS OFF...
Page 213: Zone Configuration Menu (D5)
4-3. DISK Maintenance Mode (M1) 4-3-7. Zone Configuration Menu (D5) 4-3-7. Zone Configuration Menu (D5) Description of superimpose picture DISK MAINTENANCE MODE DISK MAINTENANCE MODE The D5 : ZONE CONFIGURATION menu sets the zone D5:ZONE CONFIGURATION D5:ZONE CONFIGURATION of the hard disk that this unit uses as a current zone. This #INTERNAL (1.5H) INTERNAL...
Page 214 4-3. DISK Maintenance Mode (M1) 4-3-7. Zone Configuration Menu (D5) Change from INTERNAL to EXT (3) Turn the search dial in FORWARD(2) direction while A # mark is also displayed when the current zone is set to pressing the JOG button and change the display from INTERNAL.
Page 215 http://getMANUAL.com 4-3. DISK Maintenance Mode (M1) 4-3-7. Zone Configuration Menu (D5) Example 1 of display and operation Example 2 of display and operation During change from EXT FULL to EXT HALF-1 During ZONE MISMATCH display (change from INTERNAL to EXT HALF-1) Superimpose picture Time data display area Superimpose picture...
Page 216: Disk Cleaning Menu (D9)
4-3. DISK Maintenance Mode (M1) 4-3-8. Disk Cleaning Menu (D9) 4-3-8. Disk Cleaning Menu (D9) To execute the cleaning (1) Turn the search dial in FORWARD (2) direction The D9 : DISK CLEANING menu is used to replace the while pressing the JOG button and change the “OFF” defective sector with a media error with a substitutive display to “ON”.
Page 217 4-3. DISK Maintenance Mode (M1) 4-3-8. Disk Cleaning Menu (D9) Example of display and operation Superimpose picture Time data display area D9-CLEAN DISK MAINTENANCE MODE D9:DISK CLEANING ------ Caution ------- All the user data in the disk will be lost. After executing this.
Page 218: Error Logger Display Mode (M2)
4-4. Error Logger Display Mode (M2) 4-4-1. Outline 4-4. Error Logger Display Mode (M2) TAPE ERROR An error code and error message are recorded as a message 4-4-1. Outline when the error (error codes 01 to 99) related to a VTR and system occurs.
Page 219: Display Mode
4-4. Error Logger Display Mode (M2) 4-4-2. Display Mode 4-4-2. Display Mode Example of display and operation ERROR LOGGER The operation in the ordinary display mode is described (001/003) 001 REEL TROUBLE-1 based on a display example on the superimpose picture. 002 TAPE TENSION ERROR 003 INTERNAL I/F ERROR The log number/total log count is displayed in the second...
Page 220 4-4. Error Logger Display Mode (M2) 4-4-2. Display Mode SET button Example of display and operation A white square mark is displayed in the upper-right ERROR LOGGER position of the superimpose picture when the SET button is (001/003) 001 REEL TROUBLE-1 pressed.
Page 221: Setting Mode
4-4. Error Logger Display Mode (M2) 4-4-3. Setting Mode 4-4-3. Setting Mode (2) To change the setting from ON to OFF, turn the search dial in REVERSE (3) direction while pressing the The setting mode is used to display a menu that limits the JOG button.
Page 222 4-4. Error Logger Display Mode (M2) 4-4-3. Setting Mode Calendar/clock setting Example of display and operation The calendar/clock’s date and time of this unit can be ERROR LOGGER adjusted in the setting mode as described below. (001/003) 001 REEL TROUBLE-1 In a display/operation example on the right, 9:23 of July 002 TAPE TENSION ERROR 003 INTERNAL I/F ERROR...
Page 223: Periodic Maintenance And Inspection
Section 5 Periodic Maintenance and Inspection This section explains about periodic maintenance and how to clean. 5-1. Periodic Maintenance To make the most of the functions, fully realize the performances of this unit and to lengthen the life of the unit, periodic check and parts replacement are recommended. 5-1-1.
Page 224: Periodic Replacement And Check Item Table
5-1. Periodic Maintenance 5-1-2. Periodic Replacement and Check Item Table The replacement time shown in the following table is not the guarantee term of parts. The replacement time of parts varies depending on the operating environment and conditions of the unit. Especially, the pinch roller, cleaners and air filter may be required replacing earlier than replacement period shown in table depending on the degree of their dirt or abrasion.
Page 225 http://getMANUAL.com 5-1. Periodic Maintenance Part No. Name Q’ty Note A-8277-421-A Upper drum DJR-13A-R DNW-A100/A100P A-8277-915-A Upper drum DJR-16A-R DNW-A50/A45/A50P/A45P A-8277-425-A Drum DJH-13A-R DNW-A100/A100P A-8277-914-A Drum DJH-16A-R DNW-A50/A45/A50P/A45P A-8277-462-A Ring 3 assy (RP), brush slip X-3167-281-3 Roller assy, V cleaning 3-182-765-02 Spacer, CR A-8267-398-J Cleaner assy, video head...
Page 226: Hours Meter
5-1. Periodic Maintenance Replace the parts shown in the table below periodically when the threading/ unthreading operation is repeated frequently. Replacement parts Replacement period Part No. Name Q’ty Brake solenoid Every 200,000 times of threading 1-454-417-31 Solenoid, Plunger S tension regulator Every 200,000 times of threading A-8267-795-E Tension regulator assy (RP)
Page 227: Cleaning
5-2. Cleaning 5-2. Cleaning To make the most of the functions, fully realize the performance of this unit, and to lengthen the life of the unit and tape, clean the components often. 5-2-1. Cleaning using Cleaning Tape If the video heads are clogged, clean the video head as the following procedure. Make sure to use the specified cleaning tape.
Page 228 5-2. Cleaning 3. Cleaning Parts < Mechanical Deck Block > Tape guide Capstan AT head Video heads Full-erase head/CTL head Upper drum Tape cleaner Lower drum Cassette support Cassette supports Cassette support Pinch roller Cassette supports < Cassette Compartment > <...
Page 229: Tape Running Surface Of Upper Drum And Video Heads Cleaning
5-2. Cleaning 5-2-3. Tape Running Surface of Upper Drum and Video Heads Cleaning Never contact the rotating drum. Be sure to turn off the power and wait until the drum comes to a complete stop before cleaning. Caution The video heads are the part that can be damaged easily. Be careful not to damage the video heads during cleaning.
Page 230: Tape Running Surface Of Lower Drum And Lead Surface Cleaning
5-2. Cleaning 5-2-4. Tape Running Surface of Lower Drum and Lead Surface Cleaning Caution Be careful not to damage the lower drum (specially lead surface) during cleaning. Pay careful attention when cleaning the edge portion above the lower drum because it is located near the video heads.
Page 231: Stationary Heads Cleaning
5-2. Cleaning 5-2-5. Stationary Heads Cleaning Caution . Be careful not to damage the head surface when cleaning the stationary heads. Tools . Cleaning cloth: 3-184-527-01 . Cleaning fluid: 9-919-573-01 Procedure 1. Clean the tape-running surfaces of the AT head, AT erase head, CTL head, and full-erase head in the vertical direction using a cleaning cloth moistened with a cleaning fluid.
Page 232: Tape Running System And Tape Cleaner Cleaning
5-2. Cleaning 5-2-6. Tape Running System and Tape Cleaner Cleaning The tape cleaner has a sharp edge. Do not touch the edge with bare hands. Pay careful attention when cleaning the tape cleaner. Tools . Cleaning cloth: 3-184-527-01 . Cleaning fluid: 9-919-573-01 Procedure 1.
Page 233: Fan Motors Cleaning
5-2. Cleaning 5-2-7. Fan Motors Cleaning Notice Clean the fan motor on the rear panel often because it accumulates dust easily. The dusty fan motors disturb the air flow through the unit, and a rise in the inside temperature of the unit may badly influence the performance and life of the unit. Tools .
Page 234: Cassette Compartment And Cassette Supports Cleaning
5-2. Cleaning 5-2-8. Cassette Compartment and Cassette Supports Cleaning Notes . Being careful not to apply an excessive force to the compartment block or mirror, clean the cassette compartment. . Do not use an alcoholic chemical in cleaning of the lid and mirror to aviod cracking them.
Page 235: Video Head Tip Protrusion Check
http://getMANUAL.com 5-3. Video Head Tip Protrusion Check 5-3. Video Head Tip Protrusion Check 5-3-1. Head Tip Protrusion Measurement When performing the periodic maintenance or inspection, Preparations for VTR measure the tip protrusion of the video heads using a head tip protrusion measurement gauge to check them for the 1.
Page 236 5-3. Video Head Tip Protrusion Check 7. Turn the adjustment screw clockwise until the dial Setting of Head Tip Protrusion Measurement gauge pointer rotates approximately a half turn. Gauge 8. Turn the outer circumference of the dial gauge to align zero (0) to the pointer.
Page 237 5-3. Video Head Tip Protrusion Check This table is in measure order of the heads. Measurement of Head Tip Protrusion Head tip protrusion (Hr = Hb _ _ _ _ _ Ha) Head Spec. µ name First time Second time .
Page 238: Brush Slip Ring Assembly Removal/Reinstallation
5-3. Video Head Tip Protrusion Check 5-3-2. Brush Slip Ring Assembly Removal/Reinstallation Preparing tools . Torque screwdriver (6 kg.cm) (JB-5251): J-6252-510-A If replacing the brush slip ring assembly, refer to Section 3 . Torque screwdriver’s bit (+2 mm, l = 75 mm): in the maintenance manual part 2, volume-1.
Page 239: Replacement Of Plug-In Boards
DNW in without completing the specified modification to them. Please consult your local Sony Sales Office/Service Center in detail. . Check that the state of 525/625 system is following state before starting the electrical adjustment.
Page 240: Service Action Before/After Plug-In Board Replacement
6-1. Service Overview for Plug-in Board Replacement 6-1-2. Service Action before/after Plug-in Board Replacement List up the service action (except function check) after replacing each plug-in board. Refer to “6-1-3. Pulling out /Insertion of Plug-in Board” for pulling out and insertion of board when Referring section Column of below table is shown “_”.
Page 241: Plug-In Board Pulling Out/Insertion
6-1. Service Overview for Plug-in Board Replacement 6-1-3. Plug-in Board Pulling out/Insertion Turn off the power of DNW and then wait 30 seconds before starting the service operation. Pulling out (1) Remove the upper lid. (Refer to “2-3-1. Upper Lid, (4) Pull up the eject levers on the board to the direction of the arrows.
Page 242: Equipment List
(SONY part No. 8-960-075-01) EQ-56 Recording tape BCT SX series (SONY standard products) EQ-56 If the DNW-A100/A50/A45 is operated on the 625/50 system, the adjustments for the 625/50 system are required at the electrical adjustments after the VPR-17 board replacement. In this time, the composite video monitor for 625/50 system is required to display the maintenance mode screen.
Page 243 (SONY part No. 8-960-075-51) EQ-56 Recording tape BCT SX series (SONY standard products) EQ-56 If the DNW-A100P/A50P/A45P is operated on the 525/60 system, the adjustments for the 525/60 system are required at the electrical adjustments after the VPR-17 board replacement. In this time, the composite video monitor for 525/60 system is required to display the maintenance mode screen.
Page 244: Content Of Alignment Tapes
6-1-5. Content of Alignment Tapes Describes the contents of alignment tapes to be appeared in Section 6. CR5-1B (SONY part No. 8-960-096-41): For DNW-A100/A50/A45 CR5-1B PS (SONY part No. 8-960-096-91): For DNW-A100P/A50P/A45P Time (min. : sec.) Video * * * * * LAU tracks...
Page 245 6-1. Service Overview for Plug-in Board Replacement CR8-1A (SONY part No. 8-960-097-45): For DNW-A100/A50/A45 CR8-1A PS (SONY part No. 8-960-098-45): For DNW-A100P/A50P/A45P Time (min. : sec.) LAU tracks CTL track Video 0:00 - 1 kHz sine wave, 0 VU...
Page 246 6-1. Service Overview for Plug-in Board Replacement SR5-1 (SONY part No. 8-960-075-01): For DNW-A100/A50/A45 SR5-1P (SONY part No. 8-960-075-51): For DNW-A100P/A50P/A45P Time (min. : sec.) Digital video Digital audio CTL track 0:00 - 100% color-bar 1 kHz sine wave, _20 dB FS...
Page 247 <This page is blank.> DNW-A100/A50/A45 DNW-A100P/A50P/A45P...
Page 248: Board Replacement
. Shorting clips (2 pcs.) . Alignment tape(s) For DNW-A100/A50/A45: CR8-1A (SONY part No. 8-960-097-45) For DNW-A100P/A50P/A45P: CR8-1A PS (SONY part No. 8-960-098-45) and CR8-1B PS (SONY part No. 8-960-096-86) 6-2-1. Replacement Procedure . Turn off the POWER switch before starting the replacement.
Page 249: Electrical Adjustments
6-2. APR-12 Board Replacement 6-2-2. Electrical Adjustments Adjustment Items No. Item Adjustment point Notes Preparation Unity level adjustment 1RV101/APR-12(A-3) AUDIO OUTPUT CH1 1RV201/APR-12(E-3) AUDIO OUTPUT CH2 Offset level adjustment 1RV103/APR-12(D-2) TP700/APR-12(G-3) 1RV203/APR-12(G-2) TP700/APR-12(G-3) LAU PB frequency response adjustment 1RV501/APR-12(A-1) AUDIO OUTPUT CH1 (OXIDE) 1RV500/APR-12(A-1) (Audio head dumping adjustment)
Page 250 6-2. APR-12 Board Replacement Setting(Check) of the shorting plugs on the APR-12 board Set the positions of shorting plugs as follows: Ref. No. Item Position COR100 Analog audio CH1 input level COR101 Analog audio CH1 input headroom COR200 Analog audio CH2 input level COR201 Analog audio CH2 input headroom COR300...
Page 251 6-2. APR-12 Board Replacement Setting of the DNW Turn on the power, and set each control panel and connector panel as shown below. However, setting of the connector panel is not needed when the optional kit BKNW-105 is equipped in the DNW.
Page 252 6-2. APR-12 Board Replacement Setting of the setup extend menu . For the DNW-A100/A50/A45 None. . For the DNW-A100P/A50P/A45P Set the ITEM-F01: AUDIO NR IN SP MODE to “SW”. . To display the ITEM-F00 series, turn the search dial while pressing the PLAY button. .
Page 253 6-2. APR-12 Board Replacement 2. Offset Level Adjustment Measuring equipment: Oscilloscope More than 20 minutes should elapse after turning the power on, when this adjustment is performed. (1) Short-circuit TP101/APR-12(B-3) and E100/APR-12(C-3) with a shorting clip. (2) Short-circuit TP201/APR-12(F-3) and E200/APR-12(G-3) with a shorting clip. (3) Connect and set the oscilloscope as follows: CH-1: TP700/APR-12(G-3), DC 5 V/DIV, 2 us/DIV CH-2: TP701/APR-12(G-6), DC 5 V/DIV...
Page 254 6-2. APR-12 Board Replacement 3. LAU PB Frequency Response Adjustment (OXIDE) Measuring equipment: Audio analyzer (dB ratio measurement mode, 80 kHz LPF) CH1 adjustment (1) Connect the input of audio analyzer to AUDIO OUTPUT CH1 connector. However, when the optional kit BKNW-105 is equipped in the DNW, connect the audio analyzer to MONITOR OUTPUT L connector.
Page 255 http://getMANUAL.com 6-2. APR-12 Board Replacement 4. LAU PB Frequency Response Adjustment (METAL) Perform this adjustment for only DNW-A100P/A50P/A45P. Measuring equipment: Audio analyzer (dB ratio measurement mode, 80 kHz LPF) CH1 adjustment (1) Connect the input of audio analyzer to AUDIO OUTPUT CH1 connector. However, when the optional kit BKNW-105 is equipped in the DNW, connect the audio analyzer to MONITOR OUTPUT L connector.
Page 256 6-2. APR-12 Board Replacement 5. LAU Dolby Level Adjustment Measuring equipment: Audio level meter CH1 adjustment (1) Connect the audio level meter to TP501/APR-12(C-1). GND : E500/APR-12(B-1) (2) Playback the 1 kHz, 0 VU portion (0:00 to 2:55) of alignment tape CR8-1A or CR8-1B PS, and perform the level adjustment.
Page 257 6-2. APR-12 Board Replacement 6. LAU PB Level Adjustment Measuring equipment: Audio analyzer (dBm measurement mode, 80 kHz LPF) CH1 adjustment (1) Connect the input of audio analyzer to AUDIO OUTPUT CH1 connector. However, when the optional kit BKNW-105 is equipped in the DNW, connect the audio analyzer to MONITOR OUTPUT L connector.
Page 258 6-2. APR-12 Board Replacement 7. LAU PB Phase Adjustment Measuring equipment: Oscilloscope (X-Y mode) (1) Connect and set the oscilloscope as follows: CH-1: Pin 2 (X) of AUDIO OUTPUT CH1 connector [GND: Pin 1(G)], AC CH-2: Pin 2 (X) of AUDIO OUTPUT CH2 connector [GND: Pin 1(G)], AC However, when the optional kit BKNW-105 is equipped in the DNW, connect CH1 and CH2 to MONITOR OUTPUT L and R connectors respectively.
Page 259: Board Replacement
Always, the audio analyzer should be filtered through 80 kHz LPF. . Oscilloscope: TEKTRONIX 2465B or equivalent . Extension board: EX-556 (SONY part No. A-8277-212-A) . Shorting clip (1 pc.) 6-3-1. Replacement Procedure Turn off the POWER switch before starting the replacement.
Page 260 6-3. APR-13 Board Replacement 0. Preparation Setting(Check) of the shorting plugs on the APR-13 board Set the position of shorting plugs as follows: Ref. No. Item Position COR100 Analog audio CH3 input level COR101 Analog audio CH3 input headroom COR200 Analog audio CH4 input level COR201 Analog audio CH4 input headroom...
Page 261 6-3. APR-13 Board Replacement Setting of the DNW Trun on the power, and set each control panel and connector panel as shown below. REGEN PRESET (Push) PB.EE : Lights LTC INT RECRUN INPUT : ANALOG VIDEO INPUT SELECT AUDIO INPUT/MIXING/MONITOR SELECT TC GENERATOR REMOTE /LOCAL...
Page 262 6-3. APR-13 Board Replacement 1. Unity Level Adjustment 2. Offset Level Adjustment Measuring equipment: Oscilloscope When the optional kit BKNW-105 is equipped in the DNW, “Unity Level Adjustment” is not needed. More than 20 minutes should elapse after turning the Measuring equipment: Audio analyzer power on, when this adjustment is performed.
Page 263: Board Replacement
For DNW-A100/A50/A45: CR5-1B (SONY part No. 8-960-096-41) and CR5-2A (SONY part No. 8-960-097-44) For DNW-A100P/A50P/A45P: CR5-1B PS (SONY part No. 8-960-096-91) and CR5-2A PS (SONY part No. 8-960-098-44) 6-4-1. Replacement Procedure Turn off the POWER switch before starting the replacement.
Page 264: Electrical Adjustments
6-4. DM-89 Board Replacement 6-4-2. Electrical Adjustments Adjustment Items No. Item Adjustment point Remarks Preparation Initial data setting All data of A3 : BETACAM PB ADJUST EQ RF output level adjustment METAL Y A30 : EQ VR : RF GAIN METAL-Y-A TP100/DM-89 A30 : EQ VR : RF GAIN METAL-Y-B METAL C...
Page 265 http://getMANUAL.com 6-4. DM-89 Board Replacement (Continued) No. Item Adjustment point Remarks DM RF output level rough adjustment METAL Y 1RV211/DM-89 TP3/DM-89 METAL C TP7/DM-89 1RV406/DM-89 OXIDE C 1RV407/DM-89 TP7/DM-89 OXIDE Y 1RV212/DM-89 TP3/DM-89 OMC carrier balance adjustment OXIDE Y TP105/DM-89 1RV107/DM-89, 1RV108/DM-89 OXIDE C TP305/DM-89...
Page 266 6-4. DM-89 Board Replacement (Continued) No. Item Adjustment point Remarks 13 RF envelope adjustment TP203/DM-89 1RV205/DM-89 1RV405/DM-89 TP403/DM-89 TH H level A36 : DM VR 5 : ENV-TH-H Set the data to 20 TH L level A36 : DM VR 5 : ENV-TH-L Set the data to 10 Data save A3F : NV-RAM CONTROL...
Page 267 6-4. DM-89 Board Replacement Connection Connect the video signal generator, component waveform monitor, and video monitor as shown below. Video signal generator BLACK REF.VIDEO VIDEO OUTPUT COMPOSITE COMPONENT Component waveform monitor R-Y B-Y 75 Z a : Use the same length cables (0.5 m) Video monitor (terminated with 75 Z)
Page 268 6-4. DM-89 Board Replacement (2) Turn on the power, and set each control panel as shown below. REGEN PB.EE : Lights LTC INT FREE RUN VIDEO INPUT SELECT AUDIO INPUT/MIXING/MONITOR SELECT TC GENERATOR REMOTE /LOCAL CH-1 CH-2 CH-3 CH-4 VITC SDTI MIXING (VIDEO &...
Page 269 6-4. DM-89 Board Replacement (4) Entering the maintenance mode To enter the maintenance mode, press S1101 on the SS-63 board. The operation of the maintenance mode is described as follows: The sub mode and menus of the maintenance mode that are used after replacing the DM-89 board are as shown below.
Page 270 6-4. DM-89 Board Replacement 1. Initial Data Setting (1) Enter A3 : BETACAM PB ADJUST of the maintenance mode. (2) Enter A30 : EQ VR. (3) Set the specified data to all items of A30 : EQ VR. (For setting data, refer to the table below.) (4) To exit A30 : EQ VR, press the MENU button once.
Page 271 6-4. DM-89 Board Replacement (11) Enter A34 : DM VR 3. (12) Set the specified data to all items of A34 : DM VR 3. (For setting data, refer to the table below.) (13) To exit A34 : DM VR 3, press the MENU button once. (14) Enter A35 : DM VR 4.
Page 272 6-4. DM-89 Board Replacement 2. EQ RF Output Level Adjustment Wait for more than 20 minutes after turning on the power, then perform the adjustments. Measuring equipment: Oscilloscope (Band width limit: ON) (1) Enter A30 : EQ VR of the maintenance mode. (2) Connect and set the oscilloscope as follows: CH-1: TP100/DM-89(F-7), AC 100 mV/DIV, 2 ms/DIV, GND: E101/DM-89(F-7)
Page 273 6-4. DM-89 Board Replacement (5) Change the connection of the oscilloscope as follows: CH-1: TP300/DM-89(B-7), GND: E301/DM-89(B-7) Trigger: TP5/DM-89(D-1), GND: E702/DM-89(D-1) (6) METAL C adjustment Playback the flat field signal portion (24:00 to 26:00) of the alignment tape CR5-1B or CR5-1B PS, and perform the adjustment.
Page 274 6-4. DM-89 Board Replacement (11) OXIDE Y adjustment Playback the 75% color-bar signal portion (0:00 to 3:00) of the alignment tape CR5-2A or CR5-2A PS, and perform the adjustment. (DNW-A100/A50/A45: CR5-2A, DNW-A100P/A50P/A45P: CR5-2A PS) Adjust respectively for Y-A and Y-B channels. When watching the Y-A channel, set the trigger of oscilloscope to _ slope.
Page 275 http://getMANUAL.com 6-4. DM-89 Board Replacement (1) Set No.1 and No.3 of S901/DM-89(A-1) to ON (up side). (2) Set S101/DM-89(E-6) and S301/DM-89(A-5) to TEST (left) side. (3) Insert the alignment tape CR5-1B or CR5-1B PS. (STANDBY OFF mode) (DNW-A100/A50/A45: CR5-1B, DNW-A100P/A50P/A45P: CR5-1B PS) METAL Y adjustment [to step (16)] (4) Short-circuit TP4/DM-89(E-1) and E702/DM-89(D-1) with a shorting clip.
Page 276 6-4. DM-89 Board Replacement (9) Enter A33 : DM VR 2 of the maintenance mode. (10) Connect the oscilloscope’s CH-2 to TP3/DM-89(E-1). GND: E702/DM-89(D-1) (11) METAL Y, Main adjustment (i) Adjust the level difference at 12 MHz use 2 MHz as the reference. Adjustment point: A33 : DM VR 2 : MAIN METAL-Y-A B = +8.0 ±...
Page 277 6-4. DM-89 Board Replacement METAL C adjustment [to step (28)] (17) Short-circuit TP5/DM-89(D-1) and E702/DM-89(D-1) with a shorting clip. (18) Connect the output of network analyzer to TP303/DM-89(B-5). GND: E301/DM-89(B-7) (19) Connect the oscilloscope’s CH-2 to TP304/DM-89(B-5). GND: E302/DM-89(B-5) (20) METAL C, Group delay adjustment Adjust the group delay time in 3 MHz through 9 MHz.
Page 278 6-4. DM-89 Board Replacement (25) Enter A34 : DM VR 3 of the maintenance mode. (26) METAL C, Sub adjustment For DNW-A100/A50/A45 Conform that the data value of A34 : DM VR 3 : SUB METAL-C-A and SUB METAL-C-B are 70. If not, set them to 70.
Page 279 6-4. DM-89 Board Replacement (33) Connect the oscilloscope’s CH-2 to TP7/DM-89(C-1). GND: E702/DM-89(D-1) (34) Enter A33 : DM VR 2 of the maintenance mode. (35) OXIDE C, Main adjustment (i) Adjust the level difference at 6 MHz or 7 MHz use 2 MHz as the reference. (DNW-A100/A50/A45: 6 MHz, DNW-A100P/A50P/A45P: 7 MHz) Adjustment point: A33 : DM VR 2 : MAIN OXIDE-C-A B = +1.2 ±...
Page 280 6-4. DM-89 Board Replacement (37) Enter A34 : DM VR 3 of the maintenance mode. (38) Connect the oscilloscope’s CH-2 to TP6/DM-89(D-1). GND: E702/DM-89(D-1) (39) OXIDE C, Sub adjustment (i) Adjust the level difference at 7 MHz use 2 MHz as the reference. Adjustment point: A34 : DM VR 3 : SUB OXIDE-C-A C = +11.0 ±...
Page 281 6-4. DM-89 Board Replacement OXIDE Y adjustment [to step (56)] (42) Turn RV103/DM-89 (E5) counter clockwise fully when is exist. RV103 is not equipped on the DM-89 board of the LOT Nos. 407 and higher. (43) Short-circuit TP4/DM-89(E-1) and E702/DM-89(D-1) with a shorting clip. (44) Connect the output of network analyzer to TP103/DM-89(E-6).
Page 282 6-4. DM-89 Board Replacement (51) Enter A34 : DM VR 3 of the maintenance mode. (52) Connect the oscilloscope’s CH-2 to TP2/DM-89(E-1). GND: E702/DM-89(D-1) (53) OXIDE Y, Sub adjustment (i) Adjust the level difference at 8 MHz use 2 MHz as the reference. Adjustment point: A34 : DM VR 3 : SUB OXIDE-Y-A C = +14.0 ±...
Page 283 6-4. DM-89 Board Replacement 4. Cosine Equalizer Provisional Adjustment . This provisional adjustment explains how to adjust without using the network analyzer. When performed “3. Cosine Equalizer Adjustment” using the network analyzer, this provisional adjustment is not required. . Do not perform this provisional adjustment except an urgent maintenance and the network analyzer is not available.
Page 284 6-4. DM-89 Board Replacement (10) Data save Enter A3F : NV-RAM CONTROL of the maintenance mode, execute “SAVE ALL ADJUST DATA”. (11) Check that the message “Save Complete” is displayed on the video monitor. (12) To exit A3F : NV-RAM CONTROL, press the MENU button once. (13) Set the following RVs on DM-89 board to each specified position as shown figure below.
Page 285 http://getMANUAL.com 6-4. DM-89 Board Replacement 5. DM RF Output Level Rough Adjustment Measuring equipment: Oscilloscope (Band width limit: ON) (1) Connect and set the oscilloscope as follows: CH-1: TP3/DM-89(E-1), AC 100 mV/DIV, 2 ms/DIV, GND: E702/DM-89(D-1) CH-2: TP4/DM-89(E-1), DC 1 V/DIV, GND: E702/DM-89(D-1) Trigger: CH-2, _ slope (2) METAL Y adjustment Playback the flat field signal portion (24:00 to 26:00) of the alignment tape CR5-1B or CR5-1B PS,...
Page 286 6-4. DM-89 Board Replacement (7) OXIDE C adjustment Playback the 75% color-bar signal portion (0:00 to 3:00) of the alignment tape CR5-2A or CR5-2A PS, and perform the adjustment. (DNW-A100/A50/A45: CR5-2A, DNW-A100P/A50P/A45P: CR5-2A PS) Adjustment point: 1RV407/DM-89(C-5) C = 400 ± 40 mV p-p Specification: (8) Stop the playback of the alignment tape CR5-2A/CR5-2A PS.
Page 287 6-4. DM-89 Board Replacement 6. OMC Carrier Balance Adjustment If the spectrum analyzer is not available, perform “7. OMC Carrier Balance Provisional Adjustment”. Measuring equipments: Spectrum analyzer and Oscilloscope (Refer to next figure.) DM-89 Oscilloscope Spectrum analyzer CF : 10 MHz CH-1 AGATE EXIT TRIG...
Page 288 6-4. DM-89 Board Replacement (4) Change the connection of the oscilloscope as follows: CH-1: TP5/DM-89(D-1), GND: E702/DM-89(D-1) CH-2: TP305/DM-89(C-4), GND: E303/DM-89(B-1) (5) OXIDE C adjustment Playback the pulse & bar signal portion (9:00 to 11:00) of the alignment tape CR5-2A or CR5-2A PS, and perform the adjustment.
Page 289 6-4. DM-89 Board Replacement (9) Change the connection of the oscilloscope as follows: CH-1: TP4/DM-89(E-1), GND: E702/DM-89(D-1) CH-2: TP105/DM-89(G-4), GND: E105/DM-89(G-1) (10) METAL Y adjustment Playback the flat filed signal portion (24:00 to 26:00) of the alignment tape CR5-1B or CR5-1B PS, and perform the adjustment.
Page 290 6-4. DM-89 Board Replacement 7. OMC Carrier Balance Provisional Adjustment . This provisional adjustment explains how to adjust without using the spectrum analyzer. When performed “6. OMC Carrier Balance Adjustment” using the spectrum analyzer, this provisional adjustment is not required. .
Page 291 6-4. DM-89 Board Replacement Y adjustment (using the spectrum analyzer) (1) Connect and set the oscilloscope as follows: CH-1: TP4/DM-89(E-1), DC 1 V/DIV, 5 ms/DIV, GND: E702/DM-89(D-1) CH-2: TP501/DM-89(F-4), AC 1 V/DIV, GND: E501/DM-89(E-3) Trigger: CH-1, _ slope (2) Playback the flat filed signal portion (24:00 to 26:00) of the alignment tape CR5-1B or CR5-1B PS, and perform the adjustment.
Page 292 6-4. DM-89 Board Replacement C adjustment (4) Connect and set the oscilloscope as follows: TP8/DM-89(C-1), AC 200 mV/DIV, 10 µs/DIV, GND: E702/DM-89(D-1) CH-2: (5) Playback the color-bar signal portion (14:00 to 17:00) of the alignment tape CR5-1B or CR5-1B PS, and perform the adjustment.
Page 293 6-4. DM-89 Board Replacement 9. Non-liner Output Level Adjustment Measuring equipment: Oscilloscope (1) Connect and set the oscilloscope as follows: TP505/DM-89(E-2), AC 200 mV/DIV, 10 µs/DIV, GND: E501/DM-89(E-3) CH-1: (2) METAL Y adjustment Playback the color-bar signal portion (14:00 to 17:00) of the alignment tape CR5-1B or CR5-1B PS, and perform the adjustment.
Page 294 6-4. DM-89 Board Replacement (4) Change the connection of the oscilloscope as follows: CH-1: TP705/DM-89(D-2), GND: E701/DM-89(D-3) For DNW-A100P/A50P/A45P only, perform steps (5) and (6). (5) METAL C adjustment Playback the 100% color-bar signal portion (14:00 to 17:00) of the alignment tape CR5-1B PS, and perform the adjustment.
Page 295 http://getMANUAL.com 6-4. DM-89 Board Replacement (9) Change the connection of the oscilloscope as follows: CH-1: TP505/DM-89(E-2), GND: E501/DM-89(E-3) (10) OXIDE Y adjustment Playback the 75% color-bar signal portion (0:00 to 3:00) of the alignment tape CR5-2A or CR5-2A PS, and perform the adjustment. (DNW-A100/A50/A45: CR5-2A, DNW-A100P/A50P/A45P: CR5-2A PS) Adjustment point: 1RV504/DM-89(F-1) D = 1.00 ±...
Page 296 6-4. DM-89 Board Replacement 10. PB Frequency Response Adjustment Measuring equipment: Component waveform monitor (terminated with 75 Z) (1) Enter A32 : DM VR 1 of the maintenance mode. METAL Y adjustment [to step (6)] (2) Observe the Y output signal at the component waveform monitor. (3) Playback the multiburst signal portion (8:00 to 11:00) of the alignment tape CR5-1B or CR5-1B PS, and adjust the level at specified frequency part by table below.
Page 297 6-4. DM-89 Board Replacement METAL C adjustment [to step (9)] (7) Observe the R-Y output signal at the component waveform monitor. (8) Playback the multiburst signal portion (8:00 to 11:00) of the alignment tape CR5-1B or CR5-1B PS, and adjust the level at specified frequency part by table below. And check that levels at others are within specifications.
Page 298 6-4. DM-89 Board Replacement OXIDE Y adjustment [to step (13)] (11) Observe the Y output signal at the component waveform monitor. (12) Playback the multiburst signal portion (3:00 to 6:00) of the alignment tape CR5-2A or CR5-2A PS, and adjust the level at specified frequency part by table below. And check levels at others are within specifications.
Page 299 6-4. DM-89 Board Replacement OXIDE C adjustment [to step (16)] (14) Observe the R-Y output signal at the component waveform monitor. (15) Playback the multiburst signal portion (3:00 to 6:00) of the alignment tape CR5-2A or CR5-2A PS, and adjust the level at specified frequency part by table below. And check levels at others are within specifications.
Page 300 6-4. DM-89 Board Replacement 11. Drop-out Compensation Equalizer Adjustment Measuring equipment: Oscilloscope (1) Connect and set the oscilloscope as follows: CH-1: TP203/DM-89(G-7), DC >200 mV/DIV, 2 ms/DIV, GND: E902/DM-89(G-7) CH-2: TP4/DM-89(E-1), DC 1 V/DIV, GND: E702/DM-89(D-1) Trigger: CH-2, _ slope (2) METAL Y adjustment Playback the RF sweep signal portion (0:00 to 2:00) of the alignment tape CR5-1B or CR5-1B PS, and perform the adjustment.
Page 301 6-4. DM-89 Board Replacement (3) Change the connection of the oscilloscope as follows: CH-1: TP403/DM-89(D-6), GND: E303/DM-89(B-1) CH-2: TP5/DM-89(D-1), GND: E702/DM-89(D-1) (4) METAL C adjustment Playback the RF sweep signal portion (0:00 to 2:00) of the alignment tape CR5-1B or CR5-1B PS, and perform the adjustment.
Page 302 6-4. DM-89 Board Replacement 12. DM RF Output Level Adjustment Measuring equipment: Oscilloscope (Band width limit: ON) (1) Connect and set the oscilloscope as follows: CH-1: TP3/DM-89(E-1), AC 100 mV/DIV, 2 ms/DIV, GND: E702/DM-89(D-1) CH-2: TP4/DM-89(E-1), DC 1 V/DIV, GND: E702/DM-89(D-1) Trigger: CH-2, _ slope (2) METAL Y adjustment Playback the flat field signal portion (24:00 to 26:00) of the alignment tape CR5-1B or CR5-1B PS,...
Page 303 6-4. DM-89 Board Replacement (7) OXIDE C adjustment Playback the 75% color-bar signal portion (0:00 to 3:00) of the alignment tape CR5-2A or CR5-2A PS, and perform the adjustment. (DNW-A100/A50/A45: CR5-2A, DNW-A100P/A50P/A45P: CR5-2A PS) Adjustment point: 1RV407/DM-89(C-5) C = 400 ± 40 mV p-p Specification: (8) Change the connection of the oscilloscope as follows: CH-1:...
Page 304 6-4. DM-89 Board Replacement 13. RF Envelope Adjustment Measuring equipment: Oscilloscope (1) Connect and set the oscilloscope as follows: CH-1: TP203/DM-89(G-7), DC 500 mV/DIV, 5 ms/DIV, GND: E902/DM-89(G-7) CH-2: TP4/DM-89(E-1), DC 1 V/DIV, GND: E702/DM-89(D-1) Trigger: CH-2, _ slope (2) Y adjustment Playback the flat filed signal portion (24:00 to 26:00) of the alignment tape CR5-1B or CR5-1B PS, and perform the adjustment.
Page 305 http://getMANUAL.com 6-4. DM-89 Board Replacement (6) Enter A36 : DM VR 5 of the maintenance mode. (7) Setting of the threshold level Confirm the setting data of following items of A36 : DM VR 5. Item of A36 : DM VR 5 Setting data ENV-TH-H ENV-TH-L...
Page 306 6-4. DM-89 Board Replacement 14. Search Picture Adjustment Measuring equipment: Digital voltmeter and Oscilloscope (1) Voltage measurement Playback the color-bar signal portion (14:00 to 17:00) of the alignment tape CR5-1B or CR5-1B PS, and measure the DC voltage level at the following measurement points using the digital voltmeter. (DNW-A100/A50/A45: CR5-1B, DNW-A100P/A50P/A45P: CR5-1B PS) Measurement point Measuring value (fill up)
Page 307 6-4. DM-89 Board Replacement (8) Connect and set the oscilloscope as follows: TP1/DM-89(E-1), DC 1 V/DIV, 10 µs/DIV, GND: E702/DM-89(D-1) CH-1: (9) Gain adjustment Playback the color-bar signal portion (14:00 to 17:00) of the alignment tape CR5-1B or CR5-1B PS in the following modes, and perform the adjustment and check.
Page 308 6-4. DM-89 Board Replacement 15. Guard Band Width Adjustment Measuring equipment: Video monitor (1) Enter A35 : DM VR 4 of the maintenance mode (2) Confirm the setting data of following items of A35 : DM VR 4. Some setting data are different according to the board number suffix (XX of 1-648-541-XX) of DM- 89 board.
Page 309 6-4. DM-89 Board Replacement (11) Playback the 75% color-bar signal portion (0:00 to 3:00) of the alignment tape CR5-2A or CR5-2A PS in the JOG mode. (DNW-A100/A50/A45: CR5-2A, DNW-A100P/A50P/A45P: CR5-2A PS) (12) Turn the search dial until guard band appears at the center on the video monitor screen. (See Figure 1.) (13) OXIDE, Guard band width confirmation Confirm the following specifications.
Page 310 6-4. DM-89 Board Replacement 16. Component Output Level (Betacam) Adjustment Measuring equipment: Component waveform monitor (terminated with 75 Z) (1) METAL Y/C adjustment Playback the color-bar signal portion (14:00 to 17:00) of the alignment tape CR5-1B or CR5-1B PS, and perform the adjustment of each component signal level. (DNW-A100/A50/A45: CR5-1B, DNW-A100P/A50P/A45P: CR5-1B PS) Observation Specifications for...
Page 311 6-4. DM-89 Board Replacement (3) OXIDE Y/C confirmation Playback the 75% color-bar signal portion (0:00 to 3:00) of the alignment tape CR5-2A or CR5-2A PS, and perform the check of each component signal level. If the specification is not satisfied, perform the adjustment of the component output level.
Page 312: Board Replacement
To perform the electrical adjustments, the following equipment and fixtures are required. . Oscilloscope: TEKTRONIX 2465B or equivalent . Composite video monitor (to display of the maintenance mode) . Extension board: EX-377 (SONY part No. J-6269-810-A) (for DM-89 board) . Alignment tapes For DNW-A100/A50/A45: SR5-1 (SONY part No. 8-960-075-01), CR5-1B (SONY part No.
Page 313: Electrical Adjustments
6-5. EQ-56 Board Replacement 6-5-2. Electrical Adjustments Adjustment Items No. Item Adjustment point Notes Preparation All RF system adjustment DNW-A100/A100P: A17 : A10-A16 ALL ADJUST Automatically adjustment DNW-A50/A45/A50P/A45P: A17 : A11-A16 ALL ADJUST Automatically adjustment Data save A1F : NV-RAM CONTROL EQ RF output level adjustment for BETACAM/BETACAM SP PB METAL Y A30 : EQ VR : RF GAIN METAL-Y-A...
Page 314 6-5. EQ-56 Board Replacement Saving the data (1) To set the cursor (* mark) to A?F : NV-RAM CONTROL (A1F or A3F), turn the search dial. (2) Press the SET button once. (3) To set the cursor (* mark) to “SAVE ALL ADJUST DATA”, turn the search dial. (4) Press the SET button once.
Page 315 http://getMANUAL.com 6-5. EQ-56 Board Replacement 1. All RF System Adjustment (1) Insert the alignment tape SR5-1/SR5-1P, then search the alignment tape 00:01:00 in time code. (DNW-A100/A50/A45: SR5-1, DNW-A100P/A50P/A45P: SR5-1P) (2) To enter the maintenance mode, push S1101 (G-1) on the SS-63 board. (3) Enter A17 : A10-A16 ALL ADJUST (A11-A16 ALL ADJUST) in the maintenance mode.
Page 316 6-5. EQ-56 Board Replacement (5) Connect and set the oscilloscope as follows: CH-1: TP100/DM-89(F-7), AC 100 mV/DIV, 2 ms/DIV, GND: E101/DM-89(F-7) CH-2: TP4/DM-89(E-1), GND: E702/DM-89(D-1), trigger channel (6) To perform the alignment tape operation, press the SET button once. (7) Playback the flat field signal portion (24:00 to 26:00) of the alignment tape CR5-1B or CR5-1B PS. (DNW-A100/A50/A45: CR5-1B, DNW-A100P/A50P/A45P: CR5-1B PS) (8) To operate the maintenance mode, press the MENU button once.
Page 317 6-5. EQ-56 Board Replacement (12) Change the connection of the oscilloscope as follows: CH-1: TP300/DM-89(B-7), GND: E301/DM-89(B-7) CH-2: TP5/DM-89(D-1), GND: E702/DM-89(D-1) (13) Playback the flat field signal portion (24:00 to 26:00) of the alignment tape CR5-1B or CR5-1B PS. (DNW-A100/A50/A45: CR5-1B, DNW-A100P/A50P/A45P: CR5-1B PS) (14) To operate the maintenance mode, press the MENU button once.
Page 318 6-5. EQ-56 Board Replacement (23) Change the connection of the oscilloscope as follows: CH-1: TP100/DM-89(F-7), GND: E101/DM-89(F-7) CH-2: TP4/DM-89(E-1), GND: E702/DM-89(D-1) (24) Playback the 75 % color-bar signal portion (0:00 to 3:00) of the alignment tape CR5-2A or CR5-2A PS. (DNW-A100/A50/A45: CR5-2A, DNW-A100P/A50P/A45P: CR5-2A PS) (25) To operate the maintenance mode, press the MENU button once.
Page 319: Board Replacement
6-6. SS-63 Board Replacement 6-6. SS-63 Board Replacement 6-6-1. Setting of DIP Switches For the board replacement, refer to “6-1-3. Pulling out/ . The “ Insertion of Plug-in Board”. ” mark shows the knob position. . For detailed description of each DIP switch, refer to However, the following service operations are required in before and after the SS-63 board replacement.
Page 320: Error Logging Data Clear And Calendar/Clock Setting
6-6. SS-63 Board Replacement 6-6-2. Error Logging Data Clear and Calendar/Clock Setting Clear the another error logging data in NV-RAM on the SS-63 board that is installed, and set the calen- dar/clock to the correct day and time. Clear and set the data as follows after entering the error logger display mode. (1) Enter the error logger display mode.
Page 321 6-6. SS-63 Board Replacement ERR LOG 001 003 ERROR LOGGER (001/003) 001 REEL TROUBLE-1 002 TAPE TENSION ERROR Error logs (For example) 003 INTERNAL I/F ERROR '96 07 03 09:23:00 Calender/Clock (For example) [RESET] [MENU] ERR LOG 001 000 ERROR LOGGER Exit (001/000) '96 07 03...
Page 322: Board Replacement
For the TBC-23 board of the board number 1-648-543-13 or 1-648-543-14, modification is required. Please consult your local Sony Sales Office/Service Center in detail. The board number is indicated on the left margin (A-6) of A side of TBC-23 board.
Page 323: Electrical Adjustments
6-7. TBC-23 Board Replacement 6-7-2. Electrical Adjustments Adjustment Items No. Item Adjustment point Notes Preparation Initial data setting All items of A37 : TBC VR Data save A3F : NV-RAM CONTROL PB video phase confirmation (Note 1) _ VIDEO OUTPUT COMPONENT Y 1RV300/TBC-24 VIDEO OUTPUT COMPONENT A37 : TBC VR : SQ Y RZ (Note 2)
Page 324 6-7. TBC-23 Board Replacement Setting of DNW (1) Set S1100-1 on SS-63 board to ON to treat the extended menu of the setup menu. S1100 SS-63 board Set S1100-1 to ON S1100 on SS-63 Board (2) Turn on the power, and set each control panel as shown below. REGEN LTC INT PB.EE : Lights...
Page 325 http://getMANUAL.com 6-7. TBC-23 Board Replacement (3) Setting of the setup extend menu . For DNW-A100/A50/A45 Set the SUB-ITEMs of ITEM-709 and ITEM-713 as shown below. After adjustments are completed, return the SUB-ITEMs to their previous settings. ITEM SUB-ITEM Setting Previous setting (fill up) 709 : CAV LEVEL FORMAT 1.
Page 326 6-7. TBC-23 Board Replacement 1. Initial Data Setting (1) Enter the maintenance mode, then enter A37 : TBC VR. (2) Set the specified data to all items of A37 : TBC VR. Item of A37 : TBC VR Setting data for DNW-A100/A50/A45 Setting data for DNW-A100P/A50P/A45P SQ Y RZ SQ C RZ...
Page 327 6-7. TBC-23 Board Replacement System SYNC position adjustment [to step (6)] (2) Set the composite waveform/vector monitor as follows: WAVEFORM mode, SWEEP: 2H, MAG ON, INPUT: CH-A, EXT REF (3) Display the H SYNC signal part of CH-A side on the composite waveform/vector monitor, and align 50% position at falling edge readability.
Page 328 6-7. TBC-23 Board Replacement (11)Stop the playback of the alignment tape CR5-1B/CR5-1B PS. Y phase confirmation [to step (24)] (12) Set the component waveform monitor to BOWTIE mode. (13) Playback the bowtie signal portion (17:00 to 19:00) of the alignment tape CR5-1B or CR5-1B PS. (DNW-A100/A50/A45: CR5-1B, DNW-A100P/A50P/A45P: CR5-1B PS) (14) Confirm the deviation A between the center marker and bowtie dip point of CH-1/CH-2 (Y/B-Y).
Page 329 6-7. TBC-23 Board Replacement 3. TBC Y/C Delay Confirmation Measuring equipment: Refer to next figure. (1) Connect the video signal generator, measuring equipment, and video monitor as shown below. Composite video signal generator Component waveform monitor VIDEO INPUT BLACK BURST EXT REF REF VIDEO CH-1 CH-2 CH-3...
Page 330 6-7. TBC-23 Board Replacement Perform following steps (6) through (20) only when the specification in step (4) is not satisfied. METAL adjustment [to step (17)] (6) Playback the bowtie signal portion (17:00 to 19:00) of the alignment tape CR5-1B or CR5-1B PS. (DNW-A100/A50/A45: CR5-1B, DNW-A100P/A50P/A45P: CR5-1B PS) (7) Adjust the deviations of CH-1/CH-2 (Y/B-Y) and CH-1/CH-3 (Y/R-Y).
Page 331 6-7. TBC-23 Board Replacement OXIDE adjustment [to step (20)] (18) Playback the bowtie signal portion (6:00 to 9:00) of the alignment tape CR5-2A or CR5-2A PS. (DNW-A100/A50/A45: CR5-2A, DNW-A100P/A50P/A45P: CR5-2A PS) (19) Adjust the deviations of CH-1/CH-2 (Y/B-Y) and CH-1/CH-3 (Y/R-Y). Adjustment point: 1RV501/TBC-24(C-1) A = 0 ±...
Page 332 6-7. TBC-23 Board Replacement 4. VISC Phase Adjustment Measuring equipment: Composite waveform/vector monitor (Refer to next figure.) (1) Connect the video signal generator, measuring equipment, (VISC adjustment tool,) and video monitor as shown below. Composite waveform/ Composite video vector monitor signal generator VIDEO INPUT BLACK BURST...
Page 333 6-7. TBC-23 Board Replacement VISC phase adjustment [to step (11)] (8) Set the composite waveform/vector monitor as follows: DNW-A100/A50/A45: VECTOR mode, Line select: 11, EXT REF DNW-A100P/A50P/A45P: VECTOR mode, Line select: 8, EXT REF (9) Align the center position of VISC (beam spot) to 0 degree using PHASE knob of the composite waveform/vector monitor.
Page 334: Board Replacement
. Cleaning tape: BCT-5CLN (SONY standard products) . Alignment tapes For DNW-A100/A50/A45: CR5-1B (SONY part No. 8-960-096-41) and CR5-2A (SONY part No. 8-960-097-44) For DNW-A100P/A50P/A45P: CR5-1B PS (SONY part No. 8-960-096-91) and CR5-2A PS (SONY part No. 8-960-098-44) 6-96 DNW-A100/A50/A45 DNW-A100P/A50P/A45P...
Page 335: Replacement Procedure
http://getMANUAL.com 6-8. TBC-24 Board Replacement 6-8-1. Replacement Procedure Turn off the POWER switch before starting the replacement. (1) Remove the upper lid, board retainer (S), and TBC-24 (original) board. (Refer to “6-1-3. Plug-in Board Pulling out/Insertion”.) (2) Disconnect the one disconnected harness (that it connected TBC-24 board and TBC-23 board) from TBC-23 board.
Page 336: Electrical Adjustments
6-8. TBC-24 Board Replacement 6-8-2. Electrical Adjustments Adjustment Items No. Item Adjustment point Notes Preparation Component output level adjustment METAL Y 1RV101/TBC-24 VIDEO OUTPUT COMPONENT METAL C 1RV201/TBC-24 OXIDE Y 1RV504/DM-89 OXIDE C 1RV704/DM-89 (DNW-A100P/A50P/A45P only) A/D clamp DC level adjustment (Note 1) 1RV202/TBC-24 TP202/TBC-24 1RV102/TBC-24...
Page 337 6-8. TBC-24 Board Replacement 0. Preparation Connection Connect the video signal generator, measuring equipment, and video monitor as shown below. Composite video signal generator Component waveform monitor VIDEO INPUT BLACK BURST EXT REF REF VIDEO CH-1 CH-2 CH-3 75 Z 75 Z VIDEO OUTPUT COMPONENT...
Page 338 6-8. TBC-24 Board Replacement (2) Turn on the power, and set each control panel as shown below. REGEN LTC INT PB.EE : Lights FREE RUN VIDEO INPUT SELECT AUDIO INPUT/MIXING/MONITOR SELECT TC GENERATOR REMOTE /LOCAL CH-1 CH-2 CH-3 CH-4 VITC SDTI (VIDEO &...
Page 339 6-8. TBC-24 Board Replacement For Maintenance Mode The operation of the maintenance mode is described as follows: The sub mode and menus of the maintenance mode that are used after replacing the TBC-23 board are as shown below..Entering the maintenance mode M0 : TAPE MAINTENANCE (1) Press S1101 (G-1) on the SS-63 board.
Page 340 6-8. TBC-24 Board Replacement 1. Component Output Level (Betacam) Adjustment Measuring equipment: Component waveform monitor (terminated with 75 Z) (1) METAL Y/C adjustment Playback the color-bar signal portion (14:00 to 17:00) of the alignment tape CR5-1B or CR5-1B PS, and perform the adjustment of each component signal level. (DNW-A100/A50/A45: CR5-1B, DNW-A100P/A50P/A45P: CR5-1B PS) Observation Specifications for...
Page 341 6-8. TBC-24 Board Replacement (3) OXIDE Y/C confirmation Playback the 75% color-bar signal portion (0:00 to 3:00) of the alignment tape CR5-2A or CR5-2A PS, and perform the check of each component signal level. If the specification is not satisfied, perform the adjustment of the component output level.
Page 342 6-8. TBC-24 Board Replacement 2. A/D Clamp DC Level Adjustment “A/D Clamp DC Level Adjustment” is needed for TBC-24 board of the board number suffixes 11 and 12. Measuring equipment: Oscilloscope (1) When the alignment tape is inserted to DNW, eject it. (2) Connect and set the oscilloscope as follows: CH-1: TP202/TBC-24(C-3), 500 mV/DIV, 10 us/DIV, GND: E200/TBC-24(C-1)
Page 343 6-8. TBC-24 Board Replacement 3. VCO Lock-in Range Adjustment Measuring equipment: Oscilloscope (1) Set the following RVs on TBC-24 board to each specified position as shown below. Perform step (1) only when the board number suffix is 11 or 12. RV404 (G-6) RV604 (B-6) (2) Connect and set the oscilloscope as follows:...
Page 344 6-8. TBC-24 Board Replacement 4. FAST VCO Tracking Adjustment Measuring equipment: Video monitor (1) Set the following RVs on TBC-24 board to each specified position as shown below. Specified RV(s) are not equipped according to the model and the board number suffix of TBC-24 board. Suffix RV400 RV402...
Page 345 http://getMANUAL.com 6-8. TBC-24 Board Replacement 5. PB Video Phase Adjustment Perform this adjustment without using the extension board. Measuring equipment: Refer to next figure. (1) Turn off the power of DNW, then wait for 30 seconds. (2) Remove the TBC-24 board from the extension board, then pull out the extension board. (3) Insert the TBC-24 board to DNW.
Page 346 6-8. TBC-24 Board Replacement System SYNC position adjustment [to step (10)] (6) Set the composite waveform/vector monitor as follows: WAVEFORM mode, SWEEP: 2H, MAG ON, INPUT: CH-A, EXT REF (7) Display the H SYNC signal part of CH-A side on the composite waveform/vector monitor, then align 50% position of falling edge for readability.
Page 347 6-8. TBC-24 Board Replacement Y phase confirmation [to step (28)] (16) Set the component waveform monitor to BOWTIE mode. (17) Playback the bowtie signal portion (17:00 to 19:00) of the alignment tape CR5-1B or CR5-1B PS. (DNW-A100/A50/A45: CR5-1B, DNW-A100P/A50P/A45P: CR5-1B PS) (18) Adjust the deviation A between the center marker and bowtie dip point of CH-1/CH-2 (Y/B-Y).
Page 348 6-8. TBC-24 Board Replacement 6. TBC Y/C Delay Rough Adjustment Measuring equipment: Component waveform monitor (Refer to next figure.) (1) Turn off the power of DNW, then wait for 30 seconds. (2) Extend the TBC-24 board with the extension board. (3) Turn on the power.
Page 349 6-8. TBC-24 Board Replacement METAL adjustment [to step (19)] (7) Playback the bowtie signal portion (17:00 to 19:00) of the alignment tape CR5-1B or CR5-1B PS. (DNW-A100/A50/A45: CR5-1B, DNW-A100P/A50P/A45P: CR5-1B PS) (8) Adjust the difference of deviations A and B between each center marker and bowtie dip point of CH- 1/CH-2 (Y/B-Y) and CH-1/CH-2 (Y/R-Y).
Page 350 6-8. TBC-24 Board Replacement 7. Impact Error Offset Adjustment Measuring equipment: Video monitor (1) Playback the color-bar signal portion (26:00 to 28:00) of the alignment tape CR5-1B or CR5-1B PS. (DNW-A100/A50/A45: CR5-1B, DNW-A100P/A50P/A45P: CR5-1B PS) (2) Adjust the following RVs until disappear the drop-out parts (Y DO and C DO) of displaying color- bar on the video monitor.
Page 351 6-8. TBC-24 Board Replacement 8. TBC Y/C Delay Adjustment Perform this adjustment without using the extension board. Measuring equipments: Component waveform monitor (1) Turn off the power of DNW, then wait for 30 seconds. (2) Disconnect the extension harness from TBC-23 board and TBC-24 board. (3) Remove the TBC-24 board from the extension board, then pull out the extension board.
Page 352 6-8. TBC-24 Board Replacement OXIDE adjustment [to step (13)] (11) Playback the bowtie signal portion (6:00 to 9:00) of the alignment tape CR5-2A or CR5-2A PS. (DNW-A100/A50/A45: CR5-2A, DNW-A100P/A50P/A45P: CR5-2A PS) (12) Adjust the deviations A and B between each center marker and bowtie dip point of CH-1/CH-2 (Y/ B-Y) and CH-1/CH-3 (Y/R-Y).
Page 353: Board Replacement
. 75 Z BNC T adapter (1 pc.) . Composite video monitor(s): Sony’s BVM series, PVM series, etc. . For NTSC (525/60 system) and PAL (625/50 system) are required. . Having the switchable monitor of the NTSC and PAL is a convenience.
Page 354: Electrical Adjustments
6-9. VPR-17 Board Replacement 6-9-2. Electrical Adjustments Adjustment Items No. Item Adjustment point Notes Preparation Composite video output level adjustment CH1/CH2 A20 : VPR VR : VIDEO 1/2 LEVEL VIDEO OUTPUT COMPOSITE 1/2 A20 : VPR VR : VIDEO 3 LEVEL VIDEO OUTPUT COMPOSITE 3 Data save A2F : NV-RAM CONTROL...
Page 355 http://getMANUAL.com 6-9. VPR-17 Board Replacement 0. Preparation Setting of DNW (1) Set S1100-1 on SS-63 board to ON to treat the extended menu of the setup menu. S1100 SS-63 board Set S1100-1 to ON. S1100 on SS-63 Board (2) Set the sub control and connector panels as shown below. VIDEO CHROMA SET UP...
Page 356 6-9. VPR-17 Board Replacement (3) Turn on the POWER switch of DNW, then confirm that the operation system is in the standard system. The operation system can confirm with the 525 or 625 indicator on the lower control panel. If DNW is under another system, return it to the standard system with the setup menu ITEM-013 : 525/625 SYSTEM SELECT.
Page 357 6-9. VPR-17 Board Replacement For the maintenance mode The operation of the maintenance mode is described as follows: ..Entering the maintenance mode Press S1101 (G-1) on the SS-63 board. The sub modes and menus of the maintenance mode that are used after replacing the VPR-17 board are as shown below.
Page 358 6-9. VPR-17 Board Replacement 1. Composite Video Output Level Adjustment More than 30 minutes should elapse after turning the power on, then perform the adjustment (confirma- tion). Measuring equipment: Composite waveform monitor . Connection 1 . Connection 2 Composite waveform monitor Composite waveform monitor VIDEO OUTPUT...
Page 359 6-9. VPR-17 Board Replacement (10) Confirmation (Adjustment) Connect the composite waveform monitor to each VIDEO OUTPUT COMPOSITE connector and confirm each white peak level. If the specification is not satisfied, perform the adjustment. . The outputs of VIDEO OUTPUT COMPOSITE 1 and 2 connectors cannot adjust separately. .
Page 360 6-9. VPR-17 Board Replacement 2. Component Video Output Level Adjustment Measuring equipment: Component waveform monitor Video monitor VIDEO OUTPUT (terminated with 75 Z) COMPOSITE 3 Component waveform monitor CH-1 VIDEO OUTPUT CH-3 COMPONENT CH-2 a : Use the same length cables 75 Z (0.5 m) (1) Connect the component waveform monitor and video monitor as shown above figure.
Page 361 6-9. VPR-17 Board Replacement (11) Confirmation (Adjustment) Confirm each specified part’s level of VIDEO OUTPUT COMPONENT outputs. If the specification is not satisfied, perform the adjustment. Observation component Adjustment point (A20 : VPR VR) Specification A = 700 ± 7 mV Y OUTPUT LEVEL B = 700 ±...
Page 362 6-9. VPR-17 Board Replacement 3. Component Video Output (BETACAM) Level Adjustment Perform this adjustment for only DNW-A100/A50/A45. Measuring equipment: Oscilloscope (Band width limit: ON) Video monitor VIDEO OUTPUT (terminated with 75 Z) COMPOSITE 3 Oscilloscope VIDEO OUTPUT COMPONENT CH-1 75 Z BNC T adapter (1) Connect the oscilloscope (and video monitor) as shown above figure.
Page 363 6-9. VPR-17 Board Replacement (12) To exit A20 : VPR VR, press the MENU button once. Perform following steps (13) through (15) when the adjustment in step (11) is performed. (13) Data save Enter A2F : NV-RAM CONTROL, then execute “SAVE ALL ADJUST DATA”. (14) Check that the message “Save Complete”...
Page 364 6-9. VPR-17 Board Replacement 5. Reference Color Frame Pulse Confirmation Measuring equipment: Component waveform/vector monitor and Oscilloscope Composite video Oscilloscope signal generator FRAME REF CH-1 CH-2 BLACK BURST Composite video Composite signal generator waveform/vector monitor GENLOCK EXT REF CH-A BLACK BURST 75 Z VIDEO INPUT REF VIDEO...
Page 365 http://getMANUAL.com 6-9. VPR-17 Board Replacement (10) Connect and set the oscilloscope as follows: Display: ALT mode CH-1: DC 2 V/DIV (Connected SG1’s FRAME REF output) CH-2: TP502/VPR-17 (F-3), DC 2 V/DIV, GND: E501/VPR-17 (G-1) TIME: 10 ms/DIV for DNW-A100/A50/A45 20 ms/DIV for DNW-A100P/A50P/A45P Trigger: CH-1 (11) Turn the signal generator SG2’s SC PHASE control knob clockwise (2) slowly until the waveform of the oscilloscope’s CH-2 (TP502) changes from a to b.
Page 366 6-9. VPR-17 Board Replacement Perform following steps (18) through (21) only when the specification in step (17) is not satisfied. (18) Enter A20 : VPR VR of the maintenance mode. (19) Add/subtract 1 to/from the data value of “REF 1ST FLD DET”. The data increase/decrease is dependent on the angles A and B measured in steps (12) and (15).
Page 367 6-9. VPR-17 Board Replacement 7. Standard System Completion (1) Setup extended menu resetting (in the standard system) For DNW-A100P/A50P/A45P: None. For DNW-A100/A50/A45: Return the SUB-ITEMs of the setup extended menus ITEM-709 and ITEM-713 to their previous settings in the standard system. (2) Turn off the POWER switch of DNW, then wait for 30 seconds.
Page 368 6-9. VPR-17 Board Replacement 9. Composite Video Output Level Adjustment (Another System) Measuring equipment: Oscilloscope (Band width limit: ON) If the composite waveform monitor corresponding to another system is available, be sure to use it. In this case, the connection is the same connection as “1. Composite Video Output Level Adjustment”. .
Page 369 6-9. VPR-17 Board Replacement (11) Confirmation (Adjustment) Connect the Oscilloscope’s CH-1 to each VIDEO OUTPUT COMPOSITE connector and confirm each white peak level. If the specification is not satisfied, perform the adjustment. . The outputs of VIDEO OUTPUT COMPOSITE 1 and 2 connectors cannot adjust separately. .
Page 370 6-9. VPR-17 Board Replacement 10. Component Video Output Level (Another System) Measuring equipment: Component waveform monitor Video monitor VIDEO OUTPUT (terminated with 75 Z) COMPOSITE 3 Component waveform monitor CH-1 VIDEO OUTPUT CH-3 COMPONENT CH-2 a : Use the same length cables 75 Z (0.5 m) (1) Connect the component waveform monitor (and video monitor) as shown above figure.
Page 371 6-9. VPR-17 Board Replacement (11) Confirmation (Adjustment) Confirm each specified part’s level of VIDEO OUTPUT COMPONENT outputs. If the specification is not satisfied, perform the adjustment. Observation component Adjustment point (A20 : VPR VR) Specification A = 700 ± 7 mV Y OUTPUT LEVEL B = 700 ±...
Page 372 6-9. VPR-17 Board Replacement 11. Component Video Output (BETACAM) Level Adjustment (Another System) Perform this adjustment for only DNW-A100P/A50P/A45P. Measuring equipment: Oscilloscope (Band width limit: ON) Video monitor VIDEO OUTPUT (terminated with 75 Z) COMPOSITE 3 Oscilloscope VIDEO OUTPUT COMPONENT CH-1 75 Z BNC T adapter...
Page 373 6-9. VPR-17 Board Replacement (11) Confirmation (Adjustment) Connect the oscilloscope’s CH-1 to each of VIDEO OUTPUT COMPONENT R-Y and B-Y connectors and confirm each output level. If the specification is not satisfied, perform the adjustment. Observation component Adjustment point(A20 : VPR VR) Specification A = 757 ±...
Page 375: Spare Parts
2. Standardization of Parts Some repair parts supplied by Sony differ from those used for the unit. These are because of parts commonality and improvement. Parts list has the present standardized repair parts.
Page 376: Exploded Views
7-2. Exploded Views BVTT3 x 6 BVTT 3 x 6 K3 x 10 BVTT3 x 6 K3 x 10 BVTT 3 x 6 Part No. SP Description Part No. SP Description A-8278-319-E o PANEL ASSY, KEY(for DNW-A100/A100P) 3-184-994-03 o ISR STICKER (S) A-8278-393-D o PANEL ASSY, KEY 3-696-774-02 s KEY TOP, 6x6(BLACK) (for DNW-A50/A50P/A45/A45P)
Page 377 B3 x 6 B3 x 6 W 2.6 B3 x 6 W 2.6 B3 x 6 B3 x 6 PS4 x 14 PS4 x 14 PS4 x 14 Part No. SP Description Part No. SP Description A-8278-584-A o LID ASSY, UPPER 3-696-854-01 o RIGHT CABINET X-3642-018-3 o HANDLE ASSY 3-696-882-02 o COUSHION(L), PC BOARD RETAINER...
Page 378: Plug-In Boards
7-3. Plug-in Boards No. Generic name Part No. SP Description * AD-105 ------------ BKNW-104 APR-12 A-8273-626-A o MOUNTED CIRCUIT BOARD, APR-12 (for DNW-A100/A50/A45) A-8273-785-A o MOUNTED CIRCUIT BOARD, APR-12P (for DNW-A100P/A50P/A45P) APR-13 A-8273-619-A o MOUNTED CIRCUIT BOARD, APR-13 * DEC-65 ------------ BKDW-505 (for DNW-A100/A50/A45) BKDW-506 (for DNW-A100P/A50P/A45P)
Page 379: Packing Materials And Supplied Accessories
7-4. Packing Materials and Supplied Accessories For EK model For UC model DNW-A100P/A50P/A45P DNW-A100/A50/A45 DNW-A100P/A50P/A45P Q’ty Part No. SP Description ! 1-590-910-11 s CORD SET, POWER Q’ty Part No. SP Description 1-774-818-11 o CONNECTOR, SQUARE TYPE (SCSI-3) ! 1-551-812-11 s CORD, POWER (When using SSX-1 board) 1-774-818-11 o CONNECTOR, SQUARE TYPE (SCSI-3) 1-794-076-11 s TERMINATOR (SCSI, LVD)
Page 380: Fixtures List
1-957-071-11 o EXTENSION CABLE SET 3-184-527-01 o CLEANING CLOTH (15 cm x 15 cm) 7-432-114-11 o LOCKING COMPOUND, 1401B (200 g) 7-651-000-10 o SONY GREASE, SGL-601 (50 g) 7-661-018-18 o DIAMOND OIL, NT-68 (50 ml) 7-700-736-01 o L-SHAPED HEXAGONAL WRENCH (d=1.27 mm) 7-700-736-05 o L-SHAPED HEXAGONAL WRENCH (d=1.5 mm)
Page 381: Appendix A Outline Of Format
This technology enables the variable-speed (JOG) playback (_1 to +1 times the normal speed) without using the Sony DNWseries are 1/2-inch component digital VTRs using a new “Betacam SX” format. This unit is a Digital conventional dynamic tracking (DT) head. Moreover, by Video Hybrid Recorder in which the “Betacam SX”...
Page 382 A-2. Recording Format Reference Footprint of Longitudial Track The drum diameter of the Betacam SX VTR is larger than that of the Betacam/Betacam SP VTR as approximately 9%. The footprint of the Betacam SX format has three longitu- Therefore the helical track of the Betacam/Betacam SP dinal tracks (control track, time code track, and AUX format is played back with a time-compressed signal as 9%.
Page 383 A-2. Recording Format Each program track has eight audio sectors in the center. Data Arrangement on Program Tracks A pair of video sector and system data is before the audio Fig. A-2-2 shows the arrangement of data recorded on sectors and the other pair is behind the audio sectors as helical tracks (program tracks).
Page 384 A-2. Recording Format The CTL signal is recorded by approx. 60 Hz (525/60) or Longitudinal Tracks of Betacam SX Format 50 Hz (625/50) rectangular pulse system and controls the As shown in Fig. A-2-1, a control track, time code track, start timing of each field data at the rising edge of the and AUX track are provided in the longitudinal direction pulse.
Page 385: A-3. Head Configuration
http://getMANUAL.com A-3. Head Configuration A-3. Head Configuration During recording : PB A1 and PB B1 operate as the CONFIDENCE head. Fig. A-3-1 shows the configuration of the stationary and . DNW-A50/A50P/A45/A45P : rotary heads in the DNW-A100/A100P, and its top view. However, the rotary heads can be actually viewed only their 8 heads (PB A2, PB A4, PB A6, PB A8 tips from the side of the drum.
Page 386: A-4. Signal Processing
A-4. Signal Processing A-4. Signal Processing A-4-1. Features of Signal Processing A-4-2. Outline of Signal Processing In the Betacam SX format, MPEG2 4:2:2 Profile @Main Reproduction of the Betacam/Betacam SP Tape Level (omitted as MPEG2 4:2:2P@ML hereafter) is employed as the compression system of a video signal. The video and audio signals reproduced from the tape In the MPEG2 4:2:2P@ML coder of this unit, video data is based on a Betacam or Betacam SP format are converted...
Page 387 A-4. Signal Processing External Input Analog or digital video and audio input signals are con- verted into parallel video data and serial audio data, respectively. (Refer to Fig. A-4-2.) Recording on the Tape (Betacam SX Format) Codes are added to the compressed video data and record- ing-level processed audio data for error correction using an ECC encoder.
Page 388 A-4. Signal Processing Playback of Betacam SX Tape SDTI Input (Optionally set to DNW-A100/A100P.) This unit uses multiple-tracing technology in which the An SDTI input signal is output to the 1. SDTI output number of playback heads is larger than that of recording terminal , 2.
Page 389 A-4. Signal Processing Internal Dubbing This unit has a function that dubs data from the Betacam/ Betacam SP/Betacam SX tape to the hard disk drive and from the hard disk drive to the Betacam SX tape. For dubbing from the Betacam SX tape to the hard disk drive, the SDTI format data during tape playback is directly transmitted to the recording system of the hard disk drive.
Page 391: Appendix B Setting Check Sheet
Appendix B Setting Check Sheet It is reccomended to copy these check sheets and write down the setup conditions (switch and so on) under the application. If the setting is changed temporarily by changing operating condition, the setting can be reset easily. It is recommended to attach the sheets to the unit when check, maintenance and repair.
Page 392 Connector panel Switch Factory setting Setting [||] [||] [||] Analog audio input level 600 Z HIGH ON HIGH OFF HIGH ON [||] [||] [||] HIGH ON HIGH OFF HIGH ON [||] [||] [||] HIGH ON HIGH OFF HIGH ON [||] [||] [||] HIGH ON...
Page 393 Short plugs on the board nNever change the setting of Factory use switches. Board Name Ref. No./channel Factory setting Setting APR-12 Audio input level COR100/CH1 +4 dBm/600 Z COR200/CH2 +4 dBm/600 Z Audio input headroom COR101/CH1 20 dB COR201/CH2 20 dB Monitor output level COR302 +4 dBm/600 Z...
Page 394 Switches on the board nNever change the setting of Factory use switches. Board Switch No.: Name Factory setting Setting DM-89 S101 : Y-RF LPF & EQ TEST NORMAL POSITION S102 : Factory use NORMAL POSITION S301 : C-RF LPF & EQ TEST NORMAL POSITION S302 : Factory use...
Page 395 http://getMANUAL.com Board Switch No.: Name Factory setting Setting SS-63 S1102 (for board number suffix -12) Never change the settings of S1102 switch since each switch is set according to the characteristics of the unit. 1, 2 : Model ID switch DNW-A100/A100P DNW-A50/A50P DNW-A45/A45P OFF (OPEN)
Page 396 525/60 For 525/60 system Setup menu nWhen Bank 1 to 4 menu is recalled, the current menu will be overwritten. Be sure to check the current menu first, before recall Bank 1 to 4. Main menu ITEM-000 series: Operational parameter ITEM Factory setting Current...
Page 397 525/60 Extended menu ITEM-100 series: Operational panel parameter ITEM Factory setting Current Bank 1 Bank 2 Bank 3 Bank 4 101: SELECTION FOR SEARCH DIAL ENABLE DIAL 102: MAXIMUM SPEED 104: AUDIO MUTING TIME 105: REFERENCE SYSTEM ALARM 106: CAPSTAN LOCK 107: REC INHIBIT LAMP FLASHING 108: AUTO EE SELECT S/F/R...
Page 398 525/60 ITEM Factory setting Current Bank 1 Bank 2 Bank 3 Bank 4 321: VIDEO SIGNAL FLOW IN DISK TO DISK 322: AUDIO SIGNAL FLOW IN DISK TO DISK 323: EXTERNAL SIGNAL FLOW DELAY 324: VIDEO SIGNAL FLOW IN DISK TO TAPE 325: AUDIO SIGNAL FLOW IN DISK TO TAPE ITEM-400 series: Preroll parameter ITEM...
Page 399 525/60 ITEM-700 series: Video control parameter ITEM Factory setting Current Bank 1 Bank 2 Bank 3 Bank 4 701: SELECTION OF VIDEO DELAY/SYNC DELAY SYNC 703: BLANK LINE SELECT SUB-ITEM 0: All line 12: 12 line BLANK 13: 13 line BLANK 14: 14 line BLANK...
Page 400 525/60 ITEM Factory setting Current Bank 1 Bank 2 Bank 3 Bank 4 714: VIDEO ADJUST RANGE _3~+3 715: VIDEO GAIN CONTROL 800H 716: CHROMA GAIN CONTROL 800H 717: CHROMA PHASE CONTROL 718: SETUP LEVEL 110H 719: SYSTEM PHASE SYNC 720: SYSTEM PHASE SC 721: Y/C DELAY 723: INPUT VIDEO BLANK...
Page 401 525/60 ITEM-800 series: Audio control parameter ITEM Factory setting Current Bank 1 Bank 2 Bank 3 Bank 4 802: DIGITAL AUDIO MUTE IN SHUTTLE MODE 805: AUDIO MONITOR OUTPUT MIXING 806: LEVEL METER SCALE PEAK 0 807: AUDIO OUTPUT PHASE 808: INTERNAL AUDIO SIGNAL GENERATOR 809: AUDIO LEVEL METER DIMMER CONTROL 810: AUDIO EDIT PREVIEW SWITCHER...
Page 402 625/50 For 625/50 system Setup menu nWhen Bank 1 to 4 menu is recalled, the current menu will be overwritten. Be sure to check the current menu first, before recall Bank 1 to 4. Main menu ITEM-000 series: Operational parameter ITEM Factory setting Current...
Page 403 625/50 Extended menu ITEM-100 series: Operational panel parameter ITEM Factory setting Current Bank 1 Bank 2 Bank 3 Bank 4 101: SELECTION FOR SEARCH DIAL ENABLE DIAL 102: MAXIMUM SPEED 104: AUDIO MUTING TIME 105: REFERENCE SYSTEM ALARM 106: CAPSTAN LOCK 107: REC INHIBIT LAMP FLASHING 108: AUTO EE SELECT S/F/R...
Page 404 625/50 ITEM Factory setting Current Bank 1 Bank 2 Bank 3 Bank 4 321: VIDEO SIGNAL FLOW IN DISK TO DISK 322: AUDIO SIGNAL FLOW IN DISK TO DISK 323: EXTERNAL SIGNAL FLOW DELAY 324: VIDEO SIGNAL FLOW IN DISK TO TAPE 325: AUDIO SIGNAL FLOW IN DISK TO TAPE ITEM-400 series: Preroll parameter ITEM...
Page 405 http://getMANUAL.com 625/50 ITEM-700 series: Video control parameter ITEM Factory setting Current Bank 1 Bank 2 Bank 3 Bank 4 701: SELECTION OF VIDEO DELAY/SYNC DELAY SYNC 703: BLANK LINE SELECT SUB-ITEM 0: All line 9: 9,322 line BLANK 10: 10,323 line BLANK 11: 11,324 line BLANK...
Page 406 625/50 ITEM Factory setting Current Bank 1 Bank 2 Bank 3 Bank 4 714: VIDEO ADJUST RANGE _3~+3 715: VIDEO GAIN CONTROL 800H 716: CHROMA GAIN CONTROL 800H 717: CHROMA PHASE CONTROL 718: BLACK LEVEL 110H 719: SYSTEM PHASE SYNC 720: SYSTEM PHASE SC 721: Y/C DELAY 723: INPUT VIDEO BLANK...
Page 407 625/50 ITEM-800 series: Audio control parameter ITEM Factory setting Current Bank 1 Bank 2 Bank 3 Bank 4 802: DIGITAL AUDIO MUTE IN SHUTTLE MODE 805: AUDIO MONITOR OUTPUT MIXING 806: LEVEL METER SCALE PEAK 0 807: AUDIO OUTPUT PHASE 808: INTERNAL AUDIO SIGNAL GENERATOR 809: AUDIO LEVEL METER DIMMER CONTROL 810: AUDIO EDIT PREVIEW SWITCHER...
Page 409: Appendix C Block Diagrams
INDEX Appendix C Block Diagrams INDEX Page OVERALL (1/2) Signal Processing system .......... C-3 OVERALL (2/2) Servo/System Control system ........C-5 DNW-A100/A50/A45 DNW-A100P/A50P/A45P...
Page 411: Overall (1/2
OVERALL (1/2) OVERALL (1/2) Block Diagram Block Diagram DRUM ASSEMBLY BLOCK DNW-A100/A100P ONLY TC-96 ERASE ERASE ERASE CONT OPTION (Either BKDW-505/506 or BKNW-104) DRIVE FULL ERASE TP102 DEC-65 (BKDW-505/506) REC GUARD PB LTC (FROM MS-50) TP201 IC601 IC604 IC606 HEAD CONT REC/PB REC LTC CP-277(1/2)
Page 412 OVERALL (2/2) OVERALL (2/2) Block Diagram Block Diagram IC2500 SYS2(A BUS, D BUS) COMMON CONTROL VPR-17 IC118 IC317 IC905 IC909 IC1302-1306 VIDEO FRAME SUPERIMPOSE IC2501 CONTROL PROCESS CHARACTER CONTROL CN1100 3P (FACTORY USE) CN1901 3P RS-232C (FACTORY USE) IC300 IC302 IC306 IC523 IC714...
Page 413: Overall (2/2
OVERALL (2/2) OVERALL (2/2) Block Diagram Block Diagram MS-50 PTC-59 IC2502 COMMON CASSETTE'S TABS SENSOR CONTROL IC103 NV-RAM TR-79 (EEPROM) SERVO IC112 UNTHREAD END SENSOR IC2503 THREAD END SENSOR 20 MHz T-TENSION SENSOR IC2302 IC301,309 UB MARK IC115 TENSION IC109,110 TR-78 DETECT S-TENSION SENSOR...
Page 415 The material contained in this manual consists of screws, and all other exposed metal parts for AC information that is the property of Sony Corporation and leakage. Check leakage as described below. is intended solely for use by the purchasers of the equipment described in this manual.
Page 416 DNW-A100 (UC) DNW-A100P (CE, UC) DNW-A50 (UC) DNW-A50P (CE, UC) DNW-A45 (UC) Printed in Japan Sony Corporation DNW-A45P (CE, UC) E 2000. 9 08 Communication System Solutions Network Company 3-190-561-06 ©1996...

This manual is also suitable for:

Betacam sx dnw-a100p Betacam sx dnw-a50 Betacam sx dnw-a50p Betacam sx dnw-a45 Betacam sx dnw-a45p Betacam sx bkdw-505 ... Show all

Sony Betacam SX DNW-A100 Maintenance Manual

Quick Links

Related Manuals for Sony Betacam SX DNW-A100

Summary of Contents for Sony Betacam SX DNW-A100

This manual is also suitable for:

Table of Contents
