Quick Start Guide
SSR1300
IN THIS GUIDE
Step 1: Begin | 1
Step 2: Up and Running | 5
Step 3: Keep Going | 15
Step 1: Begin
SUMMARY
In this guide, we provide a simple, three-step path, to quickly
get the Juniper Networks® SSR1300 appliance up and
running on Juniper Mist™ cloud. You'll learn how to install,
power on, and configure basic settings for an AC-powered
SSR1300 appliance.
Meet the SSR1300
The SSR1300 is a 1 U fixed configuration appliance that's ideal for medium data center or campus deployments.
Powered by the Juniper® Session Smart Router (SSR) software, the SSR1300 provides secure and resilient WAN
connectivity.
The SSR1300 has four 1 GbE ports, four 1/10 GbE SFP+ ports, four 10 GbE SFP+ ports, a management port (for Mist
operations), 128 GB of memory, and a 256 GB enterprise-grade solid-state drive (SSD) for storage.
IN THIS SECTION
Meet the SSR1300 | 1
Install the SSR1300 | 2
Power On | 4
Advertisement
Related Manuals for Juniper SSR1300
Summary of Contents for Juniper SSR1300
- Page 1 Powered by the Juniper® Session Smart Router (SSR) software, the SSR1300 provides secure and resilient WAN connectivity. The SSR1300 has four 1 GbE ports, four 1/10 GbE SFP+ ports, four 10 GbE SFP+ ports, a management port (for Mist operations), 128 GB of memory, and a 256 GB enterprise-grade solid-state drive (SSD) for storage.
- Page 2 What's in the Box? | 2 What Else Do I Need? | 2 Rack It | 3 What's in the Box? Along with your SSR1300, you’ll find: • RJ-45 to USB A serial cable • AC power cord (country-specific) • Rack mount kit •...
- Page 3 Use the two M3 flat-head screws to secure the rails. Grasp both sides of the SSR1300 chassis, lift it, and position it in the rack so that the front mounting bracket holes align with the threaded holes in the rack rail.
- Page 4 Power On Now that you’ve installed your SSR1300 in the rack and grounded the chassis, you’re ready to connect it to power. The SSR1300 supports redundant AC power supplies that are pre-installed at the factory. It comes with two AC power supplies preinstalled on the rear of the device.
-
Page 5: Table Of Contents
Assign the SSR1300 to a Site | 14 Now that the SSR1300 is powered on, let's get it up and running on Juniper Mist™ cloud. You"ll need Juniper Mist WAN Assurance subscription and login credentials for the Juniper Mist portal. -
Page 6: Connect Your Ssr1300 To The Mist Cloud
Your SSR1300 uses port MGMT (mgmt-0/0/0) as the default port to contact Mist for zero-touch provisioning (ZTP). It uses port 0/3 (xe-0/0/3) to connect to the LAN. 1. Connect the MGMT port to an Ethernet link that can assign a DHCP address to the SSR1300 and provide connectivity to the Internet and Mist. -
Page 7: Claim Your Appliance
Enter the Mist Claim Code | 8 To add the SSR1300 to your organization's WAN Edge inventory, you'll need to enter the SSR1300 claim information into Mist. The claim label (QR code sticker) on the front panel has the claim information. -
Page 8: Add The Network
3. Click Claim WAN Edges in the upper right portion of the inventory screen. 4. Enter the SSR1300 claim code and click Add. 5. Uncheck the Assign claimed WAN Edges to site check box to place the SSR1300 in the inventory. The SSR1300 is assigned to a site later. -
Page 9: Add Applications
4. Enter the network subnet as 192.168.1.0/24. 5. Click Add. This network is now defined for use across the entire organization, including the template that you'll apply to your SSR1300. Add Applications 1. Select Organization > Applications from the menu on the left. -
Page 10: Create A Template
Create a Template Excellent! Now you have the SSR1300 waiting to be claimed, a network for your LAN, and an Internet application. Next, you need to create a WAN Edge template that ties them all together. Templates are reusable and keep the configuration consistent for every SSR1300 you deploy. - Page 11 3. Enter the interface as xe-0/0/0 to designate it as a WAN port. 4. Click Add. Configure the LAN Port Next, associate your LAN network segment with the appropriate port on the SSR1300. Scroll to the LAN section of the template, and click Add LAN. Video: Add LAN Configuration From the Network dropdown menu, select your network segment to associate it with the LAN port.
- Page 12 Select Server under DHCP to provide DHCP services to endpoints on this network. Give your DHCP server an address pool starting with 192.168.1.100 and ending with 192.168.1.200. Enter 192.168.1.1 as the gateway to be assigned to DHCP clients. Finally, enter the IP addresses for the DNS Servers to be assigned to clients on the network. For example, 8.8.8.8, 8.8.4.4.
- Page 13 Configure Traffic Steering and Application Policies Your template has the WAN and LAN information. Now, you need to tell the SSR1300 how to use the information to connect users to applications. This is done using traffic steering and application policies.
-
Page 14: Assign The Template To A Site
2. Click the Assign to Site button, and select the site where you want the template configuration applied. Assign the SSR1300 to a Site After the SSR1300 is onboarded to the Mist cloud, you'll need to assign it to a site so you can begin to manage the configuration and gather data in Mist cloud. - Page 15 NOTE: Under Manage Configuration, do not check the Manage Configuration with Mist checkbox for the SSR1300 if it is using Session Smart Router software version 5.4.4. This allows the SSR1300 to reach out to the conductor IP address specified when the site was created to receive configuration information.
