Harbor Freight Tools COVERPRO 62860 Owner's Manual

10 ft. x 17 ft. portable garage
Hide thumbs

Advertisement

Quick Links

Owner's Manual & Safety Instructions
Save This Manual
operating, inspection, maintenance and cleaning procedures. Write the product's serial number in the
back of the manual near the assembly diagram (or month and year of purchase if product has no number).
Keep this manual and the receipt in a safe and dry place for future reference.
Email our technical support at: predator@harborfreight.com
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
©
Copyright
2023 by Harbor Freight Tools
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
Tools required for assembly and service may not be included.
Keep this manual for the safety warnings and precautions, assembly,
WARNING! TO PREVENT SERIOUS
INJURY: Do not start or operate any internal
combustion engine inside or near Shed.
Vehicle not included.
Visit our website at: http://www.harborfreight.com
®
. All rights reserved.
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
23b

Advertisement

loading

Related Manuals for Harbor Freight Tools COVERPRO 62860

Summary of Contents for Harbor Freight Tools COVERPRO 62860

  • Page 1 No portion of this manual or any artwork contained herein may be reproduced in Failure to do so can result in serious injury. any shape or form without the express written consent of Harbor Freight Tools. Diagrams within this manual may not be drawn proportionally. Due to continuing SAVE THIS MANUAL.

  • Page 2: Table Of Contents

    Table of Contents Safety ............3 Maintenance ..........14 Specifications ..........4 Parts List and Diagram ......18 Assembly ............ 4 Warranty ............ 20 WARNING SYMBOLS AND DEFINITIONS This is the safety alert symbol. It is used to alert you to potential personal injury hazards.

  • Page 3: Safety

    Do not use grill, heater, If unreadable or missing, contact or ignition sources inside or near cover. Harbor Freight Tools for a replacement. 5. Do not allow snow, rainwater or debris to accumulate or pool on cover. SAVE THESE INSTRUCTIONS.

  • Page 4: Specifications

    Specifications Overall Dimensions 10′ W x 17′ L x 9′ 2" H Center Height 9′ 2" Side Height 6′ 5" Pole Tubing Diameter 1.27" Assembly Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this manual including all text under subheadings therein before set up or use of this product. Note: For additional information regarding the parts listed in the following pages, refer to Parts List and Diagram on page 18.
  • Page 5 Roof Frame Assembly Note: Much of this product’s assembly uses slip fit construction. Nut and Bolt connections are required during proper assembly. Line up all holes on tubes and connectors. Insert Bolt through hole and secure with Nut installed on the other end. Make sure all parts seat completely and securely. A rubber mallet (sold separately) can be used to gently tap parts in place to ensure a tight fit.
  • Page 6 3. Assemble a roof side rail using a 3-Way Side Connector B (A2), three Rails (4) with 4-Way Side Connectors (B1) between them, and then a 3-Way Side Connector A (A1) on the other end (see Figure D). Align holes and insert six M8x45 Round Head Bolts (20) and secure with Wing Nut for all Side Connectors.
  • Page 7 Foot, Leg, and Stud Assembly 1. Assemble a Foot (7) to the bottom 2. Attach Corner Leg (6) to the bottom of each Center Stud (1): of each Corner Stud (2): a. Place a Foot onto the bottom of the Center Stud. a.
  • Page 8 Stud Installation 1. With assistance, raise one side of the roof assembly. 2. Install the Center Studs (1) into the 4-Way Side Connectors (B1), and the Corner Studs (2) into the 3-Way Side Connectors A/B (A1, A2) with the Corner Legs (6) facing inward, align holes and insert four M8x45 Round Head Bolts (20) and secure with Wing Nut as show in Figure G.
  • Page 9 Anchoring Frame TO PREVENT SERIOUS INJURY: Contact local utility companies to ensure that the installation area is free of pipes, cables, and other hazards BEFORE installing anchors or choosing installation area. 1. Position the frame in the desired installation location. 3.
  • Page 10 Securing Ratchet Tie-Downs Note: Use these instructions for installing 2. Insert the S-hook of the Ratchet into Door, Back, and Roof Cover. the hole in the Corner Leg (6). 1. Thread the strap through the Ratchet’s (8) spindle as far as it will go. Figure L: Inserting Hook into Corner Leg 3.
  • Page 11 Door and Back Cover Installation Note: When installing Door and Back Cover, ensure 2. Disconnect the Rail (4) from the that pre-installed straps are not pulled out of Hem. 3-Way Ridge Connector (A), and place the gap at the top center of the Door Cover around 1.
  • Page 12 Roof Cover Installation 1. Lay the Roof Cover (15) on the ground, next to 2. Slide two Bottom Rails (5) into the the frame, so that the three inside pockets for the middle openings of the pocket. opposite side is facing up as shown in Figure R. 3.
  • Page 13 8. After installing roof cover, insert three Bottom 10. Attach Bottom Rails to the Corner Studs (2) Rails (5) into the fabric tubes on each side using 3-Way End Rail Clamps (9), Bolts of the Roof Cover as shown in Figure T. and Nuts (13), and to the Center Studs (1) with 4-Way Center Rail Clamps (10), as shown in Figure V.

  • Page 14: Maintenance

    Maintenance Procedures not specifically explained in this manual must be performed only by a qualified technician. TO PREVENT SERIOUS INJURY FROM PRODUCT FAILURE: Do not use damaged products. If damage is noted, have the problem corrected before further use. MONTHLY, inspect the general condition of the Portable Garage. Check for: •...
  • Page 15 Cleaning 1. Immediately remove any accumulated 2. PERIODICALLY, clean cover with mild debris from the cover with a broom, mop, soap and water. DO NOT use bleach or other soft-sided instrument from the or harsh abrasive products. outside. DO NOT use sharp instruments. Item 62860 For technical questions, please call 1-888-866-5797.
  • Page 16 Record Product’s Serial Number Here: Note: If product has no serial number, record month and year of purchase instead. Note: Some parts are listed and shown for illustration purposes only, and are not available individually as replacement parts. Specify UPC 193175507211 when ordering parts. Page 16 For technical questions, please call 1-888-866-5797.
  • Page 17 PLEASE READ THE FOLLOWING CAREFULLY THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT.

  • Page 18: Parts List And Diagram

    Parts List and Diagram Parts List Note: Individual part illustrations not to scale. Part Description Illustration Part Description Illustration 3-Way Ridge 3-Way End Connector Rail Clamp 3-Way Side 4-Way Center Connector A Rail Clamp 3-Way Side 11-1 Anchor Connector B 4-Way Ridge 11-2 Cable - 1′...
  • Page 19 Assembly Diagram 4 20 5 13 11-1 11-2 11-3 11-1 11-3 11-1 11-1 11-2 11-3 11-2 11-2 11-3 Item 62860 For technical questions, please call 1-888-866-5797. Page 19...

  • Page 20: Warranty

    Limited 90 Day Warranty Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards, and warrants to the original purchaser that this product is free from defects in materials and workmanship for the period of 90 days from the date of purchase.
