- Page 1 Quick Start Guide MSO/UPO3000E Series Oscilloscope...
-
Page 2: Copyright Information
UNI-T is the registered trademark of Uni-Trend Technology (China) Co., Ltd. Document Version MSO/UPO300020221130-V1.00 Statement UNI-T products are protected by patent rights in China and foreign countries, including issued and pending patents. UNI-T reserves the rights to any product specification and pricing changes. -
Page 3: Safety Requirements
Users must follow the following conventional safety precautions in operation, service and maintenance of this device. UNI-T will not be liable for any personal safety and property loss caused by the user’s failure to follow the following safety precautions. This device is designed for professional users and responsible organizations for measurement purposes. - Page 4 Quick Start Guide MSO/UPO3000E Series Oscillosc ope “Note” sign is present, all conditions must be met before this device will function properly. Alternating current of device. Please check the region’s voltage range. Direct current device. Please check the region’s voltage range. Groundin Frame and chassis grounding terminal.
- Page 5 Quick Start Guide MSO/UPO3000E Series Oscillosc ope This environment-friendly use period (EFUP) mark indicates that dangerous or toxic substances will not leak or cause damage within this indicated time EFUP period. The environment-friendly use period of this product is 40 years, during which it can be used safely.
- Page 6 Please use power fuse of specified specification. If the fuse needs to be Power fuse replaced, it must be replaced by maintenance personnel authorized by UNI-T to replace the fuse that meets the specified specifications. There are no components available to operators inside. Do not remove the Disassembly and protective cover.
-
Page 7: General Inspection
It is recommended to inspect the instrument follow the steps below before using the MSO/UPO3000E series for the first time. (1) Check for Damages caused by Transport If the packaging carton or the foam plastic cushions are severely damaged, please contact the UNI-T distributor of this product immediately. (2) Check Attachment Please check appendix for the list of accessories. -
Page 8: Before Use
UNI-T or local distributors of this product. If the equipment is damaged due to shipping, please keep the packaging and notify both the transportation department and UNI-T distributors, UNI-T will arrange maintenance or replacement. 3.2 Before Use To perform a quick verification of the instrument's normal operations, please follow the steps below: (1) Connect to the Power Supply The power supply voltage range is from 100 VAC to 240 VAC, the frequency range is 50 Hz to 60 Hz. - Page 9 Quick Start Guide MSO/UPO3000E Series Oscillosc ope match the probe and the input channel. Probes that are not compensated may lead to measurement errors or mistake. If need to adjust the probe compensation, please follow the following steps: Set the attenuation coefficient in the probe menu and the switch on the probe 10x, and connect the ...
-
Page 10: Front Panel
Quick Start Guide MSO/UPO3000E Series Oscillosc ope 4. Front Panel Figure 3 Front Panel Table 1 Front Panel Description Description Factory setting, LA, AWG, Screen display area protocol decoding Multipurpose knob Trigger control (TRIGGER) Recording waveform Horizontal control (HORIZONTAL) Jog dial knob Analog channel input port Function menu Vertical control (VERTICAL) -
Page 11: Rear Panel
Quick Start Guide MSO/UPO3000E Series Oscillosc ope Rear Panel Figure 4 Rear Panel Table 2 Rear Panel Description Description EXT Trig port AUX Out and arbitrary waveform AC Power Input Socket signal output VIDEO Out Power Switch USB Device port Safety Lock User Interface Figure 5 User Interface... -
Page 12: Touch Screen
Quick Start Guide MSO/UPO3000E Series Oscillosc ope Table 3 User Interface Description Description Trigger status identification System time Time base scale USB DEVICE icon Sampling rate/storage depth CH4 state icon Waveform indicator CH3 state icon Waveform trigger position CH2 state icon Horizontal displacement CH1 state icon Trigger status... - Page 13 Quick Start Guide MSO/UPO3000E Series Oscillosc ope 7.2 Squeeze Squeeze two fingers together or separate. Squeeze gesture can zoom out or zoom in the waveform. If the waveform need to zoom out, squeeze two finger together and then slide away; If the waveform need to zoom out, separate two fingers and then squeeze two fingers together as shown in Figure 8.
- Page 14 Quick Start Guide MSO/UPO3000E Series Oscillosc ope Select “Area A”: Drawing the area of trigger area A; Open trigger area A; Open “trigger area” menu. Select “Area B”: Drawing the area of trigger area B; Open trigger area B; ...
-
Page 15: Operation Menu
Quick Start Guide MSO/UPO3000E Series Oscillosc ope automatically adjust the delay on horizontal direction at a constant speed according to the user-defined, it is convenient for user to observe the waveform. Press the guide key on the front panel, it can adjust to play forward, stop or backward. When in guiding, press Multipurpose knob can also stop the guide. -
Page 16: Remote Control
After completing the above steps, restart the oscilloscope. If the instrument still cannot work, please contact UNI-T. (2) After signal acquisition, signal of waveform does not appear on the screen. Check whether BNC port is connected properly. - Page 17 Appendix Contact Us If the use of this product has caused any inconvenience, if you in mainland China, you can contact UNI-T company directly. Service support: 8am to 5.30pm (UTC+8), Monday to Friday or via email. Our email address is infosh@uni- trend.com.cn...
