Seagate HAWK 2 ST12400N Installation Manual

Hide thumbs Also See for HAWK 2 ST12400N:
Table of Contents

Advertisement

Quick Links

Download this manual
. . . . . . . . . . . . . . . . . . . . . . . . . . .
HAWK 2 Family:
. . . . . . . . . . . . . . . . . . . . . . . . . . .
ST12400N/ND/NC
. . . . . . . . . . . . . . . . . . . . . . . . . . .
ST11900N/ND/NC
. . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation Guide
. . . . . . . . . . . . . . . . . . . . . . . . . . .

Advertisement

Table of Contents
loading

Related Manuals for Seagate HAWK 2 ST12400N

Summary of Contents for Seagate HAWK 2 ST12400N

  • Page 1 ......HAWK 2 Family: ......ST12400N/ND/NC .

  • Page 2: Table Of Contents

    Drive specifications ..........14 Initial set-up information ........17 Drive configuration..........23 Drive installation ..........33 Drive Setup ............37 © 1994 Seagate Technology, Inc. All rights reserved Publication Number: 77767451, Rev. C. March 1994 Seagate ® , Seagate Technology ®...

  • Page 3: Introduction

    Hawk 2 Family Installation Guide, Rev. C Introduction Before attempting any installation, please read through all applicable sections of this document, including all warnings and cautions. Warning. This equipment generates, uses, and can radiate radio frequency energy and if not installed in accordance with these instruc- tions, may cause interference to radio com- munications.

  • Page 4: Before You Begin

    Hawk 2 Family Installation Guide, Rev. C The physical design characteristics of the drive(s) described herein, serve to minimize EMI radiation when installed in an enclosure that provides reason- able shielding. As such, the drive(s) are capable of meeting the Class B limits of the FCC Rules and the Regulations of the Canadian Department of Communi- cations.
  • Page 5 Discrepancies or damage should be reported to the shipping company. • When transporting or shipping a drive or system, please ensure that they are correctly packed in original Seagate approved (or equivalent) container and shipped via an air-ride carrier experienced in handling computer equipment.
  • Page 6 Hawk 2 Family Installation Guide, Rev. C Caution. The circuit assemblies and components con- tained in this equipment can be degraded or destroyed by Electrostatic Overstress (EOS) or by Electrostatic Discharge (ESD). Static electrical charges can accumulate quickly on personnel, clothing and synthetic materials.
  • Page 7 4. The power supply must satisfy the safety require- ments for SELV (Safety Extra Low Voltage) cir- cuits. 5. Service is to be provided by trained Seagate ser- vice personnel. 6. The incorporation of the disc drives listed in this...
  • Page 8 3. Die Versorgungsspannungen werden im Kapitel 1.0 (Produkt Information) gezeigt. 4. Die Versorgungsspannung muss SELV entspre- chen. 5. Alle Arbeiten dürfen nur von ausgebildetem Seagate Service-Personal durchgefürhrt werden. 6. Der Einbau des Drives muss den Anforderungen gemäss DIN VDE 0805/05.90 oder EN60950: 1988...

  • Page 9: Installation Overview

    Hawk 2 Family Installation Guide, Rev. C Installation Overview Installation of the drive can be divided into distinct phases as outlined below. Some of these may not be applicable to your particular installation requirements. Refer to the individual drive installation sections for specific information on your drive model.
  • Page 10 If an installed drive is low-level formatted, all user data stored on the drive will be lost. Note. Seagate Technology assumes no liability for lost user data. • Partitioning and high level formatting: A drive can be sub-divided into "partitions"...

  • Page 11: Product Repair Information

    Hawk 2 Family Installation Guide, Rev. C Product repair information Service requirements The special facilities required for the manufacture of these drives generally prohibit repair in the field. If problems occur during installation, please contact your supplier for assistance. Do not attempt to disassemble or repair.

  • Page 12: Shipping

    Shipping: When transporting or shipping a drive, a Seagate approved container must be used. Keep your original box. They are easily identified by the Seagate Approved Package label. Shipping a drive in a non- approved container voids the drive warranty.

  • Page 13: Technical Support Services

    . Technical support services Please contact your dealer for technical support and installation troubleshooting. Product Technical Sup- port is available for all Seagate products by calling the SeaFAX, SeaFONE or SeaBOARD services. These are toll calls. SeaFAX: 408/438-2620...
  • Page 14 This service is available from 8:00 AM to 5:00 PM PST, Monday through Friday. SeaBOARD: The Seagate Technical Support Bulletin Board System (BBS) is available 24 hours a day, 7 days a week. A modem is required to access this service. The commu- nications software must be set for eight data bits, no parity and one stop bit (8N1).
  • Page 15 Hawk 2 Family Installation Guide, Rev. C With this service you can access: • Specifications and jumper configurations for all Seagate products. • Reprints of Seagate documentation. • A directory of information and helpful utilities that you can download to your own computer. Modem...

  • Page 16: Drive Specifications

    Hawk 2 Family Installation Guide, Rev. C Drive specifications Product Hawk 2 Family Information ST12400N/NC ST12400ND Interface [7] SCSI-2 Fast SCSI-2 Fast Cache Type Multi-segmented, 256 Kb Capacity MB Unformatted 2537 2537 Formatted [1] 2148 2148 Cylinders 2621 2621 Heads Sectors/track (Avg.) Recording method RLL (1,7)
  • Page 17 Hawk 2 Family Installation Guide, Rev. C Product Hawk 2 Family Information ST11900N/NC ST11900ND Interface [7] SCSI-2 Fast SCSI-2 Fast Cache Type Multi-segmented, 256 Kb Capacity MB Unformatted 2003 2003 Formatted [8] 1700 1700 Cylinders 2621 2621 Heads Sectors/track (Avg.) Recording method RLL (1,7) RLL (1,7)
  • Page 18 Hawk 2 Family Installation Guide, Rev. C Notes. [1] Standard Hawk 2 units are factory formatted with 512 data bytes per sector with twelve spare sectors per cylinder and 2 cylinders at inner tracks re- served for spares in addition to capacity listed. [2] Does not Include on-board controller overhead.

  • Page 19: Initial Setup Information

    Hawk 2 Family Installation Guide, Rev. C Initial setup information For the initial setup connect the cables, set the SCSI bus address and remove, install, or leave as is the SCSI I/O line terminator resistor packs. These procedures are described in paragraphs following. Before continu- ing, note whether drive model number letter suffix contains N, ND or NC.
  • Page 20 Hawk 2 Family Installation Guide, Rev. C SCSI address selection On "N/ND" drives, make sure that the SCSI bus ad- dress jumper(s) are properly set for the bus address assigned to the drive. See figures at beginning of Section 3 showing the bus address select header and the jumper configurations that select addresses 0 through 7.
  • Page 21 PCB. The user, systems integrator or system manufacturer must provide some external means of I/O line termination. Read/write head auto-park Seagate disc drives described herein park the heads automatically at power off. This feature requires no operator intervention.
  • Page 22 Hawk 2 Family Installation Guide, Rev. C Optional parity bit enable Some systems require parity bit checking. Consult the system documentation for the specific requirements. See figures in Section 3 for location of Parity Bit Enable jumper. Jumper-on enables parity reporting by the SCSI bus.
  • Page 23 Hawk 2 Family Installation Guide, Rev. C Power +12V +12V ret + 5V ret + 5V DC Power Connector Pin 1 I/O Terminator Module ("N" models only) Pin 1 (not removable) SCSI I/O Connector Pin 1 End "NC" model drives have a single, 80 pin I/O connector that also provides DC power.
  • Page 24 Hawk 2 Family Installation Guide, Rev. C 80 Pin SCSI I/O Connector Pin 1 Figure 1b. "NC" model drive physical interface (80 pin I/O and DC power connector)

  • Page 25: Drive Configuration

    Hawk 2 Family Installation Guide, Rev. C Drive configuration Each disc drive has option select header connectors on the sides and front where jumper plugs are installed to select the way that the drive is to be configured or to select its ID on the I/O bus.
  • Page 26 Hawk 2 Family Installation Guide, Rev. C SCSI I/O Connector See Figure 2b Pin 1 Pin 1 Drive with HDA up, Drive Front PCB down, viewed from front Pin 1 DC Power Connector A 2 A 1 A 0 Pin 1 SCSI ID = 0 Jumper Positions...
  • Page 27 Hawk 2 Family Installation Guide, Rev. C Side View of Drive Pin 1 1 2 3 SCSI I/O Connector A 0 A 1 A 2 Pin 1 Pin 1 SCSI ID = 0 SCSI ID = 1 Drive Front SCSI ID = 2 SCSI ID = 3 DC Power SCSI ID = 4...
  • Page 28 Hawk 2 Family Installation Guide, Rev. C Pin 1 Drive with HDA up, Drive Front PCB down, viewed from front 80 Pin SCSI I/O Connector Pin 1 A 2 A 1 A 0 Pin 1 SCSI ID = 0 Jumper Positions SCSI ID = 1 Reserved...
  • Page 29 Hawk 2 Family Installation Guide, Rev. C Notes for Figure 2a, 2b and 2c: [1] Notes explaining the functions of the various jumpers on jumper header connectors J2, J5 and J6 are given below in left to right order of jumper position.
  • Page 30 Hawk 2 Family Installation Guide, Rev. C J2 Jumper Installation Jumper Function Description Off/On Reserved. Default is no jumper installed. Spindle starts immediately after power up - Default setting. Drive spindle does not start until Start Unit command received from host. Spindle Startup is delayed by SCSI ID times 12 seconds after power is applied, i.e., drive 0 spindle starts immediately when DC power...
  • Page 31 Hawk 2 Family Installation Guide, Rev. C J2 Jumper Installation Jumper Function Description With the jumper installed, the On-board (non- removable) terminator circuits are enabled (connected to the I/O lines). Default is jumper installed only on "N" models and "NC" mod- els having factory installed terminator mod- ule U5.
  • Page 32 Hawk 2 Family Installation Guide, Rev. C TP Position A This horizontally positioned jumper across the two TP positions nearest PCB edge, connects terminator power from SCSI bus I/ O pin 26 to the drive's internal terminators (for single-ended I/O only). See above explanations for TP jumpers.
  • Page 33 Hawk 2 Family Installation Guide, Rev. C J6 Jumper Installation Jumper Function Description 1,2,3 Drive ID on SCSI bus. Either J5 or J6 (optional) may be used to select drive ID. Both should not be used at the same time, because at some future time when the ID is changed the user could fail to configure both J5 and J6 the same.
  • Page 34 Hawk 2 Family Installation Guide, Rev. C Sync Interface REFIND + Master Sync Source Spindle Host Control (or other drive) Drive 1 SCSI Bus System Spindle Interface Control J1 37 Drive 2 Spindle Control J1 37 Drive n [1] Configuration select header. See Figure 2. [2] Applies to "NC"...

  • Page 35: Drive Installation

    Hawk 2 Family Installation Guide, Rev. C Drive installation This section describes the physical mounting of the drive in the host cabinet and the logical installation as a system member, which is called drive setup. Disc drive mounting Do not touch the connector pins or any PCB compo- nents without observing static-discharge precautions.
  • Page 36 Hawk 2 Family Installation Guide, Rev. C • Mount to host system chassis using four 6-32 UNC screws. Three mounting holes are in each side and four in the bottom of the drive. See Figure 4. The maximum length that the screws should extend into the side chassis mounting holes is 0.150 inch (3.81 mm), and 0.20 inch (5.08 mm) into bottom holes, measured from the outer surface of the chassis.
  • Page 37 Hawk 2 Family Installation Guide, Rev. C Do not power up the host system until the drive is mounted and the system cover is replaced. • Connect DC power connector to the drive, except on "NC" model drives which do not have a separate DC power connector.
  • Page 38 Hawk 2 Family Installation Guide, Rev. C Notes: [1] Mounting holes three on each side, 6-32 UNC. Max screw length into side of drive 0.15 in. (3.81 mm). See "Disc Drive Mounting" paragraph. [2] Mounting holes four on bottom, 6-32 UNC. Max screw length into bottom of drive 0.20 in.

  • Page 39: Drive Setup

    FORMAT for high-level formatting. Consult your DOS manual for FORMAT and FDISK command options. Warning. If an installed drive is low-level format- ted, all user data stored on the drive is lost. Seagate Technology assumes no liability for lost user data.

  • Page 40: Publication Number: 77767451, Rev. C

    Seagate Technology, Inc. 920 Disc Drive Scotts Valley, CA 95066-4544, USA Publication Number: 77767451, Rev. C Printed in USA...
