6 FT. FOLDING UTILITY RAMP KIT
Assembly And OperAtiOn instructiOns
Due to continuing improvements, actual product may differ slightly from the product described herein.
Visit our website at: http://www.harborfreight.com
tO preVent seriOus injury, reAd And understAnd
All wArnings And instructiOns befOre use.
Copyright
©
or any artwork contained herein may be reproduced in any shape or form without the
express written consent of Harbor Freight Tools.
for technical questions or replacement parts, please call 1-800-444-3353.
3491 Mission Oaks Blvd., Camarillo, CA 93011
2006 by Harbor Freight Tools
94643
. All rights reserved. No portion of this manual
®
®
