As th e dehumidifi er embodies electrical and rotational equipment, ONLY competent
persons should carry out any work on th is type of machine. (See warranty).
1.1 MOUNTING, POSITION .........................................................................................................................2
1.2 WALL HANGING/FLOOR STANDING ..................................................................................................4
2.1 CONDENSATE DRAIN CONNECTION .................................................................................................5
2.2 ELECTRICAL CONNECTION ................................................................................................................6
3.0 HUMIDISTAT SETTINGS .......................................................................................................................7
4.1 OPTIONAL HYGROSTAT/AIRSTAT ......................................................................................................8
4.2 OPTIONAL LPHW ...............................................................................................................................10
4.3 OPTIONAL AIR FILTER ....................................................................................................................... 11
4.4 FRESH AIR FEATURE .........................................................................................................................12
5.1 OPERATION ........................................................................................................................................13
5.2 SERVICE NOTES ................................................................................................................................13
6.0 TECHNICAL DATA ..............................................................................................................................14
7.0 WIRING DIAGRAMS ............................................................................................................................15
8.0 WARRANTY CONDITIONS .................................................................................................................19
OWNER/INSTALLATION MANUAL
WALLHUNG/FLOORSTANDING
DEHUMIDIFIERS
DH44/66 RANGE
SD496251 ISS 9
01/11/16
HEALTH AND SAFETY WARNING
Contents
Page 1
R
CALOREX HEAT PUMPS & DEHUMIDIFIERS
The Causeway, Maldon, Essex CM9 4XD
Service No:
Tel No: +44(0)1621 856611
Fax No: +44(0)1621 850871
Email:
Website
+44(0)1621 857171
sales@calorex.com
http://www.calorex.com
SD496251 iss 9
Advertisement
Table of Contents
Related Manuals for Calorex monitair DH44 Series
Summary of Contents for Calorex monitair DH44 Series
-
Page 1: Table Of Contents
5.1 OPERATION ............................13 5.2 SERVICE NOTES ..........................13 6.0 TECHNICAL DATA ..........................14 7.0 WIRING DIAGRAMS ..........................15 8.0 WARRANTY CONDITIONS .........................19 CALOREX HEAT PUMPS & DEHUMIDIFIERS The Causeway, Maldon, Essex CM9 4XD Service No: +44(0)1621 857171 Tel No: +44(0)1621 856611 Fax No: +44(0)1621 850871 Email: sales@calorex.com... -
Page 3: Mounting, Position
Health and Safety This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless th ey have been given supervision or instruction concerning use of th e appliance by a person responsible for th eir safety. - Page 4 16TH EDITION REGULATIONS AND CALOREX UNITS 1,25 - 2,0M MUST BE FITTED WITH AN RCD AND BE AT LEAST 300mm FROM FLOOR CAN BE WITHIN 1,25M BUT MUST BE FITTED WITH RCD MUST THEN BE 2,5M ABOVE 2,0-3,5M POOL SURFACE ANY HEIGHT ACCEPTABLE 1) N.B.
-
Page 5: Wall Hanging/Floor Standing
1.2 WALL HANGING/FLOOR STANDING When th e dehumidifi er is unpacked it is suitable for use standing on th e fl oor. The feet can be adjusted to allow for unevenness in th e surface. If th e unit is to be mounted on a wall, th e complete package contains wall brackets and antivibration buff... -
Page 6: Condensate Drain Connection
2.1 CONDENSATE DRAIN CONNECTION The condensate output and electrical connections can be at eith er end of th e machine, at th e side or in th e back, depending on th e requirements of th e user. To gain access to th e unit remove th e covers, unscrewing th e fi... -
Page 7: Electrical Connection
2.2 ELECTRICAL CONNECTION ELECTRICAL ELECTRICAL ENTRY POINT ENTRY POINT TRANSPORT BLOCK POSITION OF 22.00 22.00 40.00 40.00 ELECTRIC BOX CAUTION! REMOVE COMPRESSOR TRANSPORT BLOCK BEFORE RUNNING MACHINE DH66 DEHUMIDIFIER SHOWN POSITIONS OF KNOCKOUTS FOR ELECTRICAL CONNECTION The electrical connection should be carried out by an auth orised electrician, paying special attention to th e latest IEE regulations. -
Page 8: Humidistat Settings
3.0 HUMIDISTAT SETTINGS The dehumidifi er is provided with automatic control by a humidistat th at can be adjusted to suit room requirements. Adjustment is by a dial th at is located on th e right hand side of th e unit. The dial is marked as % relative humidity. -
Page 9: Optional Hygrostat/Airstat
4.1 OPTIONAL HYGROSTAT/AIRSTAT REMOTE HUMIDISTAT CONNECTIONS HUMIDISTAT (NOT SUPPLIED, WE RECOMMEND CALOREX PART SD385250. SIEBE PART No.119 1701 91100) BOILER DEMAND REMOV SIGNAL VOLT FREE LINK COMMON HUMIDISTAT AIR STAT L (L1) N (L2) E (GND) 100M MAX 1mm SQ CABLE... - Page 10 COMBINED REMOTE HUMIDISTAT/AIR STAT CONNECTIONS HUMIDISTAT/AIR STAT (NOT SUPPLIED, WE RECOMMEND CALOREX PART SD385252. EBERLE PART No.HYG-E-7001) BOILER DEMAND REMOVE SIGNAL VOLT FREE LINK COMMON HUMIDISTAT AIR STAT L (L1) N (L2) E (GND) 100M MAX 1mm SQ CABLE WITH REMOTE HUMIDISTAT/AIR STAT FITTED ENSURE HUMIDISTAT...
-
Page 11: Optional Lphw
The 3 way, motorised, diverting valve fi tted to machines with th e LPHW option is operated by a remote 12V AC air temperature th ermostat (available from Calorex). When th e valve is energised th e fl ow is th rough th e LPHW coil. -
Page 12: Optional Air Filter
4.3 OPTIONAL AIR FILTER The optional air fi lter is situated behind th e front covers, in front of th e evaporator fi ns and is accessed by removing th e covers. Undo th e screw in each side moulding and lift off covers. This should only be done with th e power turned OFF. -
Page 13: Fresh Air Feature
4.4 FRESH AIR FEATURE The facility to draw fresh air through the dehumidifier is incorporated into the design. Aft er removing th e blanking plate, a suitable spigot may be attached to th e back of th e dehumidifi er. 70.00 M6 FIXINGS DH44 STYLE DEHUMIDIFIER SHOWN... -
Page 14: Operation
If you do not fi nd a registration card with your machine please contact th e CALOREX service department giving your name, address, and th e serial number of your machine. A card will th en be sent to you for your completion. -
Page 15: Technical Data
6.0 TECHNICAL DATA MODEL DH44A/AX DH66A/AX DEHUMIDIFICATION l/hr 1.25 2.41 l/day 30.0 58.0 TOTAL HEAT TO AIR: DEHUMIDIFIER ONLY DEHUMIDIFIER & LPHW LPHW ONLY NOMINAL POWER CONSUMED:- FAN ONLY 0.04 0.07 DEHUM' (COMP & FAN) 0.51 0.98 SUPPLY 230V 50Hz 230V 50Hz FUSE NOMINAL RUNNING AMPS... -
Page 16: Wiring Diagrams
COMP G/Y 1.0 G/Y 1.0 EARTH STUD BOILER DEMAND SIGNAL VOLT FREE REMOTE REMOTE THERMOSTAT HUMIDISTAT REMOTE STAT WIRING CORRECTED 23/06/16 MATERIAL AS DRAWN 10/08/15 APPD DATE FINISH CALOREX HEAT PUMPS LTD DRAWING CHANGE U.C.C. Page 15 SD496251 iss 9... - Page 17 DRG No. D706950 FOR DH 66 WIRE FANS AS SHOWN BELOW SPEED SOLENOID COIL LEDs FUNCTION AS FOLLOWS: FAN MOTOR D1 - BOTH HUMIDSTATS ACTIVE D2 - non 'X' - NOT IN DEFROST + BOTH HUMIDSTATS ACTIVE 'X' - FAN RUNNING + NOT IN DEFROST D3 - non 'X' - HP OK + DEFROST INACTIVE + BOTH HUMIDISTATS ACTIVE 'X' - HP OK + BOTH HUMIDISTATS ACTIVE D4 - non 'X' - LP OK + HP OK + DEFROST INACTIVE + BOTH HUMIDISTATS ACTIVE...
- Page 18 7.1 FEATURES OF THE PRINTED CIRCUIT BOARD The Printed board, mounted in th e Electric Box has six small LEDs in th e bottom right hand corner. These illuminate to show diff erent states and marked D1 to D6. VOLT FREE TERMINALS LEDs HERE DH44A/DH66A DH44AX/DH66AX...
- Page 19 VOLT FREE TERMINALS Six pairs of Volt Free terminals are present on th e printed circuit board. Five of th em can be used to connect th e DH44/66 to a BMS system or to lamps to monitor th e status of th e dehumidifi...
-
Page 20: Warranty Conditions
If you do not fi nd a Registration Card with your Dehumidifi er please contact th e Calorex Service Department giving your name, address and serial number of your Dehumidifi er. A card will be sent to you for completion.
