Nextar Q3 Owner's Manual

Nextar q3: user guide
Hide thumbs Also See for Q3:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Quick Manual
，
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK). NO USE-SERVICEABLE PARTS
INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within an equilateral triangle, is
intended to alert the user to the presence of uninsulated "dangerous voltage"
within the product's enclosure that may be of sufficient magnitude to
constitute a risk of electric to persons.
The exclamation point within an equilateral triangle is intended to alert the
user to the presence of important operating and maintenance (servicing)
instructions in the literature accompanying the appliance.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
DO NOT EXPOSE THIS APPLIANCE TO RAIN OF MOISTURE.
POWER SUPPLY:
Connect the supplied adapter to the side of the unit in the slot marked "Power In." Plug
the two-prong end of the power cord to an AC100-240V outlet. If you have difficulty
inserting the plug, turn it over and reinsert it. If the unit will not the used for a long time,
disconnect the plug from the outlet.
NOTE:
Before plugging the power cord into an AC outlet, make sure that all the connections
have been made.
CAUTION: These servicing instructions are for use by qualified service personnel only.
To reduce the risk of electric shock, do not perform any servicing other than that
contained in the operating instructions unless you are qualified to do so.
Refer to service manual for servicing instructions.
Important Safety
Instructions
1

Advertisement

Table of Contents
loading

Related Manuals for Nextar Q3

Summary of Contents for Nextar Q3

  • Page 1: Important Safety Instructions

    ， CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USE-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric to persons.
  • Page 2 Important Safety Instructions NOTES Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with a damp cloth. Do not block any of the ventilation openings. manufacturer's instructions. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
  • Page 3 Important Safety Instructions Warning Failure to avoid the following potentially hazardous situations may result in injury or property damage. The unit is designed to provide you with route suggestions. It does not reflect road closures or road conditions, traffic congestion, weather conditions, or other factors that may affect safety or timing while driving.

  • Page 4: Features

    Features Navigation Function Navigation Function: The unit is designed to provide you with route suggestions. It supports voice navigation. Other Special Functions 1 GB Flash Storage: Built-in 1G Flash Storage can store map data. Power Adapter Switch: Automatically adapts to voltage requirements in U.S and other countries.

  • Page 5: Accessories

    Accessories List ITEM NAME Remote Control (with battery) Owner’s Manual Power Adaptor Car Adaptor Mounting Bracket Mounting cradle Dashboard mount disk Pouch NOTE Accessories and their parts numbers are subject to modification without prior notice due to improvements. Accessories...

  • Page 6: Table Of Contents

    Contents Important Safety Instructions …………………………………..………..1 ……………………………….…………...4 Features ……………………………….…………...5 Accessories ……………………………….…………...7 View of Main Unit ……………………………….……….…..9 Remote Control …………………………….……….…….10 System Connections ……………………………….…………..12 Power Supply Preparation …………………………….……………..14 General Setup ……………………………….…………..18 Playing Music …………………………….……………..19 Use of the Mount Accessories ……………………………………………22 Troubleshooting Specifications ………………………………………..….23...

  • Page 7: View Of Main Unit

    Front View MENU button Press to enter the main menu. Speaker Charge Indicator When charging the battery, it is red. When the battery is fully charged, it turns green. POWER button Press the power button to enter or exit the standby mode. LCD Screen Remote Sensor Receive signal from remote control for operation.

  • Page 8: Power Adaptor

    Used to connect to the supplied power adaptor or car adapter. Rear View When headphones 1. Build-in GPS Antenna Receiving GPS signals. 2. External GPS Antenna Jack Connected external antenna (optional). 3. ON/OFF Switch Used to switch power on or off.

  • Page 9: Remote Control

    POWER button Press to enter or exit standby mode. direction buttons Press to select items in the setup menu. direction buttons Press to adjust items in the setup menu. OK button Press to confirm selection. MENU button Press to enter the main setup menu. Remote Control - button Press to zoom out the map.

  • Page 10: System Connections

    -50 MB available hard drive space -Available serial port and/or USB Port -256-color display adapter and monitor (16 bit color required) In the near future map updates will be available for down load from our website. Please check www.nextar.com periodically for the information on downloads.
  • Page 11 System Connections Inserting SD Card The unit is designed with SD/MMC Card jack which allows you to insert the SD/MMC card into the unit as shown below: Connecting to Headphones Connect the headphones to the right side of the unit for private listening. When headphone is connected, the speakers will automatically turn off.

  • Page 12: Car Adaptor

    Attention Place the unit in a proper position for viewing. Disconnect the player from the Car Adaptor when starting the vehicle. Your portable GPS player comes with a built-in rechargeable battery. Please see details in the following segment.

  • Page 13: Charging The Battery Pack

    About Rechargeable Battery Your portable GPS player comes with a built-in rechargeable battery. Charge the battery fully before initial use. Charging time is normally about 5 hours. A fully charged battery delivers about 3 hours of use. Working conditions and precautions for the rechargeable battery New batteries should be fully charged before initial use.

  • Page 14: General Setup

    General Setup General Setup When turn on the unit, the screen will display the main menu for about 3~5 seconds and then enter the warning menu, as shown below: Tap I Agree to enter the map view. Press the MENU button to return to the main menu. In the main menu, there are three items for selecting.
  • Page 15 Language in the settings menu to enter Language settings menu for language selecting, as shown below: Tap the buttons to select language. Then tap Backlight in the settings menu to enter Backlight settings menu for backlight adjusting, as shown below: Tap the first group buttons to adjust the backlight level.
  • Page 16 General Setup Clock/Time in the settings menu to enter Clock/Time settings menu for changing to the current time zone, as shown below: Tap the buttons to select the proper Time Zone. Tap the to change the corresponding date and tap the corresponding time.
  • Page 17 Calibrate in the settings menu to calibrate, the screen will display as below: This item is used to calibrate the sensitivity of the unit. Tap the center of “+” as it moves around the screen. If you touch the center of “+” every time, it will disappear and tap the screen to return to the settings menu.

  • Page 18: Playing Music

    Playing Music The unit is designed with SD/MMC card slot. You can insert the SD/MMC card with MP3, WMA files. It supports MP3 and WMA format files playback. Note: Do not store MP3 or WWA format files in the Flash storage, for the flash storage is used to store map data, any attempt to open the Flash storage may result in the map data missing and lost.
  • Page 19 Playing Music In the menu, tap to enter the MP3 playlist menu, as shown below: In the playlist menu, if there are no songs in the playlist, tap to add songs into the playlist. The screen will display as below: Double tap the MMC_Storage icon to open the folder, the songs in the folder will be displayed on the screen.

  • Page 20: Help Window

    Playing Music Help Window In the playback or MP3 playlist menu, tap below: Tap each button to view its function. During playback, tap button to go to the previous track. During playback, tap button to go to the next track. During playback, tap button to pause playback, or in stop status, tap the button to resume playback.

  • Page 21: Mounting Bracket

    When using the unit in vehicle, you can use the supplied mount accessories (mount bracket, mount cradle and dashboard mount disk) to mount the unit in the vehicle. Take the following steps to operate: Slide the mounting cradle onto the end of the mounting bracket. Set the bottom edge of the unit on the bottom of the mounting cradle.

  • Page 22: Troubleshooting

    Troubleshooting Take steps described in the tables below to solve simple problems before contacting customer service. If you suspect something wrong with the unit, immediately turn the power off and disconnect the power connector from the unit. Never try to repair the unit yourself because it is dangerous to do so.

  • Page 23: Specifications

    TFT screen size Frequency Response Audio Signal-to-noise Rate Audio distortion or noise Channel Separation Dynamic Range Power AC 100-240V ～ Power Consumption Dimensions 130mmX74mmX24mm (L*W*D) Weight DESIGN AND SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE Specifications 3.5 inches 20Hz～20kHz ≥65dB ≤－20dB (1kHz) ≥70dB (1kHz) ≥80dB (1kHz)
