Page 2: Start Here
Owner Registration Card, and Support Information Card Verify PC Requirements The instructions given in this guide are for using the NETGEAR EA101 USB Ethernet Adapter in a PC that has a Microsoft operating system. Model EA101 USB Ethernet Adapter Installation Guide ®... - Page 3 Model EA101 USB Ethernet Adapter. Model EA101 USB Ethernet Adapter 3. Turn on power to the PC, if you have chosen to install the adapter with the power turned off. Model EA101 USB Ethernet Adapter Installation Guide 9308FA...
- Page 4 Note: One of the ports on NETGEAR hubs is switchable between Normal (MDI-X) and Uplink (MDI) with a Normal/Uplink push button. If you are using this switchable port on a NETGEAR hub to connect to a PC, a network card, or to the Model EA101 USB Ethernet adapter, make sure the Normal/Uplink push button is set to Normal.
- Page 5 PC (each name must be only one word and the name of each PC must be different). You also need to have the Windows CD-ROM and the NETGEAR EA101 Drivers and Diagnostics Disk ready to use in the installation process.
- Page 6 Microsoft Windows Update Specify a Location: < Back Select “Floppy disk drives” and insert the NETGEAR EA101 Ethernet Adapter Drivers and Diagnostics Disk into the floppy drive. Select “Specify a Location” and make sure the location is “A:\.” Click on “Next.”...
- Page 7 Insert Disk Please insert the the disk labeled 'NETGEAR EA101 USB Ethernet Adapter Drivers Disk' and then click OK. Click on “OK.” Copying Files... The file 'EA101ND4.SYS' on NETGEAR EA101 USB Ethernet Adapter Drivers Disk could not be found. Insert NETGEAR EA101 USB Ethernet Adapter Drivers Disk in the selected drive and click OK.
- Page 8 Do you want to resatrt your computer now? Y e s Remove the NETGEAR EA101 Drivers and Diagnostics Disk and the Windows 98 CD-ROM. Click on “Yes” to restart your computer. You must restart your computer to complete the installation of the driver.
-
Page 9: Verify Installation
Verify Installation Double-click on “My Computer” on your desktop, double-click on “Control Panel,” and then double-click on “System.” Click on “Device Manager.” Model EA101 USB Ethernet Adapter Installation Guide... - Page 10 Double-click on “Network adapters” and then double-click on “NETGEAR EA101 USB Ethernet Adapter” to open the “Properties” window that displays a message regarding the status of the device. If there is a problem with the driver installation, an exclamation point appears next to “NETGEAR EA101 USB Ethernet Adapter.”...
-
Page 11: Technical Specifications
0 to 45 C Operating humidity 10% to 90% noncondensing Agency Compliance CE mark, commercial FCC, Part 15, Class B EN 55 022 (CISPR 22), Class B Canada ICES-003, Class B VCCI Class B Model EA101 USB Ethernet Adapter Installation Guide... - Page 12 In the interest of improving internal design, operational function, and/or reliability, NETGEAR reserves the right to make changes to the products described in this document without notice. NETGEAR does not assume any liability that may occur due to the use or application of the product(s) or circuit layout(s) described herein.
- Page 13 NETGEAR, Inc. 4500 Great America Parkway Santa Clara, CA 95054 Phone: 1-888-NETGEAR E-mail: support@NETGEAR.com http://www.netgear.com *M-EA101NA-2* Model EA101 USB Ethernet Adapter Installation Guide...
