Sony SS-CNP7M Service Manual

SERVICE MANUAL
Ver. 1.0 2012.02 Ver. 1.0 2012.02
Photo: Photo:
SS-CNP7M SS-SRP7M
• SS-CNP7M is the center speaker in HT-M3/M5/M7.
• MSP2M is the front speaker for HT-M2.
• MSP3M is the front speaker for HT-M3 and surround speaker for HT-M7.
• MSP7M is the front speaker for HT-M5/M7.
• SRP-7M is the surround speaker for HT-M2/M3/M5 and surround back speaker for
HT-M7.
• SS-CRP2M is composed of SS-MSP2M and SS-SRP7M.
• SS-CRP3M is composed of SS-MSP3M, SS-CNP7M and
SS-SRP7M.
• SS-CRP5M is composed of SS-MSP7M, SS-CNP7M and
SS-SRP7M.
• SS-CRP7M is composed of SS-MSP7M, SS-CNP7M, SS-MSP3M and SS-SRP7M.
Speaker section
Front speaker for HT-M2 (SS-MSP2M)
Speaker system 2-way, 2-driver, Bass
reflex
Speaker unit
Woofer: 160 mm, cone type
Tweeter: 25 mm, horn type
Rated Impedance 6 ohms
Dimensions (width/height/depth) (Approx.)
280 mm × 485 mm ×
290 mm
(with foot)
Mass (Approx.) 7.3 kg
Front speaker for HT-M7/HT-M5
(SS-MSP7M)
Speaker system 2-way, 3-driver, Bass
reflex
Speaker unit
Woofer: 200 mm, cone type × 2
Tweeter: 25 mm, horn type
Rated Impedance 6 ohms
Dimensions (width/height/depth) (Approx.)
280 mm × 925 mm ×
265 mm
(with foot)
Mass (Approx.) 15.0 kg
Sony Corporation
9-890-589-01
2012B80-1 Audio & Video Business Group
©
2012.02 Published by Sony EMCS (Malaysia) PG Tec
SS-CRP2M/CRP3M/CRP5M/CRP7M
Photo: Photo:
SS-MSP2M SS-MSP3M
SPECIFICATIONS
Front speaker for HT-M3/Surround speaker
for HT-M7 (SS-MSP3M)
Speaker system 2-way, 2-driver, Bass
reflex
Speaker unit
Woofer: 160 mm, cone type
Tweeter: 25 mm, horn type
Rated Impedance 6 ohms
Dimensions (width/height/depth) (Approx.)
280 mm × 885 mm ×
265 mm
(with foot)
Mass (Approx.) 13.0 kg
Center speaker for HT-M7/HT-M5/HT-M3
(SS-CNP7M)
Speaker system Full range, Bass reflex,
Magnetically shielded
Speaker unit
Woofer: 100 mm, cone type
Rated Impedance 6 ohms
Dimensions (width/height/depth) (Approx.)
430 mm × 182 mm ×
178 mm
(with foot)
Mass (Approx.) 3.3 kg
Surround back speaker for HT-M7/
Surround speaker for HT-M5/HT-M3/HT-M2
(SS-SRP7M)
Speaker system Full range, Closed box
Speaker unit
Woofer: 100 mm, cone type
Rated Impedance 6 ohms
Dimensions (width/height/depth) (Approx.)
280 mm × 235 mm ×
162 mm
(with foot)
Mass (Approx.) 2.4 kg
SS-CNP7M/MSP2M/
MSP3M/MSP7M/SRP7M
SS-CNP7M/MSP3M/MSP7M/SRP7M
S SS-CNP7M/MSP2M/MSP3M/MSP7M/SRP7M
Photo:
SS-MSP7M
• JIG
When disassembling the set, use the following jig (for speaker
removal).
Part No.: J-2501-238-A
JIG FOR SPEAKER REMOVAL
PARTS LIST
Ref. No. Part No. Description
A-1851-402-A SS-CNP7M (Center speaker)
A-1852-944-A SS-SRP7M (Surround back speaker: L-CH)
A-1852-945-A SS-SRP7M (Surround back speaker: R-CH)
A-1852-932-A SS-SRP7M (Surround speaker: L-CH)
A-1852-933-A SS-SRP7M (Surround speaker: R-CH)
A-1853-476-A SS-MSP2M (Front speaker: L-CH)
A-1853-477-A SS-MSP2M (Front speaker: R-CH)
SPEAKER SYSTEM
Mexican Model
SS-CNP7M/MSP3M/SRP7M
E Model
Australian Model
Argentina Model
Remark
