Siemens SIRIUS 3RA2711 Equipment Manual

Industrial switchgear
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Industrial switchgear
Switchgear
SIRIUS 3RA2711 function modules
for IO-Link
Equipment Manual
08/2022
A8E96801709001A/RS-AD/006
Introduction
Standards
Safety notes
Product description
Application planning
Configuring the IO-Link
Parameters
Process image
Installing
Connecting
Operator control
Diagnostics
Appendix
1
2
3
4
5
6
7
8
9
10
11
12
A

Advertisement

Table of Contents
loading

Related Manuals for Siemens SIRIUS 3RA2711

Summary of Contents for Siemens SIRIUS 3RA2711

  • Page 1 Introduction Standards Safety notes Industrial switchgear Product description Switchgear SIRIUS 3RA2711 function modules Application planning for IO-Link Configuring the IO-Link Equipment Manual Parameters Process image Installing Connecting Operator control Diagnostics Appendix 08/2022 A8E96801709001A/RS-AD/006...
  • Page 2 Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.

  • Page 3: Table Of Contents

    Product description..........................29 Properties .......................... 29 Scope of supply ......................... 30 Technical data........................34 4.3.1 Technical data in Siemens Industry Online Support............. 34 4.3.2 Overview tables ........................ 34 Application planning ........................... 35 Product combinations ......................35 Assembly of function modules for IO-Link, direct starting ........... 45 Assembly of function module for IO-Link, reversing starting..........
  • Page 4 Removing function modules for IO-Link................77 Mounting the cover sealing....................79 Connecting ............................81 10.1 Connection via terminals....................81 10.2 Connecting function modules for IO-Link ................84 10.3 Input for local shutdown ....................88 SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...
  • Page 5 Preset configuration - data set (index) 130................ 119 References........................122 A.5.1 References........................122 A.5.2 Manuals - SIRIUS Modular System..................123 ESD Guidelines......................... 124 Electromagnetic compatibility (EMC) according to IEC 60947-4-2 ........126 Index ..............................127 SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...
  • Page 6 Table of contents SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...

  • Page 7: Introduction

    Nor can Siemens assume liability for recommendations that appear or are implied in the following description. No new guarantee, warranty, or liability claims beyond the scope of the Siemens general terms of supply are to be derived or inferred from the following description.

  • Page 8: Purpose Of The Manual

    The information in this manual enables you to commission the function modules for IO-Link. SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...

  • Page 9: Required Basic Knowledge

    Introduction 1.3 Required basic knowledge Required basic knowledge To understand these operating instructions you should have a general knowledge of automation engineering and low-voltage switchgear. SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...

  • Page 10: Scope Of The Manual

    1.4 Scope of the manual Scope of the manual This manual is valid for the available function modules for IO-Link. It describes the components that are valid at the time of publication. SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...

  • Page 11: Siemens Industry Online Support

    Siemens Industry Online Support Information and Service In Siemens Industry Online Support, you can obtain up-to-date information from our global support database quickly and simply. To accompany our products and systems, we offer a wealth of information and services that provide support in every phase of the lifecycle of your machine or plant –...
  • Page 12 Change personal data and contact information here • CAx data Simple access to thousands of items of CAx data such as 3D models, 2D dimension drawings, EPLAN macros and much more SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...

  • Page 13: Further Documentation

    The Appendix "References (Page 122)" has a list of the operating instructions. You can find more information about Siemens IO-Link masters in the corresponding manuals for the electronic modules 4SI IO‑Link and 4SI SIRIUS (IP20), as well as for ET 200eco PN (IP65).

  • Page 14: Datamatrix Code

    In the case of basic and coupling modules, there is a further DataMatrix code behind the labeling plate. DataMatrix codes are standardized in ISO/IEC 16022. The DataMatrix codes on Siemens devices use ECC200 coding for powerful error correction. The following device information is encoded in the front DataMatrix code as a bit stream: •...
  • Page 15 Introduction 1.7 DataMatrix code As well as fast access to the serial numbers of the respective devices for unique identification, the DataMatrix codes simplify communication with Siemens Technical Support. SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...

  • Page 16: Siemens Industry Online Support App

    Siemens Industry Online Support app Siemens Industry Online Support app The Siemens Industry Online Support app provides you access to all the device-specific information available on the Siemens Industry Online Support portal for a particular article number, such as operating instructions, manuals, data sheets, FAQs etc.

  • Page 17: Recycling And Disposal

    The available function modules for IO-Link can be recycled, as they are low in pollutants. For environmentally-friendly recycling and disposal of your electronic waste, please contact a company certified for the disposal of electronic waste. SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...

  • Page 18: Support Request

    1.10 Support Request After you have registered, you can use the Support Request form in the online support to send your question directly to Technical Support: Support Request: Internet (https://www.siemens.com/support-request) SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...

  • Page 19: Standards

    SIRIUS components have been approved by a whole range of bodies for various sectors (e.g. shipbuilding). An up-to-date list of approvals appears in the appendix of the Catalog IC 10 - SIRIUS "Industrial Controls" (http://www.siemens.com/sirius/catalogs), and more information, as well as an option to download certificates, can be obtained on the Internet (http:// www.siemens.com/sirius/support).

  • Page 20: Requirements For Switching High-Efficiency Motors

    All SIRIUS protection devices and switchgear that are subject to the IEC 60947‑4‑1 product standard meet the increased requirements in accordance with utilization category AC‑3e and are suitable for use with high-efficiency motors. SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...

  • Page 21: Voltages

    Voltage specification Ue in the Line system configurations Equipment Manual   Three-phase four-wire systems Three-phase three-wire systems 230 / 400 260 / 440 400 / 690 690 (only from size S3) 1000 1000 -- not specified SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...

  • Page 22: Notes On The Protection Of Device Connections

    Equipment Manual or the technical data sheet. IO-Link You can find more information about communication via IO‑Link, and about the valid standards for monitoring relays for IO-Link, on the Internet (http://www.io-link.com/en). SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...

  • Page 23: Approvals, Test Certificates, Characteristics

    You can find an overview of the certifications available for low-voltage controls and distribution products, test certificates and characteristics on the Internet (http://www.siemens.com/sirius/ approvals). You can find further information in the appendix of Catalog IC 10 "SIRIUS Industrial Controls" (https://support.industry.siemens.com/cs/ww/en/view/109771990). SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...
  • Page 24 Standards 2.5 Approvals, test certificates, characteristics SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...

  • Page 25: Safety Notes

    By subscribing to the appropriate newsletter, you will ensure that you are always up-to-date and able to make changes to your system, when necessary: For this purpose, go to the page: SIEMENS newsletter (http://www.siemens.com/sirius/ newsletter) Click "Subscribe to newsletter".
  • Page 26 The devices may only be used for the applications described in the catalog and the technical description, and only in conjunction with equipment or components from other manufacturers which have been approved or recommended by Siemens. This product can function correctly and reliably only if it is transported, stored, assembled, and installed correctly, and operated and maintained as recommended.
  • Page 27 Safety notes 3.1 Current information about operational safety See also SIEMENS newsletter (http://www.siemens.com/sirius/newsletter) SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...

  • Page 28: Security Information

    Siemens’ products and solutions undergo continuous development to make them more secure. Siemens strongly recommends that product updates are applied as soon as they are available and that the latest product versions are used. Use of product versions that are no longer supported, and failure to apply the latest updates may increase customer’s exposure...

  • Page 29: Product Description

    If communication between the IO-Link master and IO-Link device is interrupted, the IO-Link devices switch off connected loads for safety reasons. Manual operation is still possible with the operator panel. SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...

  • Page 30: Scope Of Supply

    Article number supplement for type of connection: 1 - with screw-type terminals, 2 - with spring-loaded terminals The table shows only the function modules with screw-type terminals. See also Product combinations (Page 35) SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...
  • Page 31 3RA2711-0EE16 Module connector 14-pin (only 10 pins occupied), length 90 mm for additional supply of auxiliary voltage   3RA2910-0 5 x sealable cover 3RA2711-0EE15 5 x interface cover SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...
  • Page 32 3RA2711-0EE07 Module connector 14-pin, Bypassing spaces 3RT201 to 3RT203 length 260 mm 3RA2711-0EE08 Module connector 14-pin, Bypassing spaces 3RT201 to 3RT204 length 335 mm max. 1 auxiliary switch max. 2 auxiliary switches SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...
  • Page 33 1 x interface cover operator panel 4 x mounting bracket 3RA2711-0EE11 Connecting cable 10 to 14-pole, length 2 m (round) for operator pan‐ 3RA6936-0A Enabling block 3RA6936-... 5 x interface cover operator panel SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...

  • Page 34: Technical Data

    4.3.1 Technical data in Siemens Industry Online Support Technical data sheet You can also find the technical data of the product at Siemens Industry Online Support (https:// support.industry.siemens.com/cs/ww/en/ps/16208/td). 1. Enter the full article number of the desired device in the "Product" field, and confirm with the Enter key.

  • Page 35: Application Planning

    Wiring modules for reversing contactor assemblies • Function modules for IO-Link, reversing start Pre-wired reversing contactor assembly, comprising: • Reversing contactor assembly with communication connection (24 V DC) • Function modules for IO-Link, reversing start SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...
  • Page 36 The wiring modules for connecting the control current paths are not required. Figure 5-1 Removal of the wiring modules for connecting the control current paths on a reversing contactor assembly with 3RA231 screw-type connections SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...
  • Page 37 Removal of the wiring modules for connecting the control current paths on a reversing contactor assembly with 3RA231 spring-loaded connections Figure 5-3 Removal of the wiring modules for connecting the control current paths on a reversing contactor assembly with 3RA232 screw-type connections SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...
  • Page 38 Removal of the wiring modules for connecting the control current paths on a reversing contactor assembly with 3RA232 spring-loaded connections Figure 5-5 Removal of the wiring modules for connecting the control current paths on a reversing contactor assembly with 3RA233 screw-type connections SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...
  • Page 39 The procedure for removing the wiring modules on a 3RA234 reversing contactor assembly is identical. Figure 5-7 Removal of the wiring modules for connecting the control current paths on a contactor assembly for star-delta (wye-delta) start with 3RA241 screw-type connections SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...
  • Page 40 (wye-delta) start with 3RA241 spring-loaded connections Figure 5-9 Removal of the wiring modules for connecting the control current paths on a contactor assembly for star-delta (wye-delta) start with 3RA242 screw-type connections SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...
  • Page 41 (wye-delta) start with 3RA242 spring-loaded connections Figure 5-11 Removal of the wiring modules for connecting the control current paths on a contactor assembly for star-delta (wye-delta) start with 3RA243 screw-type connections SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...
  • Page 42 7.5 kW/400 V, 24 V DC 3RT2023- . BB40-0CC0 3RT2023- . BB40 4 kW/400 V, 24 V DC 3RT2024- . BB40-0CC0 3RT2024- . BB40 5.5 kW/400 V, 24 V DC 3RT2025- . BB40-0CC0 3RT2025- . BB40 7.5 kW/400 V, 24 V DC 3RT2026- . BB40-0CC0 3RT2026- . BB40 11 kW/400 V, 24 V DC 3RT2027- . BB40-0CC0 3RT2027- . BB40 15 kW/400 V, 24 V DC 3RT2028- . BB40-0CC0 3RT2028- . BB40 18.5 kW/400 V, 24 V DC 3RT2035- . NB30-0CC0 3RT2035- . NB30 18.5 kW/400 V, 20‑33 V AC/DC SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...
  • Page 43 3RA2324-8XE30- . BB4 5.5 kW/400 V, 24 V DC 3RA2325-8XE30- . BB4 7.5 kW/400 V, 24 V DC 3RA2326-8XE30- . BB4 11 kW/400 V, 24 V DC 3RA2327-8XE30- . BB4 15 kW/400 V, 24 V DC 3RA2328-8XE30- . BB4 18.5 kW/400 V, 24 V DC 3RA2335-8XE30-1NB3 18.5 kW/400 V, 20‑33 V AC/DC 3RA2336-8XE30-1NB3 22 kW/400 V, 20‑33 V AC/DC 3RA2337-8XE30-1NB3 30 kW/400 V, 20‑33 V AC/DC 3RA2338-8XE30-1NB3 37 kW/400 V, 20‑33 V AC/DC 3RA2345-8XE30-1NB3 37 kW/400 V, 20‑33 V AC/DC SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...
  • Page 44 AC3, 75 kW/400 V, 20‑33 V AC/DC 3RA2446-8XH32-1NB3 AC3, 90 kW/400 V, 20‑33 V AC/DC * Article number supplement for type of connection:    • 1 - with screw-type terminals    • 2 - with spring-loaded terminals See also Scope of supply (Page 30) SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...

  • Page 45: Assembly Of Function Modules For Io-Link, Direct Starting

    The figure below shows the assembly for direct starting. ① IO function module for IO-Link, direct starting Contactor for communication connection Figure 5-13 Assembly of function module for IO-Link, direct starting SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...

  • Page 46: Assembly Of Function Module For Io-Link, Reversing Starting

    Reference You can find information about the contactors in the operating instructions for the contactors and contactor combinations used. Appendix "References (Page 122)" has a list of the relevant operating instructions. SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...

  • Page 47: Assembly Of Function Modules For Io-Link, Star-Delta Starting

    Reference You can find information about the contactors in the operating instructions for the contactors and contactor combinations used. Appendix "References (Page 122)" has a list of the relevant operating instructions. SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...
  • Page 48 Application planning 5.4 Assembly of function modules for IO-Link, star-delta starting SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...

  • Page 49: Configuring The Io-Link

    • Application-specific name: V1.0: 64 bytes max./V1.1: 32 bytes max. • IO-Link device LED: V1.0: green/V1.1: Green blinking • Device ID: V1.0: 0x00/V1.1: 0x01 • Parameter server functionality: V1.0: not available/V1.1: available SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...

  • Page 50: Configuring With Step 7 And The S7-Pct Port Configuration Tool

    > "IO‑Link" > "Master". 2. With the Port Configuration Tool S7-PCT , you configure the connected IO‑Link devices. Note The block library for IO-Link (LIOLink) is available as download in the Siemens Industry Online Support (SIOS) via the following link: Library for IO-Link (LIOLink) (https:// support.industry.siemens.com/cs/ww/en/view/82981502)

  • Page 51: Configuration

    4. Drag the IO‑Link device out of the component catalog to the required port of the IO‑Link master. 5. Start by parameterizing the IO‑Link device. More information is available in the S7-PCT online help. SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...

  • Page 52: Configuring With The S7-Pct Port Configuration Tool (Stand-Alone)

    3. Double-click to select a bus category (PROFIBUS DP / PROFINET IO). 4. Double-click to select an IO-Link master. 5. Select the IO-Link device in the component catalog of the S7‑PCT Port Configuration Tool. SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...
  • Page 53 To be able to access the IO-Link master or an IO-Link device online, communication between the ET 200 and the higher-level controller must be active (BF LED on ET 200 interface module is off). SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...

  • Page 54: Block Library For Io-Link (Liolink)

    IO-Link master via the S7 program (master exchange without engineering tool) Device-specific blocks for simple communication with IO-Link devices The library for IO-Link is available as download in the Siemens Industry Online Support (SIOS) via the following link: Library for IO-Link (LIOLink) (https://support.industry.siemens.com/cs/ww/en/view/82981502)

  • Page 55: Replacing An Io-Link Device

    In the event of a replacement, a PG/PC is available with the SIMATIC project of the plant. With the data stored in the SIMATIC project, and the S7-PCT port configuration tool, you transfer the parameters belonging to the replaced IO‑Link‑Device to the new IO‑Link‑Device. SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...

  • Page 56: Procedure Without Pg/Pc

    Spezifikation V1.1 are available, the "parameter server" function can be used to automatically back up parameter data. When devices are replaced, this parameter data is written back to the new IO‑Link device automatically on system startup. SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...
  • Page 57 The preset configuration of a starter group is saved by the starter connected to the IO-Link master via the removable terminal. Make sure that the correct preset configuration is electronically stored in the new starter after the starters have been replaced. SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...
  • Page 58 Configuring the IO-Link 6.5 Replacing an IO-Link device SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...

  • Page 59: Parameters

    The preset configuration of a starter group is saved by the starter connected to the IO-Link master via the removable terminal. Make sure that the correct preset configuration is electronically stored in the new starter after the starters have been replaced. SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...

  • Page 60: Parameters For Starters 1 To 4

    If you parameterize 3 or fewer starters in a starter group, the PRESET-ACTUAL comparison automatically becomes active. Practical implementation The IO-Link master is connected to the first function module that is actually available for the IO- Link of a group. SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...

  • Page 61: Parameter "Operation At Preset <> Actual Operation

    The "Operation at Preset <> Actual Operation" parameter determines whether or not the types of starter of the ACTUAL configuration are to be compared with those of the PRESET configuration. SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...
  • Page 62 Operation at Preset <> Actual Operation: block‐ blocking Operation at Preset <> Actual Operation: ena‐ — bling You can find more information on the data sets in the annex under "Data sets (Page 110)". SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...

  • Page 63: Parameters For The Operator Panel

    If the value of the "Operation at Preset <> Actual Configuration" parameter is set to "Enable", the IO‑Link device can be operated via IO‑Link regardless of whether an operator panel is connected or not. SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...
  • Page 64 • The condition of the "Operator panel available" parameter is not fulfilled. • The combination of different motor starters of one group on an IO‑Link channel does not correspond to the parameterization. SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...

  • Page 65: Parameters For Io-Link Devices (According To Io-Link Communication Specification V1.1)

    With the "Data storage inhibition" parameter, you define whether or not the mechanism for data storage is inhibited. The table below shows the parameter values. Table 7-8 "Data storage inhibition" parameter Value Description Default setting Data storage inhibition: unlocked Data storage inhibition: locked — SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...
  • Page 66 Parameters 7.3 Parameters for IO-Link devices (according to IO-Link communication specification V1.1) SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...

  • Page 67: Process Image

    1: Ready (automatic) DI1.1 1: Motor on DI1.2 1: Group fault DI1.3 1: Group warning DI1.4 1: Ready (automatic) DI1.5 1: Motor on DI1.6 1: Group fault DI1.7 1: Group warning SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...

  • Page 68: Process Image Output (Piq)

    DO1.3 1: Reserved DO1.4 1: Motor direction of rotation 1 (clockwise) DO1.5 1: Motor direction of rotation 2 (counter-clockwise) - for reversing start only DO1.6 1: Reserved DO1.7 1: Reserved SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...

  • Page 69: Installing

    Hazardous voltage! Will cause death or serious injury. Turn off and lock out power before working on this equipment. ① Check that the locking slide is engaged in the topmost position. SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...
  • Page 70 When mounting the basic modules for IO-Link, simultaneously insert the contacts (b) into the openings on the contactor. ③ Push the locking slide down with a screwdriver until it engages. SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...
  • Page 71 Insert the coded module connector into the slot in the correct position from above until the module connector engages in the locking mechanism. The colored conductor (a) must point towards the contactor. SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...
  • Page 72 You can find information about mounting the contactors in the operating instructions for the contactors used. You will find a list of all the operating instructions in the Appendix "References" (Page 122). SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...

  • Page 73: Connecting Io-Link Starters

    The diagram below provides an example of starter combination connections. ① Connection to IO-Link master ② Module connector for bridging a blank space ③ Module connector 35 mm Direct starter Blank space Reversing starter Star-delta starter Figure 9-1 Connecting starters SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...
  • Page 74 The colored conductor (a) must point towards the contactor. Inserting the interface covers Use the interface covers to close unused interfaces. This prevents damage or contamination to the interfaces. SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...

  • Page 75: Mounting An Operator Panel

    Insert the operator panel in the cutout. ③ Snap the four mounting brackets onto the operator panel. ④ Lock the operator panel in position by tightening the four screws on the securing brackets. SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...
  • Page 76 In order to guarantee the IP54 tightness and correct functionality of the operator panel, ensure that the tightening torque of the screws selected is not excessive when tightening the enclosed screws. SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...

  • Page 77: Removing Function Modules For Io-Link

    Before you remove the modules from the contactors, you have to remove the module connectors. ① Use a screwdriver to release the locking mechanisms. ② Remove the module connecter from the slot by lifting it up and out. SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...
  • Page 78 Press the screwdriver towards the contactor. ② Push the locking slide up with a screwdriver. It is not possible to unlock from below. ③ Pull the function module for IO-Link straight out from the contactor. SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...

  • Page 79: Mounting The Cover Sealing

    Insert the sealable cover into the openings on the IO-Link basic module. ③ Fold up the sealable cover. ④ Insert the clip into the opening until it engages. ⑤ Seal the clip to secure it against unauthorized removal. SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...
  • Page 80 Installing 9.5 Mounting the cover sealing SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...

  • Page 81: Connecting

    Conductor cross-sections for screw-type terminals Connection type Conductor cross-section ∅ 5 … 6 mm/PZ 2 0.8 … 1.2 Nm (7 to 10.3 lb·in) 1 x (0.5 … 4) mm 2 x (0.5 … 2.5) mm 1 x (0.5 … 2.5) mm 2 x (0.5 … 1.5) mm 2 x (20 to 14) SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...
  • Page 82 Insert the cable as far as it will go into the oval opening and hold it in place. ④ Remove the screwdriver. The terminal closes and the conductor is now securely clamped. Pull on the cable to ensure it is tight. SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...
  • Page 83 The removable terminals of the basic modules facilitate module replacement when necessary. ① Press the locking interlock. ② Remove the terminal. ③ Attach the new terminal and press the terminal into the device until the interlock audibly engages. SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...

  • Page 84: Connecting Function Modules For Io-Link

    • In addition, connect the 24 V DC V auxiliary voltage to the fourth motor starter. • Use the 10-pin 3RA2711-0EE16 module connector for the connection between the third and fourth motor starter. SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...
  • Page 85 3RT202 / 3RT203 / 3RT204), you must additionally connect the 24 V DC auxiliary voltage V the fourth motor starter, and use the 10-pin module connector 3RA2711-0EE16 for the connection between the third and fourth motor starter. SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...
  • Page 86 The same applies when selecting appro‐ priate protective devices. You can find the technical specifications of the 3RA2711 in the Siemens Industry Online Sup‐ port (https://support.industry.siemens.com/cs/ww/en/ps/16132/td). You can find all the tech‐ nical data of the 3RT2 in the Siemens Industry Online Support (https:// support.industry.siemens.com/cs/ww/en/ps/16132/td).
  • Page 87 The same applies when selecting appro‐ priate protective devices. You can find the technical specifications of the 3RA2711 in the Siemens Industry Online Sup‐ port (https://support.industry.siemens.com/cs/ww/en/ps/16132/td). You can find all the tech‐ nical data of the 3RT2 in the Siemens Industry Online Support (https:// support.industry.siemens.com/cs/ww/en/ps/16132/td).

  • Page 88: Input For Local Shutdown

    When delivered, terminals A3+/Y1 - Y2 are bridged as standard by a conductor. Remove this conductor bridge before connecting an optional NC contact. Figure 10-1 Optional NC contact - direct starting Figure 10-2 Optional NC contact - reversing starting SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...
  • Page 89 Connecting 10.3 Input for local shutdown Figure 10-3 Optional NC contact - star-delta starting See also Connection via terminals (Page 81) SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...

  • Page 90: Emergency Stop

    Auxiliary voltage V for motor starter 1, 2, and 3 (with NC contact) ③ Auxiliary voltage V for motor starter 4 (with NC contact) Figure 10-4 Connecting the EMERGENCY STOP function SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...

  • Page 91: Operator Control

    The switchover time from star mode to delta mode is at least 50 ms. ① Startup time in star mode ② Switchover time from star mode to delta mode Figure 11-1 Setting the switchover time from star mode to delta mode SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...

  • Page 92: Operation Using The Operator Panel

    Operator control and display elements of the operator panel ① DEVICE LED The DEVICE LED indicates whether the operator panel is ready to run: - Green: Operator panel is ready. - Red: Operator panel is not ready. SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...
  • Page 93 1. Select a starter. To do so, press the SELECT button until the desired LED (1, 2, 3 or 4) lights up. 2. Check whether a group fault is present: – SF LED red: Group fault present. – SF LED off: No group fault SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...
  • Page 94 Jogging: The starter is only activated while you press the button. Activation stops as soon as you release the button. Continuous operation: If you press the  or button, the starter is activated until you press the button again. SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...
  • Page 95 People may be injured if they stay in the danger area of the machine. Make sure that the danger area of the machine is kept clear of people. See also Scope of supply (Page 30) SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...
  • Page 96 Operator control 11.2 Operation using the operator panel SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...

  • Page 97: Diagnostics

    Operator panel connected and "manual • None if "manual operation" is sup‐ operation activated" executed posed to be valid • Perform "reset to automatic opera‐ tion" to have PLC assume control SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...
  • Page 98 SW = group warning: You can obtain detailed information via diagnostics data set 90 (see Section "Group diagnostics - data set (index) 90 (Page 113)"). for a restart x: Bit set ○: Not relevant —: Status does not change SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...

  • Page 99: Appendix

    Appendix CAx data You can find the CAx data in the Siemens Industry Online Support (https:// support.industry.siemens.com/cs/ww/en/ps/16208/td). 1. Enter the full article number of the desired device in the "Product" field, and confirm with the Enter key. 2. Click the "CAx data link.

  • Page 100: Dimension Drawings

    Size 3RT201 57.5 3RT202 (AC) 3RT202 (DC) 3RT203 3RT204 Function module for IO-Link, direct start with spring-loaded terminals (with contactor) ① Function module for IO-Link, direct start ② 3RT20 contactor SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...
  • Page 101 Function modules for IO-Link, reversing start ② 3RT20 contactors Table A-3 Dimensions in mm Size 3RT201 3RT202 (AC) 3RT202 (DC) 3RT203 140.5 3RT204 159.5 Function module for IO-Link, reversing start with screw-type terminals (with contactors) SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...
  • Page 102 Function module for IO-Link, star-delta (wye-delta) start with screw-type terminals (with contactors) ① Function modules for IO-Link, star-delta (wye-delta) start ② 3RT20 contactors Table A-5 Dimensions in mm Size 3RT201 3RT202 (AC) 3RT202 (DC) SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...
  • Page 103 3RT202 (AC) 3RT202 (DC) Function module for IO-Link, star-delta (wye-delta) start (with contactor) ① Function modules for IO-Link, star-delta (wye-delta) start ② 3RT20 contactor ③ Coupling modules ④ Basic module SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...
  • Page 104 Appendix A.2 Dimension drawings Table A-7 Dimensions in mm Size 3RT203 177.5 141.5 55.1 222.3 3RT204 244.5 SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...

  • Page 105: Circuit Diagrams

    Appendix A.3 Circuit diagrams Circuit diagrams A.3.1 Main circuit Direct starter Figure A-1 Main circuit direct starter SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...
  • Page 106 Appendix A.3 Circuit diagrams Reversing starter Figure A-2 Main circuit reversing starter SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...
  • Page 107 Appendix A.3 Circuit diagrams Star-delta starter Figure A-3 Main circuit star-delta starter SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...

  • Page 108: Control Circuit

    Appendix A.3 Circuit diagrams A.3.2 Control circuit Direct starter 24V DC IO-Link Master A3+/Y1 Figure A-4 Control circuit direct starter Reversing starter 24V DC IO-Link Master A3+/Y1 Figure A-5 Control circuit reversing starter SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...
  • Page 109 Appendix A.3 Circuit diagrams Star-delta starter IO-Link 24 V DC Master A3+/Y1 Figure A-6 Control circuit star-delta starter SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...

  • Page 110: Data Sets

    Parameter Page 1 - IO-Link communication parameters Table A-9 Parameter Page 1 Address Parameter name Access Description 0x00 Master Command — 0x01 Master Cycle Time — 0x02 Min. Cycle Time 0x32 0x03 Frame Capability 0x11 SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...

  • Page 111: Device-Specific Parameters

    See 1.0 See 1.1   0: Reserved   0: Reserved 2.4 to 2.7 Profile version 1: Starter group Starter 1 Type of starter 4.0...4.7 Reserved Starter 2 Type of starter 6.0...6.7 Reserved SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...

  • Page 112: Identification Data

    — — 0x12 Product Name SIRIUS Function Module IO- Link — 0x13 Product ID 3RA2711 — 0x14 Product Text — — 0x15 Serial Number — — 0x16 Hardware Revision — SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...

  • Page 113: Group Diagnostics - Data Set (Index) 90

    Data set (index) 90 - starter 1 Data set Byte.Bit Description Index Subindex Specific module diagnostics - starter 1 9.0...9.6 Starter 1 (item number) 10.0 Module fault (device fault) 10.1 Starter available 10.2 Reserved Specific diagnostics - starter 1 SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...
  • Page 114 Reserved 24.4 Reserved 24.5 Switch off - end position right 24.6 Switch off - end position left 24.7 Process mapping error 25.0 Manual operation 25.1 Manual operation aborted 25.2 Reserved SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...
  • Page 115 Supply voltage switching element missing 42.2 No mains voltage 42.3 Reserved 42.4 Reserved 42.5 Switch off - end position right 42.6 Switch off - end position left 42.7 Process mapping error SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...

  • Page 116: Actual Configuration - Data Set (Index) 105

    0.0...0.7 Fixed value 0x21 1.0...1.7 Fixed value 0x00 2.0...2.7 Fixed value 0x00 3.0...3.7 Fixed value 0x00 Diagnostics of the motor starter group 4.0...4.6 Fixed value 0x05 8.0...8.7 Fixed value 0x07 SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...
  • Page 117 Data set (index) 105 - (actual configuration) - starter 3 Table A-20 Data set (index) 105 - (actual configuration) - starter 3 Data set Byte.Bit Description Index Subindex 23.0...23.6 Starter 3 (item number) 24.0...24.7 Fixed value 0x62 SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...
  • Page 118 38.0...38.7 Fixed value 0x60 39.1 Operator panel available 40.0...40.7 Fixed value 0xD2 41.0...42.7 Reserved You can find more information on the "Starter available" parameter in Section Starter available parameter (Page 60). SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...

  • Page 119: Preset Configuration - Data Set (Index) 130

    Subindex 9.0...9.6 Starter 1 (item num‐ ber) 10.0...10.7 Fixed value 0x62 11.0 Preset <> actual configu‐ ration 11.1 Starter available 12.0...12.7 Type of starter 13.0...14.7 Starter version 15.0...15.7 Fixed value 0x07 SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...
  • Page 120 Data set (index) 130 - (preset configuration) - starter 4 Data set Byte.Bit Description Index Subindex 30.0...30.6 Starter 4 (item num‐ ber) 31.0...31.4 Fixed value 0x62 32.0 Preset <> actual configu‐ ration 32.1 Starter available 33.0...33.7 Type of starter SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...
  • Page 121 You can find additional information on the "Starter available" parameter in Section ""Starter available" parameter (Page 60)". You can find additional information on the "Type of starter" parameter in Section ""Starter type" parameter (Page 60)". SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...

  • Page 122: References

    In addition to this manual, please refer to the operating instructions and manuals for any accessories. You can download the relevant documentation from the Internet (http:// www.siemens.com/sirius/manuals). Simply enter the article number of the relevant item into the search field. Operating instructions...

  • Page 123: Manuals - Sirius Modular System

    3RA27 function modules for connection to • "SIRIUS - SIRIUS 3RA2712 Function Modules for AS-Interface" (https:// the higher-level control support.industry.siemens.com/cs/ww/en/view/39318922) manual • "SIRIUS - SIRIUS 3RA2711 Function Modules for IO-Link" (https:// support.industry.siemens.com/cs/ww/en/view/39319600) manual SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...

  • Page 124: Esd Guidelines

    The figure below shows the maximum electrostatic voltage which may build up on a person coming into contact with the materials indicated. These values correspond to IEC 801-2 specifications. SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...
  • Page 125 In this way, the discharged energy can not affect the sensitive devices. Discharge your body before you start taking any measurements on a module. Do so by touching grounded metallic parts. Always use grounded measuring instruments. SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...

  • Page 126: Electromagnetic Compatibility (Emc) According To Iec 60947-4-2

    Electromagnetic compatibility (EMC) according to IEC 60947-4-2 This product is designed for Environment A. It may produce radio interference in domestic environments, in which case the user may be required to take adequate mitigation measures. SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...

  • Page 127: Index

    Locking slide, 69 Data sets Overview, 110 Device-specific parameters Unit status, 111 Dimension drawings, 12 Manual mode, 94 Display elements MANUAL MODE, 94 Operator panel, 92 Modular System, 123 Disposal, 17 Module connectors, 71 plugging in, 71, 74 Removing, 77 Monitoring mode, 93 SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...
  • Page 128 Pre-wired contactor assembly for star-delta (wye- delta) start, 44 Pre-wired reversing contactor assembly, 43 Properties Function module for IO-Link, 29 Recycling, 17 References, 122 Removable terminals, 83 Removing, 77 Replacing Terminals, 83 Required basic knowledge, 9 Reversing starter Installing, 71 SIRIUS 3RA2711 function modules for IO-Link Equipment Manual, 08/2022, A8E96801709001A/RS-AD/006...

Table of Contents
