Stanley Access Technologies
Magic-Swing™, Magic-Force™, and Bifold
MC521 Control Box
Quick-Reference Guide
204027
Rev. C, 11/9/05
Prohibition on Copying
Any unauthorized reproduction, disclosure or distribution of copies by any person of any
portion of this work may be a violation of copyright law of the United States of America and
other countries, could result in the awarding of statutory damages of up to $250,000 (17
USC 504) for infringement, and may result in further civil and criminal penalties. All rights
reserved.

Advertisement

Table of Contents
loading

Related Manuals for Stanley MC521

Summary of Contents for Stanley MC521

  • Page 1 Stanley Access Technologies Magic-Swing™, Magic-Force™, and Bifold MC521 Control Box Quick-Reference Guide 204027 Rev. C, 11/9/05 Prohibition on Copying Any unauthorized reproduction, disclosure or distribution of copies by any person of any portion of this work may be a violation of copyright law of the United States of America and other countries, could result in the awarding of statutory damages of up to $250,000 (17 USC 504) for infringement, and may result in further civil and criminal penalties.

  • Page 2: Table Of Contents

    Wiring the Cycle Counter........................11 TUNE-IN INSTRUCTIONS ........................12 Initial Tune-In Settings..........................12 Tuning In the MC521 Controller Using the Palm Pilot................12 Tuning In the MC521 Controller Using the Controller Pushbuttons............16 Final Tune-In Adjustments........................20 SPARE PARTS LIST..........................21 ATTACHMENTS Attachment 1, Breakout Status Wiring on Magic-Swing Operators..............

  • Page 3: Purpose

    This manual provides abbreviated descriptive information, wiring instructions, and tune-in instructions for the MC521 controller used with Magic-Swing™, Magic-Force™, and Bifold operators. The manual is intended as a quick-reference guide. Attachment 6 illustrates the MC521 controller controls and indicators. Applicability This manual is applicable on MC521 control box used with Magic-Swing™, Magic-Force™, and...

  • Page 4: Precautions

    FASTEN screw, star washer, and ground wire to header. 3.2.5 In a concealed location inside the header, DRILL a second hole for a No. 8 screw. 204027 © 2005, THE STANLEY WORKS. ALL RIGHTS RESERVED. Rev. C, 11/9/05 3 of 31...

  • Page 5: Connecting Breakout Status Signal Wiring (Magic-Swing Operators)

    REPEAT steps 3.3.3 and 3.3.4 for the second door operator. b. CONNECT stripped end of one yellow jumper wire from each operator to terminals 9 and 10 of control box connector TB3. 204027 © 2005, THE STANLEY WORKS. ALL RIGHTS RESERVED. Rev. C, 11/9/05 4 of 31...
  • Page 6 Using a multimeter, CHECK continuity between TB3 terminals 9 and 10, and ENSURE there is an open circuit. g. RELEASE door. h. PLUG TB3 into control box. 204027 © 2005, THE STANLEY WORKS. ALL RIGHTS RESERVED. Rev. C, 11/9/05 5 of 31...

  • Page 7: Connecting Breakout Status Signal Wiring (Magic-Force Operators)

    TB3. • CONNECT remaining two yellow breakout status switch wires together with a wire nut. 3.4.4 VERIFY breakout status/breakout cams are properly set as follows: 204027 © 2005, THE STANLEY WORKS. ALL RIGHTS RESERVED. Rev. C, 11/9/05 6 of 31...
  • Page 8 ROTATE CLOSE CHECK CAM COUNTERCLOCKWISE UNTIL RAISED PORTION OF CAM ACTUATES SWITCH, THEN ROTATE CAM 10 DEGREES CLOCKWISE. ROTATE AUXILIARY CAM AS DESIRED. DETAIL B: LEFT HAND OPERATOR CAM SETTINGS MF0026 204027 © 2005, THE STANLEY WORKS. ALL RIGHTS RESERVED. Rev. C, 11/9/05 7 of 31...

  • Page 9: Wiring The Operator Switch Module (Magic-Force Operators)

    CONNECT wiring to auxiliary position switch terminal block as shown. c. SLIDE switch module into operator housing until switch module release lever snaps into place. 204027 © 2005, THE STANLEY WORKS. ALL RIGHTS RESERVED. Rev. C, 11/9/05 8 of 31...

  • Page 10: Wiring The Operator For Required Handing (Magic-Force Operators)

    Specific wiring instructions from the manufacturer must also be consulted. 3.8.1 Refer to Attachment 2, 3, or 4 and applicable manufacturer's instructions, and CONNECT door activation or safety device. 204027 © 2005, THE STANLEY WORKS. ALL RIGHTS RESERVED. Rev. C, 11/9/05 9 of 31...

  • Page 11: Wiring Sentrex

    Wiring Bodyguard NOTE The Bodyguard does not require a lockout relay for use with the MC521 control box. A 300-ohm 5-watt resistor is needed. Part Number 516861 provides the resistor and terminal block. The MC521 control box generates the data signals for door open, closing, and closed positions. Refer to Attachment 2, 3 , or 4 as applicable for wiring connections.

  • Page 12: Wiring The Cycle Counter

    Cycle counter 413787 is optional. 3.13.1 Refer to Figure 5, and CONNECT wiring for cycle counter. Figure 5. Cycle Counter Wiring CYCLE COUNTER SEN003 BLACK 204027 © 2005, THE STANLEY WORKS. ALL RIGHTS RESERVED. Rev. C, 11/9/05 11 of 31...

  • Page 13: Tune-In Instructions

    To prevent injury to personnel and damage to equipment, the following settings must be made before using the door. NOTE The following steps provide instructions for tuning the MC521 controller using the Palm Pilot. MC521 application software is required. Step 1: Select MC521 Tool Box from the list Step 2: Select Restart FIS on the Main of applications.
  • Page 14 Closed. During this sequence the sensors are inactive and the door has no SAFETY. To stop the door, turn power off. 204027 © 2005, THE STANLEY WORKS. ALL RIGHTS RESERVED. Rev. C, 11/9/05 13 of 31...
  • Page 15 Step 15: Press More> to access more Step 16: Press Clone Settings to pull all of the functions. settings out of one controller and put them into another door. 204027 © 2005, THE STANLEY WORKS. ALL RIGHTS RESERVED. Rev. C, 11/9/05 14 of 31...
  • Page 16 Step 18: Press Summary Listing to view all Step 19: Review the information on the current settings for Motor 1 and Motor 2. summary listing. 204027 © 2005, THE STANLEY WORKS. ALL RIGHTS RESERVED. Rev. C, 11/9/05 15 of 31...

  • Page 17: Tuning In The Mc521 Controller Using The Controller Pushbuttons

    Tuning In the MC521 Controller Using the Controller Pushbuttons NOTE 1. To change the INDEX: Hold ENTER switch while pressing UP or DOWN to get to desired INDEX 2. To change a VALUE: Unlock the keypad by setting index 99 to value 01.
  • Page 18 API Mode Specific Door Operational Values-These depend upon the mode selected 90-95 Reserved Command - Restart FIS. Entering 01 will cause FIS to restart. Reserved Command – RESTART AUTOCONFIGURATION, Entering 01 will cause auto configuration. 204027 © 2005, THE STANLEY WORKS. ALL RIGHTS RESERVED. Rev. C, 11/9/05 17 of 31...
  • Page 19 Open Braking Slope Magic touch mode (Dual = 00, Single = 01) Reserved Note: Door must be cycled open for changes to be stored in permanent memory. 204027 © 2005, THE STANLEY WORKS. ALL RIGHTS RESERVED. Rev. C, 11/9/05 18 of 31...
  • Page 20 First installation sequence (FIS) Auto-configuration sequence Auto-configuration confirmation sequence Invalid mode Encoder error Display door cycle counter Obstruction in Learn Mode Obstruction after Learn Mode 204027 © 2005, THE STANLEY WORKS. ALL RIGHTS RESERVED. Rev. C, 11/9/05 19 of 31...

  • Page 21: Final Tune-In Adjustments

    Refer to Attachment 7, and ENSURE all ANSI/BHMA, and UL compliance requirements are met. m. POWER DOWN the door, POWER UP the door, and ENSURE that all settings have been stored in the controller. 204027 © 2005, THE STANLEY WORKS. ALL RIGHTS RESERVED. Rev. C, 11/9/05 20 of 31...

  • Page 22: Spare Parts List

    SPARE PARTS LIST Table 7 shows the spare parts for the MC521 control box used with Magic-Swing™, Magic-Force™, and Bifold operators. Table 7. Spare Parts Description Part Number MC521 Controller and 3 terminal blocks 313969 MC521 Controller Manual 204027 Power and Function Switch Assembly 8 feet...

  • Page 23: Attachment 1, Breakout Status Wiring On Magic-Swing Operators

    COMM. MATE-N-LOCK RECEPTACLE CONTACTS AUX. SWITCH WIRE HARNESS (CONNECTOR SEEN FROM WIRES SIDE) OPERATOR NO. 2 BREAKOUT STATUS WIRING--SINGLE DOOR BREAKOUT STATUS WIRING--DUAL DOOR MCBA017A 204027 Rev. C, 11/9/05 Page 22 of 31 © 2005, THE STANLEY WORKS. ALL RIGHTS RESERVED.

  • Page 24: Attachment 2, Magic-Force Wiring Diagram-Mc521

    SWITCH ASS'Y P/N 516671 HOLDING BEAM COMMON SENSOR BEAM 12 VAC COMMON SAFETY OPERATE 12 VAC OPERATE COMMON PRESS SENSOR COMMON OPERATE PLATE UCSW008B 204027 Rev. C, 11/9/05 Page 23 of 31 © 2005, THE STANLEY WORKS. ALL RIGHTS RESERVED.

  • Page 25: Attachment 3, Magic-Force Wiring Diagram-Mc521 With Power Close Option

    Attachment 3 Magic-Force Wiring Diagram—MC521 With Power Close Option (Sheet 1 of 1) HARNESS P/N 413791 SENTREX 3 POWER CLOSE P/N 516116 MOTOR RELAY SET TO #2 LEFT HAND OPERATOR FLEX LINK 516861 BREAKOUT BREAKOUT STATUS ENCODER BODY GUARD COUNTER...

  • Page 26: Attachment 4, Magic-Swing Wiring Diagram-Mc521

    12 VAC SAFETY HOLD COMMON HOLDING BEAM BEAM SENSOR 12 VAC COMMON SAFETY OPERATE 12 VAC OPERATE COMMON COMMON SENSOR PRESS OPERATE PLATE UCSW010B 204027 Rev. C, 11/9/05 Page 25 of 31 © 2005, THE STANLEY WORKS. ALL RIGHTS RESERVED.

  • Page 27: Attachment 5, Terminal Block Connections-Tb1 Through Tb5

    COMMON (WH) COMMON (WH) COMMON SAFETY (GN) SAFETY (GN) BREAKOUT (YL) PUSH PLATE COMMON (YL) COMMON * REMOVE IF EXTERNAL 204027 POWER SUPPLY IS USED. UCSW011B Rev. C, 11/9/05 Page 26 of 31 © 2005, THE STANLEY WORKS. ALL RIGHTS RESERVED.

  • Page 28: Attachment 6, Mc521 Controller Controls And Indicators

    REPLACE ONLY WITH THE SAME TYPE AND RATING OF FUSE. SEE DETAIL A U305 U306 ENCODER 2 J403 ENCODER 1 J402 DOWN ENTER 204027 Rev. C, 11/9/05 Page 27 of 31 DETAIL A UC001B © 2005, THE STANLEY WORKS. ALL RIGHTS RESERVED.
  • Page 29 Connection point for stall sensor, safety sensor, and breakout switch. Using jumper wires across TB3 terminals 1 to 5 and 2 to 6, internal transformer supplies power to multiple external sensors. J401 Connection point for Sentrex microboard. 204027 Rev. C, 11/9/05 Page 28 of 31 © 2005, THE STANLEY WORKS. ALL RIGHTS RESERVED.

  • Page 30: Attachment 7, Ansi/Bhma And Ul Compliance Requirements For Swinging And Folding Doors

    All power operated door systems must be installed in compliance with the current edition of UL 325, “Standard for Safety for Door, Drapery, Gate, Louver, and Window Operators and Systems”. 204027 Rev. C, 11/9/05 Page 29 of 31 © 2005, THE STANLEY WORKS. ALL RIGHTS RESERVED.
  • Page 31 Closing time through the final 2 inches of closing (latch check) must be greater than 1.5 seconds measured at the lead edge of each FX (fold slide) panel. • Maximum recommended door weight: Bifold Door = 100 lbs (45 kg) each panel 204027 Rev. C, 11/9/05 Page 30 of 31 © 2005, THE STANLEY WORKS. ALL RIGHTS RESERVED.

  • Page 32: Attachment 8, Palm Troubleshooting Aid-Swing/Bifold

    Dark = detecting TB4-4 Operate Sensor Input (connected internally) TB5-3 Sentrex Operate Internal From MicroBoard Dark = detecting TB5-7 Holding Beam Dark = detecting TB5-10 Spare 204027 Rev. C, 11/9/05 Page 31 of 31 © 2005, THE STANLEY WORKS. ALL RIGHTS RESERVED.
