NEC MultiSync LCD2070WNX User Manual page 7

Display Setup
. Hold the all cables firmly and place the cable cover onto the stand (Figure 10). To
remove the cable cover, lift the cover off as shown (Figure 11).
2. Connect the power cord to the power outlet (Figure 13).
N OTE: If you have difficulty removing the cable cover, please push the the cover up
(towards the top of the monitor) in order to unhook the cover from the stand,
then remove, as shown (Figure 12). Handle with care when removing cable cover.
NOTE: If you use this monitor at AC25-240V, please refer to Recommended Use section
of this manual for proper selection of power cord.
3. The vacation switch on the back side of the monitor must be turned on (Figure 13).
Turn on the monitor with the front power button and the computer.
N OTE: The vacation switch is a true on/off switch. If this switch is on the OFF position,
the monitor cannot be turned on using the front button. DO NOT switch on/off
repeatedly.
Figure 10
Figure 12
–continued
Figure 11
Figure 13
5
Power Button
ON Position
OFF Position
