Display Setup
6. Replace Connector Cover (Figure 6).
7. For successful cable management, place the cables in the following order into the
cable management: power cable and DVI cable (Figure 7).
8. Place DVI cable and power cable into the specific hooks indicated in (Figure 8).
9. Place the D-Sub and the USB cable into the specific hooks indicated in (Figure 9).
 0. Make sure all cables are resting flat against the stand (Figure 9).
Figure 6
–continued
Figure 8
D-Sub Cable
Figure 7
Power Cable
(Bottom)
D-SUB Cable
USB Cable
Figure 9
USB Cable
4
DVI Cable
(Top)
Flat
