FCC Information 1. Use the attached specified cables with the MultiSync LCD1970VX™(L194RK) and LCD1970NX™ (L194RH) color monitor so as not to inter- fere with radio and television reception. (1) Please use the supplied power cord or equivalent to ensure FCC compliance.
User's Manual MultiSync LCD1970V MultiSync LCD1970VX MultiSync LCD1970NX User’s Manual * Remember to save your original box and packing material to transport or ship the monitor. LCD monitor box* should contain the ® • User’s Manual (NX and VX only)
NOTE: To obtain the MultiSync Macintosh cable adapter, call NEC Display Solutions of America, Inc. at (800) 632-4662. 3. Place hands on each side of the monitor to tilt the LCD panel to a 30-degree angle and lift up to the highest position (Figure 4).
Page 6
(NX and VX only) Figure 4 Highest Stand Position Power cord (NX only) DC-OUT NEC optional product atttachment. Do not use this connector unless specified. Figure 5 Power Cable (Bottom) -continued Figure 2 Macintosh Cable Adapter (not included) Note: Some Macintosh systems do not require a Macintosh Cable Adapter 30•...
Page 7
Display Setup -continued Figure 7 Figure 8 Figure 9 Figure 11 Figure 10 OFF Position Vacation Switch ON Position Power Button...
Raise and Lower Monitor Screen The monitor may be raised or lowered. To raise or lower screen, place hands on each side of the monitor and lift or lower to the desired height (Figure RL.1). NOTE: Handle with care when raising or lowering the monitor screen.
Remove Monitor Stand for Mounting To prepare the monitor for alternate mounting purposes: 1. Place hands on each side of the monitor and lift up to the highest position. Remove the cable cover (Figure M.1). NOTE: If you have difficulty removing the cable cover, please...
This LCD monitor is designed for use with a flexible arm. To mount the monitor to a flexible arm: 1. Follow the instruction on how to Remove Monitor Stand for Mounting to remove the stand. 2. Use the 4 screws from the stand removal to attach the arm to the monitor (Figure F.1).
(On-Screen Manager) control buttons on the front of the monitor function ® as follows: To access OSM menu, press any of the control buttons ( To change signal input, press the SELECT button (NX and VX only). NOTE: OSM must be closed in order to change signal input.
Page 12
OSM TURN OFF: The OSM control menu will stay on as long as it is in use. In the OSM Turn Off submenu, you can select how long the monitor waits after the last touch of a button to shut off the OSM control menu.
Page 13
No Signal window will appear. RESOLUTION NOTIFIER: This function gives a warming if the monitor is using a resolution other than the optimized resolution. After power is turned on or when there is a change of input signal or the video signal doesn’t have proper resolu- tion, the Resolution Notifier window will open.
• Do not place any heavy objects on the power cord. Damage to the cord may cause shock or fire. • Do not place this product on a sloping or unstable cart, stand or table, as the monitor may fall, causing serious damage to the monitor.
Page 15
• For optimum performance, allow 20 minutes for warm-up. • Adjust the monitor height so that the top of the screen is at or slightly below eye level. Your eyes should look slightly downward when viewing the middle of the screen.
(Intelligent Power Manager) System: Provides innovative power-saving methods that ® allow the monitor to shift to a lower power consumption level when on but not in use, saving two-thirds of your monitor energy costs, reducing emissions and lowering the air conditioning costs of the workplace.
• Check the signal input, “INPUT 1” or “INPUT 2”. Power Button does not respond • Unplug the power cord of the monitor from the AC outlet to turn off and reset the monitor. • Check the Vacation Switch on the back side of the monitor.
NEC Monitor Customer Service & Support Customer Service and Technical Support: (800) 632-4662 Parts and Accessories/Macintosh Cable Adapter: Warranty Information: Online Technical Support Sales and Product Information Sales Information Line: Canadian Customers: Government Sales: Government Sales email: Electronic Channels World Wide Web:...
U.S.A. or Canada by NEC DISPLAY SOLUTIONS No warranty service is provided outside of the U.S.A. or Canada. Proof of Purchase will be required by NEC DISPLAY SO- LUTIONS to substantiate date of purchase. Such proof of purchase must be an original bill of sale or receipt containing name and address of seller, purchaser, and the serial number of the product.
TCO’99 -Black Models Congratulations! You have just purchased a TCO’99 approved and la- belled product! Your choice has provided you with a product developed for professional use. Your purchase has also contributed to reducing the burden on the environment and also to the further development of environmentally adapted electronics products.
Page 24
-continued researchers fear that disturbances in foetus development may occur. TCO’99 demand requires that plastic components weighing more than 25 grams must not contain flame retardants with organically bound chlorine and bromine. Flame retardants are allowed in the printed circuit boards since no substitutes are available. Lead** Lead can be found in picture tubes, display screens, solders and capacitors.
-White Models Some of the features of the TCO’03 Display requirements: Ergonomics • Good visual ergonomics and image quality in order to improve the working environment for the user and to reduce sight and strain problems. Important parameters are luminance, contrast, resolution, reflectance, colour rendition and image stability.
ISO (International Organization for Standardization) and TCO (Swedish Trades Union). For more information, and for help in recycling your old NEC monitors, please visit our website at: USA: http://www.necdisplay.com...
Page 27
Council Directive 73/23/EEC: – EN 60950-1 Council Directive 89/336/EEC: – EN 55022 – EN 61000-3-2 – EN 61000-3-3 – EN 55024 and marked with NEC Display Solutions, Ltd. 4-13-23, Shibaura, Minato-Ku Tokyo 108-0023, Japan (L194RK), (L194RK) and (L194RH) are...
AFIN D’ÉVITER TOUT RISQUE D’INCENDIE OU D’ÉLECTROCUTION, NE PAS EXPOSER CET APPAREIL À LA PLUIE OU À L’HUMIDITÉ. NE PAS UTILISER LA FICHE D’ALIMENTATION POLARISÉE AVEC UNE PRISE DE CORDON DE RALLONGE OU AUTRE PRISE SAUF SI LES BROCHES PEUVENT ÊTRE ENTIÈREMENT INTRODUITES. NE PAS OUVRIR LE BOÎTIER, LEQUEL CONTIENT DES COMPOSANTS À...
Contenu La boîte* de votre nouveau moniteur NEC MultiSync • Moniteur MultiSync LCD1970V, LCD1970VX ou LCD1970NX avec sa base ajustable en hauteur • Cordon d’alimentation • Câble d’USB (NX seulement) • Câble pour le signal vidéo • Câble pour le signal vidéo Un cache-câbles...
D-SUB à 15 broches du câble de signal à l’adaptateur de câble Macintosh (Figure 3). Serrez toutes les vis. REMARQUE: Pour vous procurez l’adaptateur de câble Macintosh MultiSync, contactez NEC Display Solutions of America, Inc. au 1-800-632-4662. 3. Placez les mains de chaque côté du moniteur pour incliner l’écran ACL dans un angle de 30 degrés tout en le soulevant dans sa position la plus haute (Figure 4).
Page 31
Figure 4 Position du support la plus élevée Power cord (NX seulement) DC-OUT Fixationde produit NEC en option. N’utilisez pas ce connecteur sauf indication contraire. Figure 5 Cordon d’alimentation (milieu) Figure 2 Adaptateur de câble (non fourni) Remarque: Certains systémes Macintosh ne nécessitent pas un...
Page 32
Configuration de I’affichage (suite) Figure 7 Figure 8 Figure 9 Figure 11 Figure 10 Position OFF (Arrêt) Interrupteur de vacances Position On Bouton d’alimentation (Marche)
Page 33
Levez et baissez l’écran du moniteur Le moniteur peut être élevé ou abaissé. Pour élever ou abaisser l’écran, placez les mains de chaque côté du moniteur et situez-le à la hauteur de votre choix (Figure RL.1). REMARQUE: Manipule sur soin quand augmentant ou l’écran diminuant écran. Inclinaison et pivotement Maintenez les deux côtés du moniteur, puis ajustez l’inclinaison et l’orientation à...
Enlevez le support du moniteur pour le montage Pour préparer le moniteur à des fins de montage différents : 1. Placez les mains de chaque côté du moniteur en le soulevant dans sa posi- tion la plus haute. Enlevez la gaine de câble (Figure M.1). REMARQUE: Si vous avez la difficulté...
Installation du bras flexible Ce moniteur ACL est conçu pour une utilisation avec un bras flexible. Pour fixer le moniteur à un bras flexible: 1. Suivez les instructions sur comment enlever le support de moniteur pour le montage afin d’enlever le support. 2.
Les boutons de rélage OSM tes : Pour accéder au menu OSM, appuyez sur une des touches de commande Right, Down, Up) Pour changer l’entrée du signal, appuyez sur le bouton SELECT (NX ou VX seulement). REMARQUE: Le menu OSM doit être fermé pour pouvoir modifier le signal d’entrée. Bouton Menu principal MENU/EXIT...
Page 37
Commandes (suite) Systéme de contrôe des couleurs AccuColor ® Six colore prérégle sélectionner la désiré couleur mettant (sRGB et NATIVE couleur préré- gle sommes standards et cannot être transformé).R, V, B: Augmente ou diminue le niveau des couleurs rouge, vert ou bleu, suivant celui qui a été sélectionné. Le changement de couleur apparraît à...
Page 38
Commandes (suite) Avertissement OSM ® OSM prémunissant menu dispara ît sur Exit bouton. PAS DE SIGNAL: Cette fonctionne vous avertit de l’absence de signal. Après la mise sous tension ou si le signal d’entrée a été changé ou si la vidéo est inactive, la fen être PAS DE s’...
être mis hors tension pendant une heure pour effacer I’image.Comme pour tous les équipe- ments d’affichage personnels, NEC DISPLAY SOLUTIONS recommande d’afficher des images animées et d’utiliser à intervalles réguliers un économiseur d’écran animé chaque fois que l’écran est en veille, ou d’éteindre le moniteur lorsqu’il n’est pas utilisé.
Page 40
LA MODIFICATION DE LA POSITION ET DU RÉGLAGE DU MONITEUR PEUT RÉDUIRE LA FATIGUE DES YEUX, DES ÉPAULES ET DE LA NUQUE. OBSERVER LES DIRECTIVES CI-APRÈS LORS DU POSITIONNEMENT • Pour une performance optimale, laissez le moniteur se réchauffer pendant 20 minutes. •...
Page 41
• Veuillez ne pas utiliser du nettoyant OA parce qu’il causera une détérioration ou une décoloration sur la surface ACL. Nettoyage du coffret • Débranchez la source d’alimentation. • Essuyez délicatement le coffret avec un chiffon doux. • Pour nettoyer le coffret, humidifies le chiffon avec un détergent neutre et de l’eau, essuyez-le et continuez avec un chiffon sec.
Fonctions Le design à mince encadrement vous permet de libérer davantage d’espace pour travailler et jouer, alors que les images brillantes et éclatantes et le texte aussi clair que du cristal de l’éran plat vous offrent une expérience de visionnement incomparable. La fonction avancée Réglage automatique sans touche offre des réglages d’image opti- maux dès la mise sous tension initiale.
être mis hors tension pendant une heure pour effacer I’image.Comme pour tous les équipements d’affichage personnels, NEC DISPLAY SOLUTIONS recommande d’afficher des images animées et d’utiliser à intervalles réguliers un économiseur d’écran animé chaque fois que l’écran est en veille, ou d’éteindre le moniteur lorsqu’il n’est pas utilisé.
Service à la clientèle et assistance technique du moniteur NEC Service à la clientèle et assistance technique: (800) 632-4662 Pièces et accessoires/adaptateur de câble Macintosh: Information sur la garantie: Assistance technique en ligne Ventes et information produit Ligne d’information sur les ventes: Clientèle canadienne:...
être déterminée par le consommateur et n’est pas garantie par NEC DISPLAY SOLUTIONS. Pour connaître le nom du centre de service technique agréé NEC Display Solutions of America, Inc. le plus proche, appeler NEC Display Solutions of America, Inc. au 1-800-632-4662.
TCO’99 -le mod e noir (C’est une traduction de portion Anglaise de TCO’99.) Félicitations! Vous avez acheté un produit qui répond à la directive TCO’99. En choisissant ce produit conçu pour une utilisation professionnelle, vous contribuez aussi à la réduction des effets nuisibles sur l’environnement et aussi au développement continu de produits électroniques respectueux de l’environnement.
Page 50
(suite) organiquement liés. Les retardateurs de flame sont autorisés dans les cartes à circuits imprimés étant donné qu’aucun substitut n’est encore disponible. Plomb** Le plomb peut être présent dans les tubes cathodiques, les écrans, les soudures et les condensateurs. Le plomb s’attaque au système nerveux et, à doses élevées, entraîne l’intoxication par le plomb. La directive TCO’99 permet l’inclusion du plomb était donné...
TCO’03 le modéle blanc Voici certaines caractéristiques de ces directives « TCO’03 Display » : Ergonomie • Bonne ergonomie visuelle et qualité de l’image afin d’améliorer l’environnement de travail des utilisateurs, et afin de réduire les problèmes de vue et de tension nerveuse.
édictées par les organismes tels lSO (International Organization for Standardization) et TCO (Swedish Trades Union). Pour de plus amples informations et pour obtenir de l’aide pour recycler votre ancien moniteur NEC, veuillez visiter notre site Web au: É.-U.: http://www.necdisplay.com Europe: htttp://www.nec-display-solutions.com Japon: http://www.nec-display.com...
Page 53
73/23/EEC du Counseil: – EN 60950-1 la directive 89/336/EEC du Counseil: – EN 55022 – EN 61000-3-2 – EN 61000-3-3 – EN 55024 et porte le sigle NEC Display Solutions, Ltd. 4-13-23, Shibaura, Minato-Ku Tokyo 108-0023, Japan (L194RK), (L194RK) ou (L194RH)
Page 54
à condition que ces droits n’ont pas été directement délivrés à d’autres. Les produits de NEC Display Sulutions of America,Inc. dont il est question dans ce document sont garantis conformément aux termes de la déclaration de garantie limitée accompagnant chaque produit. Cependant, les performances réelles de chaque produit dépendent de facteurs tels que la configuration du système, les données du client et la manière...
Þ c i e n c y . h e N E R NEC LCD Series C C R u l e s . p e r a t i o n i s s u b j e c t t o t h e f o l l o w i n g t w o c o n d i t i o n s . ( ) t h i s d e v i c e m u s t a c c e p t a n y i n t e r f e r e n c e r e c e i v e d , i n c l u d i n g i n t e r f e r e n c e N E C D i s p l a y S o l u t i o n s o f A m e r i c a , I n c .
