THANK YOU We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this ceiling fan. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for...
Warranty The manufacturer warrants the fan motor to be free from defects in workmanship and material present at time of shipment from the factory for a period of lifetime after the date of purchase by the original purchaser. The manufacturer warrants the light kit (excluding any glass), to be free from defects in workmanship and material at the time of shipment from the factory for a period of three years after the date of purchase by the original purchaser.
Page 4
Pre-Installation (continued) HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity Plastic wire nut 9 watt LED bulb Pull chain and fob Hex wrench...
Page 5
Pre-Installation (continued) PACKAGE CONTENTS Part Description Quantity Part Description Quantity Mounting bracket (preassembled) Blade Canopy Blade arm Canopy bottom cover (preassembled) Switch housing Hanger ball/downrod assembly Light kit Coupling cover Light cover assembly Fan motor assembly HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance.
Installation MOUNTING OPTIONS NOTE: You may need a longer downrod to maintain proper WARNING: To reduce the risk of fire, electric shock, or blade clearance when installing on a steep, sloped ceiling. personal injury, mount the fan to an outlet box marked The maximum angle allowable is 18°...
Assembly Preparing the canopy Preparing the motor Remove the canopy bottom cover (C) from the canopy (B) by Remove the cotter pin (FF) and clevis pin (GG), and loosen turning the canopy bottom cover (C) counterclockwise. the two collar set screws (HH) from the fan motor assembly (F) collar.
Page 8
Assembly — Hanging the Fan Installing the mounting bracket to the Hanging the fan on the mounting electrical box bracket WARNING: The tab in the ring must rest in the groove of WARNING: To reduce the risk of fire, electric shock or other the hanger ball/downrod assembly (D).
Page 9
Assembly — Hanging the Fan (continued) Making the electrical connections Ground WARNING: To avoid possible electrical shock, be sure Neutral conductor electricity is turned off at the main fuse box before wiring. Black White WARNING: Check to see that all connections are tight, including ground, and that no bare wire is visible at the wire nuts, except for the ground wire.
Page 10
Assembly — Hanging the Fan (optional) Single Switch Connections Dual Switch Connections On a single switch the fan and light can be turned on or off On a dual switch the fan and light can be turned on or off together.
Page 11
Assembly — Hanging the Fan (continued) Installing the canopy Attaching the canopy bottom cover NOTE: Adjust the canopy mounting screws (EE) as necessary WARNING: Make sure the tab on the mounting bracket (A) until the canopy (B) and canopy bottom cover (C) are snug. properly sits in the groove in the hanger ball (D) before attaching the canopy (B) to the mounting bracket (A) by turning the canopy housing until it drops into place.
Page 12
Assembly — Attaching the Fan Blades Removing the rubber packing mounts The fan motor assembly (F) is shipped with rubber packing mounts (II) to prevent movement during transportation. Remove the five rubber packing mounts (II) from the fan motor assembly (F) and discard prior to attaching the blade arms (H).
Page 13
Assembly — Attaching the Fan Blades (continued) Fastening the blade assemblies to the motor WARNING: To reduce the risk of personal injury, do not bend the blade arms (H) while installing, balancing the blades (H), or cleaning the fan. Do no insert foreign objects between rotating fan blades (G).
Page 14
Assembly — Installing the Light Kit Attaching the switch housing to Attaching the light kit assembly to the mounting ring the switch housing Remove one of the three light kit mounting screws (SS) from CAUTION: Before starting installation, disconnect the the switch housing (I) and loosen the other two screws (SS).
Page 15
Assembly — Installing the Light Kit (continued) Installing the light bulbs and light cover assembly CAUTION: Before starting installation, disconnect the power by turning off the circuit breaker or removing the fuse at the fuse box. Turning power off using the fan switch is not sufficient to prevent electric shock.
Operation PULL CHAIN OPERATING INSTRUCTIONS Install the pull chains and fobs (CC) onto the pull chains located in the switch housing (I). Turn on the power and check the operation of the fan. The pull chain controls the fan speed as follows: 1 pull - High, 2 pulls - Medium, 3 pulls - Low, and 4 pulls - Off.
Care and Cleaning Check the support connections, brackets, and blade attachments twice a year. Make sure they are secure. Because of the fan’s natural movement, some connections may become loose over time. It is not necessary to remove the fan from the ceiling. Clean your fan periodically.
Page 18
- Consult the dealer or an experienced radio/TV technician for help. Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service 8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST Saturday 1-855-HD-HAMPTON HAMPTONBAY.COM...
