- Page 1 User’s Manual of IGT-90x User’s Manual IGT-902 / 902T IGT-902S / 902TS IGT-905A 10/100/1000Base-T to 1000Base-SX / LX Industrial Managed Media Converter...
- Page 2 PLANET has made every effort to ensure that this User's Manual is accurate; PLANET disclaims liability for any inaccuracies or omissions that may have occurred.
-
Page 3: Table Of Contents
3.3 Management Methods............................. 20 3.3.1 Web Management ............................20 3.3.2 Login the Industrial Managed Media Converter....................20 3.3.3 SNMP Management ............................21 3.3.4 PLANET Smart Discovery Utility........................21 4. WEB MANAGEMENT ....................24 4.1 Main Menu................................24 4.2 System ..................................25 4.2.1 System Information............................ - Page 4 User’s Manual of IGT-90x 4.2.6 Factory Default ..............................33 4.2.7 System Reboot ..............................35 4.3 Port Management..............................37 4.3.1 Port Configuration............................. 37 4.3.2 Port Status ................................ 40 4.3.3 Port Statistics..............................41 4.4 Converter Configuration ............................42 4.5 VLAN ..................................43 4.5.1 VLAN Group ..............................
-
Page 5: Introduction
User’s Manual of IGT-90x 1. INTRODUCTION 1.1 Package Contents Check the contents of your package for following parts: Industrial Managed Gigabit Ethernet Media Converter x1 ● CD-ROM User's Manual x1 ● Quick Installation Guide x1 ● Wall Mount Kit x1 ●... -
Page 6: Product Description
User’s Manual of IGT-90x 1.3 Product Description The Industrial Managed Media Converter IGT-90X provide conversion between 10/100/1000Base-T and 1000Base-SX /LX network. There are SC / LC connectors and single-mode / multi-mode media for your needs. Ethernet signal that allows two type segments connect easily, efficiently and inexpensively. The Industrial Managed Media Converter equipped with remote Web / SNMP interface. -
Page 7: Product Features
User’s Manual of IGT-90x 1.5 Product Features Interface 1-Port 10/100/1000Base-T RJ-45 with Auto-negotiation and Auto-MDI/MDI-X function 1 Port 1000Base-SX SC interface, provide long distance up to 220/550m on IGT-902/902T 1 Port 1000Base-LX SC interface, provides long distance for 10km on IGT-902S/902TS 1 Mini-GBIC slot, port provides multi choice of SFP modules on IGT-905A Industrial Conformance 12 to 48V DC, redundant power with polarity reverse protect function... -
Page 8: Product Specification
TS-1000 OAM / IEEE 802.3ah OAM / Loop Back Test 16 TCP / UDP Filter groups Password setting, IP setting and devices description setting through Planet Smart discovery utility Firmware upgrade via remote Web interface Reset Button at the front panel for the factory default reset 1.6 Product Specification... - Page 9 User’s Manual of IGT-90x 12 to 48V DC Power Input Redundant power with polarity reverse protection function 7.7 Watts/ 26 BTU (maximum) Power Consumption -10~60 -30~75 -10~60 -30~75 -30~75 Operating Temperature Degree C Degree C Degree C Degree C Degree C 5~90% non-condensing Operating Humidity -20~85...
-
Page 10: Hardware Installation
SFP ports and one Auto-Sensing 10/100/1000Mbps Ethernet RJ-45 Port. Figure 2-1, 2-2, 2-3, 2-4 & 2-5 shows a front panel of Industrial Managed Media Converter. Figure 2-1 & 2-2 PLANET Figure 2-3 & 2-4 PLANET Figure2-5 PLANET IGT-902 / IGT-902S Front Panel... -
Page 11: Led Indicators
User’s Manual of IGT-90x 2.1.1 LED Indicators Color Function Indicate the power 1 has power. Green Indicate the power 2 has power. Green Indicate the either power 1 or power 2 has no power. Green FAULT To indicate that the Fiber Optical Port is successfully connecting to the Lights Fiber network at 1000Mbps. -
Page 12: Wiring The Power Inputs
User’s Manual of IGT-90x 2.1.3 Wiring the Power Inputs The 6-contact terminal block connector on the top panel of Industrial Media Converter is used for two DC redundant powers input. Please follow the steps below to insert the power wire. 1. -
Page 13: Wiring The Fault Alarm Contact
User’s Manual of IGT-90x 2.1.4 Wiring the Fault Alarm Contact The fault alarm contacts are in the middle of the terminal block connector as the picture shows below. Inserting the wires, the Industrial Management Media Converter will detect the fault status of the power failure, or port link failure (available for managed model) and then forms an open circuit. -
Page 14: Mounting Installation
In the installation steps below, this Manual use IGS-801(PLANET 8 Port Industrial Gigabit Switch) as the example. However, the steps for PLANET Industrial Switch & Industrial Media / Serial Converter are similar. -
Page 15: Wall Mount Plate Mounting
User’s Manual of IGT-90x Step 3: Check the DIN-Rail is tightly on the track. Step 4: Please refer to following procedures to remove the Industrial Gigabit Ethernet Switch from the track. Step 5: Lightly press the button of DIN-Rail for remove it from the track. 2.2.2 Wall Mount Plate Mounting To install the Industrial Equipment on the wall, please follows the instructions described below. -
Page 16: Stand-Alone Installation
User’s Manual of IGT-90x Step 3: Use the screws to screw the wall mount plate on the Industrial Equipment. Step 4: Use the hook holes at the corners of the wall mount plate to hang the Industrial Equipment on the wall. Step 5: To remove the wall mount plate, reverse steps above. - Page 17 Step 3: Connect the fiber cable. Attach the duplex LC connector on the network cable into the SFP transceiver. Figure 2-8 IGT- 905A stand alone installation It recommends using PLANET MGB series 1000Base-SX / LX / LX WDM SFP on the IGT-905A. If you insert a SFP transceiver that is not supported, the IGT-905A will not recognize it.
- Page 18 User’s Manual of IGT-90x SFP-Port 1000Base-LX mini-GBIC module- LC WDM(TX:1310nm), SM,10km MGB-LA10 SFP-Port 1000Base-LX mini-GBIC module- LC WDM(TX:1550nm), SM,10km MGB-LB10 SFP-Port 1000Base-LX mini-GBIC module- LC WDM(TX:1310nm), SM,20km MGB-LA20 SFP-Port 1000Base-LX mini-GBIC module- LC WDM(TX:1550nm), SM,20km MGB-LB20 SFP-Port 1000Base-LX mini-GBIC module- LC WDM(TX:1310nm), SM,40km MGB-LA40 SFP-Port 1000Base-LX mini-GBIC module- LC WDM(TX:1550nm), SM,40km MGB-LB40...
-
Page 19: Industrial Media Converter Management
User’s Manual of IGT-90x 3. INDUSTRIAL MEDIA CONVERTER MANAGEMENT This chapter describes how to manage the Industrial Managed Media Converter. Topics include: - Overview - Management methods - Assigning an IP address to the Industrial Managed Media Converter - Logging on to the Industrial Managed Media Converter 3.1 Overview This chapter gives an overview of Industrial Managed Media Converter management. -
Page 20: Management Methods
-Using SNMP Network Management Station. 3.3.1 Web Management The PLANET Industrial Managed Media Converter provides a built-in browser interface. You can manage the Industrial Managed Media Converter remotely by having a remote host with Web browser, such as Microsoft Internet Explorer, Netscape Navigator or Mozilla Firefox.
