Icom IC-F3011 Service Manual Addendum page 13

SECTION 1.
P
GENERAL
• Frequency coverage
• Type of emission
• Channel spacing
• Number of conventional channels
• Antenna impedance
• Operating temperature range
• Power supply requirement
• Current drain (at 7.2 V DC ; approx.)
• Dimensions (projections not included)
• Weight (Including BP-231)
P
TRANSMITTER
• Output power (at 7.2 V DC)
• Modulation
• Maximum permissible deviation
• Frequency error
• Spurious emissions
• Adjacent channel power
• Audio harmonic distortion
• FM Hum and Noise (without CCITT filter) : 40 dB min. (46 dB typ.) for Wide
• Limiting charact of modulator
• Microphone impedance
P
RECEIVER
• Receive system
• Intermediate frequencies
• Sensitivity
• Adjacent channel selectivity
• Spurious response
• Intermodulation rejection ratio
• Hum and Noise (without CCITT filter)
• Audio output power
• Squelch sensitivity (at threshold)
• Output impedance (audio)
Specifications are measured in accordance with TIA-603.
All stated specifications are subject to change without notice or obligation.
SPECIFICATIONS
: 136–174 MHz
: 16K0F3E (25.0 kHz) for Wide
: 11K0F3E (12.5 kHz) for Narrow
: 15.0/30.0 kHz
: 16 ch
: 50 Ω
: –30˚C to +60˚C (–22˚F to +140˚F)
: Specified Icom's battery pack only (7.2 V DC nominal; negative ground)
:
RECEIVING
Stand-by Max. audio
70 mA
: 53.0 (W)×120.0 (H)×38.0 (D) mm; 2
3
: Approx. 260 g (9 /
16 oz
: 5 W (Hi)/2 W (L2)/1 W (L1)
: Variable reactance frequency modulation
: ±5.0 kHz (Wide), ±2.5 kHz (Narrow)
: ±2.5 ppm
: 80 dB typ.
: 70 dB min. (80 dB typ.) for Wide
60 dB min. (70 dB typ.) for Narrow
: 3% typ. (at 1 kHz, 40% deviation)
34 dB min. (40 dB typ.) for Narrow
: 60–100% of maximum deviation
: 2.2 kΩ
: Double conversion superheterodyne system
: 1st IF: 46.35 MHz, 2nd IF: 450 kHz
: 0.25 µV (–119 dBm) typ. at 12 dB SINAD
: 70 dB min. (75 dB typ.) for Wide
60 dB min. (65 dB typ.) for Narrow
: 70 dB min.
: 70 dB min. (74 dB typ.)
: 40 dB min. (50 dB typ.) for Wide
34 dB min. (45 dB typ.) for Narrow
: 0.5 W typ. (at 5% distortion with an 8 Ω load)
: 0.25 µV typ.
: 8 Ω
1 - 1
TRANSMITTING
High (at 5 W)
300 mA 1.5 A
3 / (W)×4 23 /
32 32
)
Low (at 1 W)
0.7 A
(H)×1 1 / (D) in
2
