Instructions G3 Reservoir Replacement Kit 3A6385A Instructions for replacing G3 reservoir. For professional use only. Part No.: 8 Liter - 25E455 12 Liter - 25E456 16 Liter - 25E457 20 Liter - 25E458 Important Safety Instructions Read all warnings and instructions in this manual and the G3 Pump Instruction manual included with your unit.
Page 2
Instructions Instructions Disassembly Reference numbers used in these instructions Pressure Relief correspond to parts included in Kit. Parts identified with an alpha character are user provided or already installed components. WARNING Reservoir Disassembly 1. Pump or drain all grease from reservoir to relieve spring pressure on follower plate.
Page 3
Securely tighten nuts (8) on the bottom of the tie NOTICE rods (F . 7). Be careful when installing reservoir that the seal is not pinched. If the seal is not correctly installed, grease could leak out of the bottom of the G3 reser- 9/10 voir. 3A6385A...
