Icom IC-F4TR Service Manual page 13

[MAIN UNIT]
REF ORDER
NO. NO.
R453 7030005230 S.RESISTOR
R455 7030005090 S.RESISTOR
R456 7030005030 S.RESISTOR
R457 7030008010 S.RESISTOR
R458 7030005600 S.RESISTOR
R459 7030005220 S.RESISTOR
R460 7030004990 S.RESISTOR
R464 7030008410 S.RESISTOR
R465 7030007250 S.RESISTOR
R466 7030009320 S.RESISTOR
R467 7030005240 S.RESISTOR
R468 7030005110 S.RESISTOR
R469 7030009140 S.RESISTOR
R470 7030005090 S.RESISTOR
R471 7030005240 S.RESISTOR
R472 7030005240 S.RESISTOR
R473 7030005090 S.RESISTOR
R474 7030005230 S.RESISTOR
R480 7030005230 S.RESISTOR
R481 7030005090 S.RESISTOR
R482 7030008010 S.RESISTOR
R483 7030007340 S.RESISTOR
R484 7030005220 S.RESISTOR
R485 7030009140 S.RESISTOR
R486 7030008010 S.RESISTOR
R487 7030007340 S.RESISTOR
R491 7030009700 S.RESISTOR
R492 7030009710 S.RESISTOR
R493 7030008010 S.RESISTOR
R494 7030008410 S.RESISTOR
R495 7030005530 S.RESISTOR
R496 7030009700 S.RESISTOR
R497 7030009700 S.RESISTOR
R498 7030008010 S.RESISTOR
R500 7030005240 S.RESISTOR
R503 7030005090 S.RESISTOR
R504 7030007300 S.RESISTOR
R505 7410000950 S.ARRAY
R508 7030005240 S.RESISTOR
R509 7030007350 S.RESISTOR
R512 7030008400 S.RESISTOR
R514 7030008290 S.RESISTOR
R516 7030005090 S.RESISTOR
R517 7030005090 S.RESISTOR
R519 7410000750 S.ARRAY
R520 7030005090 S.RESISTOR
R521 7030005220 S.RESISTOR
R522 7030005600 S.RESISTOR
R523 7030005600 S.RESISTOR
R524 7030005600 S.RESISTOR
R525 7410000770 S.ARRAY
R526 7410000850 S.ARRAY
R527 7410000950 S.ARRAY
R528 7410000950 S.ARRAY
R529 7030005120 S.RESISTOR
R530 7410000770 S.ARRAY
R531 7030005120 S.RESISTOR
R532 7410000770 S.ARRAY
R533 7410000770 S.ARRAY
R534 7410000950 S.ARRAY
R535 7410000770 S.ARRAY
R536 7030005120 S.RESISTOR
R537 7030005120 S.RESISTOR
R538 7030005090 S.RESISTOR
R539 7410000950 S.ARRAY
R540 7410000950 S.ARRAY
R545 7030008370 S.RESISTOR
R547 7030005720 S.RESISTOR
R548 7410000730 S.ARRAY
R549 7030005240 S.RESISTOR
R550 7030005070 S.RESISTOR
R551 7030007600 S.RESISTOR
R552 7030007290 S.RESISTOR
R553 7030005090 S.RESISTOR
R555 7030005240 S.RESISTOR
R556 7030009320 S.RESISTOR
R557 7030006610 S.RESISTOR
R558 7030006610 S.RESISTOR
R559 7410000770 S.ARRAY
R560 7410000750 S.ARRAY
R561 7030005120 S.RESISTOR
DESCRIPTION
ERJ2GEJ 334 X (330 kΩ)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 152 X (1.5 kΩ)
ERJ2GEJ 123 X (12 kΩ)
ERJ2GEJ 273 X (27 kΩ)
ERJ2GEJ 223 X (22 kΩ)
ERJ2GEJ 221 X (220 Ω)
ERJ2GEJ 392 X (3.9 kΩ)
ERJ2GEJ 220 X (22 Ω)
ERJ2GEJ 4R7 X (4.7 Ω)
ERJ2GEJ 473 X (47 kΩ)
ERJ2GEJ 224 X (220 kΩ)
ERJ2GEJ 272 X (2.7 kΩ)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 473 X (47 kΩ)
ERJ2GEJ 473 X (47 kΩ)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 334 X (330 kΩ)
ERJ2GEJ 334 X (330 kΩ)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 123 X (12 kΩ)
ERJ2GEJ 153 X (15 kΩ)
ERJ2GEJ 223 X (22 kΩ)
ERJ2GEJ 272 X (2.7 kΩ)
ERJ2GEJ 123 X (12 kΩ)
ERJ2GEJ 153 X (15 kΩ)
ERJ2GEJ 202 X (2 kΩ)
ERJ2GEJ 203 X (20 kΩ)
ERJ2GEJ 123 X (12 kΩ)
ERJ2GEJ 392 X (3.9 kΩ)
ERJ2GEJ 100 X (10 Ω)
ERJ2GEJ 202 X (2 kΩ)
ERJ2GEJ 202 X (2 kΩ)
ERJ2GEJ 123 X (12 kΩ)
ERJ2GEJ 473 X (47 kΩ)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 332 X (3.3 kΩ)
EXB-V8V 102 JV (1 kΩ)
ERJ2GEJ 473 X (47 kΩ)
ERJ2GEJ 393 X (39 kΩ)
ERJ2GEJ 182 X (1.8 kΩ)
ERJ2GEJ 183 X (18 kΩ)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 104 X (100 kΩ)
EXB-V4V 104JV (100 kΩ)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 223 X (22 kΩ)
ERJ2GEJ 273 X (27 kΩ)
ERJ2GEJ 273 X (27 kΩ)
ERJ2GEJ 273 X (27 kΩ)
EXB-V4V 102 JV (1 kΩ)
EXB-V4V 151 JV (150 Ω)
EXB-V8V 102 JV (1 kΩ)
EXB-V8V 102 JV (1 kΩ)
ERJ2GEJ 102 X (1 kΩ)
EXB-V4V 102 JV (1 kΩ)
ERJ2GEJ 102 X (1 kΩ)
EXB-V4V 102 JV (1 kΩ)
EXB-V4V 102 JV (1 kΩ)
EXB-V8V 102 JV (1 kΩ)
EXB-V4V 102JV (1 kΩ)
ERJ2GEJ 102 X (1 kΩ)
ERJ2GEJ 102 X (1 kΩ)
ERJ2GEJ 104 X (100 kΩ)
EXB-V8V 102 JV (1 kΩ)
EXB-V8V 102 JV (1 kΩ)
ERJ2GEJ 561 X (560 Ω)
ERJ2GEJ 563 X (56 kΩ)
EXB-V8V 104 JV (100 kΩ)
ERJ2GEJ 473 X (47 kΩ)
ERJ2GEJ 683 X (68 kΩ)
RR0816R-913-D (91 kΩ)
ERJ2GEJ 222 X (2.2 kΩ)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 473 X (47 kΩ)
ERJ2GEJ 4R7 X (4.7 Ω)
ERJ2GEJ 394 X (390 kΩ)
ERJ2GEJ 394 X (390 kΩ)
EXB-V4V 102 JV (1 kΩ)
EXB-V4V 104 JV (100 kΩ)
ERJ2GEJ 102 X (1 kΩ)
[MAIN UNIT]
REF ORDER
NO. NO.
R562 7030005090 S.RESISTOR
R563 7030005050 S.RESISTOR
R564 7030005220 S.RESISTOR
R565 7030009320 S.RESISTOR
R566 7030009530 S.RESISTOR
R567 7030004980 S.RESISTOR
R568 7030004980 S.RESISTOR
R569 7030004980 S.RESISTOR
R571 7030005040 S.RESISTOR
R572 7030005220 S.RESISTOR
R573 7030004980 S.RESISTOR
R574 7030005110 S.RESISTOR
R575 7030005120 S.RESISTOR
R578 7030008290 S.RESISTOR
R579 7410000770 S.ARRAY
R581 7030007350 S.RESISTOR
R582 7030004980 S.RESISTOR
R584 7310004090 S.TRIMMER
R585 7030005220 S.RESISTOR
R586 7030005220 S.RESISTOR
R587 7030005220 S.RESISTOR
R589 7030005090 S.RESISTOR
R590 7030009320 S.RESISTOR
R591 7030008010 S.RESISTOR
R592 7030005720 S.RESISTOR
R593 7030005060 S.RESISTOR
R594 7030005090 S.RESISTOR
R595 7030005090 S.RESISTOR
R596 7030004980 S.RESISTOR
R597 7030005040 S.RESISTOR
R598 7030005240 S.RESISTOR
R599 7030005240 S.RESISTOR
R600 7030005050 S.RESISTOR
R601 7030005090 S.RESISTOR
R602 7030007340 S.RESISTOR
R603 7030008400 S.RESISTOR
R604 7030005170 S.RESISTOR
R605 7030008300 S.RESISTOR
R606 7030009320 S.RESISTOR
R607 7030009320 S.RESISTOR
R608 7030005090 S.RESISTOR
R609 7030003500 S.RESISTOR
R610 7030003500 S.RESISTOR
R611 7030005240 S.RESISTOR
R612 7030007280 S.RESISTOR
R613 7510001240 S.THEMISTOR
R614 7030005050 S.RESISTOR
R615 7030009290 S.RESISTOR
R616 7510001240 S.THEMISTOR
R617 7030008010 S.RESISTOR
R618 7030005050 S.RESISTOR
R619 7030005170 S.RESISTOR
C3 4030006990 S.CERAMIC
C4 4030009500 S.CERAMIC
C5 4030009920 S.CERAMIC
C7 4030009530 S.CERAMIC
C8 4030010760 S.CERAMIC
C9 4030014490 S.CERAMIC
C10 4030014490 S.CERAMIC
C11 4030006990 S.CERAMIC
C12 4030014490 S.CERAMIC
C13 4030014490 S.CERAMIC
C14 4030016790 S.CERAMIC
C15 4030014160 S.CERAMIC
4030009780 S.CERAMIC
C16 4030014490 S.CERAMIC
C17 4030014490 S.CERAMIC
C18 4030014490 S.CERAMIC
C19 4030014490 S.CERAMIC
C20 4030014490 S.CERAMIC
C21 4510005310 S.ELECTROLYTIC ECEV1CA220SR
C22 4030014060 S.CERAMIC
C24 4030014490 S.CERAMIC
C25 4030014120 S.CERAMIC
C26 4030014490 S.CERAMIC
C27 4030014080 S.CERAMIC
C28 4030014130 S.CERAMIC
C30 4030014130 S.CERAMIC
C31 4030014080 S.CERAMIC
6 - 3
DESCRIPTION
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 223 X (22 kΩ)
ERJ2GEJ 4R7 X (4.7 Ω)
ERJ2GEJ 270 X (27 Ω)
ERJ2GEJ 101 X (100 Ω)
ERJ2GEJ 101 X (100 Ω)
ERJ2GEJ 101 X (100 Ω)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 223 X (22 kΩ)
ERJ2GEJ 101 X (100 Ω)
ERJ2GEJ 224 X (220 kΩ)
ERJ2GEJ 102 X (1 kΩ)
ERJ2GEJ 183 X (18 kΩ)
EXB-V4V 102JV (1 kΩ)
ERJ2GEJ 393 X (39 kΩ)
ERJ2GEJ 101 X (100 Ω)
EVM-1YSX50 B14 (103)
ERJ2GEJ 223 X (22 kΩ)
ERJ2GEJ 223 X (22 kΩ)
ERJ2GEJ 223 X (22 kΩ)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 4R7 X (4.7 Ω)
ERJ2GEJ 123 X (12 kΩ)
ERJ2GEJ 563 X (56 kΩ)
ERJ2GEJ 333 X (33 kΩ)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 101 X (100 Ω)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 473 X (47 kΩ)
ERJ2GEJ 473 X (47 kΩ)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 153 X (15 kΩ)
ERJ2GEJ 182 X (1.8 kΩ)
ERJ2GEJ 474 X (470 kΩ)
ERJ2GEJ 184 X (180 kΩ)
ERJ2GEJ 4R7 X (4.7 Ω)
ERJ2GEJ 4R7 X (4.7 Ω)
ERJ2GEJ 104 X (100 kΩ)
ERJ3GEYJ 332 V (3.3 kΩ)
ERJ3GEYJ 332 V (3.3 kΩ)
ERJ2GEJ 473 X (47 kΩ)
ERJ2GEJ 331 X (330 Ω)
ERTJ0EV 473 J (47K)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 562 X (5.6 kΩ)
ERTJ0EV 473 J (47K)
ERJ2GEJ 123 X (12 kΩ)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 474 X (470 kΩ)
C1608 CH 1H 080D-T-A
C1608 CH 1H 0R5B-T-A
C1608 CH 1H 050B-T-A
C1608 CH 1H 030B-T-A
C1608 CH 1H 331J-T-A
ECUE1E331KBQ
ECUE1E331KBQ
C1608 CH 1H 080D-T-A
ECUE1E331KBQ
ECUE1E331KBQ
ECJ0EB1C103K
ECUE1H270JCQ [24 keys]
C1005 CH 1E 270J-T-A [7 keys]
ECUE1E331KBQ
ECUE1E331KBQ
ECUE1E331KBQ
ECUE1E331KBQ
ECUE1E331KBQ
ECUE1H3R5BCQ
ECUE1E331KBQ
ECUE1H100CCQ
ECUE1E331KBQ
ECUE1H050BCQ
ECUE1H120JCQ
ECUE1H120JCQ
ECUE1H050BCQ
S.=Surface mount
