Icom IC-F4TR Service Manual page 12

[MAIN UNIT]
REF ORDER
NO. NO.
L420 6200004780 S.COIL
L421 6200004780 S.COIL
L422 6200004780 S.COIL
L423 6200004780 S.COIL
L424 6200004780 S.COIL
L425 6200005650 S.COIL
L426 6200005650 S.COIL
L427 6200005670 S.COIL
L428 6200006770 S.COIL
R1 7030003670 S.RESISTOR
R2 7030005050 S.RESISTOR
R3 7030005120 S.RESISTOR
R7 7030004980 S.RESISTOR
R8 7030005210 S.RESISTOR
R9 7030005210 S.RESISTOR
R12 7030005220 S.RESISTOR
R13 7030005530 S.RESISTOR
R14 7030004980 S.RESISTOR
R15 7030005050 S.RESISTOR
R17 7030005040 S.RESISTOR
R18 7030005240 S.RESISTOR
R19 7030004980 S.RESISTOR
R20 7030005070 S.RESISTOR
R21 7030004990 S.RESISTOR
R22 7030005070 S.RESISTOR
R23 7030004990 S.RESISTOR
R40 7030007060 S.RESISTOR
R41 7030005580 S.RESISTOR
R42 7410000950 S.ARRAY
R44 7030007570 S.RESISTOR
R46 7030009320 S.RESISTOR
R52 7030005090 S.RESISTOR
R53 7030005050 S.RESISTOR
R54 7030005100 S.RESISTOR
R59 7030004980 S.RESISTOR
R62 7030005110 S.RESISTOR
R63 7030005050 S.RESISTOR
R64 7030005110 S.RESISTOR
R65 7030005050 S.RESISTOR
R66 7030005100 S.RESISTOR
R67 7030005050 S.RESISTOR
R68 7030005050 S.RESISTOR
R69 7030005120 S.RESISTOR
R70 7030005040 S.RESISTOR
R72 7030005240 S.RESISTOR
R75 7030008280 S.RESISTOR
R77 7030004980 S.RESISTOR
R82 7030007290 S.RESISTOR
R83 7030009320 S.RESISTOR
R84 7030004970 S.RESISTOR
R85 7030005030 S.RESISTOR
R86 7030005090 S.RESISTOR
R87 7030009270 S.RESISTOR
R88 7030005230 S.RESISTOR
R89 7030005050 S.RESISTOR
R90 7030005030 S.RESISTOR
R92 7310004110 S.TRIMMER
R94 7030007350 S.RESISTOR
R95 7030007290 S.RESISTOR
R97 7030005060 S.RESISTOR
R98 7030005230 S.RESISTOR
R99 7030007340 S.RESISTOR
R100 7030008400 S.RESISTOR
R103 7030008010 S.RESISTOR
R104 7030005090 S.RESISTOR
R105 7030004990 S.RESISTOR
R107 7030005110 S.RESISTOR
R108 7030008300 S.RESISTOR
R109 7030005120 S.RESISTOR
R112 7030005090 S.RESISTOR
R114 7030005060 S.RESISTOR
R116 7030005120 S.RESISTOR
R117 7030008400 S.RESISTOR
R119 7310004090 S.TRIMMER
R120 7030005070 S.RESISTOR
R121 7030005120 S.RESISTOR
R122 7030009700 S.RESISTOR
R123 7030007290 S.RESISTOR
R124 7030009140 S.RESISTOR
DESCRIPTION
MLF1608A 1R5K-T
MLF1608A 1R5K-T
MLF1608A 1R5K-T
MLF1608A 1R5K-T
MLF1608A 1R5K-T
ELJRE 8N2Z-F
ELJRE 8N2Z-F
ELJRE 12NG-F
ELJRE 1N5Z-F
ERJ3GEYJ 823 V (82 kΩ)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 102 X (1 kΩ)
ERJ2GEJ 101 X (100 Ω)
ERJ2GEJ 822 X (8.2 kΩ)
ERJ2GEJ 822 X (8.2 kΩ)
ERJ2GEJ 223 X (22 kΩ)
ERJ2GEJ 100 X (10 Ω)
ERJ2GEJ 101 X (100 Ω)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 473 X (47 kΩ)
ERJ2GEJ 101 X (100 Ω)
ERJ2GEJ 683 X (68 kΩ)
ERJ2GEJ 221 X (220 Ω)
ERJ2GEJ 683 X (68 kΩ)
ERJ2GEJ 221 X (220 Ω)
ERJ2GEJ 684 X (680 kΩ)
ERJ2GEJ 560 X (56 Ω)
EXB-V8V 102 JV (1 kΩ)
ERJ2GEJ 122 X (1.2 kΩ)
ERJ2GEJ 4R7 X (4.7 Ω)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 154 X (150 kΩ)
ERJ2GEJ 101 X (100 Ω)
ERJ2GEJ 224 X (220 kΩ)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 224 X (220 kΩ)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 154 X (150 kΩ)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 102 X (1 kΩ)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 473 X (47 kΩ)
ERJ2GEJ 271 X (270 Ω)
ERJ2GEJ 101 X (100 Ω)
ERJ2GEJ 222 X (2.2 kΩ)
ERJ2GEJ 4R7 X (4.7 Ω)
ERJ2GEJ 470 X (47 Ω)
ERJ2GEJ 152 X (1.5 kΩ)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 821 X (820 Ω)
ERJ2GEJ 334 X (330 kΩ)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 152 X (1.5 kΩ)
EVM-1YSX50 B54 (503)
ERJ2GEJ 393 X (39 kΩ)
ERJ2GEJ 222 X (2.2 kΩ)
ERJ2GEJ 333 X (33 kΩ)
ERJ2GEJ 334 X (330 kΩ)
ERJ2GEJ 153 X (15 kΩ)
ERJ2GEJ 182 X (1.8 kΩ)
ERJ2GEJ 123 X (12 kΩ)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 221 X (220 Ω)
ERJ2GEJ 224 X (220 kΩ)
ERJ2GEJ 184 X (180 kΩ)
ERJ2GEJ 102 X (1 kΩ)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 333 X (33 kΩ)
ERJ2GEJ 102 X (1 kΩ)
ERJ2GEJ 182 X (1.8 kΩ)
EVM-1YSX50 B14 (103)
ERJ2GEJ 683 X (68 kΩ)
ERJ2GEJ 102 X (1 kΩ)
ERJ2GEJ 202 X (2 kΩ)
ERJ2GEJ 222 X (2.2 kΩ)
ERJ2GEJ 272 X (2.7 kΩ)
[MAIN UNIT]
REF ORDER
NO. NO.
R125 7030005600 S.RESISTOR
R126 7030009320 S.RESISTOR
R127 7030003200 S.RESISTOR
R128 7030003200 S.RESISTOR
R130 7030005090 S.RESISTOR
R131 7030005000 S.RESISTOR
R132 7030005000 S.RESISTOR
R133 7030005120 S.RESISTOR
R134 7030007290 S.RESISTOR
R135 7030005050 S.RESISTOR
R137 7030005040 S.RESISTOR
R139 7030005040 S.RESISTOR
R141 7030005040 S.RESISTOR
R144 7030005060 S.RESISTOR
R146 7030005090 S.RESISTOR
R147 7030005110 S.RESISTOR
R148 7030005090 S.RESISTOR
R149 7030005050 S.RESISTOR
R153 7030005120 S.RESISTOR
R154 7030008290 S.RESISTOR
R155 7030004980 S.RESISTOR
R156 7030000160 S.RESISTOR
R157 7030000160 S.RESISTOR
R158 7030005050 S.RESISTOR
R160 7030000290 S.RESISTOR
R161 7030007330 S.RESISTOR
R162 7030005120 S.RESISTOR
R163 7030005060 S.RESISTOR
R164 7030009140 S.RESISTOR
R165 7030008400 S.RESISTOR
R167 7030005090 S.RESISTOR
R174 7030007340 S.RESISTOR
R176 7030008410 S.RESISTOR
R178 7030008410 S.RESISTOR
R181 7030005090 S.RESISTOR
R182 7510001240 S.THEMISTOR
R184 7030005050 S.RESISTOR
R185 7030005120 S.RESISTOR
R186 7030005240 S.RESISTOR
R205 7030005030 S.RESISTOR
R208 7030005090 S.RESISTOR
R209 7030005090 S.RESISTOR
R210 7030007290 S.RESISTOR
R214 7030008010 S.RESISTOR
R215 7030005520 S.RESISTOR
R216 7030005630 S.RESISTOR
R400 7030005090 S.RESISTOR
R403 7030009320 S.RESISTOR
R404 7030005110 S.RESISTOR
R405 7030005050 S.RESISTOR
R406 7030008280 S.RESISTOR
R407 7030005310 S.RESISTOR
R408 7030005120 S.RESISTOR
R409 7030005530 S.RESISTOR
R410 7030007300 S.RESISTOR
R411 7030009140 S.RESISTOR
R412 7030009320 S.RESISTOR
R413 7030009320 S.RESISTOR
R414 7030005000 S.RESISTOR
R415 7030005530 S.RESISTOR
R416 7030007300 S.RESISTOR
R417 7030007300 S.RESISTOR
R419 7030009320 S.RESISTOR
R420 7030009280 S.RESISTOR
R421 7030005050 S.RESISTOR
R422 7030005110 S.RESISTOR
R424 7030005050 S.RESISTOR
R438 7030005230 S.RESISTOR
R439 7030005050 S.RESISTOR
R441 7510001290 S.THEMISTOR
R442 7030005050 S.RESISTOR
R443 7030005050 S.RESISTOR
R444 7030005050 S.RESISTOR
R445 7030004990 S.RESISTOR
R446 7030005720 S.RESISTOR
R447 7030005000 S.RESISTOR
R448 7030003210 S.RESISTOR
R449 7030005000 S.RESISTOR
R450 7030007290 S.RESISTOR
R451 7030005160 S.RESISTOR
R452 7030009320 S.RESISTOR
6 - 2
DESCRIPTION
ERJ2GEJ 273 X (27 kΩ)
ERJ2GEJ 4R7 X (4.7 Ω)
ERJ3GEYJ 100 V (10 Ω)
ERJ3GEYJ 100 V (10 Ω)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 471 X (470 Ω)
ERJ2GEJ 471 X (470 Ω)
ERJ2GEJ 102 X (1 kΩ)
ERJ2GEJ 222 X (2.2 kΩ)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 333 X (33 kΩ)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 224 X (220 kΩ)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 102 X (1 kΩ)
ERJ2GEJ 183 X (18 kΩ)
ERJ2GEJ 101 X (100 Ω)
MCR10EZHJ 15 Ω (150)
MCR10EZHJ 15 Ω (150)
ERJ2GEJ 103 X (10 kΩ)
MCR10EZHJ 180 Ω (181)
ERJ1WRSJR15U (0.15 Ω)
ERJ2GEJ 102 X (1 kΩ)
ERJ2GEJ 333 X (33 kΩ)
ERJ2GEJ 272 X (2.7 kΩ)
ERJ2GEJ 182 X (1.8 kΩ)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 153 X (15 kΩ)
ERJ2GEJ 392 X (3.9 kΩ)
ERJ2GEJ 392 X (3.9 kΩ)
ERJ2GEJ 104 X (100 kΩ)
ERTJ0EV 473 J (47K)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 102 X (1 kΩ)
ERJ2GEJ 473 X (47 kΩ)
ERJ2GEJ 152 X (1.5 kΩ)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 222 X (2.2 kΩ)
ERJ2GEJ 123 X (12 kΩ)
RR0816R-334-D (330 kΩ)
RR0816R-154-D (150 kΩ)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 4R7 X (4.7 Ω)
ERJ2GEJ 224 X (220 kΩ)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 271 X (270 Ω)
ERJ2GEJ 124 X (120 kΩ)
ERJ2GEJ 102 X (1 kΩ)
ERJ2GEJ 100 X (10 Ω)
ERJ2GEJ 332 X (3.3 kΩ)
ERJ2GEJ 272 X (2.7 kΩ)
ERJ2GEJ 4R7 X (4.7 Ω)
ERJ2GEJ 4R7 X (4.7 Ω)
ERJ2GEJ 471 X (470 Ω)
ERJ2GEJ 100 X (10 Ω)
ERJ2GEJ 332 X (3.3 kΩ)
ERJ2GEJ 332 X (3.3 kΩ)
ERJ2GEJ 4R7 X (4.7 Ω)
ERJ2GE 391 X (390 Ω)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 224 X (220 kΩ)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 334 X (330 kΩ)
ERJ2GEJ 103 X (10 kΩ)
ERTJ0ER 472 J (4.7K)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 221 X (220 Ω)
ERJ2GEJ 563 X (56 kΩ)
ERJ2GEJ 471 X (470 Ω)
ERJ3GEYJ 120 V (12 Ω)
ERJ2GEJ 471 X (470 Ω)
ERJ2GEJ 222 X (2.2 kΩ)
ERJ2GEJ 105 X (1 MΩ)
ERJ2GEJ 4R7 X (4.7 Ω)
S.=Surface mount
