SECTION 5

5-1 PREPARATION

When adjusting IC-F510, IC-F520 or IC-F521, the optional CS-F500 ADJ
OPC-1122* (modifi ed OPC1122
JIG CABLE
*The CS-F500 ADJ (Rev. 2.0 or later) are requied for BIIS version.
M REQUIRED TEST EQUIPMENT
EQUIPMENT
Output voltage
DC power supply
Current capacity
Frequency range
FM deviation meter
Measuring range
Frequency range
Frequency counter Frequency accuracy : ± 1 ppm or better
Sensitivity
Digital multimeter Input impedance
Measuring range
Frequency range
RF power meter
Impedance
SWR
SYSTEM REQUIREMENTS
® ®
• Microsoft Windows 95/98/Me
• RS-232C serial port (D-sub 9 pin)
ADJUSTMENT SOFTWARE INSTALLATION
q Quit all applications when Windows is running.
w Insert the CD into the appropriate CD drive.
e Double-click the "Setup.exe" contained in the 'CS-F500
ADJ' folder in the CD drive.
r The "Welcome to the InstallShield Wizard for CS-F500
ADJ" will appear. Click [Next>].
t The "Choose Destination Location" will appear. Then click
[Next>] to install the software to the destination folder. (e.g.
C:\Program Files\Icom\CS-F500 ADJ)
y After the installation is completed, the "InstallShield Wiz-
ard Complete" will appear. Then click [Finish].
u Eject the CD.
i Program group 'CS-F500 ADJ' appears in the 'Programs'
folder of the start menu, and 'CS-F500 ADJ' icon appears
on the desk top screen.
BEFORE STARTING SOFTWARE ADJUSTMENT
Program the adjustment frequencies into the transceiver
using with the CS-F500 before starting the software adjust-
ment. Otherwise, the transceiver can not start software ad-
justment.
CAUTION!: BACK UP the originally programmed mem-
ory data in the transceiver before program-
ming the adjustment frequencies.
When program the adjustment frequencies into
the transceiver, the transceiver's memory data
will be overwritten and lose original memory
data at the same time.

ADJUSTMENT PROCEDURES

; see illustration page 5-3) are required.
CLONING CABLE
GRADE AND RANGE
: 13.6 (13.2) V DC
: 20 A or more
: DC–600 MHz
: 0 to ±10 kHz
: 0.1–600 MHz
: 100 mV or better
: 10 MΩ/V DC or more
: 1–75 W
: 100–800 MHz
: 50 Ω
: Better than 1.2 : 1
ADJUSTMENT SOFTWARE
EQUIPMENT
Audio generator
Attenuator
Standard signal
generator (SSG)
AC millivoltmeter
Oscilloscope
External speaker
STARTING SOFTWARE ADJUSTMENT
q Connect the transceiver and PC with the OPC-1122*.
w Turn the transceiver power ON.
e Boot up Windows, and click the program group 'CS-F500
ADJ' in the 'Programs' folder of the [Start] menu, then
CS-F500 ADJ's window appears.
r Click 'Connect' on the CS-F500 ADJ's window, then ap-
pears the transceiver's adjustment screen.
t Set or modify adjustment data as desired.
• ADJUSTMENT FREQUENCY LIST
CH FREQUENCY
1 155.000 MHz
2 155.000 MHz
3 155.000 MHz
4 155.000 MHz
5 155.000 MHz
6 174.000 MHz
7 174.000 MHz
8 136.000 MHz
Microsoft and Windows are registered trademarks of
Microsoft Corporation in the U.S.A. and other countries.
5 - 1
(Rev. 2.0 or later)* and the
GRADE AND RANGE
Frequency range : 300–3000 Hz
Measuring range : 1–500 mV
Power attenuation : 50 or 60 dB
Capacity : 100 W
Frequency range : 0.1–600 MHz
Output level : 0.1 µV to 32 mV
(–127 to –17 dBm)
Measuring range : 10 mV to 10 V
Frequency rang : DC–20 MHz
Measuring range : 0.01–20 V
: 4 Ω
Input impedance
Capacity : 7 W or more
CONDITION
TX power : Low1
Mode : Wide
TX power : Low2
Mode : Wide
TX power : High
Mode : Wide
TX power : Low1
Mode : Narrow
TX power : Low1
Mode : Wide
CTCSS : 88.5 Hz
DTCS code : 007
TX power : Low1
Mode : Wide
TX power : Low1
Mode : Narrow
TX power : Low1
Mode : Wide
