- Page 1 MB2059A User’s Guide 15 Hours Digital Voice Recorder Before operating this product, please read these instructions completely.
- Page 2 Thank you for purchasing this Memorex audio system. The serial number of your unit can be found on a label on the rear of the cabinet. We suggest that you record the serial number in the space provided below in case this information is ever needed at a future date.
- Page 3 LOCATION OF INDICATORS R DATE REMAIN A. Play Indicator B. Recording Quality Indicators C. Message/Year Indicators D. REPEAT 1/ALL Indicators E. Record Indicator F. Battery Indicator G. Date/Volume Indicators H. Minute/Second (Timer) Indicators REMAIN Indicator J. R (Record) DATE Indicator K.
- Page 4 LOCATION OF CONTROLS FRONT 1. MIC (Microphone) Jack 2. Built-in Microphone 3. Display 4. REV Button 5. MODE/PAUSE Button 6. PLAY/STOP Button 7. REC/STOP Button 8. Speaker 9. EAR (Earphone) Jack 10. REC Indicator 11. VOLUME Up Button 12. VOLUME Down Button 13.
- Page 5 LOCATION OF CONTROLS REAR MIC SENS (Microphone Sensitivity) Switch VOX Switch HOLD Switch Battery Compartment...
- Page 6 BATTERY INSTALLATION Open the battery compartment by sliding it towards the bottom of the unit. Insert two (2) "AAA" size (not included) following the polarity diagram. compartment back in place. NOTE: When replacing the batteries, the recorded messages will be saved, but the time will have to be reset.
- Page 7 BATTERY INSTALLATION BATTERY INDICATORS: : The batteries are fresh. : The batteries are weak or dead; replace. BATTERY PRECAUTIONS Follow these precautions when using batteries in this device: 1. Use only the size and type of batteries specified. 2. Be sure to follow the correct polarity when installing the batteries as indicated in the battery compartment.
-
Page 8: Setting Time And Date
SETTING SETTING THE THE TIME Press and hold the MODE/PAUSE button for two seconds, then release; “SET” will appear in the display. Press the MODE/ PAUSE button once again to enter the Set Date mode. Press the PLAY/STOP button and the year will blink. Set the year using the REV and FWD PLAY/STOP button... - Page 9 Set the Month using the FWD buttons, then press the PLAY/STOP button again to confirm. Repeat this step to set the Day, Hour and Minute. After setting the minute, press the PLAY/STOP button again and the date/time will be set. While the date/time appears in the display, press the FILE/TIME button to select 12 or 24 hour time display.
- Page 10 T T O O TURN TURN THE THE UNIT To turn the unit on, press the REC/STOP PLAY/STOP do not touch any button for 30 seconds, and the unit will automatically turn off and show the time. TO SWITCH BETWEEN MODES To enter the Standby mode, press the REC/STOP button while the unit is off (Time shows on display).
- Page 11 ADJUSTING ADJUSTING THE THE VOLUME To adjust the volume, while in the Standby mode or during playback of a file, press the VOL+ or VOL– button number will increase or decrease to indicate the volume level (i.e. “0” is minimum and “15” is maximum). EARPHONE JACK For private listening, connect an earphone (not included) to this jack.
- Page 12 RECORDING QUALITY You can choose between four voice recording quality modes. For best sound quality, select HP (High Play), for very good sound quality, select SP (Standard Play) and for good quality, select MP (Medium Play). For longer recording time (reasonable sound quality), select LP (Long Play).
- Page 13 When the desired recording When the desired recording quality appears, press the MODE/PAUSE button twice to confirm and (Time will show on the display) or the unit will turn off automatically if no button is pressed in 30 seconds. High Play: ...185 min. Standard Play: ...275 min.
- Page 14 S S E E L L E E C C T T I I N N G G A A F F I I L L E E F F O O L L D D E E R R This unit has four memory storage areas (file folders) to choose from, labeled A, B, C and D.
- Page 15 RECORDING SENSITIVITY Slide the MIC SENS switch to the LOW position if recording sounds that are close. Select the HIGH position if recording sounds that are further away. HOLD SWITCH Slide the HOLD switch to the LOCK position to disable the buttons; HOLD will appear in the display if the unit is in the Standby mode.
- Page 16 NORMAL RECORDING This unit is capable of recording only when sound is heard. To use this feature, see page 17. For normal recording, follow steps below. Make sure the VOX switch on the rear of unit is set to OFF. Turn the unit on (by pressing the REC/STOP or PLAY/STOP button desired sound quality as previously described.
- Page 17 Speak into the built-in microphone or insert a microphone into the MIC jack and speak into it in a normal tone of voice. Press the REC/STOP button again to stop recording. Press and hold the PLAY/STOP button 1 to see the remaining recording time during recording.
- Page 18 VOICE ACTIVATED (VOX) RECORDING Voice activated recording will allow dictation only when you speak. When the unit detects a pause of a few seconds, it will temporarily stop recording until it detects sound again. Slide the VOX switch on the rear of the unit to the ON position.
- Page 19 Press the REC/STOP button and the REC indicator will light and the elapsed time will appear. Speak into the built-in microphone or insert a microphone into the MIC jack and when the unit picks up sound, it will record. When there is no sound, it will not recording, the REC indicator will blink and PAUSE will blink in the display until sound is detected.
- Page 20 TO PLAY BACK MESSAGES Turn the unit on (by pressing the REC/STOP or PLAY/STOP select a File Folder by pressing the FILE/TIME button (see page 13). Select the desired message number by pressing the REV 1 or FWD 2 button; the message number and the message length will appear in the display.
- Page 21 Press the PLAY/STOP button the currently selected message, then stop. During playback, the Play indicator and the elapsed time of the message will appear in the display. You can check the message recording time and date by pressing the REC/STOP button display the elapsed time, press the REC/STOP button NOTES:...
- Page 22 TO REPEATEDLY PLAY BACK MESSAGES You can set the unit to repeat 1 or repeat all messages in the selected file folder as follows: REPEAT MESSAGE: While playing back a message, press the DEL/REPEAT button 1 once; “REPEAT” will appear in the display and the message playing will repeat over and over until the PLAY/STOP button 2 is pressed.
- Page 23 TO CANCEL REPEAT PLAYBACK: To cancel repeat playback, press the DEL/REPEAT button once or twice until the REPEAT indicator disappears from the display. TO PAUSE A MESSAGE To pause Recording or Playback, press the MODE/PAUSE button; PAUSE will blink in the display.
-
Page 24: Scan Playback
SCAN PLAYBACK This unit can play back the first five seconds of each recorded message as follows: While in the Standby mode, select the file folder (A,B,C,D) using the FILE/TIME button 1. Press and hold the PLAY/STOP button 2 for 2 seconds; SCAN will appear in the display. -
Page 25: Erasing A Single Message
ERASING A SINGLE MESSAGE While in the Standby mode, select the desired file folder using the FILE/TIME button 1, and the desired message to delete using the REV 2 or FWD 3 button; the message number and the message length will appear in the display. Press the DEL/REPEAT button;... - Page 26 ERASING ALL MESSAGES While in the Standby mode, press and hold the DEL/REPEAT button 1 first, then press and hold the REC/STOP button 2 for two seconds; ALL and ERASE will blink in the display. To erase all the messages, press the DEL/REPEAT button again DEL/REPEAT button is not pressed again within...
- Page 27 CARE AND MAINTENANCE RESETTING THE UNIT If the unit is exposed to a strong static electrical charge, the unit may lock up, or the display may dim. This is very rare, but if it does happen, remove the batteries and then reinstall. All settings will return to their preset values, but the previous messages are saved.
- Page 28 CARE AND MAINTENANCE CARE • Keep the unit dry. If it gets wet, wipe it immediately. Liquids may contain minerals that can corrode the circuits. • Use and store the unit only in normal temperature environments. Extreme temperatures can shorten the life of electronic devices, damage batteries and/or melt plastic parts.
- Page 29 CONTACT CUSTOMER SERVICE AT PLEASE KEEP ALL PACKAGING MA TERIAL FOR AT LEAST 90 DAYS IN CASE YOU NEED TO RETURN THIS PRODUCT TO YOUR PLACE OF PURCHASE OR MEMOREX. FOR PARTS AND ACCESSORIES, CONTACT FOX INTERNATIONAL AT 1-800-321-6993. (954) 660-7100.
- Page 30 Memcorp, Inc. Weston, FL Printed in China Visit our website at www.memorexelectronics.com...
