EMM20K22BA Freestanding Microwave Oven Installation & User manual Tungku Gelombang Mikro Panduan Instalasi & Penggunaan Nomor MKG: IMKG.1147.05.2022...
Products must be used, installed and operated in accordance with this manual. You may not be able to claim on the Electrolux manufacturer’s warranty in the event that your product fault is due to failure to adhere this manual.
GENERAL WARNINGS • Only use utensils that are suitable for use in microwave ovens. Important safety instructions, read carefully and keep for • When heating food in plastic or paper containers, future reference. Pass the user manual on to possible new keep an eye on the appliance due to the possibility of owners of the appliance.
SAFETY INSTRUCTIONS Installation WARNING! Risk of injury, burns or electric shock or explosion. WARNING! • Use this appliance in a household environment. Only a qualified person must install this appliance. • Do not change the specification of this appliance. • Remove all the packaging.
PRODUCT DESCRIPTION CONTROL PANEL Observation window Control panel Door assembly Turntable shaft Safety interlock system Turntable ring assembly Glass tray ACCESSORIES Turntable set Hub ( underside) Glass tray Symbol Function Description Quick Cook Fast or normal cooking. Turntable shaft Reheat Normal cooking.
DAILY USE Suitable cookware and materials Microwave Grilling/ Cookware / Material Convection Defrosting Heating Cooking Ovenproof glass and porcelain (with no metal ■ ■ ■ ■ components, e.g. Pyrex, heat-proof glass) Non-ovenproof glass and ■ porcelain Glass and glass ceramic made of ovenproof / ■...
Page 7
DAILY USE (CONTINUED) Materials to be avoided in microwave oven Utensils Remarks • Aluminum tray May cause arcing. Transfer food into microwave-safe dish. • Food carton with metal handle May cause arcing. Transfer food into microwave-safe dish. • Metal or metal-trimmed utensils Metal shields the food from microwave energy.
USING THE ACCESSORIES Turntable Installation Hub ( underside) WARNING! Refer to the safety chapters. Glass tray CAUTION! Do not cook food without the turntable set. Use only the turntable set provided with the appliance. Turntable shaft Never cook food directly on the glass cooking tray. Turntable ring assembly 1.
CARE AND CLEANING • Clean the appliance interior after each use. Then you can remove dirt more easily and it does not burn on. • Clean stubborn dirt with a special cleaner. WARNING! • Clean all accessories regularly and let them dry. Use a Refer to the safety chapters.
INSTALLATION Blocking the intake or outlet vents can damage the oven. If air vents are blocked during operation, the oven may overheat, and this may lead to malfunctioning. Hot air escapes from the vents, so be sure not to obstruct it or let CAUTION! curtains come between the oven and the rear wall.
Taiwan Contact Center: 1566-1238 Consumer Care Center Toll Free: 0800-888-259 Electrolux Korea Ltd. Electrolux S.E.A Private Limited Taiwan Branch 9th Floor, Pine Avenue B, 100 Eulji-ro, 4F., No.3, Sec. 1, Dunhua S. Rd. Jung-gu, Seoul 04551, Korea Songshan Dist., Taipei City 105408 Electrolux Korea Home page: Taiwan (R.O.C.)
Page 12
KAMI MEMPRIORITASKAN ANDA DAFTAR ISI Terima kasih telah membeli perabot Electrolux. Anda telah Peringatan umum ..............3 memilih produk dengan pengalaman dan inovasi profesional Petunjuk keselamatan ..............4 selama puluhan tahun. Desain yang cerdas dan modis ini Deskripsi produk ...............5 dirancang dengan mempertimbangkan kebutuhan Anda. Jadi ketika menggunakannya, Anda dapat yakin bahwa Anda akan Aksesori ..................5...
PERINGATAN UMUM • Hanya gunakan peralatan makan yang sesuai untuk digunakan dalam oven microwave. Petunjuk keselamatan penting, baca dengan cermat dan • Saat memanaskan makanan dalam wadah dari bahan simpan untuk referensi di masa mendatang. Berikan panduan plastik atau kertas, selalu awasi karena dapat berisiko penggunaan kepada pemilik perabot ini.
PETUNJUK KESELAMATAN Penggunaan Instalasi PERINGATAN! Risiko cedera, luka bakar, sengatan listrik, atau ledakan. PERINGATAN! • Gunakan perabot hanya di lingkungan rumah tangga. Instalasi perabot hanya boleh dilakukan oleh orang yang kompeten. • Jangan mengubah spesifikasi perabot. • Buka semua kemasan. •...
DESKRIPSI PRODUK PANEL KONTROL Jendela kaca Panel kontrol Pintu Poros pemutar Sistem kunci pengaman Ring pemutar Baki kaca AKSESORI Set baki putar Poros (di bawah) Baki kaca Simbol Fungsi Deskripsi Memasak Memasak cepat Cepat atau normal. Poros pemutar Memanaskan Memasak normal. Memanaskan.
PENGGUNAAN HARIAN Material untuk alat masak Microwave Memanggang/ Material Alat Masak Membakar Defrost Pemanasan Memasak Kaca dan porselen tahan oven (tanpa komponen ■ ■ ■ ■ logam, seperti Pyrex, kaca tahan panas) Kaca dan porselen tidak ■ tahan oven Kaca dan keramik tahan oven/tahan beku ■...
Page 17
PENGGUNAAN HARIAN (LANJUTAN) Material yang harus dihindari untuk oven microwave Material Keterangan • Baki aluminum Dapat menyebabkan bunga api. Pindahkan makanan ke piring tahan microwave. • Karton dengan pegangan dari logam Dapat menyebabkan bunga api. Pindahkan makanan ke piring tahan microwave. •...
MENGGUNAKAN AKSESORI Memasang Baki Putar Poros (di bawah) PERINGATAN! Lihat bab keamanan. Baki kaca AWAS! Jangan memasak makanan tanpa memasang baki putar. Gunakan hanya baki putar yang disediakan bersama perabot. Poros pemutar Jangan memasak makanan langsung di atas baki. Rangkaian ring putar 1.
PERAWATAN DAN PEMBERSIHAN PERINGATAN! • Bersihkan kotoran yang membandel dengan deterjen Lihat bab keselamatan. khusus. Catatan ketika membersihkan: • Bersihkan semua aksesori secara rutin dan kering anginkan. Gunakan kain lembut dengan air hangat dan • Untuk membersihkan panel depan stainless steel deterjen pembersih.
PENEMPATAN Menutup lubang ventilasi dapat merusak oven. Jika ventilasi udara terhalang selama pengoperasian, oven dapat menjadi terlalu panas, dan dapat menyebabkan malafungsi. Udara panas keluar dari ventilasi, jadi pastikan tidak terhalang atau AWAS! tertutup tirai di antara oven dan dinding belakang. Jangan menghalangi ventilasi udara karena dapat membuat suhu perabot menjadi terlalu panas.
Taiwan Contact Center: 1566-1238 Telp. Pusat Layanan Pelanggan Bebas Pulsa: 0800-888-259 Electrolux Korea Ltd. Electrolux S.E.A Private Limited Taiwan Branch 9th Floor, Pine Avenue B, 100 Eulji-ro, 4F., No.3, Sec. 1, Dunhua S. Rd. Jung-gu, Seoul 04551, Korea Songshan Dist., Taipei City 105408 Electrolux Korea Home page: Taiwan (R.O.C.)
Page 24
Indonesia PT Electrolux Indonesia Jl. Abdul Muis No.34, Petojo Selatan,Gambir, Jakarta Pusat 10160, Indonesia Hotline Service: 0804 111 9999 SMS: 0812 8088 8863 WA: 0811 8339 777 Email: customercare@electrolux.co.id Website: www.electrolux.co.id Diimpor oleh PT Electrolux Indonesia.
