Summary of Contents for Makita 5277NB
- Page 1 Parts Breakdown 5277NB Page 1 of 3 2/8/2008...
- Page 2 Fig # Part ID Part Name 1 265315-4 H.F.H. BOLT M8X20, 5277B 2 224275-9 OUTER FLANGE, 5620DWA 3 224268-6 INNER FLANGE 40 5277NB 4 285809-3 BEARING RETAINER 23-36, 9218PB 5 322840-9 SPINDLE, 5177B 6 254001-2 WOODRUFF KEY 4, HM1303B 7 211251-2 B.BEARING 6003LLB, 5277B...
- Page 3 68 931402-8 HEX NUT M8, 5037NB 69 911108-4 P.H. SCREW M4X8, LS1013 70 265042-3 FLAT HEAD SCREW M8, 5177B 70 265163-1 + FLAT HEAD SCREW M8, 5277NB 71 163436-5 BASE, 5277NB 71 163462-4 BASE, 5277NB 72 931302-2 HEX NUT M6, HR2400...
