M S-7353 M ainboard
7 Serial ATA Connector
This connector is a high-speed Serial ATA interface port. Each connector can connect to
one Serial ATA device.
Important
Please do not fold the Serial ATA cable into 90-degree angle. Otherwise, data
loss may occur during transmission.
8 Front Panel Connectors
These connectors are for electrical connection to the front panel switches and LEDs.
The JFP1 is compliant with Intel
Power
LED
2
1
HDD
LED
IEEE1394 Connector (Green)
9
This connector allows you to connect the IEEE1394 device via an optional IEEE1394
bracket.
2
1
En-10
®
Front Panel I/O Connectivity Design Guide.
Power
Switch
10
9
Reset
Switch
JFP1
10
9
Speaker
2 8
7
1
Power
LED
JFP2
IEEE1394 Bracket
(Optional)
