Crest Audio BRBFMS Quick Start Manual

24.5mm
201.5mm
5 YEAR WARRANTY
Olbertz Holdings Pty Ltd ACN 010 003 933 trading as The Crest Company of 165 South Pine Road, Brendale, Queensland, 4500, Ph: 1800 812 261,
www.crest.com.au, warrants that if this Crest product purchased by you from The Crest Company or a retail outlet is found by The Crest Company to be defective
in workmanship or materials within 5 years of the date of purchase, The Crest Company will (at its election) either repair that product, replace the product, supply
an equivalent product or pay the costs of repairing or replacing the product or acquiring an equivalent product.
This limited warranty will not extend to or cover any expenses associated with removing, demounting the original product or installing the repaired, replaced or
equivalent product or all or any of its components, you must bear these expenses. It also does not cover damage or loss resulting from intentional or unintentional
misuse of, tampering with, alterations to or incorrect installation of this product or use of this product for purposes other than that for which it is designed or in a
manner inconsistent with the product's instructions. This limited warranty also does not apply to damage or loss resulting from fair wear and tear or events beyond
The Crest Company control including but not limited to natural disasters.
In order to claim under this warranty, you must contact The Crest Company and return to The Crest Company (via our nominated reply paid address) the product
and its components and proof of purchase (including the date and location of purchase) so that The Crest Company can verify the defect and your purchase.
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure
and compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of
acceptable quality and the failure does not amount to a major failure. The benefits given by this warranty are in addition to other rights and remedies which you
may have under a law in relation to the goods or services to which the warranty relates.
120mm
45mm
75mm
100mm
200mm
230mm
AUSTRALIAN OWNED
BRBFMS
FULL MOTION
TV WALL MOUNT
23"-55"
200 x 200 MAX
VESA COMPATIBILITY
75x75,100x100, 100x200,
200x100,200x200
UP TO 391mm
EXTEND
Hardware Kit Contents
Tools Required
DRYWALL INSTALLATION (TIMBER SUPPORTS):
Proudly brought to you by:
• Adjustable spanner/socket set
• Philips head screwdriver
• Power drill
• High speed 4.5mm drill bit
• Stud finder
PO Box 5658 Brendale
• Pencil
QLD Australia 4500
Customer Support
1800 812 261
www.crest.com.au
Articulate d
SMALL
30kg MAX
TV WEIGHT
The maximum supported
weight is up to 30kg
-90° TO 90° -15° TO 15°
PAN TILT
6.3 x 55mm Lag Bolt
10 x 6 x 50mm Anchor
6 x 16 x 1.5mm Washer
MASONRY INSTALLATION:
• Adjustable spanner/socket set
• Philips head screwdriver
• Power drill with hammer function
• 10mm Masonry drill bit
• Pencil
• Hammer
SAFETY FIRST
1. Installation of this TV Wall Mount will be easier with
two people.
2. Some images in this guide may vary slightly from
the actual components supplied.
3. Ensure this instruction manual is completely read
and understood before attempting installation.
4. This TV Wall Mount MUST NOT be installed solely
in plasterboard, fibre cement and similar surfaces.
5. This TV Wall Mount MUST be installed in sound
supporting structures such as those made
of timber, steel or masonry using appropriate
fasteners.
6. The supporting structure must be capable of
sustaining the combined weight of the TV Wall
Mount and the display otherwise the structure
must be reinforced.
7. The fasteners supplied in this hardware pack
allow for fixing into timber and masonry only. If
installing into a supporting structure made of steel,
appropriate fasteners must be used and sourced
from an appropriate supplier.
8. Use appropriate tools and safety equipment and
ensure adequate ventilation during installation.
9. If uncertain about any aspect of installation,
contact The Crest Company or an installation
professional.
.
10. Please retain these instructions for future reference
