Crest Audio BRBSB Installation Instructions

C. INSTALLINg IN MASONRY
WARNING: Ensure you have a minimum of 35mm of actual concrete/
brick thickness in the hole for the anchors. Do not drill into mortar
joints. Installer must verify that the supporting surface will safely
support the combined weight of the TV Wall Mount and speaker.
The Crest Company holds no responsibility for incorrectly installed
Speaker Wall Mounts.
1. Mark 2 fixing holes using the wall plate as a guide.
Ensure plate is straight and level.
2. Pre-drill holes to a depth of 25mm using 5.5mm
masonry drill bit. Clean out holes.
3. Fully insert the concrete anchors (B) in the drill holes.
Tap with hammer if required.
4. Attach the wall plate using the 25mm woodscrews (A) into
each concrete anchor (B). Do not over tighten.
The Crest Company is not responsible for any damage
that may be caused by incorrect installation.
Step 4: Mount Speaker to Wall Plate
1. Re-assemble the speaker Wall Mounts by attaching the speaker and speaker wall plate onto the already mounted wall
plate using the screw/washer and swivel that was disassembled in 'Step 1'.
2. Once you have positioned the speaker into the desired position, tighten the main screw.
3. To reposition the speaker simply loosen the main screw and tighten again once you have the correct position.
Check your Speaker Wall Mounts are secure and safe to use at regular intervals (at least every three months).
