Cobra 02-4265 Instruction Manual

Items Supplied >
1 – FORMED RACK
2 – LONG SPACERS
2 – SHORT SPACERS
4 – M8 x 50mm BUTTONHEAD BOLTS
Instruction Manual >
Your formed rack will install in just a few minutes using common tools. Read all instructions carefully and
1. Remove the front left and right M8 bolts from both fender rails and discard.
2. Install your new rack by inserting (2) of the supplied M8 x 50 mm buttonhead bolts through the front rack
mounting holes, (2) supplied short chrome spacers, fender rail holes and into frame. Snug bolts with rack slightly
elevated in the rear to access the rear fender rail bolts.
3. Remove the (2) M8 rear fender bolts and discard. Place the (2) long chrome spacers in fender rails and lower the
rear of rack until holes line up. Insert the (2) remaining M8 x 50mm buttonhead bolts through rack, spacers,
fender rails and into frame. Check rack for proper alignment and torque all (4) bolts to their factory specifications.
1.
recommends you always wear a helmet while riding. Please never operate your motorcycle while under
*Cobra
®
the influence of alcohol and/or drugs. Enjoy the new look of your motorcycle and please ride safely.
DOCUMENT NO. 0019 REV. A
12/08
23801 E. La Palma Ave., Yorba Linda, Ca 92887 Ph. 714.692.8180, Fax. 714.692.5016
®
completely before installing your new rack.
Application(s) >
YAMAHA RAIDER
02- 4265
www.cobrausa.com
2008-2018
®
