Lorex CVC6994CL Quick Setup Manual

4. Camera Specifications
Specifications:
Image Sensor 1/4" Advanced Color
Video Format / Pixels NTSC: 656(H) x 492 (V)
Horizontal Resolution 450 TVL
Internal; 2:1 Internlace
Sync. & Scan. Systems
S/N Ratio > 48dB
Iris & Shutter Speed AES; 1/60 ~ 1/50,000 sec.
Minimum Illumination 0.6 LUX @ F1.2 (IR Off)
0 LUX (IR LEDs ON)
Video Output Comp. 1.0 Vpp @ 75ohm
Lens / Lens Mount 5.0mm F2.8/ Fixed
FOV (diagonal) 50 Degree
Termination Video: BNC Female
Power: Barrel Female
IR / Night Vision Range 30IRLED/ 850nm/ 50'(15m)
Power Requirement 12V DC ±10%
Power Consumption 220mA or 3W max
Operating Temp. 14°F ~ 122°F
(-10°C ~ 50°C)
Weight (with stand) 10.4 oz / 294.8 g
Dimensions 3.9" x 2.7" x 3.2"
(H x D x Dia) 100mm x 68mm x 80mm
Dimensions:
It's all on the web
Specification Sheets
Product Information
Software Upgrades
User Manuals
Firmware Upgrades
Quick Start Guides
VISIT
www.lorexcctv.com
LOREX Technology Inc.
Copyright © 2008 LOREX Technology Inc. As our
products are subject to continuous improvement,
LOREX and its subsidiaries reserve the right to mod-
ify product design, specifications and prices, without
notice and without incurring any obligation. E&OE
H O M E & B U S I N E S S S E C U R I T Y
HIGH RESOLUTION INDOOR/
OUTDOOR COLOR CAMERA
with Night Vision
Model: CVC6994CL
Quick Set-up Guide
English Version 2.0
