Hunter QLS-03CB Instructions

READ AND SAVE THESE INSTRUCTIONS!
reach of children.
for any signs of damage. DO NOT use the product if the
cord has been damaged.
not in operation or while it is being cleaned.
DO NOT use water bottles greater than 22oz.
This product is intended for residential use only. DO
NOT use outdoors.
Initial Setup:
1. Unravel and straighten the cord before use.
2.
3. Use the water cap that came with your
4. Turn your water bottle upside down
and insert into the water reservoir.
Failure to ensure the tank is seated correctly could cause
the unit to leak water from the tank.
Bottle Cap
Power Adapter
20301-01
Personal Ultrasonic Personal Ultrasonic Personal Ultrasonic
QLS-03BK QLS-03LP
QLS-03BU QLS-03NT
QLS-03CB QLS-03PU
QLS-03CP QLS-03RD
QLS-03FB QLS-03WH
ld
Mist Exhaust
Reservoir
Cover
Power Plug
Humidity Adjustment Knob
5. Insert the power adapter into the
bottom right side of the unit, then plug
the adapter into a wall outlet.
Model
Operation:
adjustment knob clockwise until you feel the
knob click. At this time the unit should be
on and you can adjust the amount of mist
the unit outputs by continuing to turn the knob clockwise. To
turn the unit off, turn the humidity adjustment knob counter-
clockwise until it clicks.
Maintenance:
1.
from the wall and the unit.
2. Remove the water bottle from the unit and remove the
cap.
3. Empty the water from the bottle.
4.
Replace the water bottle if necessary.
5.
empty any remaining water.
6. Wipe any mineral deposits from the cover and base
with a soft cloth.
7. Replace the cover onto the base. Align
the notch on the cover with the groove
on the base. The mist exhaust should
be 45 O to the right of the humidity
adjustment knob.
Transducer
Fan Exhaust
20180718
e
e
t
b l k
n
e
Power Shut-off Float
