Lexmark W812 Clearing Paper Jams

Clearing Paper Jams

When a jam occurs, the printer displays a 2xx Paper Jam
message and stops printing. Once you clear the jam, open and
close the top cover to clear the message and resume printing.
203 Fuser jam 202 Print cartridge jam
230/231/232
Duplex jam
200/201 Paper
tray jam
Clearing 200/201 jams from the
paper tray or multipurpose feeder
A 200 Paper Jam may occur when the printer is turned off while a
job is printing.
A 201 Paper Jam occurs when paper does not feed correctly from
the tray or multipurpose feeder.
Clearing jams from the paper tray
Paper may get jammed in the tray or lodged behind the tray. To
clear the jam:
1 Pull out the tray the printer is using for the current job, and
then remove the tray cover.
200/201
Multipurpose
feeder jam
2 If the paper is jammed in the tray, remove it.
3 Check inside the tray area for any jammed paper and remove
it.
4 Replace the cover, and then reinsert the tray.
5 Open and close the top cover to clear the message.
Clearing jams from the multipurpose feeder
1 Open the multipurpose feeder and remove any paper from the
tray.
2 If paper is jammed inside the multipurpose feeder, remove it.
3 Open and close the top cover to clear the message.
Clearing 202 jams from the print
cartridge
A 202 Paper Jam occurs after paper has left the paper tray but
has not reached the fuser.
To clear the jam:
1 Remove any paper in the output tray.
2 Press the release button on the left side of the printer to open
the top cover.
