Lexmark Optra 1200 Quick Reference Manual

SUPPLIES MENU MAINTENANCE MENU
<color> Toner Maint Status
<color> PC Drum
Tray 1 Status
Tray 2 Status
Tray 3 Status
TESTS MENU
JOB MENU
Print Menus Cancel Job
Print Fonts Reset Printer
Print Directory
Print Buffer
Print Demo
Color Samples
Factory Defaults
Format Flash
Format Disk
Job Acct Stat
Hex Trace
SERIAL MENU NETWORK MENU
SERIAL OPTION 1 NETWORK OPTION 1
SERIAL OPTION 2 NETWORK OPTION 2
PCL SmartSwitch
PCL SmartSwitch
PS SmartSwitch
PS SmartSwitch
NPA Mode
NPA Mode
Serial Buffer Network Buffer
Job Buffering Job Buffering
RS-232/RS-422 NETWORK x SETUP
RS-422 Polarity
Serial Protocol
Robust XON
Baud
Data Bits
Note: Menu items in italics appear on the display only if a required option is installed.
Parity
Capitalized menu items (for example, PAPER SIZE) have submenus.
Honor DSR

Overview of Printer Menus

COLOR MENU PAPER MENU
Color Correction Paper Source
Print Quality PAPER SIZE
Toner Saver
PAPER TYPE
CUSTOM TYPES
Output Bin
Substitute Size
Configure MP
Size Detection
SETUP MENU
PCL EMUL MENU
Printer Language
Font Source
Power Saver Font Name
Resource Save
Point Size
Download Target
Pitch
Print Timeout
Symbol Set
Wait Timeout
Orientation
Auto Continue
Lines per Page
Jam Recovery A4 Width
Page Protect
TRAY RENUMBER
Print Area
Auto CR after LF
Display Language
Auto LF after CR
Alarm Control
Printer Usage
Timing Adj
Job Buffer Size
Job Accounting
Job Acct Limit
INFRARED MENU LOCALTALK MENU
Infrared Port LocalTalk Port
PCL SmartSwitch PCL SmartSwitch
PS SmartSwitch
PS SmartSwitch
NPA Mode
NPA Mode
LocalTalk Buffer
Infrared Buffer
Job Buffering Job Buffering
Window Size NPA Hosts
Transmit Delay LocalTalk Name
LocalTalk Addr
Max Baud Rate
LocalTalk Zone
FINISHING MENU
Copies
Blank Pages
Collation
Separator Sheets
Separator Source
Multipage Print
Multipage Order
Multipage View
Multipage Border
POSTSCRIPT MENU
PARALLEL MENU
Print PS Error
STD PARALLEL
Font Priority
PARALLEL OPT 1
Image Smoothing
PARALLEL OPT 2
PCL SmartSwitch
PS SmartSwitch
NPA Mode
Parallel Buffer
Job Buffering
Advanced Status
Protocol
Honor Init
Parallel Mode 1
Parallel Mode 2
FAX MENU
Fax Port
Fax Baud
Fax Data Bits
Fax Parity
Fax Buffer

Operator Panel

Select
Menu
Go
Stop
Press <Menu> to:
• Enter the menus from the ready state
• Scroll through menus or values
• Increase or decrease a numerical value
• Display the Job Menu or the Supplies Menu while the printer
is busy
Press Select to:
• Select the item on the second line of the display
• Save the selection as a new default setting
Press Return to:
• Back up to the previous menu level
Press Stop to:
• Temporarily stop all print activity without losing data
Press Go to:
• Exit printer menus and return to the ready state
• Clear messages
Return
