- Page 1 MC-4 Software Upgrade Instructions A Harman International Company...
-
Page 2: Safety Summary
SAFETY SUMMARY The following general safety precautions must be observed during all phases of operation, service, and repair of this unit. Failure to comply with these precautions or with specific warnings elsewhere in these instructions violates manufacturer safety standards and intended use of this unit. Harman Specialty Group assumes no liability for failure to comply with these require- ments. - Page 3 Refer to “Safety Summary” on page ii prior to performing www.lexicon.com any service. Customer Service Telephone: 781-280-0300 “Lexicon” and the Lexicon logo are registered trademarks of Harman International Industries, Inc. U.S. patent numbers and other worldwide Sales Fax: 781-280-0495 patents issued and pending. Service Fax: 781-280-0499 Windows®...
-
Page 4: Documentation Conventions
Introduction DOCUMENTATION CONVENTIONS This document contains software installation instructions for the MC-4 Digital Controller. Refer to the MC-4 User Guide for general safety, installation, and operation instructions. The following symbols are used in the document: Appears on the component to indicate the... -
Page 5: Hardware Requirements
DB-9 RS-232 connector (9-pin) MAKING CONNECTIONS If the computer has only a USB connector, a USB-to-serial port adapter is required to make the connection to the MC-4. It is not required if the computer has an RS-232 connector. Quantity Certain USB-to-serial port adapters have been reported to be incompatible with the upgrade kit. -
Page 6: Installing The Software Upgrade
Closes the window on the computer monitor and cancels the software installation or upgrade. Installing the Upgrade Program on your PC Before you can upgrade the MC-4, the upgrade software must be installed on your personal computer. To install the upgrade program on your computer: 1. - Page 7 Software Upgrade Instructions To upgrade the MC-4: Note: It will take about 45 minutes to upgrade the MC-4. Do not use the MC-4 while the upgrade is in progress. 1. Exit all computer programs. 2. Power off the MC-4 with the rear panel power switch.
- Page 8 “Update was successful. No config sent” displays if the “Skip Config Save” checkbox WAS selected. Note: Do not attempt to use the MC-4 until the message indicating a successful update displays in the Updater window. 11. Click to continue. The MC-4 restarts.
- Page 9 When user settings are not preserved, the upgrade kit downloads factory default settings to the MC-4, treating these as “preserved user settings.” 13. Power off the MC-4 with the rear panel power switch. Then, disconnect the serial extension cable from the MC-4 and the computer.
- Page 12 3 Oak Park, Bedford, MA, 01730-1413 USA | Telephone: 781-280-0300 | Fax: 781-280-0490 | www.lexicon.com Customer Service: Telephone: 781-280-0300 | Sales Fax: 781-280-0495 | Service Fax: 781-280-0499 Product Shipments: 16 Progress Road, Billerica, MA 01821-5730 USA Part No. 070-17217 | Rev 0 | 05/05...
