I/O Shield Connector

PS/2

Mouse

PS/2

Keyboard

COM1

Power-On/Off (Remote)

Note:

For maintaining the DDR SDRAM power during STR (ACPI S3) function, it is strongly

recommended to use power supplies that have a +5VSB current of (>=) 2A. Please check the

5VSB’s specification printed on the power supply’s outer case.

Note:

The board requires a minimum of 250 Watt power supply to operate. Your system configura-

tion (amount of memory, add-in cards, peripherals, etc.) may exceed this minimum power

requirement. To ensure that adequate power is provided, use a 300 Watt (or higher) power

supply.

PW-ON

Case (chassis) Power ON/OFF button (PW-ON)

Figure 4: Simple ATX power ON/OFF controller

RJ-45 LAN

(Optional)

Parallel Port

COM2

USB2.0 ports

Figure 3: I/O ports

Remote On/Off

RAC Jack

Line-in/Rear out (Light Blue)

Line-out/Front out (Lime)

Mic-in/Center&Subwoofer (Pink)

Optical connector

12V 4-pin

20-pin
