- Page 1 EDUS331608C-D 202002 Engineering Data Design Manual RXTQ-TAVJ9A / TAVJUA Heat Pump, 1 phase, 208 / 230 V, 60 Hz...
-
Page 3: Table Of Contents
RXTQ-TAVJ9A / TAVJUA EDUS331608C-D Table of Contents 1. Features and Benefits ................3 2. Nomenclature .....................4 3. Model Names .....................7 3.1 Outdoor Units ..................7 3.2 Indoor Units ..................8 3.3 Air Treatment Equipment ..............9 4. External Appearance ................10 4.1 Outdoor Units ..................10 4.2 Indoor Units ..................11 4.3 Air Treatment Equipment ..............12... - Page 4 RXTQ-TAVJ9A / TAVJUA EDUS331608C-D 20.3 FXUQ-P ..................64 20.4 FXEQ-P ...................64 20.5 FXDQ-M ..................65 20.6 FXSQ-TA ..................65 20.7 FXMQ-PB ..................65 20.8 FXHQ-M ..................65 20.9 FXAQ-P ...................66 20.10 FXLQ-M, FXNQ-M .................66 20.11 FXTQ-TA ..................66 Appendix......................67 1. Introduction ....................68 1.1 ED Book List ...................68...
-
Page 5: Features And Benefits
The new -series completes the family by introducing the enhanced features and benefits offered in Daikin’s 3-phase VRV products in to the single phase offering. • Available in 3, 4 and 5 ton models • Year round comfort and energy savings delivered by combining VRV and Variable Refrigerant Temperature (VRT) technologies •... -
Page 6: Nomenclature
RXTQ-TAVJ9A / TAVJUA EDUS331608C-D 2. Nomenclature Outdoor Unit Minor revision Standard symbol U: United States of America 9: Minor model change Power supply symbol VJ: 1 phase, 208/230 V, 60 Hz Indicates major design category Capacity indication in cooling 36: 36,000 Btu/h... - Page 7 RXTQ-TAVJ9A / TAVJUA EDUS331608C-D Indoor Unit Standard symbol U: United States of America Power supply symbol VJ: 1 phase, 208/230 V, 60 Hz Indicates major design category Capacity indication in cooling 05: 5,800 Btu/h 18: 18,000 Btu/h 48: 48,000 Btu/h...
- Page 8 RXTQ-TAVJ9A / TAVJUA EDUS331608C-D Air Treatment Equipment Outdoor Air Processing Unit Standard symbol U: United States of America Power supply symbol VJ: 1 phase, 208/230 V, 60 Hz Outdoor air processing unit Indicates major design category Capacity indication in cooling...
-
Page 9: Model Names
RXTQ-TAVJ9A / TAVJUA EDUS331608C-D 3. Model Names Outdoor Units Capacity range 3 ton 4 ton 5 ton Power supply, Standard Capacity index 36TA — — VJ9A Heat pump 208/230 V RXTQ — 48TA 60TA VJUA Note: 1 phase, 208/230 V, 60 Hz... -
Page 10: Indoor Units
RXTQ-TAVJ9A / TAVJUA EDUS331608C-D Indoor Units Capacity range 0.5 ton 0.6 ton 0.8 ton 1 ton 1.25 ton 1.5 ton 2 ton 2.5 ton 3 ton 3.5 ton 4 ton 4.5 ton 5 ton Power supply, Standard Capacity index Ceiling mounted cassette... -
Page 11: Air Treatment Equipment
RXTQ-TAVJ9A / TAVJUA EDUS331608C-D Air Treatment Equipment Outdoor Air Processing Unit Series Model name Power supply, Standard FXMQ 48MF Energy Recovery Ventilator (VAM series) Series Model name Power supply, Standard 300G 470G 600G 1200G... -
Page 12: External Appearance
RXTQ-TAVJ9A / TAVJUA EDUS331608C-D 4. External Appearance Outdoor Units RXTQ36TAVJ9A RXTQ60TAVJUA RXTQ48TAVJUA 3, 4 ton 5 ton... -
Page 13: Indoor Units
RXTQ-TAVJ9A / TAVJUA EDUS331608C-D Indoor Units Ceiling mounted cassette (Round flow with sensing) type Ceiling mounted duct type (Middle and high static pressure) FXFQ-T FXMQ-PB Shown with BYCQ125B-W1 VISTA™ 2 × 2 cassette unit Ceiling suspended type FXZQ-TA FXHQ-M Shown with BYFQ60C3W1W Shown with BYFQ60C3W1S 4-way blow ceiling-suspended type... -
Page 14: Air Treatment Equipment
RXTQ-TAVJ9A / TAVJUA EDUS331608C-D Air Treatment Equipment Outdoor air processing unit Energy recovery ventilator (VAM series) FXMQ-MF VAM-G... -
Page 15: Capacity Range
RXTQ-TAVJ9A / TAVJUA EDUS331608C-D 5. Capacity Range Connection Ratio Total capacity index of the indoor units Connection ratio = Capacity index of the outdoor units Max. connection ratio Type Min. connection ratio Types of connected indoor units VRV indoor units... -
Page 16: Specifications
RXTQ-TAVJ9A / TAVJUA EDUS331608C-D 6. Specifications Model RXTQ36TAVJ9A Power supply 1 phase, 208/230 V, 60 Hz Nominal 36,000 (10.6) Btu/h 1 Cooling capacity (kW) Rated 34,200 (10.0) Nominal 40,000 (11.7) Btu/h 2 Heating capacity (kW) Rated 37,000 (10.8) Casing color Ivory white Dimensions: (H ×... - Page 17 RXTQ-TAVJ9A / TAVJUA EDUS331608C-D Model RXTQ48TAVJUA Power supply 1 phase, 208/230 V, 60 Hz Nominal 48,000 (14.1) Btu/h 1 Cooling capacity (kW) Rated 45,500 (13.3) Nominal 52,000 (15.2) Btu/h 2 Heating capacity (kW) Rated 49,500 (14.5) Casing color Ivory white Dimensions: (H ×...
- Page 18 RXTQ-TAVJ9A / TAVJUA EDUS331608C-D Model RXTQ60TAVJUA Power supply 1 phase, 208/230 V, 60 Hz Nominal 57,500 (16.9) Btu/h 1 Cooling capacity (kW) Rated 57,500 (16.9) Nominal 57,000 (16.7) Btu/h 2 Heating capacity (kW) Rated 57,000 (16.7) Casing color Ivory white Dimensions: (H ×...
-
Page 19: Dimensions
RXTQ-TAVJ9A / TAVJUA EDUS331608C-D 7. Dimensions RXTQ36TAVJ9A... - Page 20 RXTQ-TAVJ9A / TAVJUA EDUS331608C-D RXTQ48TAVJUA...
- Page 21 RXTQ-TAVJ9A / TAVJUA EDUS331608C-D RXTQ60TAVJUA...
-
Page 22: Service Space
RXTQ-TAVJ9A / TAVJUA EDUS331608C-D 8. Service Space RXTQ36TAVJ9A / RXTQ48TAVJUA 2D102479B... - Page 23 RXTQ-TAVJ9A / TAVJUA EDUS331608C-D RXTQ36TAVJ9A / RXTQ48TAVJUA 2D102479B...
- Page 24 RXTQ-TAVJ9A / TAVJUA EDUS331608C-D RXTQ60TAVJUA 2D102480B...
- Page 25 RXTQ-TAVJ9A / TAVJUA EDUS331608C-D RXTQ60TAVJUA 2D102480B...
-
Page 26: Center Of Gravity
RXTQ-TAVJ9A / TAVJUA EDUS331608C-D 9. Center of Gravity RXTQ36TAVJ9A Unit : in. (mm) 4D101439A RXTQ48TAVJUA Unit : in. (mm) 4D101440A... - Page 27 RXTQ-TAVJ9A / TAVJUA EDUS331608C-D RXTQ60TAVJUA Unit : in. (mm) 4D101441A...
-
Page 28: Piping Diagrams
RXTQ-TAVJ9A / TAVJUA EDUS331608C-D 10. Piping Diagrams RXTQ36TAVJ9A... - Page 29 RXTQ-TAVJ9A / TAVJUA EDUS331608C-D RXTQ48TAVJUA...
- Page 30 RXTQ-TAVJ9A / TAVJUA EDUS331608C-D RXTQ60TAVJUA...
-
Page 31: Wiring Diagrams
RXTQ-TAVJ9A / TAVJUA EDUS331608C-D 11. Wiring Diagrams RXTQ36TAVJ9A... - Page 32 RXTQ-TAVJ9A / TAVJUA EDUS331608C-D RXTQ48TAVJUA...
- Page 33 RXTQ-TAVJ9A / TAVJUA EDUS331608C-D RXTQ60TAVJUA...
-
Page 34: Field Wiring
RXTQ-TAVJ9A / TAVJUA EDUS331608C-D 12. Field Wiring RXTQ36TAVJ9A / RXTQ48TAVJUA... - Page 35 RXTQ-TAVJ9A / TAVJUA EDUS331608C-D RXTQ60TAVJUA...
-
Page 36: Electrical Characteristics
RXTQ-TAVJ9A / TAVJUA EDUS331608C-D 13. Electrical Characteristics RXTQ36TAVJ9A / RXTQ48 - 60TAVJUA 3D126394... -
Page 37: Operation Limits
RXTQ-TAVJ9A / TAVJUA EDUS331608C-D 14. Operation Limits RXTQ36TAVJ9A / RXTQ48 - 60TAVJUA 3D115457... -
Page 38: Sound Levels (Reference Data)
RXTQ-TAVJ9A / TAVJUA EDUS331608C-D 15. Sound Levels (Reference Data) RXTQ36TAVJ9A (Cooling) 4D101947D... - Page 39 RXTQ-TAVJ9A / TAVJUA EDUS331608C-D RXTQ36TAVJ9A (Heating) 4D101948E...
- Page 40 RXTQ-TAVJ9A / TAVJUA EDUS331608C-D RXTQ48TAVJUA (Cooling) 4D102719C...
- Page 41 RXTQ-TAVJ9A / TAVJUA EDUS331608C-D RXTQ48TAVJUA (Heating) 4D102720D...
- Page 42 RXTQ-TAVJ9A / TAVJUA EDUS331608C-D RXTQ60TAVJUA (Cooling) 4D101949D...
- Page 43 RXTQ-TAVJ9A / TAVJUA EDUS331608C-D RXTQ60TAVJUA (Heating) 4D101950E...
-
Page 44: Accessories
RXTQ-TAVJ9A / TAVJUA EDUS331608C-D 16. Accessories 16.1 Optional Accessories RXTQ36TAVJ9A / RXTQ48 - 60TAVJUA RXTQ36TAVJ9A RXTQ48TAVJUA RXTQ60TAVJUA Optional accessories ABC I/P printed circuit board kit — BRP2A82 KHRP26M22H9 (Max. 4 branch) REFNET header KHRP26M33H9 (Max. 8 branch) Distributive piping REFNET joint... -
Page 45: Selection Procedure
RXTQ-TAVJ9A / TAVJUA EDUS331608C-D 17. Selection Procedure 17.1 Selection Procedure 17.1.1 Flowchart Given conditions: · Design temperature and humidity (indoor & outdoor) [1] Given conditions · Required heat load of each room · System peak load (if necessary) · Piping length, level difference ·... - Page 46 RXTQ-TAVJ9A / TAVJUA EDUS331608C-D 17.1.2 Selection Example The following is a selection example based on total heat load for cooling. Room F Room A Room E Room B Room D Room C Floor plan [1] Given conditions -Design conditions Indoor air temperature: 67°FWB / 80°FDB, Outdoor air temperature: 93°FDB...
- Page 47 RXTQ-TAVJ9A / TAVJUA EDUS331608C-D Capacity table of indoor unit Cooling capacity Indoor air temp.°FWB (Te: 43°F (6°C)) Model FXMQ07PBVJU FXMQ09PBVJU 10.0 FXMQ12PBVJU 10.7 12.0 12.2 10.0 12.4 12.6 FXMQ15PBVJU 11.2 10.2 12.7 10.7 14.2 11.4 14.5 11.6 14.7 11.5 14.9 FXMQ18PBVJU 14.2 13.9 16.1 14.7 18.0...
- Page 48 RXTQ-TAVJ9A / TAVJUA EDUS331608C-D [3] –2 Provisionally select outdoor unit (1) Calculate CI (Capacity Index) of the selected indoor units. CI of VRV indoor units CI of FXMQ07PBVJU = 7.5 CI of FXMQ12PBVJU = 12 CI of FXMQ15PBVJU = 15 Calculate the total CI of the indoor units.
- Page 49 RXTQ-TAVJ9A / TAVJUA EDUS331608C-D [3] –3 Calculate the corrected capacity of the outdoor unit. - Calculate the connection ratio of the system. Total CI = 69, CI of RXTQ60TAVJUA = 57 Connection ratio = 69 / 57 = 121% - Using the capacity table of the outdoor unit, calculate the capacity (B) corrected for outdoor air temperature, indoor air temperature, and connection ratio.
- Page 50 RXTQ-TAVJ9A / TAVJUA EDUS331608C-D -Confirm capacity correction factor by piping length and level difference (K1) (K1) = 0.94 -Calculate capacity correction factor by piping heat loss (K2) (K2) = 1 + (heat loss factor per feet of piping × (equivalent piping length – 25 ft.)) / 100 In cooling mode, heat loss factor per feet at 93°F is calculated as below.
-
Page 51: Caution Label
RXTQ-TAVJ9A / TAVJUA EDUS331608C-D 18. Caution Label 18.1 RXTQ36TAVJ9A 2P435101-1C... - Page 52 RXTQ-TAVJ9A / TAVJUA EDUS331608C-D 2P435101-1C...
- Page 53 RXTQ-TAVJ9A / TAVJUA EDUS331608C-D 2P435101-1C...
- Page 54 RXTQ-TAVJ9A / TAVJUA EDUS331608C-D 2P435101-1C...
-
Page 55: Rxtq48Tavjua
RXTQ-TAVJ9A / TAVJUA EDUS331608C-D 18.2 RXTQ48TAVJUA 2P435103-1B... - Page 56 RXTQ-TAVJ9A / TAVJUA EDUS331608C-D 2P435103-1B...
- Page 57 RXTQ-TAVJ9A / TAVJUA EDUS331608C-D 2P435103-1B...
- Page 58 RXTQ-TAVJ9A / TAVJUA EDUS331608C-D 2P435103-1B...
-
Page 59: Rxtq60Tavjua
RXTQ-TAVJ9A / TAVJUA EDUS331608C-D 18.3 RXTQ60TAVJUA 2P435104-1A... - Page 60 RXTQ-TAVJ9A / TAVJUA EDUS331608C-D 2P435104-1A...
- Page 61 RXTQ-TAVJ9A / TAVJUA EDUS331608C-D 2P435104-1A...
- Page 62 RXTQ-TAVJ9A / TAVJUA EDUS331608C-D 2P435104-1A...
-
Page 63: Caution For Refrigerant Leaks
RXTQ-TAVJ9A / TAVJUA EDUS331608C-D 19. Caution for Refrigerant Leaks 19.1 Introduction Points to note in connection with refrigerant leaks The installer and system specialist shall secure safety against leakage according to local regulations or standards. The following standards may be applicable if local regulations are not available. -
Page 64: Procedure For Checking Maximum Concentration
RXTQ-TAVJ9A / TAVJUA EDUS331608C-D 19.2 Procedure for Checking Maximum Concentration Check the maximum concentration level in accordance with steps 1 to 4 below and take whatever action is necessary to comply. Step1: Calculate the amount of refrigerant (lbs.) charged to each system separately. - Page 65 Step 4: Dealing with the situations where the result exceeds the maximum concentration level. Where the installation of a facility results in a concentration in excess of the maximum concentration level then it will be necessary to revise the system. Please consult your Daikin supplier.
-
Page 66: Safety Devices Setting
RXTQ-TAVJ9A / TAVJUA EDUS331608C-D 20. Safety Devices Setting 20.1 FXFQ-T Model FXFQ07TVJU FXFQ09TVJU FXFQ12TVJU FXFQ15TVJU FXFQ18TVJU Printed circuit board fuse 250 V, 3.15 A 250 V, 3.15 A 250 V, 3.15 A 250 V, 3.15 A 250 V, 3.15 A Drain pump thermal fuse °F (°C) -
Page 67: Fxdq-M
RXTQ-TAVJ9A / TAVJUA EDUS331608C-D 20.5 FXDQ-M Model FXDQ07MVJU FXDQ09MVJU FXDQ12MVJU FXDQ18MVJU FXDQ24MVJU Printed circuit board fuse 250 V, 5 A 250 V, 5 A 250 V, 5 A 250 V, 5 A 250 V, 5 A OFF: 266±9 OFF: 266±9 OFF: 266±9... -
Page 68: Fxaq-P
RXTQ-TAVJ9A / TAVJUA EDUS331608C-D 20.9 FXAQ-P Model FXAQ07PVJU FXAQ09PVJU FXAQ12PVJU FXAQ18PVJU FXAQ24PVJU Printed circuit board fuse 250 V, 3.15 A 250 V, 3.15 A 250 V, 3.15 A 250 V, 3.15 A 250 V, 3.15 A Fan motor thermal fuse °F... -
Page 69: Appendix
RXTQ-TAVJ9A / TAVJUA EDUS331608C-D Appendix 1. Introduction ....................68 1.1 ED Book List ...................68 1.2 Publication List of Engineering Data for VRV Products ....69... -
Page 70: Introduction
RXTQ-TAVJ9A / TAVJUA EDUS331608C-D 1. Introduction ED Book List Design Manual ............EDUS331608C-D RXTQ-TAVJ9A RXTQ-TAVJUA (This booklet) Capacity Table Book Heat Pump ............RXTQ-TAVJ9A ..EDUS331608C-C RXTQ-TAVJUA Installation Heat Pump, Heat Recovery ........RXYQ .... EDUS371848-N REYQ Indoor Units Ceiling Mounted Cassette Type (Round Flow with Sensing) .. -
Page 71: Publication List Of Engineering Data For Vrv Products
RXTQ-TAVJ9A / TAVJUA EDUS331608C-D Publication List of Engineering Data for VRV Products Shaded sections indicate Engineering Data Book/s published for this series. Timing of publication is subject to change without notice. Outdoor Unit Product Refrigerant Category Type Volts Model name... - Page 72 RXTQ-TAVJ9A / TAVJUA EDUS331608C-D Indoor Unit and Other Products Refrigerant Product category Product type Model name Area Book No. Published in Ceiling Mounted Cassette Type FXFQ07-48TVJU EDUS391400A-F14 May 2018 (Round Flow with Sensing) VISTA™ 2 x 2 FXZQ05-18TAVJU EDUS391776-F9 Mar.2018...
- Page 76 Improper installation can result in water or refrigerant leakage, electrical shock, fire or explosion. Use only those parts and accessories supplied or specified by Daikin. Ask a qualified installer or contractor to install those parts and accessories. Use of unauthorised parts and accessories or improper installation of parts and accessories can result in water or refrigerant leakage, electrical shock, fire or explosion.
