Page 1
On the GPS Plotter page: Press to activate/ deactivate the cursor. Cursor/ Waypoint On any page: press and hold to save a waypoint. Press to display the System Controls dialog. Power Press and hold to power the unit on/off. HOOK2 x Series | Quick Guide - EN...
Page 2
System Controls dialog • Option ON • Option OFF Display illumination • Set brightness and select day/night mode from the System Controls dialog • Repeat short presses on the Power key to cycle the backlight brightness Sonar/Flasher/DownScan pages Sonar Flasher Downscan (5x and 7x models) By default the unit is set to...
Page 3
Press and hold the Cursor/Waypoint key to save a new waypoint. • With cursor inactive, the waypoint is placed at the vessel's position • With cursor active, the waypoint is placed at the cursor position HOOK2 x Series | Quick Guide - EN...
Page 4
Overlay data The data type can be changed, and the item position on the image is selectable. The data items can be turned on/off from the System Controls dialog. Each data item can be removed individually from the panel: Edit overlay Select the option in the System Controls dialog to turn the unit into edit mode...
