Installation manual
Daikin Altherma 3 R
ERGA04E▲V3▼
ERGA06E▲V3H▼
ERGA08E▲V3H▼
ERGA04E▲V3A▼
ERGA06E▲V3A▼
ERGA08E▲V3A▼
Installation manual
English
▲= A, B, C, ..., Z
Daikin Altherma 3 R
▼= , , 1, 2, 3, ..., 9

Advertisement

Table of Contents
loading

Related Manuals for Daikin Altherma 3 R

Summary of Contents for Daikin Altherma 3 R

  • Page 1 Installation manual Daikin Altherma 3 R ERGA04E▲V3▼ ERGA06E▲V3H▼ ERGA08E▲V3H▼ ERGA04E▲V3A▼ ERGA06E▲V3A▼ ERGA08E▲V3A▼ Installation manual English ▲= A, B, C, …, Z Daikin Altherma 3 R ▼= , , 1, 2, 3, …, 9...
  • Page 2 2P633780-1B...
  • Page 3 2P633780-1B...
  • Page 4 2P633780-5B...
  • Page 5 2P633780-5B...
  • Page 6 2P633780-2B...
  • Page 7 2P633780-2B...
  • Page 8 2P633780-6B...
  • Page 9 2P633780-6B...
  • Page 10 2P633780-4B...
  • Page 11 2P633780-4B...
  • Page 12 2P633780-7B...
  • Page 13 2P633780-7B...
  • Page 14 2P633780-8C...
  • Page 15 2P633780-8C...
  • Page 16 2P633780-9C...
  • Page 17 2P633780-9C...

  • Page 18: Table Of Contents

    To determine the additional refrigerant amount ..25 Daikin website (publicly accessible). 5.3.2 To charge additional refrigerant ........25 ▪ The full set of latest technical data is available on the Daikin 5.3.3 To fix the fluorinated greenhouse gases label .... 25 Business Portal (authentication required).

  • Page 19: About The Box

    MUST comply with the applicable legislation. ▪ Make electrical connections to the fixed wiring. ▪ All components procured on-site and all electrical construction MUST comply with applicable legislation. ERGA04~08E Installation manual Daikin Altherma 3 R 4P629079-1D – 2022.05...

  • Page 20: To Remove The Accessories From The Outdoor Unit

    Protect the outdoor unit against direct snowfall and take care that the Mind the following spacing guidelines: outdoor unit is NEVER snowed up. >250 >350 >250 >250 (mm) (mm) Air outlet Air inlet Installation manual ERGA04~08E Daikin Altherma 3 R 4P629079-1D – 2022.05...

  • Page 21: Mounting The Outdoor Unit

    (EKLN08A1), different installation instructions snowfall. apply for the U-beams. See the installation manual of the low sound cover. a Low sound cover b Bottom parts of the low sound cover c U-beams ERGA04~08E Installation manual Daikin Altherma 3 R 4P629079-1D – 2022.05...

  • Page 22: To Install The Outdoor Unit

    Properly align the unit. Make sure the backside of the unit does NOT protrude. 3 Remove the protective cardboard and instruction sheet. (mm) Maximum snowfall height EKFT008D option kit Anti-vibration rubber (field supply) Installation manual ERGA04~08E Daikin Altherma 3 R 4P629079-1D – 2022.05...

  • Page 23: To Provide Drainage

    3 Insert a rubber sheet between the cables and the outdoor unit to prevent the cables from scratching the paint (field supply). 4 Attach the ends of the cables. 5 Tighten the cables. ERGA04~08E Installation manual Daikin Altherma 3 R 4P629079-1D – 2022.05...

  • Page 24: Opening The Unit

    1 hour. 5 If you do NOT reach the target vacuum or CANNOT maintain the vacuum for 1 hour, do the following: ▪ Check for leaks again. ▪ Perform vacuum drying again. Installation manual ERGA04~08E Daikin Altherma 3 R 4P629079-1D – 2022.05...

  • Page 25: To Insulate The Refrigerant Piping

    15.9 A these gases into the atmosphere. cable Voltage 230 V ▪ When charging refrigerant, ALWAYS use protective Phase gloves and safety glasses. Frequency 50 Hz Wire sizes Must comply with applicable legislation ERGA04~08E Installation manual Daikin Altherma 3 R 4P629079-1D – 2022.05...

  • Page 26: Guidelines When Connecting The Electrical Wiring

    See the indoor unit installation manual for configuration and commissioning of the system. 3 Connect the interconnection cable and power supply as follows. Ensure stress relief by using the wire clamp. Installation manual ERGA04~08E Daikin Altherma 3 R 4P629079-1D – 2022.05...

  • Page 27: Technical Data

    8 Technical data Technical data A subset of the latest technical data is available on the regional Daikin website (publicly accessible). The full set of latest technical data is available on the Daikin Business Portal (authentication required). Piping diagram: Outdoor unit 7.0 CuT...

  • Page 28: Wiring Diagram: Outdoor Unit

    PCB1 Printed circuit board (main) Switching power supply Thermal protector Q1DI # Earth leakage circuit breaker Insulated gate bipolar transistor (IGBT) Thermistor (air) Thermistor (heat exchanger) Thermistor (discharge) RTH2 Resistor Installation manual ERGA04~08E Daikin Altherma 3 R 4P629079-1D – 2022.05...
  • Page 32 4P629079-1 D 00000006 4P629079-1D 2022.05 Verantwortung für Energie und Umwelt...
